Page 2: Table Of Contents
Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette (CD changer compatible) CD changer Climate Controls Electronic automatic temperature control Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors Speed control...
Page 3 Table of Contents Driving Starting Brakes Traction control/AdvanceTrac Air suspension Transmission operation Vehicle loading Trailer towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance Reporting safety defects (U.S. only) Cleaning Cleaning your vehicle Underbody preservation...
Page 4 Table of Contents Accessories Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company. Ford may change the contents without notice and without incurring obligation.
Page 5: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Lincoln. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 6 Introduction Remember to pass on the Owner’s Guide when reselling the vehicle. It is an integral part of the vehicle. Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the engine.
Page 7 Introduction Protecting the environment We must all play our part in protecting the environment. Correct vehicle usage and the authorized disposal of waste cleaning and lubrication materials are significant steps towards this aim. Information in this respect is highlighted in this guide with the tree symbol.
Page 8 Introduction Special instructions For your added safety, your vehicle is fitted with sophisticated electronic controls. By operating other electronic equipment (e.g. mobile telephone without exterior aerial) electromagnetic fields can occur which can cause malfunctions of the vehicle electronics. Therefore you should observe the instructions of the equipment manufacturers.
Page 9 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 10 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 11: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES – km/h TURN ON HEAD LAMPS FILL ON RIGHT RPMx1000 SERVICE 000000.0 ENGINE SOON BRAKE Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions.
Page 12 Instrument Cluster Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity. Under engine misfire conditions, excessive exhaust temperatures could damage the catalytic converter, the fuel system, interior floor coverings or other vehicle components, possibly causing a fire.
Page 13 Instrument Cluster Air bag readiness Illuminates to confirm that the air bags (front or side) are operational. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Safety belt Illuminates to remind you to fasten your safety belts.
Page 14 Instrument Cluster Turn on headlamps (if equipped) Illuminates to remind the driver to TURN ON turn the headlamps on when: HEAD • the daytime running lamps (if LAMPS equipped) are on • the autolamps are off • the autolamp sensor determines it is night time High beams Illuminates when the high beam headlamps are turned on.
Page 15: Gauges
Instrument Cluster GAUGES – km/h TURN ON HEAD LAMPS FILL ON RIGHT RPMx1000 SERVICE 000000.0 ENGINE SOON BRAKE Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H”...
Page 16 Instrument Cluster Fuel gauge Displays approximately how much fuel is in the fuel tank. The fuel gauge may vary slightly when the vehicle is in motion or on a grade. When refueling the vehicle from empty indication, the amount of fuel that can be added will be less than the advertised capacity due to the FILL ON RIGHT...
Page 17: Entertainment Systems
Entertainment Systems PREMIUM AM/FM STEREO/CASSETTE/ALPINE AUDIO SYSTEM (RADIO CONTROLLED CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1-2 COMP SHUFF HIGH LEVEL AUDIO SYSTEM WITH AM/FM STEREO/CASSETTE (RADIO CONTROLLED CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON...
Page 18 Entertainment Systems controls which have a function for the specific mode of operation selected will be lit, while the controls which have no function for that mode will be turned off. Your vehicle is equipped with a delayed accessory feature. This feature enables the audio playing media to continue playing up to 10 minutes after the ignition has been turned off, or until a door is opened.
Page 19 Entertainment Systems With the radio on, press and hold the volume control for five seconds, then press: PUSH ON • to increase volume compensation • to decrease or shut off the volume compensation AM/FM select The AM/FM select control works in radio, tape and CD modes (if equipped).
Page 20 Entertainment Systems Tune adjust in radio mode • Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the TUNE control to move through the frequencies quickly. • Press to move to the next frequency up the band (whether or not a listenable station is located there).
Page 21 Entertainment Systems Seek function for CD changer (if equipped) • Press to seek to the previous track of the current disc. If a selection has been playing for SEEK three seconds or more and you press , the CD changer will replay that selection from the beginning.
Page 22 Entertainment Systems 2. Select a station. Refer to Tune adjust or Seek function for more information on selecting a station. 3. Press and hold a memory preset control until the sound returns, indicating the station is held in memory on the control you selected. SIDE 1-2 COMP SHUFF...
Page 23 Entertainment Systems Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. TREB Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers. Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers.
Page 24 Entertainment Systems Rewind The rewind control works in tape and CD modes (if equipped). • In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the beginning of the tape is reached. • In CD mode, pressing the REW control for less than three seconds results in slow rewind.
Page 25 Entertainment Systems Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation. “Dolby ” and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation. Compression feature Compression adjust brings soft and loud CD passages together for a more consistent listening level.
Page 26 Entertainment Systems Press the RDS control. Use the SEL control to select ON or OFF to enable or disable the feature. Traffic • Press the RDS control until TRAFFIC is displayed. • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting...
Page 27 Entertainment Systems Show • RDS sends information with the FM broadcast: station name, station type, and/or radio text. • With RDS activated, press the RDS control until SHOW is displayed. • Use the SEL control to select (program) TYPE, (station) NAME or NONE (no text displayed).
Page 28: Cd Changer
Entertainment Systems Press the DSP control until one of the following appears: • ALL SEATS • DRIVER SEAT • REAR SEATS Use the SELECT control to change the equalization to the desired mode. CD CHANGER (IF EQUIPPED) Your CD changer is either located in the passenger’s footwell area or in the center console.
Page 29 Entertainment Systems 1. Pull the lever to remove a CD tray from the magazine. 2. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 30 Entertainment Systems 5. Slide the door to the left to close. Use only compact discs containing this mark. The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used.
Page 31 Entertainment Systems CLEANING COMPACT DISCS Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion. CD AND CD CHANGER CARE •...
Page 32 Entertainment Systems RADIO FREQUENCY INFORMATION The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz Not all frequencies are used in a given area.
Page 33: Climate Controls
Climate Controls ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM The EATC system will maintain a ˚ FRONT selected temperature and automatically control airflow. You REAR AUTO can override automatic operation AUTO with any of the override controls, the fan speed control or the steering wheel controls (if equipped).
