Page 5: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 6 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 7 Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 8 Introduction MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book.
Page 9 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 10 Introduction Vehicle Symbol Glossary Child Safety Door Power Window Lockout Lock/Unlock Interior Luggage Compartment Release Panic Alarm Symbol Engine Oil Engine Coolant Engine Coolant Do Not Open When Hot Temperature Avoid Smoking, Flames, Battery or Sparks Battery Acid Explosive Gas Fan Warning Power Steering Fluid Maintain Correct Fluid...
Page 11: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES BRAKE TRIP CHECK FUEL kmiles Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 12 Instrument Cluster If the light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity.
Page 13 Instrument Cluster Anti-lock brake system (ABS) To confirm the anti-lock brake system (ABS) warning light is functional it will momentarily illuminate when the ignition is turned to the ON position (alternatively for some vehicles when the ignition is moved from the ON position to the START position, the light will momentarily illuminate just prior to reaching the START position).
Page 14 Instrument Cluster Engine oil pressure Illuminates when the oil pressure falls below the normal range. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and specifications chapter. Engine coolant temperature Illuminates when the engine coolant temperature is high.
Page 15 Instrument Cluster Traction Control active Illuminates when the Traction Control system is active. It will be lit for a minimum of four seconds or for the duration of the Traction Control event. For more information, refer to the Driving chapter. Steering column lock (manual transmission only) Illuminates when the steering column is locked.
Page 16 Instrument Cluster Bulb Warning Illuminates when one of the exterior bulbs has burned out. High beams Illuminates when the high beam headlamps are turned on. Door ajar (if equipped) Illuminates when any door or the trunk is open. Safety belt warning chime Sounds to remind you to fasten your safety belts.
Page 17: Gauges
Instrument Cluster GAUGES BRAKE TRIP CHECK FUEL kmiles Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”); if the needle goes above the normal range, the engine is overheating.
Page 18 Instrument Cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from an empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
Page 19 Instrument Cluster Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. To switch the display from Trip A to the Trip B feature, depress the A/B control. Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Page 20: Entertainment Systems
Entertainment Systems PREMIUM AM/FM STEREO/CASSETTE BASS TREB FADE PUSH ON TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1-2 COMP SHUFF ALPINE AUDIO SYSTEM WITH AM/FM STEREO/CASSETTE VOLUME PUSH ON BASS TREB FADE TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1-2 COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting...
Page 21 Entertainment Systems Volume/power control Press the control to turn the audio system on or off. PUSH ON Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 22 Entertainment Systems • to increase volume compensation • to decrease or shut off the volume compensation Bass adjust The bass adjust control allows you to increase or decrease the audio BASS system’s bass output. TREB Treble adjust The treble adjust control allows you BASS to increase or decrease the audio system’s treble output.
Page 23 Entertainment Systems Seek function The seek function control works in radio, tape or CD mode (if equipped). Seek function in radio mode • Press to find the next listenable station down the frequency band. SEEK • Press to find the next listenable station up the frequency band.
Page 24 Entertainment Systems first side, direction automatically reverses to the opposite side of the tape.) To stop on a particular selection, press the control again. Scan function in CD mode (if equipped) Press the SCAN control to hear a short sampling of all selections on the CD.
Page 25 Entertainment Systems Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the control. 3. When the first six strong stations AUTO are filled, the station stored in memory preset control 1 will start playing. If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.
Page 26 Entertainment Systems Tune adjust for CD changer (if equipped) • Press to select the previous disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in TUNE shuffle mode.) Refer to Shuffle feature for more information.
Page 27 Entertainment Systems Fast forward The fast forward control works in tape and CD modes (if equipped). • In the tape mode, tape direction will automatically reverse when the end of the tape is reached. • In CD mode, pressing the control for less than three seconds results in slow forward action.
Page 28 Entertainment Systems Shuffle feature The shuffle feature operates in CD mode and plays all tracks on the SHUFF current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature.
Page 29 Entertainment Systems • Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: • Classic • Country • Info • Jazz •...
Page 30 Entertainment Systems Press the control again to return to the playing media. This control will mute the playing media even if your vehicle is not equipped with a factory-installed cellular phone. Digital signal processing (if equipped) The digital signal processing (DSP) feature allows you to change the signal mode to suit your listening tastes.
Page 31 Entertainment Systems ALPINE AUDIOPHILE AM/FM STEREO IN-DASH SIX CD RADIO ALPINE SPORT AUDIO AM/FM STEREO IN-DASH SIX CD RADIO PREMIUM ALPINE AUDIO AM/FM STEREO IN-DASH SIX CD RADIO PREMIUM AM/FM STEREO IN DASH SIX CD RADIO...
Page 32 Entertainment Systems Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 33 Entertainment Systems Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. FADE Press the FADE control. Use the SEL control to adjust the sound between the front and rear speakers. Seek function The seek function works in radio or CD mode. Seek function in radio mode •...
Page 34 Entertainment Systems AM/FM select The AM/FM select control works in radio and CD modes. AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in CD mode Press this control to stop CD play and begin radio play.
Page 35 Entertainment Systems 2. AUTOSET will flash in the display as the frequency band is scrolled through. 3. When the six strongest stations are filled, the station stored in memory preset control 1 will start playing. If there are fewer than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available.
Page 36 Entertainment Systems Disc adjust for CD mode • Press to select the previous DISC TUNE disc. (Play will begin on the first track of the disc unless shuffle mode is engaged.) Refer to Shuffle feature for more information. Hold the control to continue reversing through the discs. •...
Page 37 Entertainment Systems Load The load feature allows you to load LOAD single CDs into the player internal to the radio. This six disc CD player is equipped with a CD door. Compact discs should only be inserted into the player after the door has been opened by the player.
Page 38 Entertainment Systems Auto eject Press and momentarily hold the EJ control to engage auto eject. All CDs which are present in the player will be ejected one at a time. If a CD is ejected and not removed from the door of the CD player, the player will automatically reload the CD.
Page 39 Entertainment Systems Compression feature (if equipped) The compression feature operates in CD mode and brings soft and loud MENU CD passages together for a more consistent listening level. On Audiophile audios, press the MENU control until compression status is displayed. Press the SEL control to enable the compression feature when COMP OFF is displayed.
Page 40 Entertainment Systems TRAFFIC ON/OFF— Traffic announcements can be programmed as local or distant. Refer to Traffic announcements. RDS ON/OFF— This feature allows your audio system to receive text information from RDS-equipped FM radio stations. Refer to Radio Data System feature. FIND type —...
Page 41 Entertainment Systems Program type This feature allows you to search for RDS stations selectively by their program type. Press the MENU control until FIND program type is displayed. MENU Use the SEL control to select the program type. With the feature on, use the SEEK or SCAN control to find the desired program type from the following selections: •...
Page 42 Entertainment Systems Press the DSP control to access one of the following modes: • DSP OFF • SIGNAL MODE • OCCUPANCY MODE Use the SEL control to select the desired signal mode (the selected mode will appear in the display). The following signal modes can be selected: •...
