Jøtul GF 300 BV Allagash Installation And Operation Instructions Manual
Natural vent gas stove
Hide thumbs
Also See for GF 300 BV Allagash:
- Installation and operation instructions manual (28 pages) ,
- Installation and operation instructions manual (28 pages)
Table of Contents
Advertisement
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
– Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
– Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
– In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall be
installed in the same room as the appliance.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or mobile
home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate. A conversion kit is
supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Installation and
Operation Instructions
ATTENTION : CES INSTRUCTIONS DOIVENT
DEMUERER AVEC LE PROPRIÉTERE D'UNE
MAISON.
AVERTISSEMENT: Assurez-vous de bien
suivreles instructions données dans cette
notice pour réduire auninimum le risque
d'incendie ou d'explosion ou pour éviter
tout dommage matériel, toute blessure ou la
mort.
– Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout
autre appareil.
– QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer l'appareil.
• Ne touchez à aucum interrupteur.
Ne pas vous servir des téléphones se
trouvant dans le bâtiment où vous
trouvez.
• Appelez immédiatement votre
fournisseur de gaz depuis un voisin.
Suivez les instructions du fournisseur.
• Si vou ne pouvez rejoindre le
fournisseur de gaz, appelez le service des
incendies.
– L'installatione l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
137945_Rev_F 7.29.10
1
Advertisement
Table of Contents
Related Manuals for Jøtul GF 300 BV Allagash
Summary of Contents for Jøtul GF 300 BV Allagash
-
Page 1: Operation Instructions
137945_Rev_F 7.29.10 Installation and Operation Instructions WARNING: If the information in these ATTENTION : CES INSTRUCTIONS DOIVENT instructions is not followed exactly, a fire DEMUERER AVEC LE PROPRIÉTERE D’UNE or explosion may result causing property MAISON. damage, personal injury or loss of life. AVERTISSEMENT: Assurez-vous de bien suivreles instructions données dans cette –... -
Page 2: Service Tools
137945_Rev_F 7.29.10 WARNING THIS PRODUCT MUST BE INSTALLED BY A LICENSED MASTER OR JOURNEYMAN PLUMBER OR GAS-FITTER WHEN HOT GLASS WILL INSTALLED IN THE COMMONWEALTH OF CAUSE BURNS MASSACHUSETTS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN Suggested Tools for TO TOUCH GLASS. -
Page 3: Table Of Contents
137945_Rev_F 7.29.10 Table of Contents Jøtul GF BV Allagash Service Tools ..........2 Natural Vent Gas Stove Specifications ..........4 General Information ........ 5 Manufactured and Distributed by: Safety Information ........6 Jøtul North America 55 Hutcherson Dr. Installation Requirements Gorham, Maine 04038 Location ..........6 Hearth Protection .......6 Clearances .......... -
Page 4: Specifications
137945_Rev_F 7.29.10 GF 300 BV Allagash Specifications The Jøtul GF 300 BV Allagash is a atmospherically- vented gas fireplace heater designed only for vertical THIS FIREPLACE IS SHIPPED FROM THE FACTORY venting directly to the outside of the house, using FOR USE WITH NATURAL GAS ONLY. -
Page 5: General Information
137945_Rev_F 7.29.10 General Information Consult the local or national installation code(s) to assure that adequate combustion and ventilation air is available. THIS HEATER MUST BE INSTALLED AND MAINTAINED Installer l’appareil selon les codes ou reglements BY A QUALIFIED SERVICE AGENCY. locaux, ou, en l’absence de tels reglements, selon les The installation and repair of this appliance must be ... -
Page 6: Safety Information
137945_Rev_F 7.29.10 Location Safety Information In selecting a location for the stove, consider the Due to the high operating temperatures this following points: appliance should be located out of traffic and 1) Heat distribution away from furniture, draperies, etc. Maintain 2) Vent termination requirements proper clearance to combustible mantels and 3) Gas supply line routing... -
Page 7: Clearances
137945_Rev_F 7.29.10 Stove and Vent Clearance Requirements Minimum Clearances from the Stove to Combustibles See figs. 2-3. 2” Rear: 2” (51 mm) - measured from Draft Hood (51 mm) To Rear Wall Ceiling: 32 1/4” (819 mm) - measured from stove top Corner: 3”... - Page 8 137945_Rev_F 7.29.10 Vent Requirements The GF 300 BV Allagash is specifically designed to operate using 4” Type B vent pipe components or a Listed Flexible Min. gas liner. Height • All venting components must be installed in accor- Roof Pitch in Ft.
- Page 9 137945_Rev_F 7.29.10 Venting through a Masonry or Prefabricated Manufactured Chimney • When 6” diameter decorative pipe is installed to cover the venting any Listed Flexible Gas liner must be connected directly to the stove’s draft hood. Listed termi- Storm collar nation cap •...
-
Page 10: Vent Requirements
137945_Rev_F 7.29.10 Approved B-Vent Configurations Listed B-Vent Termination Listed B-Vent Termi- Cap required. nation Cap required. Maximum NOTE: total horizontal Maximum Installation at anywhere in chimney altitude greater NOTE: venting configu- height off than 2000’ re- Installation at ration Draft Hood is quires minimum Minimum chimney altitude greater... -
Page 11: Fuel Conversion
137945_Rev_F 7.29.10 Fuel Conversion Conversion Kit Contents: • 1, regulator tower labeled for propane • 3, regulator tower screws The GF 300 BV gas stove is shipped from the factory • 1, burner orifice (#39 for NG, #53 for LPG) equipped to burn NATURAL GAS only. - Page 12 137945_Rev_F 7.29.10 Lift out the Burner Plate: NOTE: There are no screws securing the Burner to the floor of the firebox. Pull Air Shutter the Air Shutter forward and lift the burner together with shutter up and out of the stove as a unit. See fig. 8.
