Table 12-1. Gauge Attributes
Attribute Description
Utilization% Represents the traffic on the port as a
percentage of the port's bandwidth.
Collisions% Represents the number of collisions that
have occurred expressed as a percentage of
the packets transmitted through the port.
Broadcasts/sec Represents the number of broadcast packets
being transmitted through the port per
second.
Errors% Represents the number of errors that have
occurred expressed as a percentage of the
total number of packets received through the
port.
Multicasts/sec Represents the number of multicast packets
being transmitted through the port per
second.

Global Counters

Hub Global Counters
Selecting the Global Counters button displays a page listing eight counters and
their values since the last device reset. The counters are totals for the device.
To view counters by port, select the Port Counters button.
Switching Hub Global Counters
The switching hubs display the counters as shown in the following figure.
Accessing Hub Features
Interpreting Device Status
Severity Values
Warning: 40%
Critical: 75%
Warning: 30%
Critical: 50%
Warning: 150/sec
Critical: 400/sec
Warning: 0%-1%
Critical: 1%
Warning: 1500/sec
Critical: 4000/sec
12-5
