Summary of Contents for Chauvet Cirrus
- Page 1 LASER LIGHT AVOID DIRECT EYE EXPOSURE CLASS 3R LASER PRODUCT CLASSIFIED PER EN/IEC 60825-1:2007 Complies with FDA performance standards for laser products except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007. ...
-
Page 2: Table Of Contents
United Kingdom & Ireland CHAUVET® CHAUVET® Europe Ltd. General Information General Information Address: 5200 NW 108th Avenue Address: Unit 1C Sunrise, FL 33351 Brookhill Road Voice: (954) 929‐1115 Pinxton, Nottingham, UK Fax: (954) 929‐5560 NG16 6NT Toll free: (800) 762‐1084 Voice: +44 (0)1773 511115 Technical Support Fax: +44 (0)1773 511110 Voice: (954) 929‐1115 (Press 4) Email: uktech@chauvetlighting.com Fax: (954) 756‐8015 World Wide Web: www.chauvetlighting.com World Wide Web: www.chauvetlighting.co.uk Cirrus™ User Manual 8/18/2011... -
Page 3: Before You Begin
In the event that a product must be returned to the factory, it is important that the product be returned in the original factory box and packing. Manual Conventions CHAUVET® manuals use the following conventions to differentiate certain types of information from the regular text. EANING... -
Page 4: Safety Instructions
In the unlikely event your unit may require service, please contact the dealer nearest to you. Avoid direct eye contact with laser light. Never intentionally expose your eyes or others to direct laser light. Cirrus™ User Manual 8/18/2011... -
Page 5: Non Interlocked Housing Warning
The legal requirements for using laser entertainment products vary from country to country. The user is responsible for the legal requirements at the location/country of use. Always use appropriate lighting safety cables when hanging lights and effects overhead. Cirrus™ User Manual 8/18/2011... -
Page 6: Laser Safety Label Reproduction
Laser Safety Label Reproduction Cirrus™ User Manual 8/18/2011... -
Page 7: Laser Emission Data
FLPPS via the terms of Laser Notice No. 50 dated June 24, 2007. This laser device is classified 3R. (Class 3R is the international equivalent of US Class IIIa). No maintenance is required to keep this product in compliance with laser performance standards. Cirrus™ User Manual 8/18/2011... -
Page 8: Introduction
Product Overview Hanging bracket Light output Bracket adjustment knob Rubber feet (4) Safety attachment point Microphone Microphone sensitivity adjustment Green strobe speed Red strobe speed Power ON/OFF LED Dimmer Power In Rotation speed Mode switch (MANUAL/MUSIC/AUTO) Cirrus™ User Manual 8/18/2011... -
Page 9: Setup
Before powering on the unit, make sure the line voltage to which you are connecting it is within the range of accepted voltages. Only use the included power supply! To obtain a replacement power supply, contact Chauvet®. Power Supply To determine the power requirements for a particular product, see the label affixed to the back plate of the product or refer to the product’s specifications chart. -
Page 10: Proper Usage
Proper Usage This product is for overhead mounting only. For safety purposes, CHAUVET® recommends mounting your lighting effect products on steady elevated platforms or sturdy overhead supports using suitable hanging clamps. In all cases, you must use safety cables. You can obtain appropriate mounting hardware from your lighting vendor. -
Page 11: Operation
The DIMMER adjustment and ROTATION SPEED adjustment controls will function in this mode. However, they will work along with the program, which means that any adjustments will only work when the program sets the LED and lasers to ON. Cirrus™ User Manual 8/18/2011... -
Page 12: Appendix
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET® and request RMA # prior to shipping the product. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 13: General Troubleshooting
Note: Keep DMX cables separated from power cables or black lights. No laser output Bounce mirror motor may have shifted during shipping; readjust If you still have a problem after trying the above solutions, please contact CHAUVET® Technical Support. Contact Information World Headquarters United Kingdom & Ireland CHAUVET® CHAUVET® Europe Ltd. -
Page 14: Technical Specifications
PHOTO OPTIC Coverage Angle ..........................76° THERMAL Maximum ambient temperature ..................104° F (40° C) ORDERING INFORMATION Cirrus™ ............................CIRRUS WARRANTY INFORMATION Product Warranty (excluding laser diode) ............1-year limited warranty Laser Diode Warranty..................90-day limited warranty Cirrus™ User Manual...
