Safety Notices

• BURN SOLID WOOD FUEL ONLY
• DO NOT USE CHEMICALS OR FLUIDS TO START
THE FIRE. DO NOT BURN Garbage OR FLAM-
MABLE FLUIDS.
• IF THIS ROOM HEATER IS NOT PROPERLY
INSTALLED, A HOUSE FIRE MAY RESULT. TO
REDUCE THE RISK OF FIRE, FOLLOW THE
INSTALLATION INSTRUCTIONS. FAILURE TO
FOLLOW THESE INSTRUCTIONS MAY RESULT
IN PROPERTY DAMAGE, BODILY INJURY, OR
LOSS OF LIFE.
• CONTACT THE LOCAL BUILDING OR FIRE
OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION REQUIREMENTS
IN YOUR AREA. WHEN NOT ADDRESSED IN
THIS MANUAL, OR BY LOCAL CODE AUTHORI-
TIES, INSTALLATION SPECIFICATIONS AND
REQUIREMENTS DEFER TO NFPA 211 OR CSA B
365
• DO NOT CONNECT THIS FIREPLACE TO ANY
AIR DISTRIBUTION DUCT OR SYSTEM .
• EXTREMELY HOT WHILE IN OPERATION! KEEP
CHILDREN, CLOTHING AND FURNITURE AWAY.
CONTACT WILL CAUSE SKIN BURNS.
• NEVER OPERATE THE FIREPLACE WITH A
CRACKED OR BROKEN GLASS PANEL.
• Install smoke detectors in the living areas
and bedrooms of your home. Test them
regularly and install new batteries twice
annually. When installed in the same room
as the stove, a smoke detector should be
located as far from the stove as possible to
prevent it from sounding when adding fuel
to the fire.
• Avoid creating a low pressure condition in the
room where the stove is operating. Be aware
that operation of an exhaust fan or clothes
dryer can create a low pressure area and
consequently promote flow reversal through
the stove and chimney system. The chimney
and building, however, always work together
as a system - provision of outside air, directly
or indirectly to an atmospherically vented
appliance will not guarantee proper chimney
performance. Consult your local Jøtul autho-
rized dealer regarding specific installation/
performance issues.
Installation

Preparation

We strongly urge you to have your authorized Jøtul
dealer install your new Jøtul C 350 Fireplace Insert.
• Check with local building officials to determine what
permits may be required before installation.
• Notify your insurance company before installing this
fireplace.
Unpacking the Fireplace
All firebox components of the Jøtul C 350 Fireplace
Insert are contained within the carton on a single
pallet. As you unpack the contents, inspect each item
for damage. Notify your dealer of any damage such as
dents, cracked glass, or broken bricks.
Contents:
• • • • • Firebox Assembly - including Firebricks
• Steel Riser Bar
• Surround Panels (Breakdown on page 13)
• Stove Hardware Bag
• Fireplace Conversion Notice Plate
• Blower Power Cord • Blower Control Knob
• AC Power Receptacle Lead
• Receptacle Inlet Coverplate
• Door Knob parts
Tools & Materials Required:
• work gloves
• tape measure
• tin snips
• High-temperature sealant
• 1" (25 mm) masonry anchors or nails (two)
• 1/4" x 3/4" self-tapping screws (three)
• 10 mm (1/4") open end wrench or socket driver
Removing the Firebox from Pallet
1. Remove the two screws that secure the steel Riser Bar
assembly to the back of the pallet. See page 8 to
determine if Riser Bar is required for your installation.
2. The firebox may be lightened by removing the door,
firebricks and baffle plates. See fig. 22, page 22.
3. The firebox is secured to the pallet by a steel bracket
on each side and one screw in the bottom at the
front. Use a 1/4 socket to remove these five screws
and lift the firebox to disengage the brackets.
Discard brackets.
4. Install the Blower Control Knob.
5. Install the Door Knob parts in the order shown in fig.
21, page 22.
Jøtul C 350 Winterport
• Firebox Locking Pin
• safety glasses
• phillips screwdriver
• power drill
5
