3.3 Remove and open the bolt bag.
3.4 Loosen the 5/16" hardware at the two (2) discharge chute hinge points so that the
3.5 Refer to Parts Manual to help you identify and locate parts and their proper position.
3.6 Apply retaining adhesive "Fel-Pro ProLock Retaining I or Retaining II" or "Loctite RC
3.7 Attach the fuel tank hose to the tank fitting and secure with the clamp provided.
3.8 Position the lower end of the handle assembly on the outside of the upper rear
3.9 Route the throttle cable along the right side of the upper handle, under the fuel tank
NOTE: If the positive cable is also disconnected, connect the positive (red)
cable to the positive terminal on the battery first, then connect the negative
(black) cable to the negative terminal on the battery. Reinstall battery cover.
NOTE: If time does not permit charging the battery, or if charging equipment is
not available, connect the negative battery cables and run the vehicle
continuously for 20 to 30 minutes to sufficiently charge the battery.
deflector is snug, but can be moved up and down freely.
609 or 680" on the two threaded studs from the bolt bag and install into the two left
holes underneath fuel tank. Install the fuel tank on top of the fuel tank support with
the studs going through the slots in the support. Install two 5/16 x 3/4 screws with a
5/16 SAE flat washer and 5/16 lock washer into the threaded holes in the right side of
the fuel tank. Do not over tighten. Place a 5/16 SAE flat washer, then a spring,
over each of the studs and fasten with a 5/16 nyloc nut. Tighten 5/16 nyloc nut fully
then back off a 1/2 turn. This is to allow for normal fuel tank expansion and
contraction with changes in temperature and fuel levels. Do not over tighten.
section of the fuel tank and handle support. Install four 3/8-16 x 1" bolts (with four
spring disk washers against the head of each bolt) from the outside in. Secure using
four 3/8" whizlock nuts on the inside of each handle support and tighten until the
spring disk washers are flat (See Figure 1).
UPPER HANDLE MOUNTING
support, and position the cable on the left side of the engine.
Attach throttle cable to engine:
a) Position the throttle control lever (located on console) ¼" (6mm) from the upper end
of the slot.
b) Attach inner wire of the throttle cable to the top hole in the throttle control lever as
shown in Figure 2.
c) Loosen the clamp, place the cable behind it, and pull on the cable to move the
throttle linkage to the full throttle position. Tighten the cable clamp screw.
www.mymowerparts.com
FIGURE 1
- 14 -
