3.1.9 Removing the LCD board assembly
(See Fig.14)
(1) Remove the two screws K attaching the LCD board assem-
bly.
3.1.10 Removing the CD mechanism assembly
(See Fig.15)
(1) Removing the four screws L attaching the CD mechanism
assembly.
This service manual does not describe ADJUSTMENT.
L
L
