Owner's Operator and Maintenance Manual
Pronto
M91
Base
®
™
with SureStep
®
DEALER: This manual MUST be given to
the user of the wheelchair.
USER: BEFORE using this wheelchair, read
this manual and save for future reference.
For more information regarding
Invacare products, parts, and services,
please visit www.invacare.com

Advertisement

Table of Contents
loading

Related Manuals for Invacare Wheelchair Pronto M91 Base

Summary of Contents for Invacare Wheelchair Pronto M91 Base

  • Page 1 SureStep ® DEALER: This manual MUST be given to the user of the wheelchair. USER: BEFORE using this wheelchair, read this manual and save for future reference. For more information regarding Invacare products, parts, and services, please visit www.invacare.com...

  • Page 2: Reference Documents

    ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. REFERENCE DOCUMENTS Refer to the table below for part numbers of additional documents which are referenced  in this manual.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS REFERENCE DOCUMENTS ... 2 REGISTER YOUR PRODUCT ... 6 SPECIAL NOTES ... 7 LABEL LOCATIONS ... 9 M91 Standard...9 M91 Heavy Duty...10 Wheelchairs With TRRO...11 Wheelchairs Without TRRO...11 TYPICAL PRODUCT PARAMETERS ... 12 Pronto M91...12 SECTION 1—GENERAL GUIDELINES ... 13 Controller Settings/Repair or Service ...13 Accessories Information ...13 Operation Information ...13...
  • Page 4 TABLE OF CONTENTS Safety Inspection Checklists...26 Inspect/Adjust Initially ...26 Inspect/Adjust Weekly...27 Inspect/Adjust Monthly...27 Inspect/Adjust Periodically...27 Troubleshooting - Mechanical ...28 Troubleshooting - Electrical...28 SPJ+, SPJ+ w/PSS or SPJ+ w/ACC Joysticks ...28 MPJ+, PSR+, PSF+ Joysticks or Displays ...30 Checking Battery Charge Level...31 SECTION 5—WHEELCHAIR OPERATION ...
  • Page 5 TABLE OF CONTENTS Disconnecting/Connecting the Joysticks ...44 SPJ+ Joysticks ...44 Disconnecting ...44 Connecting ...44 MPJ+ Joysticks...45 SECTION 6—SEAT ... 46 Removing/Installing the Seat Assembly...46 Removing ...46 Installing...47 Tilting the Seat Assembly...47 Tilting the Seat Assembly Back ...48 Tilting the Seat Assembly Forward ...48 SECTION 7—FOOTBOARD ASSEMBLY ...

  • Page 6: Register Your Product

    Register ONLINE at warranty.invacare.com Please have your model number and purchase date available to complete your registration. Any registration information you submit will only be used by Invacare Corporation and protected as required by applicable laws and regulations. Pronto® M91™Base with SureStep®...

  • Page 7: Special Notes

    CHANGE WITHOUT NOTICE. WHEELCHAIR USER As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.
  • Page 8 The drive behavior initially experienced by the user may be different from other chairs previously used. This Power Wheelchair has Invacare’s SureStep technology, a feature that provides the wheelchair with optimum traction and stability when driving forward over transitions and thresholds of up to 3-inches.

  • Page 9: Label Locations

    LABEL LOCATIONS LABEL LOCATIONS M91 Standard NOTE: The serial number  label is located on the inside  of the right rear frame.  Part No 1143153 Pronto® M91™Base with SureStep®...

  • Page 10: M91 Heavy Duty

    M91 Heavy Duty Pronto® M91™Base with SureStep® NOTE: The serial number  label is located on the inside  of the right rear frame.  Part No 1143153...

  • Page 11: Wheelchairs With Trro

    Wheelchairs With TRRO NOTE: Also  on opposite  side. Wheelchairs Without TRRO NOTE: Auto style seat positioning  strap shown. This label is also on the  airline style seat positioning strap. Part No 1143153 NOTE: Also  on opposite  side. NOTE: Also  on opposite  side. Pronto® M91™Base with SureStep®...

  • Page 12: Typical Product Parameters

    TYPICAL PRODUCT PARAMETERS Pronto M91 SEAT-TO-FLOOR: OVERALL WIDTH (NO JOYSTICK): OVERALL HEIGHT: OVERALL LENGTH: DRIVE WHEELS/TIRES: CASTERS: WEIGHT W/SEATING SYSTEM AND ACCESSORIES W/O BATTERIES: W/BATTERIES: SHIPPING: BATTERIES: INCLINE CAPABILITY: PERFORMANCE SPEED Standard: Heavy Duty: TURNING RADIUS: *RANGE (VARIABLE) Standard: Heavy Duty: **WEIGHT LIMITATION Standard: Heavy Duty:...

  • Page 13: Section 1-General Guidelines

    SECTION 1—GENERAL GUIDELINES SECTION 1—GENERAL GUIDELINES WARNING SECTION 1 - GENERAL GUIDELINES contains important information for the safe operation and use of this product. Controller Settings/Repair or Service Set‐up of the Electronic Control Unit is to be performed ONLY by a qualified technician.  The final adjustments of the controller may affect other activities of the wheelchair.  Damage to the equipment could occur if improperly set‐up or adjusted. DO NOT service or adjust your wheelchair while occupied, unless otherwise noted. Wheelchairs should be examined during maintenance for signs of corrosion (water  exposure, incontinence, etc.). Electrical components damaged by corrosion should be  replaced IMMEDIATELY.  Wheelchairs that are used by incontinent users and/or are frequently exposed to water  may require replacement of electrical components more frequently. TRANSPORT READY PACKAGES ARE NOT RETROFITTABLE TO EXISTING  MODELS AND ARE NOT FIELD SERVICEABLE. Accessories Information EXTREME care should be exercised when using oxygen in close proximity to electric ...
  • Page 14 DO NOT attempt to reach objects if you have to move forward in the seat. DO NOT attempt to reach objects if you have to pick them up from the floor by reaching  down between your knees. DO NOT lean over the top of the back upholstery to reach objects behind you, as this may  cause the wheelchair to tip over. ALWAYS keep hands and fingers clear of moving parts to avoid injury. DO NOT store items under seat ‐ interference with seat latch may result. DO NOT use an escalator to move a wheelchair between floors. Serious bodily injury may  occur. DO NOT engage or disengage the motor release levers until the power is in the Off  position. DO NOT attempt to stop a moving wheelchair with wheel locks. Wheel locks are not  brakes. DO NOT operate on roads, streets or highways. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. NEVER leave an unoccupied wheelchair on an incline. Invacare strongly recommends proceeding down ramps or slopes at half speed or slower  and to avoid hard braking or sudden stops. DO NOT leave elevating legrests in the fully extended position when proceeding down  ramps or slopes. DO NOT attempt to move up or down an incline with a water, ice or oil film. DO NOT attempt to drive over curbs or obstacles. Doing so may cause your wheelchair  to turn over and cause bodily harm or damage to the wheelchair. DO NOT leave the power button in the On position when entering or exiting your  wheelchair. DO NOT attempt to lift the wheelchair by any removable (detachable) parts. Lifting by  means of any removable (detachable) parts of the wheelchair may result in injury to the  user or damage to the wheelchair. DO NOT stand on the frame of the wheelchair. DO NOT stand on the footplates/footboard. When getting in or out of the wheelchair,  make sure that the footboard or footplates are in the upward position or swing the  footrests towards the outside of the wheelchair. Pronto® M91™Base with SureStep® Part No 1143153...

