Page 2: Table Of Contents
Table of Contents Introduction Congratulations Safety and environment protection Symbol glossary Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette AM/FM stereo cassette (CD changer compatible) CD changer Climate Controls Electronic automatic temperature control Lights Headlamps Bulb replacement Driver Controls Steering wheel adjustment Power windows...
Page 3 Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Traction control/AdvanceTrac Transmission operation Vehicle loading Trailer towing Recreational towing Roadside Emergencies Hazard flasher switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance The dispute settlement board Utilizing the mediation/arbitration...
Page 4 Table of Contents Maintenance and Specifications Hood Engine compartment Engine oil Battery Fuel information Air filter(s) Refill capacities Lubricant specifications Engine data Vehicle dimensions Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 5: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 6: Safety And Environment Protection
Introduction Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside emergencies chapter.
Page 7 Introduction BREAKING-IN YOUR VEHICLE There are no particular guidelines for breaking-in your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in. SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper...
Page 8 Introduction MIDDLE EAST/NORTH AFRICA VEHICLE SPECIFIC INFORMATION For your particular global region, your vehicle may be equipped with features and options that are different from the ones that are described in this Owner Guide; therefore, a supplement has been supplied that complements this book.
Page 9: Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 10 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 11: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES CHECK FUEL TRUNK AJAR DOOR AJAR WASHER CIRCLE FUEL ECON LTR/100km TRAC OFF AIR SUSPENSION SLOWLY DIST TO EMPTY AVG SPEED TRIP A B O/D OFF TRAC ACTIVE km MILES/GAL SPEED CONTROL COMPASS < FILL ON LEFT km/h...
Page 12 Instrument Cluster These temporary malfunctions can be corrected by filling the fuel tank with high quality fuel of the recommended octane and/or properly installing and securely tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the light should turn off.
Page 13 Instrument Cluster Brake system warning Illuminates if the parking brake is engaged. Also momentarily BRAKE illuminates at start up to ensure the circuit is functional. If the brake warning lamp does not illuminate at these times, or illuminates after releasing the parking brake, seek service immediately.
Page 14 Instrument Cluster Engine oil pressure Illuminates when the oil pressure falls below the normal range. Check the oil level and add oil if needed. Refer to Engine oil in the Maintenance and specifications chapter. Engine coolant temperature Illuminates when the engine coolant temperature is high.
Page 15: Air Suspension
Instrument Cluster Trac off Illuminates when the Traction TRUNK AJAR DOOR AJAR Control system has been disabled CIRCLE (by the driver or as a result of a TRAC OFF AIR SUSPENSION SLOWLY system failure). For more information, refer to the Driving chapter.
Page 16 Instrument Cluster O/D off Illuminates when the overdrive TRUNK AJAR DOOR AJAR function has been turned OFF using CIRCLE the Transmission Control Switch TRAC OFF AIR SUSPENSION SLOWLY (TCS). If the light does not come on or the light flashes steadily, have your vehicle serviced as soon as O/D OFF TRAC ACTIVE...
Page 17 Instrument Cluster Trunk ajar Illuminates when the trunk is not TRUNK AJAR DOOR AJAR completely closed. This light will CIRCLE flash five times and sound a tone for TRAC OFF AIR SUSPENSION SLOWLY one second, then the light remains O/D OFF TRAC ACTIVE SPEED CONTROL COMPASS...
Page 18: Gauges
Instrument Cluster GAUGES CHECK FUEL TRUNK AJAR DOOR AJAR WASHER CIRCLE FUEL ECON LTR/100km TRAC OFF AIR SUSPENSION SLOWLY DIST TO EMPTY AVG SPEED TRIP A B O/D OFF TRAC ACTIVE km MILES/GAL SPEED CONTROL COMPASS < FILL ON LEFT km/h SERVICE ENGINE...
Page 19: Fuel Gauge
Instrument Cluster Fuel gauge Displays approximately how much < FILL ON fuel is in the fuel tank. The fuel LEFT gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the reserve fuel.
Page 20: Entertainment Systems
Entertainment Systems AM/FM STEREO CASSETTE VOL - PUSH ON BASS TREB FADE TAPE SEEK SIDE 1 - 2 SCAN TUNE Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened.
Page 21 Entertainment Systems If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output.
Page 22 Entertainment Systems Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. FADE Seek function The seek function control works in radio mode. Seek function in radio mode • Press to find the next listenable station down the frequency band.
Page 23 Entertainment Systems AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the AM control to select from AM selections, and press the FM control to select from FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play.
Page 24 Entertainment Systems • to decrease hours and • to increase hours. To set the minute, press and hold the CLK control and press: TAPE • to decrease minutes and • to increase minutes. The CLK control will allow you to switch between media display mode (radio station, stereo information, etc.) and clock display mode (time).
Page 25 Entertainment Systems Tape select • To enter tape mode while in radio mode, press the TAPE AMS control. TAPE Automatic Music Search The Automatic Music Search feature allows you to quickly locate the beginning of the tape selection being played or to skip to the next selection.
Page 26 Entertainment Systems Tape direction select Press SIDE and 1–2 at the same SIDE 1 - 2 time to play the alternate side of a tape. Eject function Press the control to stop and eject a tape. Dolby noise reduction Dolby noise reduction operates only in tape mode.
Page 27: Am/Fm Stereo Cassette (Cd Changer Compatible)
Entertainment Systems PREMIUM AM/FM STEREO/CASSETTE (CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE TUNE SEEK SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF ALPINE AUDIO SYSTEM WITH AM/FM STEREO CASSETTE (CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE SEEK TUNE...
Page 28 Entertainment Systems Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated. During the operation of any selected mode, lighting for the individual function controls will either illuminate or turn off. Those controls which have a function for the specific mode of operation selected will be lit, while the controls which have no function for that mode will be turned off.
Page 29 Entertainment Systems With the radio on, press and hold the volume control for five seconds, until the display reads SPEED VOL, then press: PUSH ON • to increase volume compensation • to decrease or shut off the volume compensation Bass adjust The bass adjust control allows you to increase or decrease the audio BASS...