Page 43: Cd Changer
Entertainment Systems This control will mute the playing media even if your vehicle is not equipped with a factory-installed cellular phone. Press the control again to return to the playing media. CD CHANGER (IF EQUIPPED) The CD changer is located in the glove compartment. Press to eject the magazine.
Page 44 Entertainment Systems 3. Insert each CD tray, with the disc loaded, all the way into the CD magazine. 4. Insert the CD magazine into the changer. Use only compact discs containing this mark. Ensure that the disc is inserted label side up. The magazine does not need to be full for the changer to operate.
Page 45 Entertainment Systems If your changer does not work, it may be that: • A disc is already loaded where you want to insert a disc. • The disc is inserted with the label surface downward. • The disc is dusty or defective. •...
Page 46 Entertainment Systems • Tighten very loose tapes by inserting a finger or pencil into the hole and turning the hub. • Remove loose labels before inserting tapes. • Do not leave tapes in the cassette player for a long time when not being played.
Page 47: Climate Controls
Climate Controls DUAL AUTOMATIC TEMPERATURE CONTROL (DATC) SYSTEM AUTO The Dual Automatic Temperature Control (DATC) system will maintain a selected temperature and automatically control air flow. You can override the automatic operation with any of the override controls. The dual temperature zone feature allows the driver and front passenger to set their own independent temperature set points for individual comfort.
Page 48 Climate Controls Turning the system off Press OFF. The outside temperature (EXT) function (if selected) will continue to operate until the ignition is turned off. AUTO DATC automatic operation Press AUTO and select the desired temperature. The selected temperature will appear in the display window, and an indicator above the AUTO control will light.
Page 49 Climate Controls DATC system AUTO temperature balance AUTO Press and hold the AUTO control for about two seconds to equalize the passenger set temperature with the driver side temperature. This feature is useful when the driver is alone in the vehicle. Driver side temperature selection AUTO The display window indicates the selected temperature and manual...
Page 50 Climate Controls maximum heating (disregarding the displayed temperature) until a cooler temperature is selected by pressing the temperature control. If maximum heating is selected, the passenger set point is not displayed and the passenger temperature adjustments will be disabled. A change of the driver-selected temperature to a temperature other than 16°...
Page 51 Climate Controls Fan speed ( AUTO When AUTO is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, press the fan control to cancel the automatic fan speed operation.
Page 52 Climate Controls In defrost mode, if the outside temperature is about 2° C (35° F) or higher, the air conditioner will automatically dehumidify the air to reduce window fogging. However, the A/C indicator will be off and the A/C override control cannot be selected. When AUTO is selected, the A/C operates automatically for existing conditions.
Page 53 Climate Controls recirculated air operation and cancel automatic recirculated air operation, press the recirculated air control. When the recirculated air is manually controlled in the AUTO mode, the AUTO indicator light will remain lit. To return to full automatic recirculated air operation, press AUTO.
Page 54 Climate Controls added customer comfort, the air distributed through the floor ducts may be slightly warmer than the air sent to the instrument panel registers. (floor) — Distributes air through the front and rear seat floor ducts. The system will allow some airflow out the defroster ducts, the demister outlets and outer instrument panel registers.
Page 55 Climate Controls In cold, dry conditions where wet snow or ice is not present it is acceptable to manually deselect the operation of this feature. The feature will run continuously unless a low battery condition is detected, or unless the feature is manually deselected, and will only activate when the vehicle engine is running (to prevent excessive drain of the vehicle battery).
Page 56 Climate Controls • To prevent humidity buildup inside the vehicle, don’t drive with the climate control system in the OFF position. • DO NOT leave the DATC system in recirculated air mode for extended periods of time while the system is in a heating mode or in cold or damp conditions as this may cause interior fogging of the front, side and rear windows.
Page 57 Climate Controls BRAKE TRIP kmiles • Do not place items over the climate temperature sensor grid. This may cause improper operation of the DATC system. • With the ignition in the OFF position after operating the vehicle, some vehicle sounds related to the climate control system may be heard. •...
Page 58 • Protects the climate control components from particle deposits The filter is located just in front of the windshield under the cowl grille on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.
Page 59: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking AUTO lamps. Rotate to the second position to turn on the headlamps. Autolamp control The autolamp system provides light sensitive automatic on-off control of AUTO the exterior lights normally controlled by the headlamp control.
Page 60 Lights Daytime running lamps (DRL) (if equipped) Turns the highbeam headlamps on with a reduced output. To activate with automatic transmission: • the ignition must be in the RUN position; • the headlamp control is in the OFF position, Parking lamps position, or Autolamp position when the autolamp function has not turned on the headlamps (daytime);...
Page 61 Lights Flash to pass Pull toward you slightly to activate and release to deactivate. AUTO PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during parklamp, headlamp, and autolamp operation. • Rotate up to brighten. • Rotate down to dim. •...
Page 62 Lights Horizontal aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove the protective cover, then locate the horizontal indicator and the adjusting screw. 3. Use a 4 mm wrench or socket to turn the horizontal adjusting screw until the end of the shaft within the clear tube lines up with the “0”...
Page 63: Turn Signal Control
Lights Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove protective cover, then locate the bubble level and the vertical adjustment screw. 3. The numbers shown on the vial indicate the directional change (up or down) of the vertical aim.
Page 64 Lights INTERIOR LAMPS Map lamps (if equipped) The map lamps and controls are located on the dome lamp. Press the controls in front of each map lamp to activate the lamps. Rear dome lamp The dome lamp lights when: • any door is opened. •...
Page 65 Lights Do not remove lamp bulbs unless they will be replaced immediately. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect performance. Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.”...
Page 66 Lights Interior bulbs Check the operation of the following interior bulbs frequently: • front map lamps • Rear dome/reading lamp For bulb replacement, see a dealer or qualified technician. Map lamps For bulb replacement, see a qualified service technician or your dealer. Replacing headlamp bulbs To remove the high or low beam headlamp bulb: 1.
Page 67 Lights Replacing foglamp bulbs The halogen bulb contains gas under pressure. The bulb may shatter if the glass envelope is scratched or if the bulb is dropped. Handle the bulb carefully. Grasp the bulb only by its base. Avoid touching the glass envelope. 1.
Page 68: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The ignition must be in the ACC or RUN position to operate the windshield wiper. The bars of varying length are for AUTO intermittent wipers.
Page 69 Driver Controls Windshield wiper blades Check the wiper blades at least twice a year or when they seem less effective. Substances such as tree sap and some hot wax treatments used by commercial car washes reduce the effectiveness of wiper blades. In cold weather conditions, the wiper blades need to be thawed before operating in order to prevent premature wear to the wiper blades.
Page 70 Driver Controls 4. Attach the new wiper to the wiper arm and reposition the clip until it locks. Repeat for driver’s side wiper arm. TILT/TELESCOPE STEERING COLUMN Power tilt/telescope steering column Never adjust the steering wheel when the vehicle is moving. The steering column can be adjusted manually by moving the four-way rocker adjustment control...