Page 34 Climate Controls If unusual conditions exist (i.e.-window fogging, etc.), the manual override controls allow you to select airflow locations and the fan control allows you to adjust fan speed as necessary. Temperature selection The display window indicates the ˚ selected temperature, function (AUTO or one of the override controls) and manual control of fan AUTO...
Page 35 Climate Controls Fan speed ( When AUTO is pressed, fan speed is adjusted automatically for existing conditions. You can override fan speed at any time. To control fan speed manually, press the fan control or the steering wheel fan speed control (if equipped) to AUTO cancel automatic fan speed operation.
Page 36 Climate Controls from the instrument panel registers. This mode can also be used to prevent undesirable odors from entering the vehicle. • (Panel) - Distributes outside air through the instrument panel registers. However, the air cannot be cooled below the outside temperature because the air conditioning does not operate in this mode.
Page 37 Climate Controls Displaying outside temperature Press EXT to display the outside air temperature. It will be displayed until EXT is pressed again. If the selected temperature is changed while the outside temperature is displayed, the new temperature will be displayed for AUTO four seconds after it is changed, then the outside temperature will...
Page 38 Climate Controls • If your vehicle has been parked with the windows closed during warm weather conditions, the air conditioner will perform more efficiently in cooling the vehicle if driven for two or three minutes with the windows open. This will force most of the hot, stale air out of the vehicle.
Page 39 The filter is located just in front of the windshield under the cowl vent screen on the passenger side of the vehicle. For more information, or to replace the filter, see your Ford, Lincoln or Mercury Dealer.
Page 40: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps only. Rotate to the second position to also turn on the headlamps. The instrument panel lighting will dim noticeably approximately 15 seconds after the wipers are turned on. The lights will remain in this state until 30 seconds after the wipers are turned off.
Page 41 Lights Flash to pass Pull toward you slightly to activate and release to deactivate. Autolamp control The autolamp system provides light AUTO sensitive automatic on-off control of LAMP the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a preselected period of time after the ignition switch is turned to OFF.
Page 42 Lights (up/down) and the horizontal (left/right) directions using your VHAD system. The headlamps on your vehicle are properly aimed at the assembly plant. A bubble (vertical indicator) that is not centered between the two red lines does not necessarily indicate out-of-aim headlamps. If your vehicle is not positioned on a level surface, the slope will be included in the vertical indication.
Page 43 Lights Turning the horizontal adjusting screw in the direction of the arrow changes the horizontal aim as shown. Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove the protective cover, then locate the bubble level and the vertical adjustment screw.
Page 44: Turn Signal Control
Lights TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. Cornering lamps When the turn signal is used and the headlamps are on, the cornering lamps will light either the right or left side depending on the direction of the turn.
Page 45: Bulb Replacement
Lights If equipped with a moon roof, the map lamps are located on the rearview mirror. Press the control next to the map lamp to illuminate the lamp. Rear courtesy/reading lamps The courtesy lamp lights when: • any door is opened. •...
Page 46 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America and an “E” for Europe to assure lamp performance, light brightness and pattern and safe visibility.
Page 47 Lights Replacing headlamp bulbs To remove the headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Lift the hood and remove the protective cover from the top of the headlamps by lifting up on the rear corners and release the velcro attachments.
Page 48 Lights 6. Remove the bulb retaining ring by rotating it counterclockwise. 7. Remove the old bulb from the lamp assembly by pulling it straight out of the lamp assembly. To install the new bulb: Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 49 Lights 7. Before reinstalling the protective cover, make sure the cover tabs are fully seated under the grille molding. 8. Turn the headlamps on and make sure they work properly. If the headlamp was correctly aligned before you changed the bulb, you should not need to align it again.
Page 50 Lights Replacing license plate lamp bulbs 1. Remove two screws, grommets and the license plate lamp assembly from the trunk lid. 2. Carefully pull the bulb from the socket and push in the new bulb. 3. Install the lamp assembly on trunk lid with two grommets, ensuring the grommets are pushed all the way in to the trunk lid and...
Page 51 Lights 4. Lower the bracket and module tray assembly. 5. Carefully remove the bulb socket from the lamp assembly. 6. Carefully pull the bulb from the socket and push in the new bulb. To install, reverse the removal procedure. Replacing backup lamp bulbs For bulb replacement, see a dealer or qualified technician.
Page 52: Driver Controls
Driver Controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 53: Steering Wheel Adjustment
Driver Controls 1. Pull the wiper arm away from the windshield and lock into the service position. 2. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 54 Driver Controls ILLUMINATED VISOR MIRROR To turn on the visor mirror lamps, lift the mirror cover. Adjust the amount of light by sliding the control. CLOCK Press to increase the time displayed. Press to decrease the time displayed. AUXILIARY POWER POINT The auxiliary power point is located on the inside of the center console armrest.
Page 55 Driver Controls Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug. Improper use of the power outlet can cause damage not covered by your warranty. CENTER CONSOLE (IF EQUIPPED) Your vehicle is equipped with a variety of console features.
Page 56: Power Windows
Driver Controls POSITIVE RETENTION FLOOR MAT Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
Page 57: Mirrors
Driver Controls Express down To make the driver window open fully without holding the window control, press the top portion of the driver window control and release quickly. Press or pull the control to stop window operation. Window lock The window lock feature allows only the driver to operate the power windows.
Page 58 Driver Controls 2. Move the control in the direction you wish to tilt the mirror. MIRRORS 3. Return to the center position to lock mirrors in place. Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 59 Driver Controls With moon roof: Press the control to turn the mirror on or off. The mirror will automatically return to the normal state whenever the vehicle is placed in R (reverse)(when the mirror is on) to ensure a bright clear view when backing up. Do not clean the housing or glass of any mirror with harsh abrasives, fuel or other petroleum-based cleaning products.
Page 60 Driver Controls Compass zone adjustment The compass in the mirror is set in ZONE eight at the factory. It may be necessary to adjust the compass if you live outside zone eight or during a long distance trip. 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map.