Page 30 Entertainment Systems Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Press the BAL control. Use the SEL FADE control to adjust the sound between the speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 31 Entertainment Systems Seek function for CD changer • Press to seek to the previous SEEK track of the current disc. If a selection has been playing for three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 32 Entertainment Systems AM/FM select in radio mode The AM/FM control allows you to select AM or FM frequency bands. Press the control to toggle between AM, FM1 or FM2 memory preset stations. AM/FM select in tape mode Press this control to stop tape play and begin radio play. AM/FM select in CD mode Press this control to stop CD play and begin radio play.
Page 33 Entertainment Systems If there are less than six strong stations available on the frequency band, the remaining memory preset controls will all store the last strong station available. To deactivate autoset and return to your audio system’s manually set memory stations, press the control again. Setting the clock with radio data system (RDS) feature (if equipped) This feature applies to vehicles not equipped with a separate, instrument...
Page 34 Entertainment Systems Rewind The rewind control works in tape and CD modes. • In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. • In CD mode, pressing the REW control for less than three seconds results in slow rewind.
Page 35 Entertainment Systems Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. The Dolby noise reduction system is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 36 Entertainment Systems • Use SEEK, TUNE or radio presets 1 through 6 to select a phone number previously programmed in the phone. • Press the phone/mute control again to send and end calls. This control will mute the playing media even if your vehicle is not equipped with a factory-installed cellular phone.
Page 37 Entertainment Systems Press the DSP control until one of the following appears: • ALL SEATS • DRIVER SEAT • REAR SEATS Use the SELECT control to change the equalization to the desired mode. Radio data system (RDS) feature This feature allows your audio system to receive station identification or program type from RDS-equipped FM radio stations.
Page 38 Entertainment Systems • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data). Traffic information is not available in most U.S. markets. Program type •...
Page 39: Cd Changer
Entertainment Systems • Use the SEL control to select TYPE (the display shows the program type), NAME (the display shows the call letters of the station) or NONE. CD CHANGER (IF EQUIPPED) Your CD changer is located in the trunk. 1.
Page 40 Entertainment Systems 4. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine. If this happens, reinsert the disc holder back into the magazine.
Page 41 Entertainment Systems Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used. The CD magazine may be inserted or ejected with the radio power off. Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur.
Page 42 Entertainment Systems Do not insert any promotional (odd shaped or sized) discs, or discs with removable labels into the CD player as jamming may occur. CLEANING CASSETTE PLAYER (IF EQUIPPED) Clean the tape player head with a cassette cleaning cartridge after 10 to 12 hours of play in order to maintain the best sound and operation.
Page 43 Entertainment Systems RADIO RECEPTION FACTORS Three factors can affect radio reception: • Distance/strength. The further an FM signal travels, the weaker it is. The listenable range of the average FM station is approximately 40 km (24 miles). This range can be affected by “signal modulation.” Signal modulation is a process radio stations use to increase their strength/volume relative to other stations.
Page 44: Climate Controls
Climate Controls ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM The EATC system will maintain a ˚ FRONT selected temperature and automatically control airflow. You REAR AUTO can override automatic operation AUTO with any of the override controls, the fan speed control or the steering wheel controls (if equipped).
Page 45 Climate Controls If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary. Temperature selection The display window indicates the ˚ selected temperature, function (AUTO or one of the override controls) and manual control of fan AUTO...
Page 46 Climate Controls Fan speed ( When AUTO is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, press the fan control or the steering wheel fan speed control (if equipped) to AUTO cancel automatic fan speed operation.
Page 47 Climate Controls • (Panel)-Distributes outside air through the instrument panel registers. However, the air cannot be cooled below the outside temperature because the air conditioning does not operate in this mode. • (Panel and floor) -Distributes outside air through the instrument panel registers and the floor ducts.
Page 48 Climate Controls If a manual override function is selected while the outside temperature is displayed, the new function will be displayed for four seconds after it is changed, then the outside temperature will return to the window along with the override selection. The outside temperature reading is most accurate when the vehicle is moving.
Page 49 Climate Controls • If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle.
Page 50: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Your vehicle’s headlamp system is equipped with a feature that will not dim the instrument panel lighting when the headlamps are on in the daytime.
Page 51 Lights Always remember to turn on your headlamps at dusk or during inclement weather. The Daytime Running Light (DRL) System does not activate your tail lamps and generally may not provide adequate lighting during these conditions. Failure to activate your headlamps under these conditions may result in a collision.
Page 52 Lights AIMING THE HEADLAMPS Your vehicle is equipped with a Vehicle Headlamp Aim Device (VHAD) on each headlamp. Each headlamp may be properly aimed in the vertical (up/down) and the horizontal (left/right) directions using your VHAD system. The headlamps on your vehicle are properly aimed at the assembly plant.
Page 53 Lights Turning the horizontal adjusting screw in the direction of the arrow changes the horizontal aim as shown. Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove protective cover, then locate the bubble level and the vertical adjustment screw.
Page 54: Bulb Replacement
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. INTERIOR LAMPS Rear courtesy/reading lamps The courtesy lamp lights when: • any door is opened. • any of the remote entry controls are pressed and the ignition is OFF.
Page 55 Lights Do not remove lamp bulbs unless they will be replaced immediately. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect performance. Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.”...
Page 56 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Open the hood. 3. Twist the plastic knobs and remove the protective cover from the back of the headlamps. Lift the cover and pull towards the windshield. 4.
Page 57 Lights 6. Remove the bulb retaining ring by rotating it counterclockwise (when viewed from the rear) to free it from the bulb socket, and slide the ring off the plastic base. Keep the ring to retain the new bulb. 7. Without turning, remove the old bulb from the lamp assembly by gently pulling it straight back out of the lamp assembly.
Page 58 Lights Replacing front parking lamp/turn signal lamp bulbs 1. Make sure the headlamp control is in the OFF position. 2. Open the hood. 3. Twist the plastic knobs and remove the protective cover from the back of the headlamps. Lift the cover and pull towards the windshield. 4.
