Page 4: Package Contents
4. Package Contents LCD Monitor Drawer with PS/2 KVM Switch (Two Consoles) 1 Piece User Manual 1 Piece DC Power Adapter 1 Piece Power Cord 1 Piece Mounting Bracket 1 Pair Fasteners 4 Pieces CD-6 3-in-1 KVM cable 8 Pieces Before Unpacking It is very important to locate the LCD Keyboard Drawer in a suitable environment. -
Page 5: Optional Accessories
5. Optional Accessories KVM Cable CD-6 / 10 / 15 6ft / 10ft / 15ft 3-in-1 KVM cable Cascade Cable CA-6 / 10 / 15 6ft / 10ft / 15ft PS/2 3-to-3 Cascade cable Conversion Adapter SUN-31 SUN / iMAC USB to PS/2 adapter 6. -
Page 6: Important Safeguards
7. Important Safeguards Please read all of these instructions carefully before you use the device. Save this manual for future reference. Unplug the LCD Keyboard Drawer from the power outlet before cleaning. ● Do not spray liquid cleaners or aerosol directly on the device. Wet a cloth with ●... - Page 7 8. Structure Diagram 1. Keyboard 2. Aluminium front panel 3. Class A active matrix TFT LCD panel 4. Rear metal case 5. LCD inverter 6. LCD membrane 7. Ball bearing telescopic slides with stopper 8. Adjustable mounting bracket 9. PS/2 KVM switch (Two consoles) •...
- Page 11 Session Rev. : 1.0 P.10...
-
Page 12: Lcd Session
10. LCD Session LCD Membrane Diagram Power Menu/Selection Exit Right Left MAIN MENU BRIGHT/CONTRAST AUTO ADJUST PHASE/CLOCK H/V POSITION MISC RESET Main Menu Bright / Contrast To enter into the Bright, Black level & Contrast sub-menu ● Auto Adjust To perform automatic optimisations of all functions ●... - Page 13 10. LCD Session Bright / Contrast 1. Brightness To perform brightness adjustment of the input RGB signal ● to “Brightness” Use the Left & Right button to adjust and button ● 2. Contrast To adjust the contrast level of the input signal ●...
-
Page 14: Osd Timer
10. LCD Session MISC 1. Information The first header row shows the current resolution setup ● The second header row shows the horizontal frequency of the current ● input signal The third header row shows the vertical frequency of the current input ●... -
Page 15: Resolution Settings
10. LCD Session Resolution Settings For Microsoft Windows Step 1 – Press right click on the desktop Step 2 – Choose “Properties” Step 3 – Change the “Screen Resolution” Step 4 – Change the “Screen refresh rate” Rev. : 1.0 P.14... -
Page 16: For Sun Servers
10. LCD Session Resolution Settings For SUN Servers Resolution configuration procedures should be run by qualified SUN ● server administrator Sun Servers are using resolution at 1152 x 900 x 76Hz. ● Supported resolution mode for 15” LCD: ● 1024 x 768 x 70/75Hz ●... - Page 17 Session Rev. : 1.0 P.16...
-
Page 18: Kvm Session
11. KVM Session Front View Bank No. Selected Channel Bank Button Online Channel Channel Select Button Shift Button LED Indication Selected Channel - Displayed channel on monitor & red in LED. Channel select button - Press to select channel from 1 – 8. Shift button - Press &... -
Page 20: Installation Steps
11. KVM Session Installation Steps Before installation, please make sure all computers are turned on and its operating system are running properly with keyboard and mouse. Connect the 3-in-1 KVM cable to the one of your server. Mini Din 6-pin Male connector to the USB Port ●... - Page 21 11. KVM Session Cascading Using a CA-6 / 10 / 15 cascade cable to connect from Bank 1’s “Cascade port” to Bank 2’s “Console port”. After connected please press “Bank” & “Channel” button on the front of the PS/2 KVM switch to reset the KVM switch.
-
Page 22: Hotkey Command
12. Start Up The channels that have PC connected and it is switch on will have a green LED on that channel. The red LED will indicate the selected channel. 7 segments LED will display the bank number. Press channel button to select the channel. Enter the password, default is “00000000”... - Page 23 12. Start Up Hot-key Command Operation Calling OSD Menu Scroll Scroll Space Bar Switch to Previous Port (powered on PC only) £ Scroll Scroll Switch to Next Power On Port (powered on PC only) ¤ Scroll Scroll Switch to Previous Bank First digit of Port Number: Scroll Scroll...
-
Page 24: Hotkey Command Operation
12. Start Up HotKey Command Operation Switch to Next Bank Scroll Scroll PgDn Enable / Disable beeper sound Scroll Scroll Note: The default Beeper function is ON and beeper control is only for available for Scan Mode. Auto Scan for Powered on PC Scroll Scroll Reset to factory Default Setting... -
Page 25: Osd Structure Diagram
12. Start Up OSD Structure Diagram Bank Session BANK : 1 ® SYSTEM 02 BANK : 1 SYSTEM ® SYSTEM 02 E ® SYSTEM 03 ® SYSTEM 04 SYSTEM PC Session ® SYSTEM 03 ® SYSTEM 04 ® SYSTEM 05 SYSTEM 06 ®... -
Page 26: Kvm Settings Session
12. Start Up KVM Settings Session OSD Menu on screen time ● default is 10 seconds. It can be modified from 05 – 99 ● seconds. Scan Scan interval from one PC port ● to next PC port when applying █... - Page 27 13. FAQ 1. The recommended distance of VGA cable is 5 meters (maximum) without ghosting and degradation. Normally, the cable length is based on driver capacity of your VGA card. If you need longer VGA cable, please use VGA extender to accomplish your applications. 2.
- Page 28 13. FAQ If you forget the “password” of the switch (default is 00000000), please contact your supplier. CAT.5 Console Receiver power LED is not ON, to make sure power adapter is connected to KVM CAT.5 receiver. No video signal is displayed on the remote monitor. Please check all VGA cables &...
-
Page 29: Technical Specifications
14. Technical Specifications Specification Item Local Console CAT.5 Remote Console PC port PC Port interface HDDB 15 pin PS/2 Keyboard: Mini Din 6 pin Female PC Computer PS/2 Mouse: Mini Din 6 pin Female Interface VGA : HDDB 15pin Female PS/2 Keyboard: Mini Din 6 pin Female Cascade Port PS/2 Mouse: Mini Din 6 pin Female...