Page 71: Power Windows
Driver Controls ILLUMINATED VISOR MIRROR To turn on the visor mirror lamps, lift the mirror cover. Adjust the amount of light by sliding the control. POWER WINDOWS Press and pull the rocker switches to open and close windows. • Press the top portion of the rocker switch to open.
Page 72 Driver Controls Express down To make the driver window open fully without holding the window control, press the top portion of the driver window control completely down to the second detent. Press or pull the control to stop window operation. Window lock The window lock feature allows only the driver to operate the rear power...
Page 73 Driver Controls Ensure the mirror is pulled down low enough to prevent visibility interference with the overhead console. The mirror support arm has COMP MIRROR two pivot points which lets you adjust the mirror UP or DOWN and from SIDE to SIDE. Press the control to turn the mirror on or off.
Page 74 Driver Controls Compass zone adjustment 1. Determine which compass zone you are in by referring to the zone map. 2. Turn the ignition to the ON/RUN position. 3. With the compass display turned on, press and hold the COMP side of the control for no more than six seconds until the zone selection COMP...
Page 75: Mirrors
Driver Controls Power side view mirrors The power mirrors can be operated at any time. To adjust your mirrors: 1. Select L to adjust the left mirror or R to adjust the right mirror. 2. Move the control in the direction you wish to tilt the mirror.
Page 76: Speed Control
Driver Controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled RESUME until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever into N (Neutral) with the speed control on.
Page 77 Driver Controls To set a speed • Press SET+ / SET−. For speed control to operate, the speed RESUME control must be ON and the vehicle speed must be greater than 48 km/h (30 mph). CANCEL If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed.
Page 78 Driver Controls To set a higher set speed • Press and hold SET+. Release the control when the desired vehicle RESUME speed is reached or • Press and release SET + to operate the Tap-Up function. Each press will increase the set speed by 1.6 km/h (1 mph) or •...
Page 79 Driver Controls • Press CANCEL or depress the brake pedal. When the desired RESUME vehicle speed is reached, press SET + / SET −. CANCEL To disengage speed control • Press CANCEL, RESUME CANCEL...
Page 80 Driver Controls • depress the brake pedal, or • depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed. RESUME CANCEL...
Page 81 Driver Controls To return to a previously set speed • Press RESUME. For RESUME to operate, the vehicle speed must RESUME be faster than 48 km/h (30 mph). CANCEL Indicator light This light comes on when the vehicle speed control is engaged and actively controlling vehicle speed.
Page 82 Driver Controls In AM, FM1, or FM2 mode: • Press to select preset MUTE stations within the selected radio band. In Tape mode: • Press to select the next selection on the tape. MEDIA In CD mode: • Press to select the next selection on the CD.
Page 83 Driver Controls MOON ROOF (IF EQUIPPED) To open the moon roof: • Push up on the control to raise the moon roof to the vent position (when the glass panel is closed). • Push the front portion of the control rearward to open the moon roof.
Page 84 Driver Controls purchase). It is also suggested that upon the sale of the vehicle, the programmed Homelink Universal Transceiver buttons be erased for security purposes, refer to Programming in this section. Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage.
Page 85 Driver Controls device should activate when the HomeLink button is pressed and released. Note: To program the remaining two HomeLink buttons, begin with step 2 in the “Programming” section — do not repeat step 1. If the red light blinks rapidly for two seconds and then turns to a continuous red, proceed with steps 6 through 8 to complete programming of a rolling code equipped device.
Page 86 Driver Controls • Proceed with step 4 in the “Programming” section. Operating the HomeLink Universal Transceiver To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
Page 87 • Dock the wireless phone in the docking station located in the center console armrest (once the phone is docked, the armrest can be closed) • Activate your Vehicle Communication System with the Lincoln Response Center by pressing the “i” Button 1. SOS BUTTON — In an...
Page 88 2. AUTOMATIC AIR BAG NOTIFICATION — If the air bag deploys, the Vehicle Communication system automatically places a call to the Lincoln Response Center and a representative will dispatch help to your location immediately if requested. If the specialist is unable to reach you, the emergency service provider will be contacted and dispatched to your location.
Page 89 • Press the “ i” Button and when voice communication is established with the Lincoln Response Center, indicate that you are a new customer and the specialist will introduce you to the features. The purpose of this call is to verify that your Vehicle Communication System is active and functioning properly.
Page 90: Message Center
Please use this technology responsibly. Due to the specialized Lincoln software contained within the phone, your local Sprint PCS store is unable to provide service or replacement units. Issues or questions about equipment including the wireless phone should be directed to your Lincoln dealer.
Page 91 Driver Controls a brief indicator chime will sound. The system will also notify you of potential vehicle problems with a system warnings display followed by a long indicator chime. Operator selectable features These features are controlled by the message center controls located above the radio.
Page 92 Driver Controls • washer fluid level • doors closed (driver and passenger side, front and rear). This message can only be reset by closing the door(s). If the RESET control is pressed, PLEASE CLOSE DOOR will be displayed. • trunk status •...
Page 93 Driver Controls Checking your highway fuel economy using the electronic message center display The following procedure will allow you to accurately monitor your actual highway fuel economy. Since this procedure requires the vehicle speed control system to be set to highway speeds, it must be run only on suitable roadways where long distance speed control can be safely maintained.
Page 94 Driver Controls 2. Pressing the RESET control cycles the message center through each of the language choices. 3. Press and hold the RESET control to set the language choice. Units (English/Metric) 1. Select this function from the SETUP control for the current units to be displayed.
Page 95 Driver Controls System warnings System warnings alert you to possible problems or malfunctions in your vehicle’s operating systems. In the event of a multiple warning situation, the message center will cycle the display to show all warnings by displaying each one for 4 seconds.
Page 96 Driver Controls Warnings Status Low brake fluid level Warning returns after the ignition key is Check tail lamps turned from OFF to Check brake lamps Check front turn lamps Check side repeater lamps (if equipped) Check rear turn lamps Check Traction Control (if equipped) Check AdvanceTrac (if equipped) Trunk ajar Low washer fluid...
Page 97 Driver Controls Engine coolant in the Maintenance and specifications chapter. If the warning stays on or continues to come on, contact your dealer as soon as possible. CHECK CHARGING SYSTEM. Displayed when the electrical system is not maintaining proper voltage. If you are operating electrical accessories when the engine is idling at a low speed, turn off as many of the electrical loads as soon as possible.
Page 98 Driver Controls CHECK REAR TURN LAMPS. Displayed when the turn signals are activated and at least one is burned out. Check the lamps as soon as possible and have the burned out lamp replaced. CHECK TRACTION CONTROL (if equipped). Displayed when the Traction Control system is not operating properly.
Page 99 Driver Controls 3. After a successful reset, the message center will display A/C FILTER LIFE SET TO 100%. CHANGE OIL SOON/OIL CHANGE REQUIRED. Displayed when the engine oil life remaining is 5 percent or less. When oil life left is between 5% and 0%, the CHANGE OIL SOON message will be displayed.
Page 100 Driver Controls 2. Press RESET and SETUP controls at the same time to activate a service mode which will display OIL LIFE XX% RESET TO ALTER. 3. Press RESET until you find your personalized OIL LIFE XX%. DATA ERROR. These messages indicate improper operation of the vehicle network communication between electronic modules.