  • Page 15: Batteries

    Before attempting to transfer in or out of the wheelchair, every precaution should be  taken to reduce the gap distance. Turn both casters parallel to the object you are  transferring onto. Also be certain the power is Off and wheel locks are engaged to prevent  the wheels from moving. DO NOT adjust the rear seat posts higher than the front seat posts. Before performing any maintenance, adjustment or service verify that On/Off switch on  the joystick is in the Off position. ALWAYS wear your seat positioning strap. The seat positioning strap is a positioning belt  only. It is not designed for use as a safety device withstanding high stress loads such as  auto or aircraft safety belts. If signs of wear appear, belt must be replaced IMMEDIATELY. With regards to seat/chest positioning straps ‐ it is the obligation of the DME dealer,  therapists and other healthcare professionals to determine if a seat/chest positioning strap  is required to ensure the safe operation of this equipment by the user. Serious injury can  occur in the event of a fall from a wheelchair. Avoid storing or using the wheelchair near open flame or combustible products. Serious  injury or damage to property may result. Batteries The warranty and performance specifications contained in this manual are based on the  use of deep cycle gel cell batteries. Invacare strongly recommends their use as the power  source for this unit. Carefully read battery/battery charger information prior to installing, servicing or  operating your wheelchair. DO NOT remove fuse or mounting hardware from POSITIVE (+) RED battery cable/ mounting screw. All battery terminal covers (two on the front battery and two on the rear battery) MUST  be installed prior to use. The use of rubber gloves is recommended when working with batteries. Some battery manufacturers mold a carrying strap and/or hold down flanges directly into  the battery case. Batteries that interfere with the battery box cannot be used for these  applications. Attempting to “wedge” a battery into a battery box may damage the box,  the battery and/or be a fire hazard, resulting in serious injury or further damage to  property. Part No 1143153 Pronto® M91™Base with SureStep®...

  • Page 16: Charging Batteries

    NEVER attempt to recharge the batteries by attaching cables directly to the battery terminals. DO NOT attempt to recharge the batteries and operate the wheelchair at the same time. DO NOT operate wheelchair with extension cord attached to the AC cable. DO NOT attempt to recharge the batteries when the wheelchair has been exposed to ANY  type of moisture. DO NOT attempt to recharge the batteries when the wheelchair is outside. DO NOT sit in the wheelchair while charging the batteries. DO NOT attempt to recharge batteries using BOTH the on‐board battery charger and an  independent battery charger (plugged into the joystick charger port) at the SAME time.  Doing so will reduce the life of the batteries. READ and CAREFULLY follow the manufacturer’s instructions for each charger  (supplied or purchased). If charging instructions are not supplied, consult a qualified  technician for proper procedures. AFTER charging batteries, ALWAYS make sure that the battery charger cord is securely  wrapped and stored within the hook and loop strap assembly on the rear of the battery  tray. Failure to do so may result in damage to the cord or personal injury to the user or  bystanders. Ensure the pins of the extension cord plug are the same number, size, and shape as those  on the charger. DO NOT under any circumstances cut or remove the round grounding plug from the  charger AC cable plug or the extension cord plug. Grounding Instructions DO NOT, under any circumstances, cut or remove the round grounding prong from any  plug used with or for Invacare products. Some devices are equipped with three‐prong  (grounding) plugs for protection against possible shock hazards and fire. Where a two‐ prong wall receptacle is encountered, it is the personal responsibility and obligation of the  customer to contact a qualified electrician and have the two‐prong receptacle replaced with  a properly grounded three‐prong wall receptacle in accordance with the National Electrical  Code. If you must use an extension cord, use ONLY a three‐wire extension cord having the  same or higher electrical rating as the device being connected. In addition, Invacare has  placed RED/ORANGE warning tags on some equipment. DO NOT remove these tags. Pronto® M91™Base with SureStep® Part No 1143153...

  • Page 17: Rain Test

    Rain Test Invacare has tested its power wheelchairs in accordance with ISO 7176 “Rain Test.” This  provides the end user or his/her assistant sufficient time to remove his/her power  wheelchair from a rain storm and retain wheelchair operation. DO NOT leave power wheelchair in a rain storm of any kind. DO NOT use power wheelchair in a shower. DO NOT store power wheelchair in a damp area for an extended period of time. Direct exposure to excessive rain or dampness may cause the wheelchair to malfunction  electrically and mechanically, may cause the wheelchair to prematurely rust or may  damage the upholstery. Check to ensure that the RED and BLACK battery terminal caps are secured in place,  joystick boot is NOT torn or cracked where water can enter and that all electrical  connections are secure at all times. DO NOT use the wheelchair if the joystick boot is torn or cracked. If the joystick boot  becomes torn or cracked, replace IMMEDIATELY. Weight Training Invacare DOES NOT recommend the use of its wheelchairs as a weight training  apparatus. Invacare wheelchairs have NOT been designed or tested as a seat for any kind  of weight training. If occupant uses said wheelchair as a weight training apparatus,  Invacare shall NOT be liable for bodily injury and the warranty is void. Weight Limitation The Pronto M91 wheelchairs have the following weight limitations: MODEL STANDARD HEAVY DUTY Part No 1143153 WEIGHT LIMITATION 300 lb 400 lb Pronto® M91™Base with SureStep®...

  • Page 18: Section 2-Emi Information

    SECTION 2—EMI INFORMATION CAUTION: IT IS VERY IMPORTANT THAT YOU READ THIS INFORMATION REGARDING THE POSSIBLE EFFECTS OF ELECTROMAGNETIC INTERFERENCE ON YOUR POWERED WHEELCHAIR. Electromagnetic Interference (EMI) From Radio Wave Sources Powered wheelchairs and motorized scooters (in this text, both will be referred to as powered wheelchairs) may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two way radios, and...
  • Page 19 2) This device has been tested to a radiated immunity level of 20 volts per meter; 3) The immunity level of the product is unknown. Modification of any kind to the electronics of this wheelchair as manufactured by Invacare may adversely affect the EMI immunity levels. Part No 1143153 WARNING...