Page 59 Lights Replacing high-mount brakelamp bulbs 1. Remove the lamp cover by prying 2. Rotate the bulb socket counterclockwise and remove from lamp assembly. 3. Carefully pull the bulb straight out of socket and push in the new bulb. 4. To complete installation, follow the removal procedure in reverse order.
Page 60: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 61: Steering Wheel Adjustment
Driver Controls Changing the wiper blades To make changing the wiper blades easy, turn the ignition to ACC, then turn the wipers on. When the wipers reach the vertical position, turn the ignition to LOCK. To replace the wiper blades: 1.
Page 62 Driver Controls Never adjust the steering wheel when the vehicle is moving. ILLUMINATED VISOR MIRROR (IF EQUIPPED) To turn on the visor mirror lamps, lift the mirror cover. CLOCK (IF EQUIPPED) If your vehicle is not equipped with an instrument panel mounted clock, refer to Setting the Clock section in the Entertainment chapter.
Page 63: Power Windows
Driver Controls AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not BASS TREB FADE PUSH ON hang any type of accessory or TAPE SEEK TUNE SCAN AUTO MUTE accessory bracket from the plug. SIDE 1 2 COMP SHUFF Improper use of the power...
Page 64: Mirrors
Driver Controls MIRRORS Automatic dimming inside rear view mirror (if equipped) Your vehicle is equipped with an inside rear view mirror which has an auto-dimming function (available as an option on the outside driver’s side mirror). The electronic day/night mirror will change from the normal state to the non-glare state when bright lights (glare) reach the mirror.
Page 65 Driver Controls 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to lock mirrors in place. Heated outside mirrors (if equipped) Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 66 Driver Controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever into N (Neutral) with the speed control on.
Page 67 Driver Controls If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed. This is normal. Speed control cannot reduce the vehicle speed if it increases above the set speed on a downhill. If your vehicle speed is faster than the set speed while driving on a downhill, you may want to shift to the next lower gear or apply the brakes to reduce your vehicle speed.
Page 68 Driver Controls • Depress the brake pedal. When the desired vehicle speed is reached, press SET ACCEL. ACCEL COAST To disengage speed control • Depress the brake pedal. Disengaging the speed control will not erase the previously programmed set speed. Pressing OFF will erase the previously programmed set speed.
Page 69 Driver Controls Indicator light Indicator message This message is displayed in the SPEED CONTROL Message Center when either the SET ACCEL or RES/RESUME controls are pressed. It turns off when the speed control OFF is pressed, the brake is applied or the ignition is turned to the OFF position. STEERING WHEEL CONTROLS (IF EQUIPPED) These controls allow you to operate some radio and climate control features.
Page 70 Driver Controls Climate control features • Press TEMP up or down to adjust temperature. • Press FAN up or down to adjust fan speed. MOON ROOF (IF EQUIPPED) To open the moon roof: • Press and release the control. • For one-touch operation, press and release the rear portion of the control;...
Page 71 Driver Controls Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage. 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default codes by holding down the two outside buttons until the red light begins to flash after 20 seconds.
Page 72 Driver Controls Operating the HomeLink Universal Transceiver Once programmed, the HomeLink Universal Transceiver can be used in place of hand-held transmitters. To operate, simply press and release the appropriate HomeLink button (the red light will illuminate, indicating the signal is being transmitted).
Page 73 Driver Controls The 2nd or 3rd press from step 3 will activate the door. The HomeLink Universal Transceiver has now been trained to the receiver. The remaining two buttons may now be programmed if this has not previously been done. Erasing HomeLink buttons Individual buttons cannot be erased, however, to erase the three...
Page 74 • Dock the wireless phone in the docking station located in the center console armrest (once the phone is docked, the armrest can be closed) • Activate your Vehicle Communication System with the Lincoln Response Center by pressing the “i” Button...
Page 75 2. AUTOMATIC AIR BAG NOTIFICATION — If the air bag deploys, the Vehicle Communication system automatically places a call to the Lincoln Response Center and a representative will dispatch help to your location immediately if requested. If the specialist is unable to reach you, the emergency service provider will be contacted and dispatched to your location.
Page 76 • Press the “ i” Button and when voice communication is established with the Lincoln Response Center, indicate that you are a new customer and the specialist will introduce you to the features. The purpose of this call is to verify that your Vehicle Communication System is active and functioning properly.
Page 77 Please use this technology responsibly. Due to the specialized Lincoln software contained within the phone, your local Sprint PCS store is unable to provide service or replacement units. Issues or questions about equipment including the wireless phone should...
Page 78: Message Center
Driver Controls Phone accessories can be purchased at Sprint PCS stores. Billing or services issues should be directed to Sprint PCS at 1–866–PCS-AUTO (1–866–727–2886). Select “2” for Client Services. ELECTRONIC MESSAGE CENTER The electronic message center only works when the ignition is in the ON position.
Page 79 Driver Controls Selectable features Select Each press of the SELECT control WASHER FUEL ECON will select a different feature as LTR/100km DIST TO EMPTY follows: AVG SPEED • FUEL ECON TRIP A B • DIST TO EMPTY • AVG SPEED km MILES/GAL •...
Page 80 Driver Controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. 2. Locate the compass module and the calibration button mounted on the center rear view mirror post. 3.
Page 81 Driver Controls 3. Press and hold the CALIBRATION TRUNK AJAR DOOR AJAR BUTTON for 2 to 4 seconds until CIRCLE CIRCLE SLOWLY is displayed on the TRAC OFF AIR SUSPENSION SLOWLY message center. 4. Release pressure from the button. O/D OFF TRAC ACTIVE 5.
Page 82 Driver Controls You may notice gradual improvement in fuel economy over the course of your vehicle’s break-in period (approximately 1 600 kilometers [1 000 miles]). 1. Set the speed control. Refer to Speed control in this chapter. 2. Select FUEL ECON FUEL ECON DIST TO EMPTY AVG SPEED...
