Removing Other Components
(Authorized Service Providers Only)
Required Equipment
•
#0 and #1 Phillips screwdrivers.
•
Small flat-blade screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Remove the assemblies and follow the additional steps listed in the table below.
Component
Battery, CMOS
Case, bottom
Case, top
CD/DVD drive
CPU module
Display assembly
Doors, PCMCIA
Floppy drive
2-38 Removal and Replacement

Table 2-5. Removing Components

Removal Procedure
Keyboard cover
(page 2-10).
Speaker (page 2-12).
Switchboard PCA
(page 2-13).
Keyboard (page 2-13).
CD/DVD (page 2-16).
Display (page 2-17).
Top case (page 2-20).
Heatsink (page 2-26).
Floppy (page 2-22).
Motherboard (page 2-30).
See page 2-34.
See page 2-20.
See page 2-16.
See page 2-28.
See page 2-17.
Keyboard cover
(page 2-10).
Speaker (page 2-12).
Switchboard PCA
(page 2-13).
Keyboard (page 2-13).
CD/DVD (page 2-16).
Display (page 2-17).
Top case (page 2-20).
Heatsink (page 2-26).
Floppy (page 2-22).
Motherboard (page 2-30).
See page 2-22.
Additional Steps
Reassembly Notes: After replacing the CMOS battery,
set the correct time and date using the BIOS Setup
utility or Date/Time in the Control Panel.
See page 2-34.
