COMPRO NC3230 Installation Manual

Dome network camera

Advertisement

Quick Links

V3-120831
P/N: 3GA0310817
Dome Network Camera

Installation Guide

Before attempting to set up or operate this camera,
please read this quick installation guide and retain it
for future reference.
Model No.
NC3230

Advertisement

Table of Contents
loading

Summary of Contents for COMPRO NC3230

  • Page 1: Installation Guide

    Dome Network Camera Installation Guide Before attempting to set up or operate this camera, please read this quick installation guide and retain it for future reference. Model No. NC3230 V3-120831 P/N: 3GA0310817...
  • Page 2 The information in this document is subject to change without notice. COMPRO reserves the right to make revisions to this publication without obligation to notify any person or entity of any such changes.
  • Page 3: Table Of Contents

    Technical Specifications ........17 NC3230 Technical Specifications ......17 Technical Support Information .
  • Page 4: Important Notices

    Important Notices Regulatory Notice This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 5: Product Overview

    If anything is missing, please don’t hesitate to contact your local distributor. Item Description Network camera Compro NC3230 dome network camera Hex cap screw For use with the hexagon nuts to mount the camera on a rack rail Spring washer...
  • Page 6: Hardware Overview

    Hardware Overview Camera Layout Name Description IR LED Provides additional lighting in low light conditions Ambient light sensor Feeds information on environmental lighting condition to the camera Lens Vari-focal, f 3~9 mm, F1.2~2.1, auto iris, megapixel, IR- corrected Lens hood For eliminating unnecessary light; direction adjustable All-in- one ter minal Intergrating power, IO, Ethernet, BNC, and audio cable,...
  • Page 7: Power Connector Pinout

    Name Description Pan adjustment screw For holding the panning position of the camera Rotation adjustment Loosen the screw to rotate the lens screw Tilt adjustment screw For holding the tilting position of the camera Screw holes (on the For installing the wall mount bracket bottom) for wall mount bracket Power connector...
  • Page 8: Digital I/O Connector Block

    Digital I/O Connector Block The digital inputs are normally used with security sensors, e.g. passive infrared sensors (PIR), smoke detectors, etc. They work by detecting a change in the state of open and closed circuit. The output ports are normally used to trigger external audio or visual in- dicators, e.g.
  • Page 9: Installation

    Installation Mounting on a Dropped Ceiling Before you mount the camera on a dropped ceiling, you must first ensure that the ceil- ing is robust enough to hold the weight of the camera. Then refer to the following steps. 1. Use the supplied drill template to drill three mounting holes on the ceiling. Then drill a hole for the camera’s protective cap.
  • Page 10: Connect The Cables

    Re-routing Terminal Cable If necessary, you can have the terminal cable exit from the bottom of the camera. To do so, remove the camera’s top cover first and go ahead to detach the entire terminal cable , along with the plastic cable gland, from the camera. Then unscrew the plastic conduit entry cover on the bottom.
  • Page 11 to the Cable/ADSL modem, please re-connect it to the Ethernet port of your net- work hub/router. 2. Ethernet port on camera: Use a RJ-45 LAN cable to connect the Ethernet port of the IP camera to the Ethernet port of your network hub/router. 3.
  • Page 12: Install Camera Software

    To begin software installation, insert the installation CD included in the package into the CD-ROM drive of your viewing PC. Make sure your Compro IP camera connects to the same home/office network that your viewing PC connects to. Then the Compro iWizard setup utility will start automatically to guide you through the installation process.
  • Page 13: Adjust The Image

    screen instructions to complete the software installation. Adjust the Image Follow the instructions below to adjust the camera's varifocal lens. Adjust Zoom and Focus 1. To adjust the zoom and focus, first remove the protection sheet from the top cover, and then loosen the fixing screw on the top cover to remove the top cover. 2.
  • Page 14 60° 60° 180° 180° 3. Loosen the tilt adjustment screw (labeled in below figure) on both sides and then tilt the lens holder (labeled in below figure) to adjust the camera's tilting position. The tilt adjustment range is between +60 degrees to -60 degrees. 4.
  • Page 15: Change Sd Memory Card

    7. Having obtained the optimal result, re-install the top cover to complete the op- eration. Change SD Memory Card The camera comes with a 4GB microSD card pre-installed inside the housing. The SD memory card is user-upgradeable. And if you like to replace it, refer to the steps below that explain the procedure.
  • Page 16: Operation

    Find Out the Camera's IP Address Using the iWizard setup utility to search for your Compro IP camera on the LAN network is the easiest way to find out your camera's IP address, as the IP address of your camera will be revealed in the search result.
  • Page 17: Access The Camera Over The Internet

    puter system is running 64-bit version of Windows, the 32-bit version of Internet Explorer must still be used to access the camera.) 6. And then the reconfirmation dialog box will come up. Please press [Install] twice to install both the "USActiveX.cab" and "ComproClientActivex.cab" on your sys- tem.
  • Page 18 Internet Explorer. For example, enter "http://61.220.20.16:80". If you have multiple Compro IP cameras installed, you will need to change the HTTP and RTSP port on them manually so each one of them will use a different port. For instance, let the second camera use HTTP port 81 and RTSP port 555 and log on to "http://61.220.20.16:81"...
  • Page 19: Technical Specifications

    Technical Specifications NC3230 Technical Specifications Sensor 1/3" CMOS 2-megapixel sensor Vari-focal, f 3~9 mm, F1.2~2.1, auto ir is, Lens megapixel, IR-corrected Zoom 3X optical, 10x digital (total 30x) Angle of View 31.7° ~ 93° Automatically controlled Infrared-cut filter, 18 CAMERA...
  • Page 20 Triggering Event Analytics, schedule, I/O, network failure System Triggering SMS, snapshot, local/remote recording, e-mail, Integration Reaction FTP, alarm output, ComproView® notification Local Storage Built-in microSD slot Local AVI (audio incl.), by events or schedule; JPEG, file Storage Format name format customizable 3GPP, ARP, DDNS, DHCP, DNS, FTP, HTTP, ICMP/ Protocols IPv4, IGP, NTP, PPPoE, QoS, RSP, RTSP, SMTP, SSL, TCP/IP, UDP, UPnP...
  • Page 21 Input Voltage DC 12V, or PoE (Power-over-Ethernet) Electrical IEEE 802.3af Class 3 Operating -20~50 ºC / -4~122ºF Environ- Temperature mental Humidity 20~80% RH non-condensing Microsoft Windows XP SP3, Vista SP1, 7 (x86/x64) Browsing Processor Intel 2.8 GHz, 2GB RAM Requirement Microsoft Internet Explorer 8.0 or above, non-IE Web Browser browsers require 3rd-party VLC plugin...
  • Page 22: Technical Support Information

    Technical Support Information Contact Compro Technical Support If you need any technical support, fill out the online form (http://comprousa.com/en/ form.htm) or directly email to support@comprousa.com. Compro Technology, Inc. www.comprosecurity.com Tel. +886 2 2918 0169, Fax +886 2 2915 2389 4F, No.12, Alley 6, Lane 45, Pao Shin Road,...
  • Page 24 Compro Technology Head Office 3F, No.12, Alley 6, Lane 45, Pao Shin Road, Hsintien District, New Taipei City 231, Taiwan Tel. +886 2 29180169 Fax. +886 2 29152389...