Page 83 Driver Controls The DTE function will flash for 5 seconds and sound a tone for 1 second when you have approximately: • 80 km (50 miles) left before you run out of fuel • 40 km (25 miles) • 16 km (10 miles) If “CO”...
Page 84 Driver Controls OVERDRIVE CONTROL Activating overdrive (Overdrive) is the normal drive position for the best fuel economy. The overdrive function allows automatic upshifts and downshifts through all available gears. Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of the gearshift lever.
Page 85 Driver Controls FUEL DOOR RELEASE Your vehicle is equipped with a locking fuel door. To open the door, press the control located on the door. Fuel filler door override release If the remote release is inoperative, open the trunk, then pull the override release handle located inside the trunk to open the fuel filler door.
Page 86 Driver Controls • To program position two, repeat the previous procedure using control 2. • To program position three, repeat the previous procedure but press controls 1 and 2 simultaneously. A position can only be recalled when the transmission gearshift is in Park.
Page 87 Driver Controls Radio/climate controls lockout The rear radio/climate control feature can be locked out by pressing the 3 and the 5 buttons on the radio simultaneously while the radio is on. To enable the rear radio/climate controls, press the 3 and the 5 buttons again.
Page 88 Driver Controls Remote seat adjustment lockout The window lockout control, located WINDOW LOCK on the drivers door, will also lockout the remote seat adjustment. To lock out the remote seat adjustment feature, press the right side of the control. Press the left side to restore the remote seat adjustment control. POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the...
Page 89: Locks And Security
Locks and Security KEYS The vehicle is equipped with a master key and valet key lock system. The master key will access doors, trunk, glove box, ignition and remote trunk release. The valet key (marked “valet”) will access doors and ignition only.
Page 90 Locks and Security INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in the event they become locked inside the luggage compartment. Adults are advised to familiarize themselves with the operation and location of the release handle.
Page 91: Anti-Theft System
Locks and Security REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 92 Locks and Security Deactivating/activating the horn chirp feature The horn chirp feature can be turned on/off through the following procedure: Complete steps 1-7 within 30 seconds or you must repeat the procedure. Wait 30 seconds before repeating the procedure. 1. Turn ignition key to ON. 2.
Page 93 Locks and Security The remote entry system allows you to open the trunk while the ignition is in any position. However, if the ignition is in the ON position and the gearshift is in D (Drive), the trunk will only open if the vehicle is moving 5 km/h (3 mph) or slower.
Page 94 Locks and Security Replacing lost transmitters Take all your vehicle’s transmitters to your dealer if service is required. If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: •...
Page 95 Locks and Security Autolock The autolock feature will lock all of the vehicle doors when: • all doors are closed • the engine is running and • you shift into any gear putting the vehicle in motion The autolock feature repeats when: •...
Page 96 Locks and Security Press the control once to unlock the driver’s door and move the memory features to the corresponding memory position, just as if you had pressed the memory control in the vehicle. • transmitter #1 will recall memory feature position one.
Page 97 Locks and Security KEYLESS ENTRY SYSTEM (IF EQUIPPED) With the keyless entry keypad, you can: 7 8 9 0 • lock or unlock the vehicle doors without using the key Your vehicle has a factory-set 5–digit code that operates the keyless entry system.
Page 98 Locks and Security You can program up to three personal codes to unlock your vehicle. These codes do not replace the permanent code that the dealership gave you. Erasing personal code To erase all of the personal entry codes programmed to a vehicle: 1.
Page 99 Locks and Security Locking doors with the keyless entry system It is not necessary to enter the factory-set code prior to locking all doors. To lock the doors: • Press 7/8 and 9/0 at the same time. 7 8 9 0 SECURILOCK PASSIVE ANTI-THEFT SYSTEM SecuriLock...
Page 100 If a problem occurs, turn ignition OFF and restart the engine with all other objects on the key ring held away from the ignition key. Check to make sure the coded key is an approved Lincoln coded key.
Page 101 Locks and Security If your keys are lost or stolen you will need to do the following: • Use your spare key to start the vehicle, or • Have your vehicle towed to a dealership or locksmith. The key codes will need to be erased from your vehicle and new key codes will need to be re-coded.
Page 102 Locks and Security Please read and understand the entire procedure before you begin. 1. Insert the first previously programmed coded key into the ignition and turn the ignition from 3 (OFF) to 4 (ON) (maintain ignition in 4 (ON) for at least one second). 2.
Page 103: Seating And Safety Restraints
Seating and Safety Restraints SEATING Head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 104 Seating and Safety Restraints To adjust the front seatback using the manual recliner: • Lift and hold the handle located on the side of the seat. • Lean against the seatback to adjust it to your desired position. You can recline the seat back or bring it forward.
Page 105 Seating and Safety Restraints Press the control to recline the seatback forward or backward. Press to move the seat forward or backward. Press to move the front portion of the seat cushion up or down. Press to move the rear portion of the seat cushion up or down.
Page 106 Seating and Safety Restraints Heated seats (if equipped) The heated seat controls are located on the door trim panel. To operate the heated seats: • Slide the control to BACK to heat BACK the seatback only. • Slide the control to BOTH to heat the seatback and the seat cushion.
Page 107: Safety Restraints
Seating and Safety Restraints Memory seats/rearview mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, outside rearview mirrors, and adjustable pedals to three programmable positions. The memory seat control is located on the driver door. • To program position one, move the driver seat to the desired position using the seat controls.
Page 108 Seating and Safety Restraints • Front crash severity sensor. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. • The electrical wiring for the air bags, crash sensor(s), safety belt pretensioners, front safety belt usage sensors, driver seat position sensor, passenger occupant classification sensor (if equipped), and indicator lights.
Page 109 If your vehicle is equipped with this feature, there will be a label located under the front passenger seat which is marked “OCS”. Alternatively, you may take your vehicle to any Ford or Lincoln Mercury dealer for assistance. For air bags to do their job they must inflate with great force, and this force can pose a potentially deadly risk to occupants that are very close to the air bag when it begins to inflate.