Page 101 Driver Controls FUEL DOOR RELEASE Press the remote fuel door release control on the instrument panel to open the fuel door. The fuel door has a manual override release located in the trunk. Pull the tab to open the fuel door. REMOVAL/INSTALLATION OF ASHTRAY Before removing and installing the ashtray, make sure the ignition is in the off position, and move the floor mounted automatic shifter from the...
Page 102 Driver Controls 3. Pull out ashtray assembly. Installation: 1. Insert ashtray into opening with face tilted upward. 2. Push face down until it clicks into position. STEERING COLUMN LOCK (IF EQUIPPED) The steering column will automatically lock when the key is removed from the ignition.
Page 103 • Repeat steps 1 and 2 for the other side. LUGGAGE RACK (IF EQUIPPED) The luggage rack is dealer installed only. See your local Lincoln Mercury dealership. The maximum load is 75 kg (165 lb) on the luggage rack structure. The vehicle’s roof panel is not designed to carry a load.
Page 104: Locks And Security
Locks and Security KEYS The vehicle is equipped with two master keys and a valet key lock system. The master key will access the driver’s door, trunk, glove box and ignition. The valet key will access door and ignition only. Refer to the Securilock Passive Anti-Theft System section for information on Securilock keys.
Page 105 Locks and Security Childproof door locks When these locks are set, the rear doors cannot be opened from the inside. The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 106: Anti-Theft System
Locks and Security Keep vehicle doors and luggage compartment locked and keep keys and remote transmitters out of a child’s reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly.
Page 107: Interior Lamps
Locks and Security • operate the memory seat/mirror/steering column feature (if equipped). The remote transmitter features only operate with the ignition in the OFF or ACC positions. For vehicles equipped with an automatic transmission, the remote transmitter features also operate if the ignition is in the RUN position and the gear shift is in P (Park).
Page 108 Locks and Security Opening all windows and moonroof (if equipped) Press this control and hold down for more than one second to begin to open all the windows and moonroof. Release the control to stop. If the control is held down for more than four seconds, the windows and moonroof will open fully.
Page 109 Locks and Security Activating the personal alarm Press this control to turn on the personal alarm. Press the control a second time to turn off the personal alarm. The personal alarm will also turn off if the remote transmitter unlock control is pressed, or if the ignition switch is turned to the RUN position, or after 30 seconds of...
Page 110 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation.
Page 111 Locks and Security The battery saver will turn off the interior lamps 40 minutes after the last door is closed even if the dimmer control switch is on. Autolock/Relock This feature automatically locks all vehicle doors when: • all doors are closed, and •...
Page 112 Locks and Security 4. Repeat this procedure for another remote transmitter if desired. Deactivating the stored memory seat/mirror/steering column positions To deactivate this feature: 1. Press the SET control on the driver’s door panel. 2. Within 5 five seconds, press one control on the remote transmitter which you would like to deactivate and then press the SET control on the driver’s door panel.
Page 113 OFF and restart the engine with all other objects on the key ring held away from the ignition key. Check to make sure the coded key is an approved Lincoln coded key. If your keys are lost or stolen you will need to do the following: •...
Page 114 Locks and Security Replacing coded keys can be very costly and you may want to store an extra programmed key away from the vehicle in a safe place to prevent an unforeseen inconvenience. The correct coded key must be used for your vehicle. The use of the wrong type of coded key may lead to a “no start”...
Page 115 Locks and Security If successful, the new coded key(s) will start the vehicle’s engine and the theft indicator will illuminate for three seconds and then go out. If not successful, the new coded key(s) will not start the vehicle’s engine and the theft indicator will flash on and off and you may repeat steps 1 through 6.
Page 116: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 117 Seating and Safety Restraints The head restraints can be moved in four directions and use the same release control as the two-way head restraints: • up and down • forward or backward Using the manual lumbar support (if equipped) The lumbar control is located on the front of the seat cushion.
Page 118 Seating and Safety Restraints Heated seats (if equipped) To operate the heated seats: • Push control to activate. • Push again to deactivate. The heated seats will activate when the ignition is in the RUN position. When activated, they will turn off automatically after 10 minutes or when the ignition is turned to the OFF position.
Page 119 Seating and Safety Restraints Rotate the vertical control to adjust the seatback. • 8 way • 6 way Slide the control forward or backward to move the seat forward or backward. • 8 way • 6 way Move the control up or down to move the seat up and down.
Page 120 Seating and Safety Restraints The seat will move 5 cm (2 inches) forward (to the original position) when: • the transmission is in N (Neutral) or P (Park) • the key is placed in the ignition cylinder Deactivating/activating the easy access/easy out feature The easy access/easy out feature can be turned off or on through the vehicle message center (if equipped).
Page 121: Safety Restraints
Seating and Safety Restraints 2ND SEAT/SPLIT-FOLDING REAR SEAT One or both rear seatbacks can be folded down to provide additional cargo space. To lower the seatback(s), pull the release handle(s) located inside the trunk. Fold the seatback(s) down. When raising the seatback(s), make sure you hear the seat latch into place.
Page 122 Seating and Safety Restraints Never let a passenger hold a child on his or her lap while the vehicle is moving. The passenger cannot protect the child from injury in a collision. All occupants of the vehicle, including the driver, should always properly wear their safety belts, even when an air bag (SRS) is provided.
Page 123 Seating and Safety Restraints Combination lap and shoulder belts • Front seat belts • Rear seat belts...
Page 124 Seating and Safety Restraints 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. 2.
Page 125 Seating and Safety Restraints Failure to replace the belt and retractor assembly could increase the risk of injury in collisions. The front outboard and rear safety restraints in the vehicle are combination lap and shoulder belts. The front passenger and rear seat safety belts have two types of locking modes.
Page 126 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is extracted. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 127 Seating and Safety Restraints Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front passenger seating positions. The safety belt pretensioner is a device which removes excess webbing from the safety belt system. The safety belt pretensioner uses the same crash sensor system as the front air bag supplemental restraint system (SRS).
Page 128 Seating and Safety Restraints Safety belt warning light and indicator chime The seat belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts. Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the...
Page 129 Seating and Safety Restraints If... Then... The driver’s safety belt is buckled The BeltMinder feature will not before the ignition switch is turned activate. to the ON position... The purpose of the BeltMinder is to remind occasional wearers to wear safety belts all of the time.
Page 130 Seating and Safety Restraints Reasons given... Consider... “I have an air bag” Air bags offer greater protection when used with safety belts. Frontal airbags are not designed to inflate in rear and side crashes or rollovers. “I’d rather be Not a good idea. People who are ejected are 40 thrown clear”...
Page 131 Seating and Safety Restraints • Steps 3–5 must be completed within 60 seconds or the procedure will have to be repeated. 3. Buckle then unbuckle the safety belt three times, ending with the safety belt unbuckled. This can be done before or during BeltMinder warning activation.