  • Page 20: Section 3-Safety/Handling Of Wheelchairs

    IMMEDIATELY. DO NOT climb, go up or down ramps or traverse slopes greater than 9°. Invacare strongly recommends proceeding down ramps or slopes at half speed or slower and to avoid hard braking or sudden stops. DO NOT leave elevating legrests in the fully extended position when proceeding down ramps or slopes.

  • Page 21: Coping With Everyday Obstacles

    Many activities require the wheelchair user to reach, bend and transfer in and out of the wheelchair. These movements will cause a change to the normal balance, center of gravity, and weight distribution of the wheelchair. To determine and establish your particular safety limits, practice bending, reaching and transferring activities in several combinations in the presence of a qualified healthcare professional BEFORE attempting active use of the wheelchair.

  • Page 22: Pinch Points

    SECTION 3—SAFETY/HANDLING OF WHEELCHAIRS Pinch Points Pinch WARNING Point Pinch point may occur when returning the tilted seat to the full upright position. Make sure the hands and body of the occupant, attendants and bystanders are clear of all pinch points before lowering seat (FIGURE 3.2).

  • Page 23: Lifting/Stairways

    MUST be removed and transported independently of the power wheelchair. Extreme caution is advised when it is necessary to move an unoccupied power wheelchair up or down the stairs. Invacare recommends using two assistants and making thorough preparations. Use ONLY secure, nondetachable parts for hand-hold supports.

  • Page 24: Transferring To And From Other Seats

    Transferring To and From Other Seats ALWAYS turn the wheelchair power Off and engage the motor release levers to prevent the wheels from moving before attempting to transfer in or out of the wheelchair. Also, make sure every precaution is taken to reduce the gap distance by aligning both the front AND rear casters parallel with the object you are transferring onto.

  • Page 25: Reaching, Leaning And Bending - Forward

    Reaching, Leaning and DO NOT attempt to reach objects if you have to move forward in the seat or pick them up from the floor by reaching down between your knees. NOTE: For this procedure, refer to FIGURE 3.6. Position the front and rear casters so that they are extended as far forward as possible and  engage Motor Release Levers.  FIGURE 3.6 Reaching, Leaning and Bending - Forward Reaching and Bending - Backward DO NOT lean over the top of the back upholstery.

  • Page 26: Section 4-Safety Inspection/Troubleshooting

    SECTION 4—SAFETY INSPECTION/ TROUBLESHOOTING NOTE: Every six months or as necessary take your wheelchair to a qualified dealer for a thorough  inspection and servicing. Regular cleaning will reveal loose or worn parts and enhance the smooth  operation of your wheelchair. To operate properly and safely, your wheelchair must be cared for just  like any other vehicle. Routine maintenance will extend the life and efficiency of your wheelchair. Safety Inspection Checklists As with any vehicle, wheels and tires should be checked periodically for cracks and wear and should be replaced as necessary. Initial adjustments should be made to suit your personal body structure needs and  preference. Thereafter follow these maintenance procedures: Inspect/Adjust Initially ❑ Ensure wheelchair rolls straight (no excessive drag or pull to one side). ❑ Ensure arms are secure but easy to release and adjustment levers engage properly (on  ASBA only).

  • Page 27: Inspect/Adjust Weekly

    Inspect/Adjust Weekly ❑ Ensure seat is secured to wheelchair frame. ❑ Ensure seat and/or back upholstery have no rips and do not sag. Replace if necessary. ❑ Ensure seat release latch is not worn and is functional. Replace if necessary. ❑ Inspect tires for flat spots and wear. ❑ Ensure arm pivot points are not worn and/or loose. Replace if necessary. ❑ Inspect and clean the stability lock gears. Replace if worn. ❑ Ensure casters are free of debris. Inspect/Adjust Monthly ❑ Ensure wheel mounting nuts are secure on drive wheels. ❑ Ensure there is no excessive side movement or binding when drive wheels are lifted  and spun when disengaged (free‐wheeling). ❑ Ensure wheel/fork assembly has proper tension when caster is spun. Caster should  come to a gradual stop. ❑ Loosen/tighten caster locknut if wheel wobbles noticeably or binds to a stop. ❑ Ensure all caster/wheel/fork/headtube fasteners are secure. ❑ Inspect for any loose hardware on the wheelchair. ❑ Inspect the seat positioning strap for signs of wear. Replace if worn or damaged. ❑ Ensure that the buckle on the seat positioning strap latches. Replace if necessary. ❑ Verify that the hardware that attaches the seat positioning strap to the seat frame is  secure and undamaged. Replace if necessary. ❑ Ensure casters are free of debris. Inspect/Adjust Periodically ❑...

  • Page 28: Troubleshooting - Mechanical

    ❑ Inspect and clean the stability lock gears. Replace if worn. ❑ Clean upholstery and armrests. ❑ Inspect charger AC power cord for damage. Replace if necessary. ❑ Check that wiring is routed and secured properly to ensure that wiring does NOT  become entangled and damaged. ❑ Inspect electrical components for signs of corrosion. Replace if corroded or damaged. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Ensure casters are free of debris. Troubleshooting - Mechanical Troubleshooting - Electrical NOTE: For additional troubleshooting information and explanation of error codes, refer to the  individual Electronics Manual supplied with each wheelchair SPJ+, SPJ+ w/PSS or SPJ+ w/ACC Joysticks The joystick information gauge and the service indicator give indications of the type of  fault or error detected by the control module. When a fault is detected, the wheelchair  may stop and not drive. The LEDs on the information gauge may flash in a particular  pattern or the service indicator light will flash. The number or type of flashes indicates the  nature of the error. If multiple errors are found, only the first error encountered by the  control module will be displayed. Pronto® M91™Base with SureStep® SOLUTIONS If pneumatic, check tires for correct and equal pressure.
  • Page 29 Contact Invacare/Dealer for service. Check to make sure joystick is connected properly. Contact Invacare/Dealer for service. Contact Invacare/Dealer for service. Contact Invacare/Dealer for service. Wrong type of remote connected. Contact Invacare/Dealer for service. COMMENTS Fewer than three LEDs on implies reduced battery charge.