Page 110 Seating and Safety Restraints Front safety belt usage sensors The front safety belt usage sensors detect whether or not the driver and front outboard passenger safety belts are fastened. This information allows your Personal safety system to tailor the air bag deployment and safety belt pretensioner activation depending upon safety belt usage.
Page 111 Seating and Safety Restraints If any of these things happen, even intermittently, have the Personal safety system serviced at your dealership or by a qualified technician immediately. Unless serviced, the system may not function properly in the event of a collision. Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 112 Seating and Safety Restraints Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair. 1) Use the shoulder belt on the outside shoulder only.
Page 113 Seating and Safety Restraints Vehicle sensitive mode The vehicle sensitive mode is the normal retractor mode, allowing free shoulder belt length adjustment to your movements and locking in response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 8 km/h (5 mph) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers.
Page 114 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is extracted. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 115 Seating and Safety Restraints Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions. Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder.
Page 116 Seating and Safety Restraints The lap belt does not adjust automatically. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 117 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition illuminates 1-2 minutes and the switch is turned to the ON warning chime sounds 4-8 seconds. position...
Page 118 Seating and Safety Restraints If... Then... The driver’s safety belt is The BeltMinder feature will not buckled before the ignition activate. switch is turned to the ON position... The purpose of the BeltMinder is to remind occasional wearers to wear safety belts all of the time.
Page 119 Seating and Safety Restraints Reasons given... Consider... “Belts wrinkle my clothes” Possibly, but a serious crash can do much more than wrinkle your clothes, particularly if you are unbelted. “The people I’m with don’t Set the example, teen deaths occur 4 wear belts”...
Page 120 Seating and Safety Restraints • the ignition switch is in the OFF position • all vehicle doors are closed • the driver’s safety belt is unbuckled • the parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure.) To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 121 Seating and Safety Restraints Safety belt extension assembly If the safety belt is too short when fully extended, there is a 20 cm (8 inch) safety belt extension assembly that can be added (part number 611C22). This assembly can be obtained from your dealer at no cost. Use only extensions manufactured by the same supplier as the safety belt.
Page 122: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) CHECK TRAC BASS TREB FADE PUSH ON < FILL ON TAPE LEFT km/h SERVICE ENGINE SEEK TUNE SCAN AUTO SOON MUTE SIDE 1 2 COMP SHUFF PANEL MIST ACCEL SELECT RESET FRONT REAR...
Page 123 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to occupants in the center front seating position.
Page 124 Seating and Safety Restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 125 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 126 Seating and Safety Restraints • a readiness light and tone. • diagnostic module. • and the electrical wiring which connects the components. The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors.
Page 127 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 128 Seating and Safety Restraints The air bag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation. The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system.
Page 129: Child Restraints
Seating and Safety Restraints • The readiness light will not illuminate immediately after ignition is turned on. • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately.
Page 130 Seating and Safety Restraints Children and safety belts If the child is the proper size, restrain the child in a safety seat. Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear safety belts. Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle.
Page 131 Seating and Safety Restraints Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 132 Seating and Safety Restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 133 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 134 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 135 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 136 Seating and Safety Restraints 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat.
Page 137: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 138 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 139: Starting The Engine
Driving 5. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely. This condition may occur when: •...
Page 140 Driving 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts. The key will return to 4 (ON). 2. If the temperature is above –12° C (10° F) and the engine does not start within five seconds on the first try, turn the key to OFF, wait 10 seconds and try again.
Page 141: Brakes
Driving If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes. These fumes are harmful and could kill you. Have the exhaust and body ventilation systems checked whenever: •...
Page 142 Driving Anti-lock brake system (ABS) On vehicles equipped with an anti-lock braking system (ABS), a noise from the hydraulic pump motor and pulsation in the pedal may be observed during ABS braking events. Pedal pulsation coupled with noise while braking under panic conditions or on loose gravel, bumps, wet or snowy roads is normal and indicates proper functioning of the vehicle’s anti-lock brake system.
Page 143 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal BRAKE...
Page 144: Traction Control/Advancetrac
Driving Your vehicle has an automatic parking brake release. To release the parking brake: 1. Turn the ignition to the ON position. 2. Press the brake pedal. 3. Move the gearshift from the P (Park) position to one of the forward gears (the parking brake will not release automatically when you shift into reverse).
Page 145 Driving The Traction Control system will allow your vehicle to make better use of available traction on slippery surfaces. The system is a driver aid which makes your vehicle easier to handle primarily on snow and ice covered roads. During Traction Control operation you may hear an electric motor type of sound coming from the engine compartment and the engine will not “rev-up”...
Page 146: Air Suspension System
Driving • high crosswinds • wheels out of alignment • loose or worn suspension components Speed sensitive steering The steering in your vehicle is speed sensitive. At high speeds, steering assist will decrease to improve steering feel. At lower speeds, maneuverability will be increased.
Page 147: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION (IF EQUIPPED) Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless the brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1.
Page 148 Driving Driving with a 4–speed automatic transmission Understanding gearshift positions To put your vehicle in gear, start the engine, depress the brake pedal, then move gearshift lever out of P (Park). Hold the brake pedal down while you move the gearshift lever from P (Park) to another position.
Page 149 Driving Overdrive The normal driving position for the best fuel economy. Transmission operates in gears one through four. Overdrive can be deactivated by pressing the transmission control switch on the gearshift lever. ON/OFF The transmission control indicator TRUNK AJAR DOOR AJAR light (TCIL) will illuminate on the CIRCLE instrument cluster.
Page 150 Driving 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide additional engine braking on downgrades. 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second) or to Overdrive.
Page 151: Vehicle Loading
Driving If driving through deep or standing water is unavoidable, proceed very slowly. Never drive through water that is higher than the bottom of the hubs (for trucks) or the bottom of the wheel rims (for cars). Once through the water, always try the brakes. Wet brakes do not stop the vehicle as effectively as dry brakes.
