JVC RV-B55 BU Instructions Manual

Jvc cd portable system instruction manual.
CD PORTABLE SYSTEM
RV-B55 GY/BU/LTD
TIMER
CLOCK
TIMER
ON/OFF
SLEEP
DOWN
UP
SET
PROGRAM
RANDOM
AUTO
PRESET
REPEAT
TUNER
AUX
C D
TAPE
BAND
FM MODE
REVERSE MODE
FF
REW
MULTI CONTROL
DISPLAY
SOUND
ACS
AHB PRO
VOLUME
RM-RXVB55
REMOTE CONTROL
INSTRUCTIONS
LVT0209-003A
[B]

   Related Manuals for JVC RV-B55 BU

   Summary of Contents for JVC RV-B55 BU

  • Page 1

    CD PORTABLE SYSTEM RV-B55 GY/BU/LTD TIMER CLOCK TIMER ON/OFF SLEEP DOWN PROGRAM RANDOM AUTO PRESET REPEAT TUNER TAPE BAND FM MODE REVERSE MODE MULTI CONTROL DISPLAY SOUND AHB PRO VOLUME RM-RXVB55 REMOTE CONTROL INSTRUCTIONS LVT0209-003A...

  • Page 2: Table Of Contents

    ENGLISH Thank you for purchasing this JVC product. Please read these instructions carefully before starting operation to be sure to obtain optimum performance and a longer service life from the unit. CONTENTS Features ... 4 Safety precautions ... 4 Handling precautions ... 5 Shoulder strap attachment/detachment ...

  • Page 3

    IMPORTANT for the U.K. DO NOT cut off the mains plug from this equipment. If the plug fitted is not suitable for the power points in your home or the cable is too short to reach a power point, then obtain an appropriate safety approved extension lead or consult your dealer.

  • Page 4: Features, Safety Precautions

    FEATURES ÷ Active Hyper-Bass (AHB) Pro circuit for low-frequency sound reproduction ÷ Active Clear Sound (ACS) circuit for enhanced sound reproduction ÷ Sound mode control ÷ One-touch operation (COMPU PLAY) ÷ 34-key remote control unit operates all CD, cassette deck and tuner functions ÷...

  • Page 5: Handling Precautions, Shoulder Strap Attachment/detachment

    HANDLING PRECAUTIONS Do not use this unit in direct sunlight where it would be exposed to high temperatures above 40°C (104°F). ÷ When abnormal operation occurs * Unplug the AC power cord from the AC wall outlet and remove all the batteries. Then reload the batteries after a few minutes, reconnect the AC power cord and switch the power ON.

  • Page 6: Connections, Power Supply

    ÓAC IN CAUTIONS: 1. ONLY USE WITH JVC POWER CORD PROVIDED WITH THIS UNIT TO AVOID MALFUNCTION OR DAMAGE TO THE UNIT. 2. BE SURE TO UNPLUG THE POWER CORD FROM THE OUTLET WHEN GOING OUT OR WHEN THE UNIT IS NOT IN USE FOR AN EXTENDED PERIOD OF TIME.

  • Page 7

    TWO WEEKS) OR WHEN ALWAYS USING HOUSEHOLD AC, REMOVE THE BATTERIES TO AVOID A MALFUNCTION OR DAMAGE TO THE UNIT. ÷ WHEN THE JVC POWER CORD PROVIDED WITH THIS UNIT IS CONNECTED, THE POWER IS AUTOMATICALLY SWITCHED FROM THE BATTERIES TO THE HOUSEHOLD AC EVEN WHEN THE BATTERIES ARE LOADED.

  • Page 8: Names Of Parts And Their Functions

    NAMES OF PARTS AND THEIR FUNCTIONS CD player/General section 34 5 6 Shoulder strap hook button AHB (Active Hyper Bass) PRO button ACS (Active Clear Sound) button SOUND button OPEN knob Turn the OPEN knob to the left to open the CD door.

  • Page 9

    Tuner/Deck section PRESET TUNING/BEAT CUT button Display window Band display Radio frequency display Mode display during FM broadcast (STEREO/MONO) Tape (TAPE) display Reverse mode indicator ( / Recording indicator (REC) Tape direction indicators (2/3) TAPE 23 button Press to select the tape mode. Press to select the tape direction.

  • Page 10: Remote Control Unit

    REMOTE CONTROL UNIT Preparation before use ÷ Installing batteries in the remote control unit 1. Remove the battery cover from the back of the remote control unit. 2. Insert two “R6/AA (15F)” size batteries. ÷ Insert the batteries with the ª and · terminals matching the indication inside the battery compartment.

  • Page 11: Switching The Power On/off

    SWITCHING THE POWER ON/OFF Switching the power on/off ÷ Switching on: ON/STANDBY STANDBY The STANDBY indicator goes out. ÷ Switching off: ON/STANDBY STANDBY The STANDBY indicator lights. One touch operation (COMPU PLAY) (only when AC power is used) Even when the power is set to STANDBY, pressing the button shown below switches on the power and selects the source.

