Maintain the Rimage 480i Printer

Use the information in this document to keep your Rimage 480i printer in optimum operating condition.
Regular preventative maintenance of your Rimage 480i printer can help to ensure clean printed labels.
Maintenance involves cleaning the ink cartridges, aligning the ink cartridges, cleaning the printer exterior,
replacing the fan filter, and replacing the ink cartridges.
Caution: To avoid damaging the Rimage 480i printer during maintenance:
Never use oils, silicone, or other lubricants on any part of your Rimage 480i printer.
Use only non-abrasive cleaners to wipe down the surfaces of your Rimage 480i printer.
Do not pour cleaner directly onto your Rimage 480i printer. Instead, apply the cleaner to a lint-free cloth
first.
When you spray compressed air, make sure that no liquid drips into your printer.

Preventative Maintenance Schedule

Important! Failure to follow the maintenance schedule outlined below may void your warranty.
Materials
Mandatory
Lint-free cloth
Non-abrasive, all-purpose
cleaner
New fan filter
Small screwdriver
New ink cartridges
Can of compressed air
Optional
None needed
None needed
110761_D
Task
Clean the printer exterior. Refer to the
instructions.
Clean the Printer Exterior
Replace the fan filter. Refer to the
instructions.
Replace the Fan Filter
Replace the ink cartridges. Refer to the
Replace the Ink Cartridges
Remove dust from the printer. Refer to
the
Remove Dust from the Rimage 480i
instructions.
Printer
Clean the ink cartridges. Refer to the
instructions.
Clean the Ink Cartridges
Align the ink cartridges. Refer to the
instructions.
Align the Ink Cartridges
Frequency
Weekly
Monthly
As needed
instructions.
Monthly
When print quality problems are
noticed
As needed
Note: The ink cartridges are
aligned at the factory.

Advertisement

loading

Related Manuals for Rimage 480i

Summary of Contents for Rimage 480i

  • Page 1: Maintain The Rimage 480I Printer

    Never use oils, silicone, or other lubricants on any part of your Rimage 480i printer. Use only non-abrasive cleaners to wipe down the surfaces of your Rimage 480i printer. Do not pour cleaner directly onto your Rimage 480i printer. Instead, apply the cleaner to a lint-free cloth first.

  • Page 2: Clean The Ink Cartridges

    Lint-free cloth Non-abrasive, all-purpose cleaner Open the cable access door and disconnect the AC power adaptor to power off the Rimage 480i printer. Wipe down all exterior surfaces of the printer. Tip: Your printer may require more frequent maintenance if it is used in an area such as a store or a warehouse.

  • Page 3: Remove Dust From The Rimage 480I Printer

    Remove Dust from the Rimage 480i Printer Required tools: Can of compressed air Open the cable access door and disconnect the AC power adaptor to power off the Rimage 480i printer. Disconnect the USB cable from the side of the printer. Remove the dust.

  • Page 4: Replace Consumables

    Maintain the Rimage 480i Printer Replace Consumables This section provides information about how to replace the consumables on the Rimage 480i printer consumables for the 480i printer include: The fan filter The ink cartridges Replace the Fan Filter You must change the fan filter every month. Use this procedure to change the fan filter.
  • Page 5 Close the ink cartridge access door. The ink cartridge status light flashes for a few seconds and then stops. The Rimage 480i printer is ready to print. Note: If the ink cartridge is not securely seated in the cradle, the printer will not recognize the ink cartridge.

  • Page 6: Navigate To Printing Preferences

    Maintain the 480i Printer Navigate to Printing Preferences You must access the Disc Color Printer 480i Printing Preferences window to set up your printing preferences. Use one of these procedures to navigate to the Disc Color Printer 480i Printing Preferences window.