Page 152: Trailer Towing
Driving engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle. • Maximum Trailer Weight: Maximum weight of a trailer the loaded vehicle (including occupants and cargo) is permitted to tow. It is determined by subtracting the weight of the loaded trailer towing vehicle from the GCWR for the towing vehicle.
Page 153 Driving Towing a trailer places an additional load on your vehicle’s engine, transmission, brakes, tires and suspension. Inspect these components carefully after towing. Your loaded trailer should weigh no more than 907 kg (2 000 lbs.). Do not exceed the GVWR or the GAWR specified on the certification label.
Page 154 Driving Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system. Your vehicle may not have enough braking power and your chances of having a collision greatly increase. The braking system of the tow vehicle is rated for operation at the GVWR not GCWR.
Page 155: Recreational Towing
Driving • If you are driving down a long or steep hill, shift to a lower gear. Do not apply the brakes continuously, as they may overheat and become less effective. • The trailer tongue weight should be 10% of the loaded trailer weight. •...
Page 156 Driving An example of recreational towing is towing your vehicle behind a motorhome. The following recreational towing guidelines are designed to ensure that your transmission is not damaged. • Place the transmission in N (Neutral). • Maximum speed is 56 km/h (35 mph). •...
Page 157: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Roadside Assistance book in the glove compartment.
Page 158: Hazard Flasher Switch
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Page 159: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located on a bracket inside of the luggage compartment. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 160 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 161 Roadside Emergencies RELAY The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Lighting Control Module (LCM), Left-Hand Low Beam Headlamp EATC Blower Motor Lighting Control Module (LCM), Right-Hand Low Beam Headlamp 7.5A Instrument Cluster 7.5A Lighting Control Module (LCM), Instrument Panel Light...
Page 162 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Lighting Control Module (LCM), Multi-Function Switch, Hi Beam Headlamps Restraint Control Module (RCM), Air Bags — Not Used Instrument Cluster, Anti-Theft, Ignition Switch, Ignition Coils Anti-Lock Brake Module, Traction Control Switch 7.5A Transmission Control Switch,...
Page 163 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Multi-Function Switch, High Mounted Stop Lamps, Stop Lamps Datalink Connector, I/P Cigar Lighter, Reardoor Cigar Lighters (Long Wheel Base Only) Front Radio Control Unit Lighting Control Module (LCM), Courtesy/Demand Lamps Digital Transmission Range (DTR) Sensor, Starter Relay Coil...
Page 164 Roadside Emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. Always replace the cover to the power distribution box before reconnecting the battery or refilling fluid reservoirs If the battery has been disconnected and reconnected, refer to the...
Page 165 Roadside Emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 50A** Ignition Switch 40A** Ignition Switch 50A** Cooling Fan-High Speed 30A** PCM Power Relay 40A** I/P Fuse Panel, Fuses 11, 19, 21, 23, 25, 27, and 32(Long Wheel Base Only) —...
Page 166: Changing Tires
Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 30A* Subwoofer, I/P Fuse Panel, Fuse 15A* Fuel Injectors, PCM 15A* Heated Oxygen Sensors, Transmission Solenoids, EVAP Canaster Vent Solenoid, EGR Vacuum Regulator, EVAP Vapor Management Valve Fuel Pump Charging System 20A* Auxiliary Power Outlet...
Page 167 Roadside Emergencies If you use the temporary spare tire continuously or do not follow these precautions, the tire could fail, causing you to lose control of the vehicle, possibly injuring yourself or others. When driving with the temporary spare tire do not: •...
Page 168 Roadside Emergencies 2. Place gearshift lever in P (Park), turn engine OFF and block the diagonally opposite wheel. 3. Remove the spare tire and the jack. The jack could be located: • A — under the spare tire or • B — in the wheel well On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to...
Page 169 Roadside Emergencies 5. Locate pry off notch (if equipped) and remove the center ornament from the aluminum wheel with the tapered end of the wheel nut wrench that came with your vehicle. Insert and twist the handle, then pry against the wheel. 6.
Page 170: Jump Starting
Roadside Emergencies To lessen risk of personnal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is ONLY meant for changing the tire. •...
Page 171 Roadside Emergencies Do not attempt to push-start your vehicle. Automatic transmissions do not have push-start capability; also, the catalytic conveter may become damaged. Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its adaptive strategy. As a result of this, the transmission may shift firmly.
Page 172 Roadside Emergencies Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 173 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 174 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 175 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 176: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 177: Customer Assistance
Customer Assistance GETTING THE SERVICES YOU NEED At home Ford Motor Company and Ford of Canada have authorized dealerships to service your vehicle. It is preferred that you return to the Ford dealer where your vehicle was purchased when warranty repairs are needed. However, you may also take your vehicle to another Ford Motor Company or Ford of Canada dealership authorized for warranty repairs.
Page 178 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 179 • Protection against covered repair costs after your Bumper-to-Bumper Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 180: The Dispute Settlement Board
What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 181 • a Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 182 Customer Assistance You will receive a letter of explanation if your application does not qualify for Board review. Oral presentations If you would like to make an oral presentation, indicate YES to question 6 on the application. While it is your right to make an oral presentation before the Board, this is not a requirement and the Board will decide the case whether or not an oral presentation is made.
Page 183: Utilizing The Mediation/Arbitration
Customer Assistance UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 184: Ordering Additional Owner's Literature
Customer Assistance If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY WORLDWIDE DIRECT MARKET OPERATIONS 1555 Fairlane Drive Fairlane Business Park #3...
Page 185 Customer Assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 186: Reporting Safety Defects (U.s. Only)
Customer Assistance REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect which could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 187: Cleaning
Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your authorized Ford, Lincoln or Mercury dealer. Always use a clean sponge or carwash mitt with plenty of water for best results. Dry the vehicle with a chamois or soft terry cloth towel in order to eliminate water spotting.
Page 188 Minor scratches or paint damage from road debris may be repaired using the Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), which is available at your authorized Ford, Lincoln or Mercury dealer. This kit contains: • Lacquer Touch-Up Paint (ALBZ-19500–XXXXA) •...