  • Page 30: Mpj+, Psr+, Psf+ Joysticks Or Displays

    This is normal behavior. Attendant control is active and can be used to drive the chair (Error code W05). Battery failure. Have batteries checked for shorted cell. Replace if necessary. Electrical malfunction. Contact Dealer/Invacare for service. SOLUTIONS Part No 1143153...

  • Page 31: Checking Battery Charge Level

    Part No 1143153 PROBABLE CAUSE Battery failure. Check batteries for shorted cell. Replace if necessary. Malfunctioning battery charger. Contact Dealer/Invacare for Service. Electrical malfunction. Contact Dealer/Invacare for Service. Batteries not charged. Have charger checked. Weak batteries. Replace batteries if necessary. Contact Dealer/Invacare for Service.

  • Page 32: Section 5-Wheelchair Operation

    SECTION 5—WHEELCHAIR OPERATION After ANY adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Set-up of the Electronic Control Unit is to be performed only by a qualified techni- cian.

  • Page 33: Using The Joystick To Drive The Wheelchair

    Using the Joystick to Drive the Wheelchair NOTE: For this procedure, refer to FIGURE 5.2. The joystick is located on the joystick housing and provides smooth control of speed and  direction. It is equipped with 360 degrees of mobility for ease of operation. The joystick is  spring‐loaded, and automatically returns to the upright (neutral) position when released.  Pushing the joystick in a given direction causes the wheelchair to move in that direction.  The joystick has proportional drive control, meaning that the further it is pushed from the  upright (neutral) position, the faster the wheelchair moves. The maximum speed,  however, is limited by the setting of the speed‐control knob. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. When first learning to drive, select a slow speed and try to drive the wheelchair as slowly  as possible by pushing the joystick slightly forward. This exercise will help you learn to  utilize the full potential of the proportional control and allow you to start and stop  smoothly. To drive the wheelchair, perform the following: 1. Adjust speed control knob to the appropriate setting. 2. Turn the power On. Refer to Turning the Power On/Off on page 32. 3. Maneuver the joystick in the following manner: MOVEMENT ACTION FORWARD Push joystick forward, towards the front of the wheelchair. REVERSE Pull joystick back, towards the rear of the wheelchair.

  • Page 34: Spj+, Mk6I Spj+ W/Pss And Mk6I Spj+ W/Acc Joystick Switches And Indicators

    SPJ+, MK6i SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators NOTE: For the following information, refer to FIGURE 5.3. On/Off Button Decrease Speed Button (Tortoise) GREEN Service Indicator *NOTE: The mode button is only  present on SPJ+ w/ACC joystick. FIGURE 5.3 SPJ+, MK6i SPJ+ w/PSS and MK6i SPJ+ w/ACC Joystick Switches and Indicators On/Off Button This button is located at the front of the joystick housing. It is used to turn the wheelchair ...

  • Page 35: Speed Control Buttons

    Speed Control Buttons The speed control buttons (tortoise button ( adjust the maximum speed. 1. To adjust the speed, perform one of the following: • Adjust Speed in 20% Increments (5 Speed Mode) ‐ Press the tortoise button ( or hare button ( ) to decrease/increase the speed in 20% increments. The larger  bars in the speedometer will light. • Adjust Speed in Smaller Increments (VSP Mode) ‐ Perform the following steps: i. Press and hold both the tortoise button ( joystick beeps. ii. Perform one of the following: • Press the tortoise button ( speed in 20% increments. The larger bars in the speedometer will light. • Press and hold the tortoise button ( increase the speed in smaller increments. The smaller bars in the  speedometer will light. Joystick The joystick has proportional drive control, meaning that the further the joystick is  pushed from the upright (neutral) position, the faster the wheelchair or seat moves. Your  top speed, however, is limited by the programmed settings. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. Charger/Programming Input The charger/programming input is located at the front of the joystick housing. This  provides easy access for charging the wheelchair batteries. This port also serves as the  Remote Programmer Communication connection. Driving is prevented while the system  is charging. Service Indicator The AMBER service indicator will light when an error or fault occurs. Refer to Service ...

  • Page 36: Information Gauge Display

    Information Gauge Display The information gauge display is located on the front of the joystick housing and provides  the following information to the user on the status of the wheelchair: 1. Power is On. 2. True state‐of‐battery‐charge, including notification of when the battery requires  charging: A. GREEN LEDs are lit, indicating well charged batteries. B. AMBER LEDs are lit, indicating batteries are moderately charged. Recharge  batteries before taking a long trip. C. RED LEDs are lit, indicating batteries are running out of charge. Recharge batteries  as soon as possible.  The Information Gauge display also serves as a system diagnostic device when a fault is  detected by the control module. A specific number of flashes of the LEDs indicate the type  of fault detected. Refer to Information Gauge Display Diagnostics on page 33 for the  diagnostic indications of the wheelchair status. Pronto® M91™Base with SureStep® Part No 1143153...

  • Page 37: Mpj+ Joystick Switches And Indicators

    MPJ+ Joystick Switches and Indicators NOTE: For this procedure, refer to FIGURE 5.4. Drive Select Toggle Switch The drive select toggle switch is located on the left side, below the LCD. The drive select  position is momentary, meaning that it will return to the neutral position after a selection  is made. This switch allows the operator to select the type of operation or performance which best  suits a particular control need or situation. The DRIVE 1 program uses performance  values which are independent of those used for the DRIVE 2 or 3 or 4 program. As an  example, an operator may have a control need for spasticity in the morning and a very  different need in the afternoon. DRIVE 1 can be programmed for higher speeds and  quicker response while DRIVE 2 can be programmed for slower speeds and less  responsiveness or vise versa. The other two drive programs could be indoor and outdoor  versions of DRIVE 1 and DRIVE 2. Selecting the Drive Mode 1. Move the toggle up and release. DRIVE 1 ( 2. Move the toggle up and release again. DRIVE 2 ( 3. Move the toggle up and release again. DRIVE 3 ( 4. Move the toggle up and release again. DRIVE 4 ( 5. Move the toggle up and release one more time to select DRIVE 1 ( Charger/Programming Input (Front of Joystick) Drive Select Toggle Switch Programmable Joystick...

