2000 Expedition/Navigator Workshop Manual
SECTION 205-02B: Rear Drive Axle/Differential — Ford 9.75-Inch Ring Gear
DISASSEMBLY AND ASSEMBLY
Differential Case and Ring Gear — Traction-Lok
Special Tool(s)
2-Jaw Puller
205-D072 (D97L-4221-A) or equivalent
Gauge, Differential (Traction-Lok)
205-384 (T97T-4205-A)
Gauge, Differential (Traction-Lok)
205-386 (T97T-4205-D)
Gauge, Differential (Traction-Lok) (mandrel for 205-135 (T80P-4946-A))
205-389 (T97T-4946-A)
Gauge, Differential Clutch (excluding mandrel)
205-135 (T80P-4946-A)
Installer, Differential Carrier Bearing
205-D044 (D81T-4221-P) or equivalent
Rotator, Differential
205-378 (T97T-4205-C)
Step Plate
205-D019 (D80L-630-8) or equivalent
Disassembly
1. Remove the differential assembly from the differential housing. For additional information, refer to
2. Remove the bolts, if differential ring gear removal is necessary.
3.
CAUTION: Do not damage the threads in the bolt holes.
Insert a punch in the bolt holes, and drive off the differential ring gear.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYJ/~MUS~LEN/21/S...
2000 Expedition/Navigator Workshop Manual
Procedure revision date: 01/13/2003
Differential Case
in this section.
Page 1 of 8
6/30/2011