Page 132: Air Bags
Seating and Safety Restraints there are no nicks, tears or cuts. Replace if necessary. All safety belt assemblies, including retractors, buckles, front seat belt buckle assemblies, buckle support assemblies (slide bar-if equipped), shoulder belt height adjusters (if equipped), shoulder belt guide on seatback (if equipped), child safety seat tether bracket assemblies (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision.
Page 133 Seating and Safety Restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
Page 134 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may affect the performance of the air bag sensors increasing the risk of injury.
Page 135 Seating and Safety Restraints How does the safety belt pretensioner and air bag supplemental restraint system work? The safety belt pretensioner and air bag SRS are designed to activate when the vehicle sustains longitudinal deceleration sufficient to cause the sensors to close an electrical circuit that initiates pretensioner activation and air bag inflation.
Page 136 Seating and Safety Restraints are not properly restrained or are otherwise out of position at the time of air bag deployment. Thus, it is extremely important that occupants be properly restrained as far away from the air bag module as possible while maintaining vehicle control.
Page 137 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always...
Page 138 Seating and Safety Restraints How does the side air bag system work? The side air bag system consists of the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 139 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual.
Page 140 Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air bag supplemental restraint system (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.
Page 141 Seating and Safety Restraints Child booster seats Children outgrow a typical convertible or toddler seat when they weigh 40 pounds and are around 4 years of age. Although the lap/shoulder belt will provide some protection, these children are still too small for lap/shoulder belts to fit properly, which could increase the risk of serious injury.
Page 142 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 143 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child.
Page 144 Seating and Safety Restraints When installing a child safety seat: • Review and follow the information presented in the Air Bag Supplemental Restraint System section in this chapter. • Use the correct safety belt buckle for that seating position. • Insert the belt tongue into the proper buckle until you hear a snap and feel it latch.
Page 145 Seating and Safety Restraints 1. Position the child safety seat in a seat with a combination lap and shoulder belt. Children 12 and under should be properly restrained in the rear seat whenever possible. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
Page 146 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 147 Seating and Safety Restraints 8. Allow the safety belt to retract to remove any slack in the belt. 9. Before placing the child in the seat, forcibly tilt the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back.
Page 148 Seating and Safety Restraints Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. 1. Position the child safety seat on the seat cushion. 2.
Page 149 Seating and Safety Restraints If the safety seat is not anchored properly, the risk of a child being injured in a collision greatly increases. Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments for child seat anchors Some child safety seats have two rigid or webbing mounted attachments that connect to two anchors at certain seating positions in your vehicle.
Page 150 LATCH attachments. Two plastic LATCH guides can be obtained at no charge from any Ford or Lincoln-Mercury dealer. They snap onto the LATCH lower anchors in the seat to help attach a child seat with rigid attachments.
Page 151: Driving
Driving STARTING Positions of the ignition 1. LOCK, locks the gearshift lever (automatic transmission only) and allows key removal. 2. OFF, shuts off the engine and all accessories without locking the steering wheel (if equipped). This position also allows the automatic transmission shift lever to be moved from the P (Park) position without the brake pedal being depressed.
Page 152 Driving Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire. Do not start your vehicle in a closed garage or in other enclosed areas.
Page 153 Driving • Push the clutch pedal to the floor. 3. Turn the key to 4 (RUN) without turning the key to 5 (START). BRAKE CHECK FUEL Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. •...
Page 154 Driving 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 4 (RUN). 2. If the temperature is above –12° C (10° F) and the engine does not start within five seconds on the first try, turn the key to OFF, wait 10 seconds and try again.
Page 155: Brakes
Driving If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes. These fumes are harmful and could kill you. Have the exhaust and body ventilation systems checked whenever: •...
Page 156 Driving If you are driving down a long or steep hill, shift to a lower gear. Do not apply your brakes continuously, as they may overheat and become less effective. Anti-lock brake system (ABS) On vehicles equipped with an anti-lock braking system (ABS), a noise from the hydraulic pump motor and pulsation in the pedal may be observed during ABS braking events.
Page 157 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the RUN position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock BRAKE brake system is disabled and normal...
Page 158 Driving Your brake handle may need to be pulled up slightly to release pressure before pushing in the button. Push the button on the end of the parking brake and push the handle down as far as possible to release the brake.
Page 159 Driving TRACTION CONTROL The Traction Control system helps maintain the stability and steerability of your vehicle. It is especially useful on slippery and/or hilly road surfaces. The system operates at all speeds by detecting and controlling wheel spin. The system borrows many of the electronic and mechanical elements already present in the anti-lock braking system (ABS).
Page 160 Driving AdvanceTrac Stability Enhancement System (if equipped) The AdvanceTrac system helps the driver maintain the stability and steerability of the vehicle. The system integrates anti-lock braking system (ABS), Traction Control and a more advanced function to further enhance the stability of the vehicle. The system shares many of the electronic and mechanical elements already present in the Traction Control and ABS systems.
Page 161 Driving The AdvanceTrac on/off control button allows the driver to control the availability of the Traction Control and AdvanceTrac system. This is independent of the ABS function, which CANNOT be switched off by the driver. The AdvanceTrac system status is indicated by a warning indicator light with a “sliding car”...
Page 162: Transmission Operation
Driving If you find yourself regularly experiencing AdvanceTrac events, you are driving too fast for conditions, you should reduce your speed, and drive less aggressively. AdvanceTrac is limited by the laws of physics. It is always possible to lose control of a vehicle due to inappropriate driver inputs for the conditions.
Page 163 Driving Do not rock the vehicle if the engine is not at normal operating temperature or damage to the transmission may occur. Do not rock the vehicle for more than a few minutes or damage to the transmission and tires may occur or the engine may overheat.
Page 164 Driving P (Park) Always come to a complete stop before shifting into P (Park). Make sure the gearshift lever is securely latched in P (Park). This position locks the transmission and prevents the rear wheels from turning. Always set the parking brake fully and make sure the gearshift lever is latched in P (Park).
Page 165 Driving N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll. Hold the brake pedal down while in this gear. Drive 5 (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears one through five.
Page 166 Driving Drive 4 (Drive) Transmission operates in gears one through four. Drive 4 (Drive) provides engine braking in 4th gear and is useful when: • driving with a heavy load. • towing a trailer up or down steep hills. • additional engine downhill braking is desired.
Page 167 Driving 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. Upshifts can be made by shifting to 3 (Third), 4 (Drive) or 5 (Overdrive). Selecting 2 (Second) at higher speeds causes the transmission to shift to a lower gear, and will shift to 2 (Second) after vehicle decelerates to the proper...
Page 168 Driving transmission. Once the vehicle is at operating temperature it may take several shifts at the same operating condition for the transmission to properly adapt. Over time the adaptive learning process will fully update transmission operation. The more varied the driving habits, speed and torque, the longer it may take to adapt but the more complete the process will be.
Page 169 Driving Automatic shift mode When in the automatic shift mode (D5 position), the 5–speed automatic transmission operates like a typical automatic transmission. Pull the gearshift lever towards you and downward to move the automatic gearshift. Refer to Driving with a 5–speed automatic transmission in this chapter for Park, Reverse, Neutral, D5 and D4 information.