  • Page 38: Joystick

    SECTION 5—WHEELCHAIR OPERATION 2. Rotate the knob counterclockwise (backward) to decrease the speed of the wheelchair  to the programmed max speed. Joystick The joystick has proportional drive control, meaning that the further the joystick is  pushed from the upright (neutral) position, the faster the wheelchair or seat moves. Your  top speed, however, is limited by the programmed settings. To slow the wheelchair to a stop, simply release the joystick. The wheelchair has  automatic speed and direction compensation to minimize corrections. Charger/Programming Input The charger/programming input is located at the front of the joystick housing. This  provides easy access for charging the wheelchair batteries. This port also serves as the  Remote Programmer Communication connection. Driving is prevented while the system  is charging. LCD Display Screens The LCD Display is located in front of the joystick and provides information on the status  of the wheelchair through a backlit display. The LCD display is readable in both bright  sunlight and complete darkness. Splash Screen NOTE: For this procedure, refer to   FIGURE 5.5. This screen is displayed at startup of the  joystick for about 2 seconds. This screen  displays the software version and date  information. After this screen, the joystick displays the  Main Screen. FIGURE 5.5 LCD Display Screens - Splash Screen Main Screen NOTE: For this information, refer to FIGURE 5.6 on page 40.

  • Page 39: Lcd Display

    Refer to LCD Display table on page 39 for descriptions of information shown. ITEM DRIVE NAME This field shows the currently selected Drive’s Name. Available choices are as follows: *NOTE: Drive names can be customized. Actual drive names may display differently. BATTERY LEVEL This symbol shows the Battery Level and will change depending on the available INDICATOR battery power.
  • Page 40 SECTION 5—WHEELCHAIR OPERATION Drive Profile Name Available Modes in Battery Gauge Display Drive Indicator this Drive (Must be Programmed) Icon appears when a joystick command Status will drive the Status/Info Indicator wheelchair Message Area FIGURE 5.6 LCD Display Screens - Main Screen Driving Screen NOTE: For this procedure, refer to ...

  • Page 41: Programmable Mono Port 1/2 Or External Mode Switch

    FIGURE 5.8 LCD Display Screens - Connected Devices Screen Programmable Mono Port 1/2 or External Mode Switch The programmable mono port or external mode switch input is located at the rear of the  joystick on the left side. The programmable mono port input offers the choice of three  options: • Remote drive select • Remote stop/mode (reset) input • Single actuator input The single switch functions operate through mono port 1. An optional y‐cable allows a  second programmable function through mono port 2. Remote Stop Switch The remote stop switch is used to stop the wheelchair. Remote Mode (Reset) Switch The remote mode reset switch functions the same way as the mode switch. Refer to Mode  Switch on page 42. Remote On/Off Switch The remote On/Off switch input is located at the rear of the joystick on the right side and ...

  • Page 42: Mode Switch

    Mode Switch NOTE: For this procedure, refer to FIGURE 5.4. The mode switch is used to select the operating mode for the wheelchair. The mode  switch is located on the joystick. A mode switch is needed whenever any of the following  operating modes are programmed: • Environmental Controls (ECU 1, ECU 2, ECU 3, ECU 4)* • 3 Speed Mode in Digital 3 Speed (Slow, Medium, Full) • Latched Modes • Sleep Mode • RIM Mode* • Remote Drive Selection Mode* • Tilt/Recline Mode* • Information Center Display Selection (does not require Reset activation at power up) If any of the above modes are selected, the control will require activation of the switch  immediately after the power switch is turned On in order to enter the drive mode. The  second line of the LCD will display ‐ PRESS RESET. *NOTE: In these modes, Standby Select allows the reset switch to be bypassed for users unable to  activate the switch. Memory Card Slot The memory card slot is used with the basic or professional memory card for saving or  reading wheelchair parameters.  Preparing the Joystick for Use NOTE: For this procedure, refer to FIGURE 5.9. NOTE: The joystick is factory installed on the right side of the wheelchair. To reposition the joystick ...

  • Page 43: Repositioning The Joystick

    Repositioning the Joystick Adjustable ASBA Seat NOTE: For this procedure, refer to FIGURE 5.10. 1. Turn the adjustment lock lever to  release the joystick mounting tube from  the mounting bracket. 2. Remove the joystick from the wheelchair. 3. Remove the three hex screws that  secure both halves of the mounting  bracket to the arm tube. 4. Reposition mounting bracket on  opposite arm tube ensuring the  threaded plate of the mounting bracket  is on the inside of the arm tube as  shown in FIGURE 5.10. 5. Using the three hex mounting screws and washers, secure both halves of the mounting  bracket to the arm tube. 6. Slide the joystick mounting tube through the mounting bracket to the desired position. 7. Turn the adjustment lock lever to secure the joystick mounting tube into the mounting  bracket. Van Seat NOTE: For this procedure, refer to FIGURE 5.11. NOTE: Take note of position and orientation of mounting hardware for reinstalling the joystick  assembly. 1. Turn the adjustment lock lever to release the joystick mounting tube from the  mounting bracket.

  • Page 44: Disconnecting/Connecting The Joysticks

    6. If necessary, perform the following to reposition the adjustment lock: A. Slide the adjustment lock from the mounting bracket. B. Rotate adjustment lock 180° and slide adjustment lock over the opposite end of the  mounting bracket. 7. Slide joystick mounting tube through the mounting bracket to the desired position  and secure adjustment lock to tube by turning lever on adjustment lock. NOTE: MK5 SPJ‐80 joystick  shown, all other joysticks  reposition in the same way. Hex Mounting Screws Adjustment Lock Lever FIGURE 5.11 Repositioning the Joystick - Van Seat Disconnecting/Connecting the Joysticks NOTE: For this procedure, refer to FIGURE 5.12. NOTE: The joystick connector is located at the rear of the seat frame. SPJ+ Joysticks Disconnecting 1. Hold the light GREY collar portion of the joystick connector with one hand and the  controller connector on the wheelchair in the other and disconnect them by pulling  them apart. Connecting The joystick connector and controller connector fit together in one way only.

  • Page 45: Mpj+ Joysticks

    SECTION 5—WHEELCHAIR OPERATION MPJ+ Joysticks NOTE: For this procedure, refer to FIGURE 5.13. Disconnecting 1. Pull the latch away from the joystick connector. 2. Disconnect the joystick connector from the remaining connectors. Connecting 1. Ensure the latch is pulled away from the joystick connector. 2. Connect the joystick connector to the other connectors. 3. Push the latch in to secure the joystick connector to the other connectors. Joystick Connector Latch Other Connectors FIGURE 5.13 Disconnecting/Connecting the Joysticks - MPJ+ Joysticks Part No 1143153 Pronto® M91™Base with SureStep®...

  • Page 46: Section 6-Seat

    SECTION 6—SEAT After any adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that On/Off switch on the joystick is in the Off position. Removing/Installing the Seat Assembly DO NOT store items under seat - interference with seat latch may result.