-
Page 13: Gas Supply Connection
137945_Rev_F 7.29.10 Pilot Head Regulator Tower Thermopile Orifice Ignitor Remove black gasket from regulator assembly Retainer Thermocouple Clip Valve Pilot Base Figure 16. Pilot orifice removal and replacement. Figure 17 Regulator assembly. Gas Supply Connection 15. Install the new regulator: Be sure the new gasket is properly positioned and tighten screws securely. -
Page 14: Gas Pressure
137945_Rev_F 7.29.10 3/8” NPT x 3/8” Flare Fitting 1/2” x 3/8” Flare Shut-off Valve 3/8” Flex Tubing 3/8”Nipple Figure 19. Pressure test points. 3/8” Union Gas Stub 3/8” Close Nipple INLET GAS PRESSURES 3/8” Shut-off Valve 1/2” x 3/8” (inches water column) Reducer Figure 18. -
Page 15: Log Set Installation
137945_Rev_F 7.29.10 PN 220729 Log Set Installation Brick Kit Note: Install the optional Antique Brick Kit 155370 before installing the logset. See page 22 and the instructions provided with that kit. The GF 300 BV logset must be installed before operating the burner. -
Page 16: Flame Adjustment
137945_Rev_F 7.29.10 Flame Appearance / Air Shutter Optional Wall Thermostat or Adjustment Remote Control The GF 300 BV gas stove is shipped from the factory Use only a 750 millivolt DC two-wire circuit thermostat equipped to burn Natural gas. If the stove has been with this appliance. -
Page 17: Decorative Pipe
The use of decorative pipe is optional. No decorative for the first time, it will take a few moments to clear pipe is included with the Jøtul GF 300 BV Allagash, the gas line of air. Once this purge is complete, the... -
Page 18: Operation
137945_Rev_F 7.29.10 If a vacuum is used during any service on the stove, WARNING: AIR SHUTTER ADJUSTMENTS SHOULD ONLY BE ALWAYS be sure the stove is cold and there are NO hot PERFORMED BY A QUALIFIED PROFESSIONAL embers. SERVICE TECHNICIAN. 5. -
Page 19: Maintenance
137945_Rev_F 7.29.10 Maintenance Your Jøtul GF 300 BV Allagash and its venting system should be inspected before use and at least annually by a FOR REPLACEMENT, USE ONLY JØTUL CERAMIC GLASS qualified service technician. REPLACEMENT KIT 155599. DO NOT USE ANY OTHER TYPE OF GLASS WITH THIS APPLIANCE. -
Page 20: Optional Blower
137945_Rev_F 7.29.10 Optional Blower # 155620 CONNECT THE GAS SUPPLY TO THE STOVE BEFORE INSTALLING THIS BLOWER. IF NECESSARY, USE A 90° ELBOW OFF THE GAS VALVE TO CREATE ADEQUATE GAS LINE CLEARANCE. BE SURE ALL WIRE CONNECTIONS HAVE BEEN MADE BEFORE CONNECTING TO POWER SUPPLY. -
Page 21: Blower Operation
137945_Rev_F 7.29.10 Figure 35. Attach Blower to the stove bottom and connect wires to Snapstat and female Male control quick connect. Quickconnector Snapstat Connectors Female M6 x 20 mm Hex Bolts Blower Operation The optional variable-speed blower will enhance heat BLOWER circulation around the firebox and out into the room. -
Page 22: Optional Antique Brick Kit
137945_Rev_F 7.29.10 Optional Antique Brick Kit # 155648 CAUTION! Figure 39. THE BRICK PANELS AND LOG PARTS ARE EX- Disengage the TREMELY FRAGILE. HANDLE WITH CARE. compression latches to remove the glass Read these instructions before beginning the installation. frame. 1. -
Page 23: High Altitude Adjustment
137945_Rev_F 7.29.10 High Altitude Adjustment Installations burning natural gas and located at altitudes Replace with #40 from 2000 - 4500 ft. (610 M - 1370 M), require compensa- orifice tion for the thinner air (less volume of air per cubic foot). Higher altitudes affect the atmospheric pressure and heat value of gaseous fuels. -
Page 24: Illustrated Parts Breakdown
137945_Rev_F 7.29.10... -
Page 25: Replacement Parts List
137945_Rev_F 7.29.10 GF 300 BV Allagash Parts List Blue Black Ivory Jøtul Iron Brown Blue Cast Iron Parts Matte Black Jøtul Iron Enamel Enamel Enamel Majolica Majolica Enamel Enamel Side Plate 10203292 10203285 102033 10203229 10203246 10203247 10203248 Base Plate... -
Page 26: Warranty Statement
137945_Rev_F 7.29.10 Jøtul Gas Product Limited Warranty 3) Damage due to service performed by an installer, service agency or gas This warranty policy applies to gas products identified supplier, unless otherwise agreed to in writing by JØTUL. by Jøtul, Scan, and Atra trade names, as set forth below. 4) Labor or other costs associated with the repair of gas controls, A. -
Page 27: Lighting Instructions
137945_Rev_F 7.29.10 LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING. WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUS- ING PROPERTY DAMAGE, PERSONAL INJURY, OR LOSS OF LIFE. A. This appliance has a pilot which must be lit •... -
Page 28: Gorham, Maine
137945_Rev_F 7.29.10 This appliance must be installed in conformance with local and national building regulations. Before beginning the installation, it is important that the these instructions be carefully read and understood. Jøtul maintains a policy of continual product development. Consequently, products may differ in speci- fication, color or type of accessories from those illustrated or described in various publications.