Page 189 Cleaning • Never spray a hot engine with cold water, as damage to the engine block or engine components may occur. • Use caution when using a self-serve power washer (1000psi maximum pressure) to clean the engine, as the high-pressure fluid could penetrate the sealed parts and cause damage.
Page 190 Clean the outside of the windshield or rear window with a non-abrasive cleaner such as Ultra Clear Spray Glass Cleaner (E4AZ-19C507–AA), available from your authorized Ford, Lincoln or Mercury dealer. If after cleaning the glass surface, the water sheets from the glass (e.g., does not bead), then the window is clean.
Page 191 Cleaning CLEANING THE INSTRUMENT PANEL Clean the instrument panel with a damp cloth, then dry with a dry cloth. Avoid cleaners or polish that increase the gloss of the upper portion of the instrument panel. The dull finish in this area helps protect the driver from undesirable windshield reflection.
Page 192: Underbody Preservation
Cleaning CLEANING LEATHER SEATS (IF EQUIPPED) All Ford, Lincoln and Mercury vehicles with leather seating surfaces have a clear, protective coating over the leather. To clean the leather seats, simply use a soft cloth with Deluxe Leather and Vinyl Cleaner (F2AZ-19521–WA). Dry the area with a soft cloth.
Page 193 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 194: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 195: Hood
Maintenance and Specifications Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running. OPENING THE HOOD 1. Inside the vehicle, pull the hood release handle located under the instrument panel. 2.
Page 196: Engine Oil
Maintenance and Specifications 2. Engine oil dipstick 3. Engine oil filler cap 4. Air filter assembly 5. Power steering fluid reservoir 6. Engine coolant reservoir 7. Battery 8. Windshield washer fluid reservoir 9. Automatic transmission fluid dipstick WINDSHIELD WASHER FLUID Checking and adding washer fluid Check the washer fluid whenever you stop for fuel.
Page 197 Maintenance and Specifications 2. Turn the engine off and wait up to 10 minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (Park). 4. Open the hood. Protect yourself from engine heat. 5.
Page 198 Maintenance and Specifications • If required, add engine oil to the engine. Refer to Adding engine oil in this chapter. • Do not overfill the engine with oil. Oil levels above this mark may cause engine DO NOT OVERFILL damage. If the engine is overfilled, some oil must be removed from the engine by a qualified service technician.
Page 199 Maintenance and Specifications Engine oil and filter recommendations Look for this certification trademark. SAE 5W-20 engine oil is recommended. Only use oils “Certified For Gasoline Engines” by the American Petroleum Institute (API). Use Motorcraft or an equivalent oil meeting Ford specification WSS-M2C153–H. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 200: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 201 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 202 Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 203 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 204 Maintenance and Specifications The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. •...
Page 205 Maintenance and Specifications To avoid personal injury, make sure the engine is cool before unscrewing the coolant pressure relief cap. The cooling system is under pressure; steam and hot liquid can come out forcefully when the cap is loosened slightly. 1.
Page 206 Maintenance and Specifications Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 207 Maintenance and Specifications • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage. • Decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage.
Page 208: Fuel Information
Maintenance and Specifications Continued operation will increase the engine temperature: • The symbol will begin to flash. • A tone will sound 5 times. • The engine will completely shut down, causing steering and braking effort to increase. Once the engine temperature cools, the engine can be re-started. Take your vehicle to a service facility as soon as possible to minimize engine damage.
Page 209 Maintenance and Specifications The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible...
Page 210 Maintenance and Specifications • Avoid getting fuel liquid in your eyes. If fuel is splashed in the eyes, remove contact lenses (if worn), flush with water for 15 minutes and seek medical attention. Failure to seek proper medical attention could lead to permanent injury.
Page 211 Maintenance and Specifications When fueling your vehicle: 1. Turn the engine off. 2. Carefully turn the filler cap counterclockwise 1/8 of a turn until it stops. 3. Pull to remove the cap from the fuel filler pipe. 4. To install the cap, align the tabs on the cap with the notches on the filler pipe.
Page 212 Maintenance and Specifications Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Octane recommendations Your vehicle is designed to use “Regular” unleaded gasoline with pump (R+M)/2 octane rating of 87. We do not recommend the use of (R+M)/2 METHOD gasolines labeled as “Regular”...
Page 213 Maintenance and Specifications Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: •...
Page 214 Maintenance and Specifications The advertised capacity is the amount of the indicated capacity and the empty reserve combined. Indicated capacity is the difference in the amount of fuel in a full tank and a tank when the fuel gauge indicates empty.
Page 215 Maintenance and Specifications 5. Follow one of the simple calculations in order to determine fuel economy: Multiply liters used by 100, then divide by total kilometers traveled. Divide total miles traveled by total gallons used. Keep a record for at least one month and record the type of driving (city or highway).
Page 216 Maintenance and Specifications Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy. • Use recommended engine oil. Refer to Lubricant specifications in this chapter. •...
Page 217 Maintenance and Specifications EMISSION CONTROL SYSTEM Your vehicle is equipped with various emission control components and a catalytic converter which will enable your vehicle to comply with applicable exhaust emission standards. To make sure that the catalytic converter and other emission control components continue to work properly: •...
Page 218 Maintenance and Specifications Please consult your Warranty Guide for complete emission warranty information. Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon”...
Page 219 Maintenance and Specifications 3. Turn the engine off. 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range. 5. If the fluid is low, add fluid in small amounts, continuously checking the level until it reaches the range between the MIN and MAX lines.
Page 220 Maintenance and Specifications Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes. Seek medical attention if irritation persists. If taken internally, drink water and induce vomiting. Seek medical attention immediately. If you use DOT 5 or any other brake fluid that is not DOT 3 or DOT 4, you will cause permanent damage to your brakes.
Page 221 Maintenance and Specifications 7. Remove the dipstick and inspect the fluid level. The fluid should be in the designated area for normal operating temperature or ambient temperature. Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the ambient temperature is above 10°C (50°F).