Page 61 Driver Controls 2. Press and hold both map light buttons, between 5 and 8 seconds, until the ZONE number appears in the display, then release. The display should show the current zone number. 3. Press either the right or left map light button to change the zone number.
Page 62: Speed Control
Driver Controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). When the ON control is pressed, the message “SPEED CONTROL READY” will appear for 5 seconds in your message center.
Page 63 Driver Controls To set a speed • Press SET ACCEL. For speed control to operate, the speed control must be ON and the vehicle speed must be greater ACCEL than 48 km/h (30 mph). When the SET ACCEL control is COAST pressed, the message “...
Page 64 Driver Controls You can accelerate with the accelerator pedal at any time during speed control usage. Releasing the accelerator pedal will return your vehicle to the previously programmed set speed. To set a lower set speed • Press and hold COAST. Release the control when the desired speed is reached or •...
Page 65 Driver Controls • Press the OFF control. Pressing OFF will erase the previously programmed set speed. When the OFF control is pressed, the message “ SPEED CONTROL OFF” will appear for 5 seconds in your message center. To return to a previously set speed •...
Page 66 Driver Controls Climate control features • Press TEMP up or down to adjust temperature. • Press FAN up or down to adjust fan speed. MOON ROOF (IF EQUIPPED) To open the moon roof: • Press and hold the control forward to raise the moon roof to the vent position (when the glass panel is closed).
Page 67 Driver Controls programmed Homelink Universal Transceiver buttons be erased for security purposes, refer to Programming in this section. Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage. Note: Your vehicle may require the ignition switch to be turned to the ACC position for programming and/or operation of the HomeLink .
Page 68 Driver Controls released. Note: To program the remaining two HomeLink buttons, begin with step 2 in the “Programming” section — do not repeat step 1. If the red light blinks rapidly for two seconds and then turns to a continuous red, proceed with steps 6 through 8 to complete programming of a rolling code equipped device.
Page 69 Driver Controls • Proceed with step 4 in the “Programming” section. Operating the HomeLink Universal Transceiver To operate, simply press and release the appropriate HomeLink button. Activation will now occur for the trained product (garage door, gate operator, security system, entry door lock, or home or office lighting etc.).
Page 70 Driver Controls CELL PHONE USE The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs. However, drivers must not compromise their own or others’ safety when using such equipment. Mobile Communications can enhance personal safety and security when appropriately used, particularly in emergency situations.
Page 71 Center. A response center representative will locate your vehicle and dispatch assistance if needed. Once a connection is made to the Lincoln Response Center, only the response center representative will be able to disconnect the call. Vehicle Communication System will redial for roadside assistance 3 times before showing on the audio display “CALL FAILED”...
Page 72 • Press the “ i” Button and when voice communication is established with the Lincoln Response Center, indicate that you are a new customer and the specialist will introduce you to the features. The purpose of this call is to verify that your Vehicle Communication System is active and functioning properly.
Page 73 Please use this technology responsibly. Due to the specialized Lincoln software contained within the phone, your local Sprint PCS store is unable to provide service or replacement units. Issues or questions about equipment including the wireless phone should be directed to your Lincoln dealer.
Page 74: Message Center
Driver Controls ELECTRONIC MESSAGE CENTER The electronic message center only SYSTEM works when the ignition is in the ON position. The message center tells you about the condition of your vehicle by two methods: MENU SELECT • operator selectable features VEHICLE HANDLING •...
Page 75 Driver Controls • Pressing the unlock control on the appropriate remote MEMORY 1 RECALL transmitter (Memory position 1 or Memory position 2 is identified by the number on the back of the remote transmitter) before opening the driver’s door. • Entering either the Personality 1 or Personality 2 personalized code into the keyless entry keypad before opening the...
Page 76 Driver Controls This option may be useful to temporarily reposition the driver’s seat and mirrors during an extended drive. Operator selectable features System check Pressing this control causes the SYSTEM message center to cycle through the status of each of the systems being monitored.
Page 77 Driver Controls • They will reappear on the display ten minutes from the reset. • They will not reappear until an ignition OFF-ON cycle has been completed. This acts as a reminder that these warning conditions still exist within the vehicle. Door Ajar Cannot be reset Driver’s Door Ajar...
Page 78 Driver Controls TRANSMISSION OVERHEAT. Indicates the transmission is overheating. This warning may appear when towing heavy loads or when driving in a low gear at a high speed for an extended period of time. Stop the vehicle as soon as safely possible, turn off the engine and let it cool.
Page 79 Driver Controls BRAKE LAMP OUT. Displayed when the brake lamps are activated and at least one is burned out. Check the lamps as soon as safely possible and have the burned out lamp replaced. The center high-mount brakelamp is not monitored. CHECK TRACTION CONTROL.
Page 80 Driver Controls TURN ON HEADLAMPS. Displayed when the headlamps are activated by the autolamp sensor. E/M (if equipped) Press this control to switch the odometer and display readouts from metric (kilometers) to English (miles) units. DRIVER ID (if equipped) Press this control and use SELECT DRIVER ID to choose DRIVER 1 or DRIVER 2 when choosing operator selectable...
Page 81 Driver Controls Press the SELECT control to change the settings to ON or OFF. These settings will be saved to the vehicle not individualized settings. Vehicles equipped with the DRIVER ID control, the settings will be saved to DRIVER 1 or DRIVER 2. SELECT Press the SELECT control to change SELECT...
Page 82 Driver Controls RESET Press this control to reset: RESET • warnings • average fuel economy • trip odometers The other selectable features are unaffected by pressing RESET. DTE/ECON • Press the DTE/ECON control DTE ECON once to display approximately how far you can drive before running out of fuel, or the distance to empty (DTE).
Page 83 Driver Controls Checking your highway fuel economy using the electronic message center display The following procedure will allow you to accurately monitor your actual highway fuel economy. Since this procedure requires the vehicle speed control system to be set to highway speeds, it must be run only on suitable roadways where long distance speed control can be safely maintained.