Page 170 Driving + and - position operation These positions allow the driver to manually select the appropriate upshift (+) or downshift (-) and gear range. • Can only be entered from the D5 (Overdrive) shift position. • Gear ranges 1–5 provide the same function and ratio as found in the D5 or D4 automatic mode positions.
Page 171 Driving downshift into the next lower gear to prevent possible engine and/or transmission damage. Once the vehicle reaches below a specified entry speed for the next lower gear, the transmission will allow another downshift to occur if selected by the driver. Recommended Shift Speeds Upshift according to the following charts: Recommended upshifts when accelerating...
Page 172 Driving Recommended upshifts when cruising Select Shift V8 3.9L Shift from: 1 - 2 2 - 3 26 km/h (16 mph) 3 - 4 47 km/h (29 mph) 4 - 5 61 km/h (38 mph) MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch Vehicles equipped with a manual transmission have a starter interlock that prevents cranking the engine unless the clutch pedal is fully...
Page 173 Driving 4. Turn the ignition to position 5 (START) to start the engine, let the engine idle for a few seconds. 5. Depress the brake pedal. 6. Release the parking brake. 7. Move the gearshift lever to the desired gear. 8.
Page 174 Driving Recommended upshifts when cruising 5-speed manual transmission Shift from: 1 - 2 18 km/h (11 mph) 2 - 3 32 km/h (20 mph) 3 - 4 51 km/h (32 mph) 4 - 5 68 km/h (42 mph) Parking your vehicle 1.
Page 175 Driving 4. Turn the ignition key to position 1 (LOCK). Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully. Reverse Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
Page 176: Vehicle Loading
Driving If driving through deep or standing water is unavoidable, proceed very slowly. Never drive through water that is higher than the bottom of the hubs (for trucks) or the bottom of the wheel rims (for cars). Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 177: Trailer Towing
Driving • Maximum Trailer Weight: Maximum weight of a trailer the loaded vehicle (including occupants and cargo) is permitted to tow. It is determined by subtracting the weight of the loaded trailer towing vehicle from the GCWR for the towing vehicle. •...
Page 178 Driving Follow these guidelines to ensure safe towing procedure: • Stay within your vehicle’s load limits. If exceeded, cargo should be removed from the trailer and/or the vehicle until all weights are within specified limits. • Thoroughly prepare your vehicle for towing. Refer to Preparing to tow in this chapter.
Page 179 Driving Preparing to tow Use the proper equipment for towing a trailer, and make sure it is properly attached to your vehicle. See your dealer or a reliable trailer dealer if you require assistance. Hitches Do not use hitches that clamp onto the vehicle bumper. Use a load carrying hitch.
Page 180 Driving Your vehicle is ready to install a Trailer Tow module that will provide the proper communication with the vehicle electrical system so your trailer lamps will function properly. See your dealer or trailer rental agency for proper instructions and equipment for hooking up trailer lamps. Driving while you tow When towing a trailer: •...
Page 181: Recreational Towing
Driving RECREATIONAL TOWING (ALL WHEELS ON THE GROUND) Follow these guidelines for your specific powertrain combination to tow your vehicle with all four wheels on the ground (such as behind a recreational vehicle). These guidelines are designed to ensure that your transmission is not damaged due to insufficient lubrication.
Page 182: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.
Page 183: Fuel Pump Shut-Off Switch
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Page 184: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located in the driver’s foot well, behind the kick panel. The reset button (RED) for the fuel pump shut-off switch is accessible through an opening in the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1.
Page 185 Roadside Emergencies Note: Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color COLOR Cartridge Fuse Mini...
Page 186 Roadside Emergencies OWNER'S MANUAL RELAY 1 The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Starter Relay Coil Radio ABS/TCS/AdvanceTrac Cluster, PCM Relay, Fuel Pump Relay, REM, Transit Relay T/A Switch, O/D Cancel Switch, Autolamp Sensor, Heated Seat Modules, VCS OBD II DDM, DSM, Anti-theft LED, Security Horn,...
Page 187 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Right Front Low Beam Left Front Turn, Left Front Repeater, Left Front Sidemarker, Left Front Park Lamps Left Front High Beam Headlamp Leveling (if equipped) Cluster RCM, DATC Not Used (Spare) E/C Mirror, Heated Seat Controls, RSM (Rain Sensor Module)
Page 188 Roadside Emergencies Front power distribution box The front power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 189: Fog Lamp
Roadside Emergencies 9 10 11 12 RELAY 01 RELAY 02 RELAY 03 RELAY RELAY 04 RELAY 05 RELAY 06 RELAY 07 RELAY RELAY RELAY RELAY RELAY The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 10A*...
Page 190 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 30A** ABS Module — Not Used 30A** Blower Motor 20A** Thermactor Air Pump (V6 Engines Only) 40A** — Not Used 30A** Wiper Motor 30A** Starter Solenoid 30A** ABS Motor —...
Page 191 Roadside Emergencies Rear power distribution box The rear power distribution box is located in the luggage compartment under the spare tire well cover. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 192 Roadside Emergencies 1 2 3 4 5 6 7 8 9 > PBT < 10 11 12 13 14 15 16 17 18 RELAY MINI-FUSE CARTRIDGE FUSE RELAY RELAY RELAY RELAY RELAY RELAY DIODE 01 DIODE 02 SEE OWNER'S MANUAL CONSULTER LA GUIDE The high-current fuses are coded as follows.
Page 193 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 20A** REM - Left Rear Window 20A** DDM - Driver Window 20A** Driver Lumbar, Power Seats 20A** Ignition Switch 30A** SSP4 30A** SSP3 40A** P-J/B 20A** FEM - Front Passenger Window 30A** SSP1 20A**...
Page 194 Roadside Emergencies Temporary spare tire information Your vehicle may have a temporary or full-size spare tire. The temporary spare tire for your vehicle is labeled as such. It is smaller than a regular tire and is designed for emergency use only. Replace this tire with a full-size tire as soon as possible.
Page 195 Roadside Emergencies If the vehicle slips off the jack, you or someone else could be seriously injured. 1. Park on a level surface, activate hazard flashers and set parking brake. 2. Place gearshift lever in P (Park) or R (manual transmission), turn engine OFF, and block the diagonally opposite wheel.
Page 196 Roadside Emergencies 4. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 5. Put the jack in the jack notch next to the tire you are changing. Turn the jack handle clockwise until the wheel is completely off the ground.
Page 197 If you lose the key, send the registration card to the manufacturer (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
Page 198: Jump Starting
Roadside Emergencies JUMP STARTING YOUR VEHICLE The gases around the battery can explode if exposed to flames, sparks, or lit cigarettes. An explosion could result in injury or vehicle damage. Batteries contain sulfuric acid which can burn skin, eyes, and clothing, if contacted.
Page 199 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 200 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to the spare tire tie-down stud. (Your vehicle may be equipped with a plastic cap on top of the tire tie-down stud.
Page 201 Roadside Emergencies 5. Ensure that the cables are clear of fan blades, belts, moving parts of both engines, or any fuel delivery system parts. Jump starting 1. Start the engine of the booster vehicle and run the engine at moderately increased speed. 2.