Page 222: Air Filter(S)
Maintenance and Specifications High fluid level Fluid levels above the safe range may result in transmission failure. An overfill condition of transmission fluid may cause shift and/or engagement concerns and/or possible damage. High fluid levels can be caused by an overheating condition. Adjusting automatic transmission fluid levels Before adding any fluid, make sure the correct type is used.
Page 223 Maintenance and Specifications 2. Release the clamps that secure the air filter housing cover. 3. Carefully separate the two halves of the air filter housing. 4. Remove the air filter element from the air filter housing. 5. Wipe the air filter housing and cover clean to remove any dirt or debris and to ensure good sealing.
Page 224 Maintenance and Specifications U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
Page 225 Maintenance and Specifications The temperature grade for this tire is established for a tire that is properly inflated and not overloaded. Excessive speed, underinflation, or excessive loading, either separately or in combination, can cause heat buildup and possible tire failure. SERVICING YOUR TIRES Checking the tire pressure •...
Page 226 Maintenance and Specifications Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification or Tire Label.
Page 227 Maintenance and Specifications Follow these guidelines when using snow tires and chains: • Use only cable type chains offered by Ford as an accessory or equivalent. Using SAE class S or other conventional link type chains may cause damage to the vehicle’s wheel house and/or body. •...
Page 228: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Name Capacity Engine oil (includes Motorcraft SAE 5W-20 filter change) Super Premium Motor 4.7L (5.0 quarts) Brake fluid Motorcraft High Performance DOT 3 Fill to line on reservoir Motor Vehicle Brake Fluid Power steering fluid Motorcraft MERCON Fill to line on reservoir...
Page 229: Lubricant Specifications
Maintenance and Specifications Add the coolant type originally equipped in your vehicle. Rear axles are considered lubricated for life when the vehicle is used for normal service. See your scheduled maintenance guide for Severe Duty requirements. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok rear axle.
Page 230 Maintenance and Specifications Item Ford part Ford part Ford name number specification Hinges, latches, Multi-Purpose XG-4 or ESB-M1C93-B or striker plates, Grease F5AZ-19G209-AA ESR-M1C159-A fuel filler door hinge and seat tracks Lock cylinders Penetrating and Motorcraft XL-1 N/A Lock Lubricant Power steering Motorcraft XT-2-QDX...
Page 231: Engine Data
Maintenance and Specifications ENGINE DATA Engine 4.6L SOHC V8 engine Cubic inches Required fuel 87 octane Firing order 1-3-7-2-6-5-4-8 Spark plug gap 1.3-1.4 mm (0.052-0.056 inch) Ignition system Coil on plug Compression ratio 9.4:1 VEHICLE DIMENSIONS Vehicle dimensions mm (in) (1) Overall length 5 469 (215.3)/5 621 (221.3) (2) Overall width...
Page 232 Maintenance and Specifications...
Page 233 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 234 Maintenance and Specifications 1. World manufacturer identifier 2. Brake type and gross vehicle weight rating (GVWR) 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped).
Page 235: Accessories
FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Lincoln Mercury dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 236 Accessories Comfort and convenience Cargo nets Cargo organizer Electrochromic compass mirror Electrochromic compass mirror with temperature display Engine block heaters HomeLink Remote start system Travel equipment Automatic headlamps with daytime running lights (DRL) Chrome wheel arch molding Daytime running lights (DRL) HomeLink Protection and appearance equipment Carpet floor mats...
Page 237 Accessories For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: • When adding accessories, equipment, passengers and luggage to your vehicle, do not exceed the total weight capacity of the vehicle or of the front or rear axle (GVWR or GAWR as indicated on the Safety compliance certification label).
Page 238: Index
Index Accessory delay ......62 Battery ........199 acid, treating emergencies ..199 Air bag supplemental restraint charging system warning system ........121, 125 light ..........12 and child safety seats ....123 jumping a disabled battery ..169 description ......121, 125 maintenance-free ....199 disposal ........128 replacement, specifications ...226 driver air bag ....123, 126 servicing ........199 indicator light ....12, 125...
Page 239 Index in front seat ......131 Getting the service you in rear seat ......131 need .........176 Ordering additional owner’s Cleaning your vehicle literature .........183 engine compartment ....187 The Dispute Settlement exterior ........191 Board ........179 instrument cluster lens ..190 Utilizing the instrument panel ....190 Mediation/Arbitration interior ........190 Program ........182...
Page 240 Index lubrication octane rating ....211, 230 specifications ....228, 230 quality ........211 refill capacities ......227 running out of fuel ....212 service points ......194 safety information relating to starting after a collision ..157 automotive fuels .....207 Engine block heater ....139 Fuses ........158–159 Engine oil ........195 change oil soon warning, message center .......195...
Page 241 Index bulb specifications ....54 Keys .......88, 98–100 daytime running lights .....49 key in ignition chime ....16 flash to pass ......50 positions of the ignition ..136 high beam ......15, 50 replacing bulbs ......55 turning on and off ....49 warning chime ......16 Lamps autolamp system .......49 HomeLink universal...
Page 242 Index Load limits .........150 Parts (see Motorcraft parts) ..226 GAWR ........150 Passenger Occupant GVWR ........150 Classification Sensor ....108 trailer towing ......150 Pedals (see Power adjustable Locks foot pedals) .........64 autolock ........94 Power distribution box childproof ........88 (see Fuses) .......163 doors ..........88 Power door locks ......88 Lubricant specifications ...228, 230 Power steering ....144–145...
Page 243 Index lap belt ........114 changing ......165–166 Occupant Classification checking the pressure ....224 Sensor ........108 replacing ........225 warning light and rotating ........224 chime ....12, 16, 115–116 snow tires and chains ....225 tire grades .......223 Safety seats for treadwear ........223 children ......129–130 Towing ........151 Seat belts (see Safety recreational towing ....154...
Page 244 Index Windshield washer fluid and wipers Warning chimes ......16 checking and adding fluid ..195 checking and cleaning ....59 Warning lights (see Lights) ..10 operation ........59 Washer fluid ......195 replacing wiper blades .....60 Water, Driving through .....149 Wrecker towing ......175 Windows power .........62...
