4. O
PERATION
Sound-Active
This fixture has a sound-active mode. This means that the triggering for the built-in program will respond to
the built-in microphone. Please see the instructions below for further explanation.
1.
Plug the fixture into power.
2.
Turn the power switch to the ON position.
3.
Turn the mode switch to the MUSIC position.
4.
Adjust the sound sensitivity pot with a suitable flat-head screw driver.
The DIMMER adjustment knob controls solely the blue LED, NOT either laser.
The DIMMER adjustment and ROTATION SPEED adjustment controls will function in this
mode. However, they will work along with the program, which means that any adjustments will
only work when the program sets the LED and lasers to ON.
Use caution when adjusting the microphone sensitivity. Failure to do so may cause damage to
the fixture or harm to the user.
Manual
This fixture has a manual mode. This means that the user will have control over each individual function of
the fixture, using the controls on the back panel. Please see the instructions below for further explanation.
1.
Plug the fixture into power.
2.
Turn the power switch to the ON position.
3.
Turn the mode switch to the MANUAL position.
4.
Combine the 4 knob adjustments to achieve the desired effect.
The DIMMER adjustment knob controls solely the blue LED, NOT either laser.
All of the adjustment knobs will function in this mode.
Turn the RED & GREEN STROBE adjustment knobs clockwise to reduce the strobe rate to
constant output.
The lasers will not turn off if the RED & GREEN STROBE adjustment knobs are turned
completely counterclockwise. They will continue to strobe slowly.
AUTO
This fixture has an automatic mode. This means that the triggering for the built-in program will progress at
a constant speed, which is not adjustable. Please see the instructions below for further explanation.
1.
Plug the fixture into power.
2.
Turn the power switch to the ON position.
3.
Turn the mode switch to the AUTO position.
The DIMMER adjustment knob controls solely the blue LED, NOT either laser.
The DIMMER adjustment and ROTATION SPEED adjustment controls will function in this
mode. However, they will work along with the program, which means that any adjustments will
only work when the program sets the LED and lasers to ON.
Cirrus™ User Manual
13
2010-08-09