  • Page 47: Installing

    Installing 1. Position the seat in the rear pivot brackets as shown in FIGURE 6.1. 2. Tilt front edge of seat down. 3. When seat is lowered, engage seat brackets into seat clevis pins. When reinstalling the seat verify that the seat brackets are engaged with the seat clevis pins by pulling up on the latch bar. 4. Pull up on latch bar to verify that brackets are engaged with seat clevis pins. 5. Connect the joystick. Refer to Disconnecting/Connecting the Joysticks on page 44. (located under the front of the seat) FIGURE 6.1 Removing/Installing the Seat Assembly Tilting the Seat Assembly NOTE: For this procedure, refer to FIGURE 6.2 on page 48.

  • Page 48: Tilting The Seat Assembly Back

    Tilting the Seat Assembly Back 1. Place the wheelchair in a well ventilated area where work can be performed without  risking damage to carpeting or floor covering. 2. Use the tilt function to tilt the seat back 20° to 25°. 3. Verify the joystick On/Off switch is in the Off position and disconnect joystick cable. 4. Engage the motor release levers. Refer to Engaging/Disengaging Motor Release Lever  on page 54. 5. Remove the footboard. Refer to Removing/Installing the Footboard Assembly on  page 49. 6. Remove the two screws and washers securing the Formula PTO Plus frame to the front  seat posts. 7. Firmly grasp the front edge of the seat assembly, slowly tilt the seat assembly back into  the up/open position. 8. Remove prop rod from the clip located on the Formula PTO Plus frame and engage  the prop rod end into the front seat post as shown in FIGURE 6.2. 9. Gently allow weight of seat assembly to be supported by the prop rod. NOTE: Only leave the seat assembly in the up/open position while performing any necessary  procedures. Always lower the seat assembly to the down/closed position when not servicing the  wheelchair and ensure it is in the locked position before using. Tilting the Seat Assembly Forward 1.

  • Page 49: Section 7-Footboard Assembly

    SECTION 7—FOOTBOARD ASSEMBLY After any adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that On/Off switch on the joystick is in the Off position. Pinch point may occur when rotating the footboard assembly.

  • Page 50: Adjusting The Footboard Assembly

    Wheelchair Frame Mounting Hole Quick Detent Release Ball FIGURE 7.1 Removing/Installing the Footboard Assembly Adjusting the Footboard Assembly Angle NOTE: For this procedure, refer to FIGURE 7.2. 1. Loosen the jam nut and set screw located underneath on the back of the footplate. 2. Adjust the set screw in or out to obtain the desired footboard assembly angle. 3. Thread the jam nut and washer inward until it is flush with the footboard bracket. 4. Securely tighten the jam nut and washer to secure the mounting screw in place. FIGURE 7.2 Adjusting the Footboard Assembly - Angle Pronto® M91™Base with SureStep® Quick Release Pin Footboard...

  • Page 51: Depth

    Depth NOTE: For this procedure, refer to FIGURE 7.3. 1. Remove the quick release pin that secures the footboard assembly to the wheelchair  frame. Make sure the detent balls of the quick release pin are fully released and protruding past the outer edge of the tube before operating the wheelchair. Otherwise, injury and/or damage may result. Keep detent balls clean. 2.

  • Page 52: Section 8-Shroud/Wheels

    SECTION 8—SHROUD/WHEELS After any adjustments, repair or service and before use, make sure that all attaching hardware is tightened securely - otherwise injury or damage may result. Before performing any maintenance, adjustment or service verify that On/Off switch on the joystick is in the Off position. Replacing the Flat Free Tires on the Wheel Rim DO NOT attempt to replace flat free tires.

  • Page 53: Installing

    Installing 1. Perform one of the following: • Top Shroud ‐ Position top shroud on to the base frame and gently press down on  top shroud to secure the four hook and loop strips that secure the top shroud to the  base frame (Detail “A”). • Front Shroud ‐ Position front shroud onto the two base frame hooks. Turn release  knob ¼‐turn to the locked position (Detail “B”). 2. Perform one of the following: • Wheelchairs with Formula PTO Plus ‐ Tilt the seat forward. Refer to Tilting the  Seat Assembly on page 47. • Wheelchairs without Formula PTO Plus ‐ Reinstall the seat. Refer to Removing/ Installing the Seat Assembly on page 46. DETAIL “A” - TOP SHROUD Rear of Wheelchair Base Frame Hook and Loop Strips FIGURE 8.1 Removing/Installing the Shrouds Part No 1143153 DETAIL “B”...

  • Page 54: Engaging/Disengaging Motor Release Lever

    Engaging/Disengaging Motor Release Lever DO NOT engage or disengage the motor release lever until the On/Off switch on the joystick is in the Off position. Ensure both motor release levers are fully engaged before driving the wheelchair NOTE: For this procedure, refer to FIGURE 8.2. NOTE: The motor lock disengagement/engagement allows freewheeling or joystick controlled  operation. Freewheeling allows an attendant to maneuver the wheelchair without power.

  • Page 55: Replacing Front/Rear Caster Assemblies

    Replacing Front/Rear Caster Assemblies NOTE: For this procedure, refer to  FIGURE 8.3. NOTE: Front and rear caster assemblies are  replaced in the same manner. NOTE: When replacing the front/rear caster  assemblies, it is necessary to brace the caster  assemblies to prevent the wheel from spinning. 1. Remove the mounting screw, two  washers, and locknut that secures the  caster to the fork. 2. Remove the caster and discard. 3. Secure new caster to fork with existing mounting screw, two washers and locknut  (FIGURE 8.3). Securely tighten. Adjusting Forks NOTE: For this procedure, refer to FIGURE 8.4. 1. Remove the dust cover. 2. To properly tighten caster journal  system and guard against flutter,  perform the following check: A. Tip back the wheelchair. B. Pivot both forks and casters to top  of their arc simultaneously. C. Let casters drop to bottom of arc  (wheels should swing once to one‐ side, then IMMEDIATELY rest in a ...

  • Page 56: Section 9-Batteries

    DO NOT tip the batteries. Keep the batteries in an upright position. Avoid storage or use near external flame or combustible products. Invacare strongly recommends that battery installation and battery replacement always be done by a qualified technician. After any adjustments, repair or service and before use, make sure all attaching hardware is tightened securely - otherwise injury or damage may result.

