2000 Expedition/Navigator Workshop Manual
SECTION 501-16: Wipers and Washers
REMOVAL AND INSTALLATION
Washer Pump and Reservoir
Removal
4x4 vehicles only
1. Remove the battery tray. For additional information, refer to
2. Position the front differential vent hose aside.
Release the retainer.
4x2 vehicles only
3. Disconnect the battery cables. For additional information, refer to
4. Remove the battery heat shield.
All vehicles
5. Disconnect the jack handle from the windshield washer reservoir (17618).
6. Disconnect the electrical connectors.
7. Remove the windshield washer reservoir screws.
http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYJ/~MUS~LEN/20/S...
Section
414-01.
Section
414-01.
Page 1 of 3
2000 Expedition/Navigator Workshop Manual
Procedure revision date: 05/15/2002
9/15/2010
Advertisement
Related Manuals for Ford Expedition 2000
Summary of Contents for Ford Expedition 2000
- Page 1 2000 Expedition/Navigator Workshop Manual Page 1 of 3 SECTION 501-16: Wipers and Washers 2000 Expedition/Navigator Workshop Manual REMOVAL AND INSTALLATION Procedure revision date: 05/15/2002 Washer Pump and Reservoir Removal 4x4 vehicles only 1. Remove the battery tray. For additional information, refer to Section 414-01.
- Page 2 CAUTION: Do not operate the windshield washer pump prior to filling the windshield washer reservoir. To install, reverse the removal procedure. Fill the windshield washer reservoir with Ultra-Clear Windshield Washer Concentrate C9AZ-19550-AC or BC or equivalent meeting Ford specification ESR-M17P5-A. http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYJ/~MUS~LEN/20/S...
- Page 3 2000 Expedition/Navigator Workshop Manual Page 3 of 3 http://www.fordtechservice.dealerconnection.com/pubs/content/~WSYJ/~MUS~LEN/20/S... 9/15/2010...