Page 202 Roadside Emergencies 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery. 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery.
Page 203 Roadside Emergencies 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 204: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 205: Customer Assistance
Customer Assistance GETTING THE SERVICES YOU NEED At home Ford Motor Company and Ford of Canada have authorized dealerships to service your vehicle. It is preferred that you return to the Ford dealer where your vehicle was purchased when warranty repairs are needed. However, you may also take your vehicle to another Ford Motor Company or Ford of Canada dealership authorized for warranty repairs.
Page 206 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 207 • Protection against covered repair costs after your Bumper-to-Bumper Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 208: The Dispute Settlement Board
What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 209 • A Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 210: Utilizing The Mediation/Arbitration
Customer Assistance Oral presentations If you would like to make an oral presentation, indicate YES to question 6 on the application. While it is your right to make an oral presentation before the Board, this is not a requirement and the Board will decide the case whether or not an oral presentation is made.
Page 211: Getting Assistance Outside The U.s. And Canada
Customer Assistance unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP). The CAMVAP program is a straight-forward and relatively speedy alternative to resolve a disagreement when all other efforts to produce a settlement have failed.
Page 212: Ordering Additional Owner's Literature
Customer Assistance If you are in another foreign country, contact the nearest Ford dealership. If the dealership employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 213: Reporting Safety Defects (U.s. Only)
Customer Assistance California Civil Code Section 1793.22(b) presumes that the manufacturer has had a reasonable number of attempts to conform the vehicle to its applicable express warranties if, within the first 18 months of ownership of a new vehicle or the first 29 000 km (18 000 miles), whichever occurs first: 1.
Page 214: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 215 Cleaning • Remove particles such as bird droppings, tree sap, insect deposits, tar spots, road salt and industrial fallout before repairing paint chips. • Always read the instructions before using the products. ALUMINUM WHEELS AND COVERS Aluminum wheel rims or covers are coated with a clearcoat paint finish. In order to maintain their shine: •...
Page 216 Cleaning • 3.0L DOHC V6 engine...
Page 217 Cleaning • 3.9L-4V V8 engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your dealer.
Page 218 Cleaning • Do not use abrasives, as they may cause scratches. • Do not use fuel, kerosene, or paint thinner to clean any parts. • Wiper blades can be cleaned with isopropyl (rubbing) alcohol or windshield washer solution. Be sure to replace wiper blades when they appear worn or do not function properly.
Page 219 Cleaning INTERIOR For fabric, carpets, cloth seats, safety belts and seats equipped with side air bags: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 220 Cleaning Ford, Lincoln and Mercury car care products Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 221: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 222: Hood
Maintenance and Specifications 3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on • Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 223: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.0L DOHC V6 engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake (and clutch, if equipped) fluid reservoir 4. Engine coolant reservoir 5. Power steering fluid reservoir 6. Air filter assembly 7.
Page 224 Maintenance and Specifications 3.9L–4V V8 engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Power steering fluid reservoir 6. Air filter assembly 7. Windshield washer fluid reservoir 8. Power distribution box 9.
Page 225: Engine Oil
Maintenance and Specifications WINDSHIELD WASHER FLUID Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a symbol. Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification ESR-M17P5–A.
Page 226 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 227 Maintenance and Specifications 3. Recheck the engine oil level. Make sure the oil level is not above the MAX mark on the engine oil level indicator (dipstick). 4. Install the indicator and ensure it is fully seated. 5. Fully install the engine oil filler cap by turning the filler cap clockwise tightly until clicks are heard, or until it is snug.
Page 228: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which is located in the luggage compartment, next to the spare tire. Your battery is designed to purge any battery gases to the outside of the vehicle by means of a vent hose. This vent hose MUST be attached at all times.
Page 229 Maintenance and Specifications Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 230 Maintenance and Specifications When the battery is disconnected or a new battery installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly. This operation is considered normal and will not affect function or durability of the transmission. Over time the adaptive learning process will fully update transmission operation to its optimum shift feel.
Page 231 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. COLD FILL LEVEL • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 232 Maintenance and Specifications Do not add engine coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly. Also, you can be burned if you spill coolant on hot engine parts. Do not put engine coolant in the windshield washer fluid container.
Page 233 Maintenance and Specifications • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled engine coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 234 Maintenance and Specifications system may have a leak. Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored).
Page 235 Maintenance and Specifications • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage. • Decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage.
Page 236 Maintenance and Specifications Once the engine temperature cools, the engine can be re-started. Take your vehicle to a service facility as soon as possible to minimize engine damage. When fail-safe mode is activated You have limited engine power when in the fail-safe mode, so drive the vehicle with caution.
Page 237 Maintenance and Specifications Check the fluid level when it is at ambient temperature (-7° to 25° C [20° to 80° F]): 1. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range.
Page 238 Maintenance and Specifications Automotive fuels can cause serious injury or death if misused or mishandled. Gasoline may contain benzene, which is a cancer-causing agent. Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle.
Page 239 Maintenance and Specifications When refueling always shut the engine off and never allow sparks or open flames near the filler neck. Never smoke while refueling. Fuel vapor is extremely hazardous under certain conditions. Care should be taken to avoid inhaling excess fumes. The flow of fuel through a fuel pump nozzle can produce static electricity, which can cause a fire if fuel is pumped into an ungrounded fuel container.
Page 240 Maintenance and Specifications The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible...
Page 241 Maintenance and Specifications It should not be necessary to add any aftermarket products to your fuel tank if you continue to use high quality fuel of the recommended octane rating. Aftermarket products could cause damage to the fuel system. Repairs to correct the effects of using an aftermarket product in your fuel may not be covered by your warranty.
Page 242 Maintenance and Specifications POWER STEERING FLUID Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 243 Maintenance and Specifications 2. Visually inspect the fluid level. 3. If necessary, add brake fluid from a clean un-opened container until the level reaches MAX. Do not fill above this line. 4. Use only brake fluids certified to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter.
Page 244 Maintenance and Specifications Do not use supplemental transmission fluid additives, treatments or cleaning agents. The use of these materials may affect transmission operation and result in damage to internal transmission components. Checking and adding manual transmission fluid (if equipped) 1. Clean the filler plug. 2.
Page 245 Maintenance and Specifications CLUTCH FLUID (IF EQUIPPED) The clutch master cylinder and brake master cylinder are part of the same system; both are refillable through the brake master cylinder with brake fluid. For more information on brake fluid maintenance, refer to Brake fluid in this chapter.
Page 246 Maintenance and Specifications Changing the air filter element 1. Loosen the hose clamp on the outlet tube at the air filter housing. 2. Release the two clamps that secure the cover to the air filter housing and place the cover aside.
Page 247 Maintenance and Specifications 3. Remove the air filter element from the air filter housing. 4. Wipe the air filter housing and cover clean to remove any dirt or debris and to ensure good sealing. 5. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover.