Page 84: Locks And Security
Locks and Security KEYS The vehicle is equipped with a master (black) key and valet (gray) key lock system. The master key will access doors, trunk, glove box, ignition and remote trunk release. The valet key will access doors and ignition only.
Page 85 Locks and Security TRUNK REMOTE CONTROL The remote trunk release control is located on the driver’s door trim panel and can be operated at any time. You can render the switch inoperable by locking the button with your master key. INTERIOR LUGGAGE COMPARTMENT RELEASE Your vehicle is equipped with a mechanical interior luggage compartment release handle that provides a means of escape for children and adults in...
Page 86 Locks and Security Keep vehicle doors and luggage compartment locked and keep keys and remote transmitters out of a child’s reach. Unsupervised children could lock themselves in the trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly.
Page 87: Anti-Theft System
Locks and Security REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 88 Locks and Security Locking the doors Press this control to lock all doors. The horn will chirp to confirm that the control was pressed. The horn chirp feature can be turned on/off by using the feature menu in the message center. This process will arm your anti-theft system (if equipped).
Page 89 Locks and Security Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. You can also deactivate the alarm by pressing the UNLOCK control from the remote transmitter and unlocking the door with the key or the keyless entry keypad.
Page 90 Locks and Security Replacing lost transmitters Take all your vehicle’s transmitters to your dealer if service is required. If you purchase additional transmitters (up to four may be programmed into memory), perform the following procedure: • Place the key in the ignition. •...
Page 91 Locks and Security Press the control once to unlock the driver’s door and move the memory features to the corresponding memory position, just as if you had pressed the memory control in the vehicle. • transmitter #1 will recall memory profile position #1.
Page 92 Locks and Security Your vehicle has a factory-set 5–digit code that operates the keyless entry system. You can also program your own 5–digit personal entry code. The factory-set code is located: • On the owner’s wallet card in the glove compartment, •...
Page 93 Locks and Security Erasing personal code To erase all of the personal entry codes programmed to a vehicle: 1. Enter the factory-set code. 7 8 9 0 2. Press 1/2 within 7.5 seconds of step one. 3. Press and hold 1/2 for two seconds.
Page 94 Locks and Security To lock the doors, press 7/8 and 9/0 at the same time. 7 8 9 0 Autolock The autolock feature will lock all of the vehicle doors when: • all doors are closed • the engine is running and •...
Page 95 OFF and restart the engine with all other objects on the key ring held away from the ignition key. Check to make sure the coded key is an approved Lincoln coded key. If your keys are lost or stolen you will need to do the following:...
Page 96 Locks and Security • Have your vehicle towed to a dealership or a locksmith. The key codes will need to be erased from your vehicle and new key codes will need to be re-coded. Replacing coded keys can be very costly and you may want to store an extra programmed key away from the vehicle in a safe place to prevent an unforeseen inconvenience.
Page 97 Locks and Security 6. To program additional new unprogrammed key(s), repeat this procedure from step 1. If successful, the new coded key(s) will start the vehicle’s engine and the theft indicator will illuminate for three seconds and then go out. If not successful, the new coded key(s) will not start the vehicle’s engine and the theft indicator will flash on and off and you may repeat steps 1 through 6.
Page 98 Locks and Security • Press 7/8 and 9/0 controls on the keyless entry pad at the same 7 8 9 0 time to lock the doors (doors opened or closed). • Open a door and press the power door lock control to lock the doors.
Page 99: Seating And Safety Restraints
Seating and Safety Restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 100 Seating and Safety Restraints Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
Page 101 Seating and Safety Restraints Press to move the rear portion of the seat cushion up or down. Heated seats (if equipped) To operate the heated seats: • Slide the control to BACK to heat BACK the seatback only. • Slide the control to BOTH to heat the seatback and the seat cushion.
Page 102: Safety Restraints
Seating and Safety Restraints • the key is removed from the ignition cylinder The seat will move 5 cm (2 inches) forward (to the original position) when: • the transmission is in N (Neutral) or P (Park) • the key is placed in the ignition cylinder SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap...
Page 103 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Safety belts and seats can become hot in a vehicle that has been closed up in sunny weather; they could burn a small child. Check seat covers and buckles before you place a child anywhere near them.
Page 104 Seating and Safety Restraints Automatic locking mode In this mode, the shoulder belt is automatically pre-locked. The belt will still retract to remove any slack in the shoulder belt. The automatic locking mode is not available on the driver safety belt. When to use the automatic locking mode •...
Page 105 Seating and Safety Restraints • Grasp the shoulder portion and pull downward until the entire belt is extracted. • Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode.
Page 106 Seating and Safety Restraints Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 107 Seating and Safety Restraints The lap belt does not adjust automatically. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 108 Seating and Safety Restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds.
Page 109 Seating and Safety Restraints The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... Consider... “Crashes are rare 36700 crashes occur every day. The more we events” drive, the more we are exposed to “rare” events, even for good drivers.
Page 110 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the Belt Minder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the Belt Minder feature please follow the directions stated below.
Page 111 Seating and Safety Restraints • After step 5 the safety belt warning light will be turned on for three seconds. 6. Within seven seconds of the safety belt warning light turning off, buckle then unbuckle the safety belt. • This will disable BeltMinder if it is currently enabled, or enable BeltMinder if it is currently disabled.
Page 112: Air Bags
Seating and Safety Restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) Your vehicle is equipped with a crash sensing and diagnostic module which records information about the air bag and sensor systems. In the event of a collision this module may save information related to the collision including information about the air bag system and impact severity.
Page 113 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to an occupant in the center front seating position.
Page 114 Seating and Safety Restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 115 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 116 Seating and Safety Restraints If the air bag has deployed, the air bag will not function again and must be replaced immediately. If the air bag is not replaced, the unrepaired area will increase the risk of injury in a collision.
Page 117 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 118 Seating and Safety Restraints How does the side air bag system work? The side air bag system consists of the following: • An inflatable nylon bag (air bag) with a gas generator concealed behind the outboard bolster of the driver and front passenger seatbacks.
