2. SPECIFICATIONS

2.1 MODEL NUMBER:

Serial Nos. 440,000 & Higher: TT3615KAC; TT4817KAC; TT5217KAC; TT4817KAEC;

2.2 ENGINE

2.2.1
2.2.2

2.3 FUEL SYSTEM

2.3.1
2.3.2
2.3.3
2.3.4

2.4 ELECTRICAL SYSTEM

2.4.1
2.4.2
2.4.3
2.4.4
2.4.5

2.5 SAFETY INTERLOCK SYSTEM

2.6 STEERING CONTROL:

2.7 TRANSMISSION:

2.7.1
2.7.2
2.7.3

2.8 WHEEL DRIVE SYSTEM:

2.9 TIRES

Size
Quantity
Tread
Ply Rating
Pressure
Engine Specifications: See your Engine Owner's Manual.
3600 RPM (No Load).
Capacity: 5.0 gal.(18.9 L.)
Type of Fuel: Regular unleaded gasoline, 87 octane or higher. In countries
using the research method, it should be a 90 octane minimum.
Fuel Filter: Replaceable in-line
Fuel Shut-Off Valve: 1/4 turn
Charging System: Flywheel Alternator
Charging Capacity: 15 amps
Battery Type: BCI Group U1
Battery Voltage: 12 Volt; Polarity, negative ground
Fuses: Two 20 amp blade type
Operator must have speed control lever in neutral, PTO disengaged, (and OPC
levers depressed for electric start) to start engine. Release of OPC levers will
cause the engine to stop if speed control lever is not in neutral and/or PTO is
engaged.
Fingertip drive control levers provide independent speed control, braking, and
neutral to each drive wheel for moving forward or reverse, stopping, and power
turning.
Twin Hydrostatic Drive
Two Hydro Gear BDP-10A series variable displacement high efficiency pumps
independently coupled to two high efficiency Parker/Ross wheel drive motors.
Hydraulic Filter is replaceable cartridge type.
P/N 1-513211: 10 microns, 18 psi bypass (Summer use above 32° F (0°C))
P/N 1-523541: 40 microns, 18 psi bypass (Winter use below 32° F (0°C))
Speed Range: Forward
Reverse
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0"
(25.4 mm) tapered shaft.
36" Drive
Pneumatic (Air-Filled)
16 x 6.50-8
2
Turf Master
4
14 psi (97 kPa)
www.mymowerparts.com
TT5217KAEC
0 - 6.2 mph (10.0 km/h)
0 - 2.2 mph (3.5 km/h)
48" & 52" Drive
Pneumatic (Air-Filled)
16 x 7.50-8
2
Turf Master
4
14 psi (97 kPa)
- 11 -
Front Caster
Semi-Pneumatic
9 x 3.50-4
2
Smooth