  • Page 57: Installing/Removing The Batteries

    Installing/Removing the Batteries NOTE: For this procedure, refer to FIGURE 9.1 on page 58 and FIGURE 9.2 on page 59. NOTE: Have the following tools available: TOOL Battery Lifting Strap 1/2-inch (6 pt) Box Wrench 7/16-inch (6pt) Box Wrench 3/8-inch (6pt) Box Wrench Diagonal Cutters Installing 1. Place the wheelchair in a well ventilated area where work can be performed without  risking damage to carpeting or floor covering. 2. Verify the joystick On/Off switch is in the Off position and disconnect joystick. Refer  to Disconnecting/Connecting the Joysticks on page 44. 3. Perform one of the following: • Wheelchairs without Formula PTO Plus ‐ Remove the seat. Refer to Removing/ Installing the Seat Assembly on page 46. •...
  • Page 58 9. If necessary, connect the wiring harness to the two batteries. Refer to Connecting/ Disconnecting the Battery Wiring Harness on page 60. 10. Reconnect RIGHT and LEFT motor leads to allow access to the FRONT of the battery  tray, if disconnected in STEP 5. DETAIL “A” - BATTERIES WITH BUILT-IN LIFTING STRAPS Rear Battery Battery Tray FIGURE 9.1 Batteries with/without Lifting straps 11. Connect the front battery to the controller (RED connector). Refer to FIGURE 9.2. 12. Connect the rear battery to the front battery (RED and BLACK connectors). Refer to  FIGURE 9.2. 13. Reinstall the top shroud. Refer to Removing/Installing the Shrouds on page 52. 14. Perform one of the following: • Wheelchairs without Formula PTO Plus ‐ Reinstall the seat. Refer to Removing/ Installing the Seat Assembly on page 46. •...

  • Page 59: Removing

    RED Connector from Battery to Controller Front Battery Tie Wrap RED Front POSITIVE (+) Battery Terminal Mounting Screw, Nut and Fuse Hardware (Terminal Cap Shown) RED Battery Connectors RED Rear POSITIVE (+) Battery Terminal Mounting Screw, Nut and Fuse Hardware* *NOTE: Terminal cap shown removed for clarity.

  • Page 60: Connecting/Disconnecting The Battery Wiring Harness

    NOTE: Perform this section on one battery at a time starting with the FRONT battery. Repeat  STEP 10 to remove remaining battery from battery tray. 11. Perform one of the following to remove the battery from the battery tray: • Batteries With Built‐in Lifting Strap‐ Use built in lifting strap to remove the battery  from the battery tray (Detail “A” of FIGURE 9.1). • Batteries Without Built‐in Lifting Strap‐ Use the battery lifting strap to remove the  battery from the battery tray (Detail “B” of FIGURE 9.1). Connecting/Disconnecting the Battery Wiring Harness NOTE: Perform this section on one battery at a time starting with the front battery. NOTE: The front battery has three connectors ‐ two to the rear battery wiring harness (RED and  BLACK) and one to the controller cable (RED), and the rear battery has two connectors (RED and  BLACK) to the front battery wiring harness. NOTE: Both the front and rear wiring harnesses are shipped with the POSITIVE (+) RED battery  cable and mounting screw connected. Use the exposed, threaded portion of the mounting screw to  secure the POSITIVE (+) RED cable to the POSITIVE (+) terminal. DO NOT remove fuse or mounting hardware from POSITIVE (+) RED battery cable/mounting screw. All battery terminal covers (two on the front battery and two on the rear battery) MUST be installed prior to use.

  • Page 61: Disconnecting

    7. Reposition battery terminal covers over battery post(s). 8. Using new tie‐wraps, secure the terminal covers to the battery terminals as shown in  FIGURE 9.3. 9. Repeat STEPS 1‐8 to install and connect the rear battery to the rear battery harness. NEGATIVE (-) Battery Cable NEGATIVE (-) Battery Terminal Mounting Screw FIGURE 9.3 Connecting/Disconnecting the Battery Wiring Harness Disconnecting NOTE: For this procedure, refer to FIGURE 9.3 on page 61. 1. Remove the existing tie‐wraps that secure the battery terminal covers to the battery  terminals. 2. Peel back RED battery terminal cover to expose RED battery cable connection to  battery terminal. 3. Peel back BLACK battery terminal cover from BLACK battery cable on front battery  or GREY battery terminal cover from BLACK battery cable on rear battery. 4. Remove the mounting screws and nuts that secure the POSITIVE (+) RED battery cable  to the POSITIVE (+) battery terminal/post as shown in FIGURE 9.3. 5.

  • Page 62: When To Charge Batteries

    When to Charge Batteries SPJ+ Joysticks NOTE: For this procedure, refer to  FIGURE 9.4. The Information Gauge Display located on the front of the joystick housing, it provides  the state‐of‐battery charge, including notification of when the battery requires charging.  It also provides the following information to the user on the status of the wheelchair: A. GREEN LEDs are lit, indicating well  charged batteries. B. AMBER LEDs are lit, indicating  batteries are moderately charged.  Recharge batteries before taking a  long trip. C. RED LEDs are lit, indicating  batteries are running out of charge.  Recharge batteries as soon as  possible. MPJ+ Joystick NOTE: For this procedure, refer to FIGURE 9.5. The far right side of the display screen is the Battery Gauge Display (BGD). It provides  information on the remaining charge in the batteries.  At full charge, solid blocks fill in all ten  segments between E (Empty) and F (Full).  As the battery becomes discharged, the  segments will progressively disappear a  bar at a time until no segments appear  between E and F. At this level the user  should charge the batteries as soon as  possible. Pronto® M91™Base with SureStep® Information Gauge Display Batteries Empty...

  • Page 63: Charging Batteries

    SECTION 9—BATTERIES Charging Batteries DANGER When using an extension cord, use only a three wire extension cord having at least 16 AWG (American Wire Gauge) wire and the same or higher electrical rating as the devise being connected. Use of improper extension cord could result in a risk of fire and electric shock.

  • Page 64: Battery Charger Operation

    DO NOT under any circumstances cut or remove the round grounding plug from the charger AC cable plug or the extension cord plug. NOTE: For this procedure, refer to FIGURE 9.6 on page 65. NOTE: Charge indicator light is only visible with rear shroud removed. 1. Plug the female connector of the AC power cord (supplied) to the AC receptacle on  the charger and plug in the male connector on the AC power cord into the wall outlet. 2. The On/Off LED indicator illuminates solid RED indicating that the charger is On. 3. If the On/Off LED indicator is “Blinking” RED, this is abnormal. Unplug AC power  cord from the on‐board battery charger and wall outlet. Contact Invacare at the  number listed on the back page of this manual. 4. When the On/Off LED indicator light is Off, charger is Off. 5. When the Charge LED indicator light is YELLOW, the batteries are charging. 6. When the Charge LED indicator light is solid GREEN, the batteries are fully charged  (as their condition will allow). At this point, the charger automatically stops charging. 7. When charging is complete, unplug the male connector of the AC power cord from the  wall outlet and then unplug the female connector of the AC power cord from the AC ...