Page 119 Seating and Safety Restraints Several air bag system components get hot after inflation. Do not touch them after inflation. If the side air bag has deployed, the air bag will not function again. The side air bag system (including the seat) must be inspected and serviced by a qualified technician in accordance with the vehicle service manual.
Page 120: Child Restraints
Seating and Safety Restraints SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children. Also see Air bag supplemental restraint system (SRS) in this chapter for special instructions about using air bags. Important child restraint precautions You are required by law to use safety restraints for children in the U.S.
Page 121 Seating and Safety Restraints Child booster seats Children outgrow a typical convertible or toddler seat when they weigh 40 pounds and are around 4 years of age. Although the lap/shoulder belt will provide some protection, these children are still too small for lap/shoulder belts to fit properly, which could increase the risk of serious injury.
Page 122 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 123 Seating and Safety Restraints Follow all instructions provided by the manufacturer of the booster seat. Never put the shoulder belt under a child’s arm or behind the back because it eliminates the protection for the upper part of the body and may increase the risk of injury or death in a collision. Never use pillows, books, or towels to boost a child.
Page 124 Seating and Safety Restraints When installing a child safety seat: • Review and follow the information presented in the Air Bag Supplemental Restraint System section in this chapter. • Use the correct safety belt buckle for that seating position. • Insert the belt tongue into the proper buckle until you hear a snap and feel it latch.
Page 125 Seating and Safety Restraints Children 12 and under should be properly restrained in the rear seat whenever possible. 1. Position the child safety seat in a seat with a combination lap and shoulder belt. 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together.
Page 126 Seating and Safety Restraints 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until you hear a snap and feel the latch engage. Make sure the tongue is latched securely by pulling on it.
Page 127 Seating and Safety Restraints 8. Allow the safety belt to retract to remove any slack in the belt. 9. Before placing the child in the seat, forcibly tilt the seat forward and back to make sure the seat is securely held in place. To check this, grab the seat at the belt path and attempt to move it side to side and forward and back.
Page 128 Seating and Safety Restraints 2. Route the child safety seat tether strap over the back of the seat. For vehicles with adjustable head restraints, route the tether strap under the head restraint and between the head restraint posts, otherwise route the tether strap over the top of the seatback.
Page 129: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 130 Driving Extended idling at high engine speeds can produce very high temperatures in the engine and exhaust system, creating the risk of fire or other damage. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover.
Page 131 Driving • Make sure the gearshift is in P (Park). 3. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely.
Page 132 Driving Starting the engine Note: Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 133: Brakes
Driving Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes.
Page 134 Driving road dust, salt or mud. If a “metal-to-metal,” “continuous grinding” or “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by a qualified service technician. If you are driving down a long or steep hill, shift to a lower gear. Do not apply your brakes continuously, as they may overheat and become less effective.
Page 135 Driving • The anti-lock system does not reduce stopping distance. Always leave enough room between your vehicle and the vehicle in front of you to stop. • We recommend that you familiarize yourself with this braking technique. However, avoid taking any unnecessary risks. ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position.
Page 136 Driving your vehicle in an emergency. Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected. Your vehicle has an automatic parking brake release. To release the parking brake: 1.
Page 137: Traction Control/Advancetrac
Driving • Wheels out of alignment • Loose or worn suspension components Speed sensitive steering The steering in your vehicle is speed sensitive. At high speeds, steering assist will decrease to improve steering feel. At lower speeds, maneuverability will be increased. See Electronic Message Center in the Driver controls chapter for personalized adjustment.
Page 138: Air Suspension
Driving If the Traction Control system is cycled excessively, the brake portion of the system will shut down to prevent the front brakes from overheating. A limited Traction Control function using only engine torque reduction will still control wheels from over-spinning. When the front brakes have cooled down, the system will again function normally.
Page 139: Transmission Operation
Driving AUTOMATIC TRANSAXLE OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) unless the brake pedal is pressed. If you cannot move the gearshift lever out of P (Park) with the brake pedal depressed: 1.
Page 140 Driving If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your dealer or a qualified service technician. Driving with a 4–speed automatic transaxle Your automatic overdrive transaxle provides fully automatic operation in either D (Overdrive) or 3 (Third).
Page 141 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. You should always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in the N (Neutral) position, the vehicle can be started and is free to roll.
Page 142 Driving D (Overdrive) The overdrive position is the normal driving position for an automatic overdrive transaxle. It works the same way as 3 (Third) but shifts to a fourth gear — an overdrive gear — when your vehicle cruises at a constant speed for any length of time.
Page 143 Driving 1 (First) Use 1 (First) for when added engine braking is desired when descending steep hills. The automatic transaxle will shift to the proper gear to ascend any grade without any need to shift to 1 (First). Do not go faster than 61 km/h (38 mph) when in this gear. You can upshift from 1 (First) to overdrive at any time.
Page 144: Vehicle Loading
Driving internal transmission damage. Have the fluid checked and, if water is found, replace the fluid. VEHICLE LOADING Before loading a vehicle, familiarize yourself with the following terms: • Base Curb Weight: Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include occupants or aftermarket equipment.
Page 145: Trailer Towing
Driving Do not exceed the GVWR or the GAWR specified on the certification label. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations. Replacement tires with a higher limit than the originals do not increase the GVWR and GAWR limitations.
Page 146 38°C [100°F]) Your vehicle does not come from the factory fully equipped to tow. However, you can contact your local Lincoln dealer to get the proper towing equipment. Do not tow a trailer until your vehicle has been driven at least 3,200 km (2,000 miles).
Page 147 Do not connect a trailer’s lighting system directly to your vehicle’s lighting system. To get the proper equipment for hooking up your trailer’s lamps, see your Lincoln Mercury dealer. Be sure to follow their instructions carefully. If you do not install trailer lights correctly, you may cause damage to the vehicle’s lighting system or other vehicle systems.
Page 148 Driving Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination. When turning, make wider turns so the trailer wheels will clear curbs and other obstacles. •...
