ECB-1221R Wireless Long Range Multi-function Client Bridge
System
o
Uptime: Duration of time since the device was last reset.
o
Firmware version: V ersion of the firmwar e t hat i s currently loaded o n th e
o
device.
Wireless Configuration:
Mode: Wireless configuration mode such as client bridge, AP, or WDS.
o
Band: Frequency and IEEE 802.11 operation mode (b-only, g-only, or b+g).
o
SSID: The name used to identify the wireless network.
o
Channel Number: The channe l us ed t o communicate o n the wirel ess
o
network.
Encryption: The ty pe o f secur ity used on this ne twork. It ma y b e disabled,
o
WEP, WPA, etc.
BSSID: The MAC address of the SSID.
o
Associated Clients: D isplays the numb er of c lients currently ass ociated to
o
the Access Point.
TCP/IP Configuration:
Attain IP Protocol: The IP address setting may be fixed or static.
o
IP Address: Displays the current IP address of the LAN port.
o
Subnet Mask: Displays the current subnet mask for the IP address.
o
Default Gateway: Displays the default gateway for the device.
o
DHCP: Displays the DHCP setting.
o
MAC Address: Displays the MAC address of the device.
o

Management

Click on t he Management lin k on the na vigation
drop-down menu . You will t hen see fi ve options:
operation mo de, sta tus, sta tistics, l og, u pgrade
firmware, s ave/reload sett ings, a nd password.
Each option is described below.