Page 248 Maintenance and Specifications U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 249 Maintenance and Specifications SERVICING YOUR TIRES Checking the tire pressure • Use an accurate tire pressure gauge. • Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 250 Maintenance and Specifications • Five tire rotation (with full-size spare tire) • Unidirectional tire rotation For vehicles equipped with original equipment unidirectional tires and full-size spare, your vehicle can be driven with the unidirectional full-size spare, rotating counter to the directional arrow on the tire sidewall.
Page 251 Maintenance and Specifications Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification or Tire Label.
Page 252: Part Numbers
Maintenance and Specifications SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires or chains.
Page 253: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid and Motorcraft High Fill to MAX line clutch fluid (if Performance on reservoir equipped) DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft SAE 3.0L-4V V6 6.5L (6.9 (includes filter 5W-20 Premium engine...
Page 254 Maintenance and Specifications Fluid Ford Part Application Capacity Name Transmission Motorcraft Automatic 11.2L (11.9 fluid MERCON V (5R55N) quarts) Motorcraft Manual 1.1L (2.3 pints) MERCON ATF Windshield Ultra-Clear Fill to line on washer fluid Windshield reservoir Washer Concentrate Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter.
Page 255: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Item Ford part Ford part Ford name number specification Brake fluid and Motorcraft High PM-1 ESA-M6C25-A clutch fluid (if Performance and DOT 3 equipped) DOT 3 Motor Vehicle Brake Fluid Door Silicone F7AZ-19G208-BA ESR-M13P4-A weatherstrips Lubricant F5AZ-19553-AA Door latch, hood...
Page 256 Maintenance and Specifications Item Ford part Ford part Ford name number specification Power steering Motorcraft XT-2-QDX MERCON and engine MERCON ATF cooling fan fluid Rear Axle Motorcraft SAE XY-75W140–QL WSL-M2C192-A Lubricant 75W-140 High Performance Synthetic Rear Axle Lubricant Automatic Motorcraft XT-5-QM MERCON V transmission...
Page 257: Engine Data
Maintenance and Specifications ENGINE DATA Engine 3.0L-4V V6 engine 3.9L-4V V8 engine Displacement 2 968 cc (181 cid) 3 949 cc (241 cid) Required fuel 91 octane 91 octane Firing order 1-4-2-5-3-6 1-5-4-2-6-3-7-8 Spark plug gap 1.30-1.45 mm 0.99-1.09 mm (0.051-0.057 inch) (0.039-0.043 inch) Ignition system...
Page 258 Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 259 Maintenance and Specifications taking fuel economy measurements during the first 1 600 km (1 000 miles) of driving (engine break-in period). You will get a more accurate measurement after 3 000 km–5 000 km (2 000 miles-3 000 miles). Filling the tank The advertised fuel capacity of the fuel tank on your vehicle is equal to the rated refill capacity of the fuel tank as listed in the Refill capacities section of this chapter.
Page 260 Maintenance and Specifications 4. Subtract your initial odometer reading from the current odometer reading. 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled. Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway).
Page 261 Maintenance and Specifications • Combine errands and minimize stop-and-go driving. Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant specifications in this chapter.
Page 262: Vehicle Dimensions
Maintenance and Specifications VEHICLE DIMENSIONS Vehicle dimensions mm (in) (1) Overall length 4 925 mm (193.9 in) (2) Overall width 1 859 mm (73.2 in) (3) Overall height 1 426 mm (56.1 in) (4) Wheelbase 2 909 mm (114.5 in) (5) Track - Front 1 537 mm (60.5 in) (5) Track - Rear...
Page 263: Certification Label
Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety MFD. BY FORD MOTOR CO. IN U.S.A. Administration Regulations require DATE: XXXXX GVWR:XXXXXXXXXXXX that a Certification Label be affixed FRONT GAWR: XXXXXX/XXXXXXX REAR GAWR: XXXXXXX/XXXXXXX to a vehicle and prescribe where the THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL Certification Label may be located.
Page 264 Maintenance and Specifications Vehicle identification number The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 265: Accessories
FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Lincoln Mercury dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 266 Accessories Travel equipment Removable bike rack Removable luggage rack adapters Removable luggage rack Removable ski rack Protection and appearance equipment Air bag anti-theft locks Molded splash guards Car cover Molded vinyl floor mats Carpet floor mats Moon roof air deflector Emergency kit Park pilot/reverse park aid First aid kit...
Page 267: Index
Index acid, treating emergencies ..227 charging system warning ABS (see Brakes) .....155 light ..........12 jumping a disabled battery ..197 Accessory delay ......71 maintenance-free ....227 AdvanceTrac ......159 replacement, specifications ...251 Air bag supplemental restraint servicing ........227 system ......131–132, 136 BeltMinder .........127 and child safety seats ....133 description ......132, 136 Brakes ........154...
Page 268 Index in rear seat ......143 Getting the service you need .........204 Cleaning your vehicle Ordering additional owner’s engine compartment ....214 literature .........211 exterior ........218 The Dispute Settlement instrument panel ....217 Board ........207 interior ......217–218 Utilizing the plastic parts ......216 Mediation/Arbitration washing ........213 Program ........209 waxing ........213...
Page 269 Index fail-safe coolant ......234 octane rating ....239, 256 idle speed control ....227 quality ........239 lubrication running out of fuel ....240 specifications ....254, 256 safety information relating refill capacities ......252 to automotive fuels ....236 service points ....222–223 Fuses ........183–184 starting after a collision ..182 Engine block heater ....153 Engine fan .........235 Garage door opener ....82...
Page 270 Index bulb specifications ....64 Keys ......103, 111–113 daytime running lights .....59 key in ignition chime ....15 flash to pass ......60 positions of the ignition ..150 high beam .........15 removing from the ignition ..174 replacing bulbs ......65 valet key ........103 turning on and off ....58 warning chime ......15 Heating Lamps...
Page 271 Index transmission PRNDL indicator ........13 turn signal indicator ....14 Panic alarm feature, remote entry system ......108 Load limits .........175 Parking brake ......156 GAWR ........175 GVWR ........175 Parts (see Motorcraft parts) ..251 trailer towing ......175 Power distribution box (see Fuses) .......187, 190 Locks autolock ........110 Power door locks ....103, 110...
Page 272 Index Safety defects, reporting ..212 tilting ........14, 69 Safety restraints ..120, 122–126 belt minder ......127 cleaning the safety belts ..130 Tachometer .........18 extension assembly ....130 for adults ......122–125 Tires ......192, 246–248 for children ......139 changing ......192–193 warning light and checking the pressure ....248 chime ......12, 15, 127 replacing ........250 rotating ........248...
Page 273 Index Vehicle loading ......175 Windows power .........70 Ventilating your vehicle ...154 Windshield washer fluid and wipers checking and cleaning ....68 Warning chimes ......15 operation ........67 replacing wiper blades .....68 Warning lights (see Lights) ..10 Wrecker towing ......203 Water, Driving through .....174...

This manual is also suitable for:

2002 continental

Lincoln LS 2002 Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Quick Links

Related Manuals for Lincoln LS 2002

Summary of Contents for Lincoln LS 2002

This manual is also suitable for:

Table of Contents