Page 149: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Owner Information Guide in the glove compartment.
Page 150: Hazard Flasher Switch
If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who need to obtain reimbursement information, call 1–800–665–2006.
Page 151: Fuses And Relays
Roadside Emergencies The fuel pump shut-off switch is located behind an access door to the left of the driver’s seat on the B-pillar. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2.
Page 152 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 153 Roadside Emergencies The fuses are coded as follows: Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Lighting Control Module: Anti-Theft Indicator Lamp, PWM Dimming Output, Illumination Lamps for Microphone, RR and LR Door Ashtrays, Heated Seat Switches, Rear Defrost Control Switch, EATC Control Panel, Message Center Switches, Speed Control Switches, Cigar Lighter, Console and Ashtray...
Page 154 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Power Door Locks and Power Windows Switch Backlights, Radio, Mobile Telephone Transceiver, Lighting Control Module, (RUN/ACC Sense), Electronic Day/Night Mirror Virtual Image Instrument Cluster, Lighting Control Module (LCM RUN/START Sense), Autolamp Light Sensor Virtual Image Instrument Cluster, RF Park/Turn Lamp...
Page 155 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description Multi-Function Switch: Flash to Pass, and Hazard Warning Input to LCM — Not Used — Not Used Digital Transmission Range Sensor Virtual Image Cluster-LF Turn Indicator, LF Turn Signal Lighting Control Module (LCM): Right Headlamp Virtual Image Instrument Cluster, EATC...
Page 156 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Panel Location Rating Description — Not Used Subwoofer Amplifier, Radio Analog Clock, CD Player, Mobile Telephone Transceiver, RESCU Power Door Locks, Power Seats, Power Mirrors, Keyless Entry, LF Seat Module, LF Door Module Cornering Lamps Door Locks Power distribution box...
Page 157 Roadside Emergencies The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description — A/C Diode — PCM Diode 30A* 20A* ALT SENSE 30A* Right Rear Passenger Window 30A* Air Suspension — Not Used 20A* Horns 15A* High Beam...
Page 158: Changing Tires
Roadside Emergencies CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily. Instead, gradually decrease your speed. Hold the steering wheel firmly and slowly move to a safe place on the side of the road. The use of tire sealants is not recommended and may compromise the integrity of your tires.
Page 159 Roadside Emergencies 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. Refer to Anti-theft lug nuts for information on removing anti-theft lug nuts. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your...
Page 160 If you lose the key, send the registration card to the manufacturer (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
Page 161: Jump Starting
Roadside Emergencies 3. Turn the wrench in a counterclockwise direction to remove the lug nut. To install the anti-theft lug nut: 1. Insert the key over the locking lug nut. 2. Place the lug nut wrench over the lug nut key and apply pressure on the key with the wrench.
Page 162 Roadside Emergencies Connecting the jumper cables 1. Connect the positive (+) booster cable to the positive (+) terminal of the discharged battery. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery.
Page 163 Roadside Emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 164 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 165 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 166: Wrecker Towing
Roadside Emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member of a roadside assistance program, your roadside assistance service provider. It is recommended that your vehicle be towed by wheel lift or flatbed equipment.
Page 167 Roadside Emergencies Before your vehicle can be towed, the air suspension control in the luggage compartment must be turned to the OFF position (if equipped). If your vehicle must be towed with the drive wheels on the ground: • place the transaxle in N (Neutral). •...
Page 168: Customer Assistance
Customer Assistance GETTING THE SERVICES YOU NEED At home Ford Motor Company and Ford of Canada have authorized dealerships to service your vehicle. It is preferred that you return to the authorized dealer where your vehicle was purchased when warranty repairs are needed.
Page 169 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 170 • Protection against covered repair costs after your Bumper-to-Bumper Warranty expires. You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 171 What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance concerns as on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written new vehicle warranty are eligible for review, except those involving: •...
Page 172 • A Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 173 Customer Assistance Making a decision Board members review all available information related to each complaint, including oral presentations, and arrive at a fair and impartial decision. Board review may be terminated at any time by either party. Every effort is made to decide the case within 40 days of the date that all requested information is received by the Board.
Page 174 Customer Assistance settlement have failed. This procedure is without cost to you and is designed to eliminate the need for lengthy and expensive legal proceedings. In the CAMVAP program, impartial third-party arbitrators conduct hearings at mutually convenient times and places in an informal environment.
Page 175 Customer Assistance If you buy your vehicle in North America and then relocate outside of the U.S. or Canada, register your vehicle identification number (VIN) and new address with Ford Motor Company Worldwide Direct Market Operations. ORDERING ADDITIONAL OWNER’S LITERATURE To order the publications in this portfolio, contact Helm, Incorporated at: HELM, INCORPORATED P.O.
Page 176: Reporting Safety Defects (U.s. Only)
Customer Assistance 2. Four or more repair attempts are made on the same nonconformity (a defect or condition that substantially impairs the use, value or safety of the vehicle) OR 3. The vehicle is out of service for repair of nonconformities for a total of more than 30 calendar days (not necessarily all at one time) In the case of 1 or 2 above, the consumer must also notify the manufacturer of the need for the repair of the nonconformity at the...
Page 177: Cleaning
Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your authorized Ford, Lincoln or Mercury dealer. Always use a clean sponge or carwash mitt with plenty of water for best results. Dry the vehicle with a chamois or soft terry cloth towel in order to eliminate water spotting.
Page 178 Minor scratches or paint damage from road debris may be repaired using the Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), which is available at your authorized Ford, Lincoln or Mercury dealer. This kit contains: • Lacquer Touch-Up Paint (ALBZ-19500–XXXXA) •...
Page 179 Road Oil Removal (B7A-19520–AA). Use only approved products to clean plastic parts. These products are available from your authorized Ford, Lincoln or Mercury dealer. WASHING THE EXTERIOR LAMPS In order to avoid scratching the plastic lamps, do not use dry paper towels, non-approved chemical solvents or abrasive cleaners.