  • Page 12: Volume, Sound Mode And Other Controls

    VOLUME, SOUND MODE AND OTHER CONTROLS VOLUME buttons + : Use to increase the volume. – : Use to decrease the volume. (Control range from VOL 0 to VOL 50.) Main unit VOLUME AHB (Active Hyper Bass*) PRO button BASS 1: The AHB PRO indicator lights up, and a mild bass boost is added to the sound.

  • Page 13: Handling Cds

    HANDLING CDs Since dirty, damaged and warped CDs may damage the unit, take care regarding the following: 1. Usable CDs Use CDs with the Compact Disc mark shown below. 2. Notes on handling CDs ÷ Do not touch the reflective recorded surface. ÷...

  • Page 14: Playing Cds

    ÷ Take the disc out of the unit before transporting it. ÷ Do not place anything other than a CD in the CD player, as this may ÷ Do not apply shock to the unit or use the unit in an unstable position, Search play (to locate the required position on the CD) ÷...

  • Page 15

    Direct access play (using the remote control unit) ÷ Pressing any of the track number buttons will start play from the beginning of the designated track. (This function cannot be used during programmed play.) CLOCK DOWN REVERSE MODE Programmed play (using the remote control unit) ÷...

  • Page 16: Handling Cassette Tapes

    Repeat play (using the remote control unit) Press the REPEAT button before or during play. A single track or all the tracks can be repeated. Whether a single track or all tracks are to be repeated can be specified. Each time the REPEAT button is pressed, the mode will change from single track ( ), to all tracks ( ALL), to clear mode, in this order.

  • Page 17: Cassette Playback, Using With Another Audio Unit

    CASSETTE PLAYBACK Operate in the order shown ÷ When AC power is used (When battery power is used, switch on the operation): ON/STANDBY AHB PRO ACS SOUND PRESET ONE TOUCH TUNING STANDBY AHB PRO BEAT CUT OPEN Load a cassette tape with side A facing out. Press to start playback.

  • Page 18: Radio Reception

    RADIO RECEPTION Operate in the order shown ÷ When AC power is used (When battery power is used, switch on the operation): Press the TUNER BAND button. ÷ The power is switched on. Select the band by pressing the TUNER BAND button. ÷...

  • Page 19

    Presetting the desired stations (using the remote control unit) 30 stations in the FM band and 15 stations in the AM (MW/LW) band can be preset as follows: ÷ Example: (Presetting an FM station broadcasting at 103.5 MHz to preset button “15”) SLEEP DOWN...

  • Page 20: Recording

    ÷ Check that the safety tab on the cassette tape is not broken off. Synchronized recording with the CD player ÷ In this system, the CD player starts play when the cassette deck enters the recording mode. Operate in the order shown...

  • Page 21

    Recording from the radio or an external source connected to the AUX IN terminals Operate in the order shown ON/STANDBY AHB PRO ACS SOUND PRESET ONE TOUCH TUNING BEAT CUT Load a cassette with side A facing out. (Wind past the tape leader before starting recording.) ÷...

  • Page 22: Clock Adjustment

    CLOCK ADJUSTMENT USING THE REMOTE CONTROL UNIT) Names of parts in the clock/timer section, and their functions: 1 2 3 Timer mode indicator Timer indicator (ON/OFF) SLEEP indicator CLOCK indicator Time display Setting the current time (when this unit is used for the first time) (Example: To set the clock to 13:15.) CLOCK...

  • Page 23: Timer Operations

    TIMER OPERATIONS (USING THE REMOTE CONTROL UNIT) Setting the timer ÷ The current time must be set before the timer can be used. Set the button to ON. Press the TIMER button. TIMER Set the start time. (Example: To set the timer to 12:15.) DOWN Set the stop time.

  • Page 24

    Timer recording of broadcast ÷ The current time must be set before the timer can be used. ÷ Make sure that the safety tabs of the cassette have not been broken off. Operations ON/STANDBY AHB PRO ACS SOUND PRESET ONE TOUCH TUNING BEAT CUT Set the...

  • Page 25

    Timer playback ÷ Timer playback of tapes, broadcasts and CDs is possible. Operations ON/STANDBY AHB PRO ACS SOUND PRESET ONE TOUCH TUNING BEAT CUT Set the button to ON. Set the timer. (Refer to “Setting the timer” on page 23.) Source sound CD play Tape playback...

  • Page 26: Maintenance

    MAINTENANCE Cleaning is important! When the tape is running, magnetic powder and dust naturally accumulate on the heads, capstan and pinch roller. When they become too dirty... ÷ Sound quality deteriorates. ÷ The output sound level drops. ÷ Previously recorded tape is not completely erased. ÷...

  • Page 27: Troubleshooting, Specifications

    * Was the power cord unplugged while the memory back-up batteries were not installed? (CD Player Section) ÷ The CD player does not play. * Is the CD upside down? * Is the CD dirty? * Is there condensation on the lens? (See “Cleaning the lens” on page 26.) ÷...

  • Page 28
