DT-V9L1D
MULTI FORMAT LCD MONITOR
CAUTION
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock. Do
not remove cover (or back). No user
serviceable parts inside. Refer servicing
to qualified service personnel.
Safety Precautions .............................................. 2
Installation ............................................................ 4
Daily Operations / Connections ......................... 6
Menu Configuration-MAIN MENU .................. 10
Menu Configuration-SET-UP MENU ............... 12
External Control ................................................. 14
Troubleshooting ................................................. 16
Specifications .................................................... 17
The lightning flash with arrowhead
symbol, within an equilateral triangle is
intended to alert the user to the presence
of uninsulated "dangerous voltage"
within the product's enclosure that may
be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
INSTRUCTIONS
Table of Contents
IMPORTANT SAFEGUARDS ........................... 2
Maintenance ..................................................... 3
To adjust the stand height ................................ 4
Front panel ....................................................... 6
Rear panel ........................................................ 8
Available signals ............................................... 9
About the external control .............................. 14
Using the MAKE/TRIGGER system ............... 14
Using the RS-232C system ............................ 15
Self-check program ........................................ 16
General ........................................................... 17
Input/output terminals ..................................... 17
Dimensions ..................................................... 18
ENGLISH
Advertisement
Table of Contents
Related Manuals for JVC DT-V9L1D
Summary of Contents for JVC DT-V9L1D
-
Page 1: Table Of Contents
DT-V9L1D MULTI FORMAT LCD MONITOR CAUTION RISK OF ELECTRICAL SHOCK DO NOT OPEN CAUTION: To reduce the risk of electric shock. Do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. Table of Contents Safety Precautions ... -
Page 2: Safety Precautions
Safety Precautions WARNING: TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE. NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. IMPORTANT SAFEGUARDS Electrical energy can perform many useful functions. This unit has been engineered and manufactured to assure your personal safety. -
Page 3: Maintenance
U.S.A. only FCC NOTICE CAUTION: Changes or modifications not approved by JVC could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Installation
Installation CAUTION • Do not rest your arm on the monitor or lean against the monitor. • Do not touch the LCD panel when installing the monitor. • Make sure to install the monitor securely to prevent the monitor from falling over, which causes damage to the monitor or injury. - Page 5 Lower position To prevent an accidental fall Fix the monitor to a wall by using strings. Fixing the monitor Attachment screws Attach the hook (not provided) to the VESA mounting holes on the rear panel (use the two 100 mm pitch holes on the upper side) using M4 x 10 mm screws (not provided).
-
Page 6: Daily Operations / Connections
Daily Operations / Connections 7 Front panel 1 Tally lamp 5 MUTING button This lamp is controlled by the tally function of the Turns off the sound when a menu screen is not MAKE/TRIGGER terminal (☞ “TALLY SELECT” in displayed. “FUNCTION SETTING”... - Page 7 Menu Operations Audio Channel Selection Select the audio channels when the SDI is Display the menu. selected as a signal input and EMBEDDED To display the MAIN MENU AUDIO signals come in. \ Press MENU button. • You have to choose a group of selectable audio To display the SET-UP MENU channels before the channel selection (☞...
-
Page 8: Rear Panel
Daily Operations / Connections (cont.) 7 Rear panel CAUTION Do not connect the power cord until all other connections are completed. 4 DC IN 12V terminal DC 12 V (maximum DC 17 V) power input 1 POWER switch connector. Turns the AC power on or off. •... -
Page 9: Available Signals
7 Available signals Signal format shown VIDEO/COMPONENT Signal name in the status display (☞ page 7) (Composite) NTSC* NTSC √ √ B/W50 NTSC √ B/W60* √ 480/59.94i* 480/60i — 576/50i 576/50i — 480/59.94p 480/60p — 576/50p 576/50p — 720/60p 720/60p —... -
Page 10: Menu Configuration-Main Menu
Menu Configuration—MAIN MENU For the operation procedure, see page 7. Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. •... - Page 11 Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. • The items controlled by the MAKE system do not appear on the menu. NOTE Setting of “E.AUDIO GROUP”...
-
Page 12: Menu Configuration-Set-Up Menu
Menu Configuration—SET-UP MENU For the operation procedure, see page 7. Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. - Page 13 Operation guide Shows the buttons for each operation. • The menu automatically disappears in about 30 seconds after the previous operation. • Some items may not appear on the menu depending on the input or the input signal. • The items controlled by the MAKE system do not appear on the menu. NOTE Setting of “CHARACTER SET.”...
-
Page 14: External Control
External Control 7 About the external control This monitor has two external control terminals. • MAKE/TRIGGER terminal (RJ-45): The following external control systems are available. (1) MAKE (make contact) system: Controls the monitor by short-circuiting the corresponding pin terminal to the GND pin terminal, or disconnecting (opening) it (☞... -
Page 15: Using The Rs-232C System
Operation Set “TYPE SEL.” of “REMOTE SETTING” to “MAKE” or “TRIGGER” in the SET-UP MENU. Short-circuit the 7th pin terminal (ENABLE) to the 8th pin terminal (GND) so that the monitor can be controlled by the external control. When selecting “MAKE” system: Operate each function by short-circuiting the corresponding pin terminal to the 8th pin terminal (GND) or opening it. -
Page 16: Troubleshooting
Troubleshooting Solutions to common problems related to the monitor are described here. If none of the solutions presented here solves the problem, unplug the monitor and consult an authorized dealer or service center. Symptom Probable cause and corrective action • Turn on the POWER switch or DC switch on the rear panel. •... -
Page 17: Specifications
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. Notice on transportation This monitor is precision equipment and needs dedicated packing material for transportation. Never use any packing material supplied from sources other than JVC or JVC-authorized dealers. 7 Input/output terminals VBS/Y... -
Page 18: Dimensions
Specifications (cont.) 7 Dimensions Unit: mm <Front view> 222.4 * at the higher position ** at the lower position tapped hole (3/8 ˝ tapped hole (1/4 ˝ <Side view> • When the stand is attached to the • When the stand is attached to the higher position.