Page 180 Clean the outside of the windshield or rear window with a non-abrasive cleaner such as Ultra Clear Spray Glass Cleaner (E4AZ-19C507–AA), available from your authorized Ford, Lincoln or Mercury dealer. If after cleaning the glass surface, the water sheets from the glass (e.g., does not bead), then the window is clean.
Page 181 Extra Strength Upholstery Cleaner (E8AZ-19523–AA). CLEANING LEATHER SEATS (IF EQUIPPED) All Ford, Lincoln and Mercury vehicles with leather seating surfaces have a clear, protective coating over the leather. To clean the leather seats, simply use a soft cloth with Deluxe Leather and Vinyl Cleaner (F2AZ-19521–WA).
Page 182: Underbody Preservation
Use the other towel to remove the residue. CLEANING AND MAINTAINING THE SAFETY BELTS Clean the safety belts with Extra Strength Upholstery Cleaner (E8AZ-19523–AA), available from your authorized Ford, Lincoln or Mercury dealer. Do not use bleach, dye or any other solvent to clean the belts, as these actions may weaken the belt webbing.
Page 183 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 184: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 185 Maintenance and Specifications Working with the engine on 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Block the wheels to prevent the vehicle from moving unexpectedly. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 186: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L DOHC V8 engine 1. Automatic transmission fluid dipstick 2. Brake fluid reservoir 3. Battery 4. Air filter assembly 5. Engine oil dipstick 6. Engine oil filler cap 7. Power steering fluid reservoir 8.
Page 187: Engine Oil
Maintenance and Specifications WINDSHIELD WASHER FLUID Check the washer fluid whenever you stop for fuel. The reservoir is highlighted with a symbol. Add fluid to fill the reservoir if the level is low. In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification ESR-M17P5–A .
Page 188 Maintenance and Specifications 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 189 Maintenance and Specifications 3. Recheck the engine oil level. Make sure the oil level is not above the MAX mark on the engine oil level indicator (dipstick). 4. Install the indicator and ensure it is fully seated. 5. Fully install the engine oil filler cap by turning the filler cap clockwise 1/4 of a turn until three clicks are heard or until the cap is fully seated.
Page 190: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 191 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 192 Maintenance and Specifications • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal. Call your local authorized recycling center to find out more about recycling automotive batteries. RECYCLE ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide.
Page 193 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “cold fill level” or within the “cold fill range” as listed on the engine coolant reservoir (depending upon application).
Page 194 Maintenance and Specifications Do not add engine coolant when the engine is hot. Steam and scalding liquids released from a hot cooling system can burn you badly. Also, you can be burned if you spill coolant on hot engine parts. Do not put engine coolant in the windshield washer fluid container.
Page 195 Maintenance and Specifications • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled engine coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 196 Maintenance and Specifications system may have a leak. Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored).
Page 197: Fuel Information
Maintenance and Specifications • NEVER decrease the coolant concentration below 40%. • Decreased engine coolant concentrations below 40% will decrease the corrosion protection characteristics of the engine coolant and may cause engine damage. • Decreased engine coolant concentrations below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage.
Page 198 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 199 Maintenance and Specifications Use the following guidelines to avoid static build-up when filling an ungrounded fuel container: • Place approved fuel container on the ground. • DO NOT fill a fuel container while it is in the vehicle (including the cargo area).
Page 200 Maintenance and Specifications If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible personal injury.
Page 201 Maintenance and Specifications Many of the world’s automakers issued the World-wide Fuel Charter that recommends gasoline specifications to provide improved performance and emission control system protection for your vehicle. Gasolines that meet the World-wide Fuel Charter should be used when available.
Page 202 Maintenance and Specifications possible. Fuel expense, frequency of fill-ups or fuel gauge readings are NOT accurate as a measure of fuel economy. We do not recommend taking fuel economy measurements during the first 1,600 km (1,000 miles) of driving (engine break-in period). You will get a more accurate measurement after 3,000 km–5,000 km (2,000 miles-3,000 miles).
Page 203 Maintenance and Specifications 3. After at least three to five tank fill-ups, fill the fuel tank and record the current odometer reading. 4. Subtract your initial odometer reading from the current odometer reading. 5. Follow one of the simple calculations in order to determine fuel economy: Calculation 1: Multiply liters used by 100, then divide by total kilometers traveled.
Page 204 Maintenance and Specifications • Resting your foot on the brake pedal while driving may reduce fuel economy. • Combine errands and minimize stop-and-go driving. Maintenance • Keep tires properly inflated and use only recommended size. • Operating a vehicle with the wheels out of alignment will reduce fuel economy.
Page 205 Maintenance and Specifications expected on the vehicle under optimum conditions. Your fuel economy may vary depending upon the method of operation and conditions. EMISSION CONTROL SYSTEM Your vehicle is equipped with various emission control components and a catalytic converter which will enable your vehicle to comply with applicable exhaust emission standards.
Page 206 Maintenance and Specifications the Vehicle Emission Control Information Decal located on or near the engine. This decal identifies engine displacement and gives some tune up specifications. Please consult your Warranty Guide for complete emission warranty information. Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system.
Page 207 Maintenance and Specifications 2. While the engine idles, turn the steering wheel left and right several times. 3. Turn the engine off. 4. Check the fluid level in the reservoir. It should be between the MIN and MAX lines. Do not add fluid if the level is in this range.
Page 208 Maintenance and Specifications Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes. Seek medical attention if irritation persists. If taken internally, drink water and induce vomiting. Seek medical attention immediately. If you use DOT 5 or any other brake fluid that is not DOT 3 or DOT 4, you will cause permanent damage to your brakes.
Page 209 Maintenance and Specifications 7. Remove the dipstick and inspect the fluid level. The fluid should be in the designated areas for normal operating temperature. Low fluid level Do not drive the vehicle if the fluid level is at the bottom of the dipstick and the outside temperatures are DON’T ADD IF IN CROSSHATCH AREA--CHECH WHEN HOT-IDLING above 10°C (50°F).