  • Page 65: Independent Charger

    DO NOT operate wheelchair with AC power cord attached to the wheelchair. To Wall Outlet Female Connector on AC Power Cord (Connects to AC Receptacle on Charger) NOTE: Wheelchair shown without seat  for clarity. NOTE: Charge indicator light is only  visible when rear shroud is removed. CHARGING INDICATOR STATUS YELLOW “Blinking” YELLOW Solid GREEN LED “Off” Solid RED or “Blinking”...
  • Page 66 TOOL Battery Charger Extension Cord 1. Attach the battery charger connector to the charger port on the joystick. 2. Plug the charger’s AC power cord, or extension, into the grounded 120 VAC wall  outlet. 3. Wait until charging is complete. NOTE: Allow eight hours for normal charging. Larger batteries (greater than 55 ampere‐hours) or  severely discharged batteries may require up to sixteen hours to be properly charged and equalized. NOTE: It is advantageous to recharge frequently rather than only when necessary. In fact, a  battery’s life is extended if the charge level is maintained well above a low condition. NOTE: If the batteries need to be charged more often or take longer to charge than normal, they  may need to be replaced. Contact an Invacare dealer for service. SPJ Joysticks Pronto® M91™Base with SureStep® QUANTITY Charger/Programming Port (On Charger/ Programming Port FIGURE 9.7 Charging Batteries COMMENTS Supplied Not Supplied MPJ Joystick...

  • Page 67: Section 10-Transport Ready Package

    NOTE: The information in this section is for wheelchairs ordered with the transport ready package  ONLY. WARNING Contact Invacare Corporation (800-333-6900) with any questions about using this wheelchair for seating in a motor vehicle. When feasible, wheelchair occupants should transfer into the vehicle seat and use the OEM (Original Equipment Manufacturer) vehicle-installed restraint system.

  • Page 68: About Transport Ready Packages

    About Transport Ready Packages TRRO includes four factory‐installed transport brackets and a wheelchair anchored  pelvic belt. TRRO has been crash‐tested in accordance with ANSI/RESNA WC Vol 1  Section 19 Frontal Impact Test requirements for wheelchairs with a 168 lb crash dummy,  which corresponds to a person with a weight of 114 to 209 lbs. TRBKTS includes four factory‐installed wheelchair transport brackets. TRBKTS has not  been crash‐tested in accordance with WC 19. Invacare recommends that these transport  brackets be used only to secure an unoccupied wheelchair during transport. As of this date, the Department of Transportation has not approved any tie‐down systems  for transportation of a user while in a wheelchair, in a moving vehicle of any type. It is  Invacare’s position that users of wheelchairs should be transferred into appropriate  seating in vehicles for transportation and use be made of the restraints made available by  the auto industry. Invacare cannot and does not recommend any wheelchair  transportation systems. Compliance Information This wheelchair conforms with the requirements of the ANSI/RESNA WC/Vol. 1 ‐ Section  NOTE: ANSI = American National Standards Institute, RESNA= Rehabilitation Engineering  and Assistive Technology Society of North America. This wheelchair has been dynamically tested in a forward‐facing mode with the specified  crash test dummy, which corresponds to a person with a weight of 114‐209 pounds,  restrained by Both pelvic and shoulder belts in accordance with ansi/resna wc Vol 1  Section 19. Both pelvic and upper torso belts should be used to reduce the possibility of  head and chest impacts with vehicle components. Specifications MODEL M91 Standard M91 Heavy Duty Pronto® M91™Base with SureStep® WHEELCHAIR WEIGHT LIMIT...

  • Page 69: Securing The Wheelchair To The Vehicle

    SECTION 10—TRANSPORT READY PACKAGE Securing the Wheelchair to the Vehicle Positioning the Wheelchair in the Vehicle WARNING This wheelchair must be in a forward facing position during travel in a motor Side View vehicle. Frontal Clear The recommended clear zones for Zone 16 in.

  • Page 70: Securement Points

    SECTION 10—TRANSPORT READY PACKAGE Securement Points Tie-Down Bracket (hidden from view) Tie-Down Brackets Tie-Down Bracket FIGURE 10.1 Securement Points Securing the Wheelchair This wheelchair is to be used only with Wheelchair Tie‐down and Occupant Restraint  Systems (WTORS) that have been installed in accordance with the manufacturerʹs  instructions and SAE J2249. NOTE: A copy of SAE J2249 Wheelchair Tie‐down and Occupant Restraint Systems (WTORS)  for use in Motor Vehicles can be obtained from: SAE International, 400 Commonwealth Drive,  Warrendale, PA 15096‐0001, (877) 606‐7232 or (724) 776‐4970. Attach WTORS to the tie‐down brackets in accordance with the manufacturerʹs  instructions and SAE J2249. Pronto® M91™Base with SureStep® Part No 1143153...

  • Page 71: Securing The Occupant

    Securing the Occupant Wheelchair-Anchored Belts The pelvic belt that is provided by Invacare has been tested for use in a motor vehi- cle on this wheelchair ONLY. DO NOT replace the pelvic belt with a different style pelvic belt. NOTE: For this procedure, refer to FIGURE 10.2.

  • Page 72: Vehicle-Anchored Belts

    Vehicle-Anchored Belts NOTE: For this procedure, refer to FIGURE 10.3. This wheelchair has an overall rating of “A” with regard to accommodating the use and  fit of vehicle‐anchored belts. This rating is scored as follows: RATING Excellent Good Fair Poor The test for Lateral Stability Displacement for Point (P) is shown in FIGURE 10.3. The  average test result for point (P) is 0.44‐inches (11.2 mm). Point (P) Test Platform FIGURE 10.3 Vehicle-Anchored Belts Seating System This wheelchair has been tested for seating in a motor vehicle with the factory installed seating system ONLY. Ensure that the factory installed seating system is secured to the wheelchair frame before ...

  • Page 73: Positioning Belts

    Positioning Belts The angle of the pelvic belt should be within the preferred zone of 45 to 75 degrees to the horizontal OR within the optional zone of 30 to 45 degrees to the horizontal. Steeper side-view pelvic belt angles are especially important if the pelvic belt is intended to be used for postural support in addition to occupant restraint in a...
  • Page 74 SECTION 10—NOTES NOTES Pronto® M91™Base with SureStep® Part No 1143153...

  • Page 75: Global Limited Warranty (Excluding Canada)

    Invacare warrants the base frame to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.

  • Page 76: Canada Limited Warranty

    Invacare warrants the base frame to be free from defects in materials and workmanship for a period of five (5) years from the date of purchase from Invacare or a dealer, with a copy of the seller’s invoice required for coverage under this warranty.