Page 210 Maintenance and Specifications Do not use supplemental transmission fluid additives, treatments or cleaning agents. The use of these materials may affect transmission operation and result in damage to internal transmission components. SECURITIRE (IF EQUIPPED) SecuriTires are designed to allow you to continue driving your vehicle a limited number of miles when one of your vehicle’s tires is at low or even zero air pressure.
Page 211 If the warning remains on after you have adjusted the tires to the recommended air pressure levels, take your vehicle to an authorized Lincoln/Mercury dealer for service. Flat tire warning If the sensors detect a tire pressure lower than 68 kPa (10 psi), the LOW...
Page 212 Maintenance and Specifications INFORMATION ABOUT UNIFORM TIRE QUALITY GRADING New vehicles are fitted with tires that have a rating on them called Tire Quality Grades. The Quality grades can be found where applicable on the tire sidewall between tread shoulder and maximum section width.
Page 213 Maintenance and Specifications The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 214 Maintenance and Specifications • Four tire rotation Replacing the tires Replace the tires when the wear band is visible through the tire treads. When replacing full size tires, never mix radial bias-belted, or bias-type tires. Use only the tire sizes that are listed on the Certification or Tire Label.
Page 215: Part Numbers
Maintenance and Specifications Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer. SNOW TIRES AND CHAINS Driving too fast for conditions creates the possibility of loss of vehicle control. Driving at very high speeds for extended periods of time may result in damage to vehicle components.
Page 216: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Engine oil Motorcraft SAE 5.7L (6.0 quarts) (includes filter 5W-20 Premium change) Synthetic Blend Motor Oil Engine coolant Motorcraft 15.0L (15.8 quarts) Premium Engine Coolant (green-colored) or Motorcraft Premium Gold Engine Coolant (yellow-colored) Brake fluid...
Page 217: Lubricant Specifications
Maintenance and Specifications LUBRICANT SPECIFICATIONS Ford Part Ford Part Ford Item Name or Number Specification equivalent Brake fluid Motorcraft High PM-1 ESA-M6C25-A Performance and DOT 3 DOT 3 Motor Vehicle Brake Fluid Hinges, latches, Multi-Purpose XG-4or ESB-M1C93-B or stricker plates, Grease F5AZ-19G209-AA ESR-M1C159-A...
Page 218 Maintenance and Specifications Ford Part Ford Part Ford Item Name or Number Specification equivalent Power steering Motorcraft XT-2-QDX MERCON fluid MERCON ATF Windshield Ultra-clear C9AZ-19550-AC ESR-M17P5-A washer fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended.
Page 219 Maintenance and Specifications...
Page 220 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 221 Maintenance and Specifications 1. World manufacturer identifier 2. Brake type and gross vehicle weight rating (GVWR) 3. Vehicle line, series, body type 4. Engine type 5. Check digit 6. Model year 7. Assembly plant 8. Production sequence number Engine number The engine number (the last eight numbers of the vehicle identification number) is stamped on the engine block, transmission, frame and transfer case (if equipped).
Page 222 FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 223 Accessories Comfort and convenience Cargo nets Cargo organizer Electrochromic compass mirror Electrochromic compass mirror with temperature display Engine block heaters HomeLink Remote start system Travel equipment Automatic headlamps with daytime running lights (DRL) Daytime running lights (DRL) HomeLink Protection and appearance equipment Carpet floor mats Door edge guards First aid kit...
Page 224 Accessories • The Federal Communications Commission (FCC) and Canadian Radio Telecommunications Commission (CRTC) regulate the use of mobile communications systems - such as two-way radios, telephones and theft alarms - that are equipped with radio transmitters. Any such equipment installed in your vehicle should comply with FCC or CRTC regulations and should be installed only by a qualified service technician.
Page 225 Index acid, treating emergencies ..189 charging system ABS (see Brakes) .....133 warning light ......12 jumping a disabled battery ..160 Accessory delay ......56 maintenance-free ....189 Air bag supplemental replacement, specifications ...214 restraint system ....111, 115 servicing ........189 and child safety seats ....113 description ......111, 115 BeltMinder .........107 disposal ........118...
Page 226 Index instrument cluster lens ..180 The Dispute Settlement Board ........169 instrument panel ....179 Utilizing the interior ........180 Mediation/Arbitration plastic parts ......178 Program ........172 safety belts ......181 washing ........176 waxing ........176 wheels ........177 Daytime running lamps windows ........181 (see Lamps) ........39 wiper blades ......179 Defrost Climate control (see Air...
Page 227 Index Engine oil ........186 Gas cap (see Fuel cap) ....198 change oil soon warning, Gas mileage message center .......186 (see Fuel economy) ....200 checking and adding ....186 dipstick ........186 Gauges .........14 filter, specifications ..188, 214 engine coolant temperature recommendations ....188 gauge .........14 refill capacities ......215 fuel gauge ........15...
Page 228 Index HomeLink universal bulb replacement specifications chart ....45 transceiver (see Garage door cargo lamps .......40 opener) ......65–66, 68 daytime running light ....39 Hood ..........184 headlamps .........39 headlamps, flash to pass ..40 instrument panel, dimming ..40 interior lamps .....43–45 replacing bulbs ..44, 46, 48–50 Ignition .......128, 217 Lane change indicator Infant seats...
Page 229 Index check air suspension ....73 menu button ......79 reset button ......81 Radio reception ......31 system check button ....75 Rear window defroster ....37 warning messages .....75 Relays ........150, 156 Mirrors .........53 Remote entry system ...86, 88 automatic dimming rearview illuminated entry ......89 mirror ........57 locking/unlocking doors ..86–87 heated ........57...
Page 230 Index SecuriLock passive anti-theft lubricant specifications ..217 system ........93–95 Transmission Servicing your vehicle ....183 fluid, checking and adding (automatic) ......207 Spark plugs, lubricant specifications ..216 specifications .....214, 217 Specification chart, Trunk ...........84 lubricants ......216–217 remote release ....84, 87 Speed control ......61 Turn signal ......12, 43 Speedometer .......15 Starting your...
