Jøtul C 350 Winterport 138376_Rev_Q 2 / 17
Fireplace Insert
Installation and Operating Instructions
for the United States & Canada
„ The Jøtul C 350 Winterport fireplace insert is
listed to burn solid wood only. Do not burn
any other fuels.
„ Read this entire manual before you install
and use this appliance.
„ Save these instructions for future reference
and make them available to anyone using or
servicing the fireplace insert.
„ This wood heater requires periodic inspection
and repair for proper operation. See this
manual for specific maintenance information.
It is against federal regulations to operate
this wood heater in a manner inconsistent
with the operating instructions in this
owner's manual.
Jøtul C 350
Winterport
1
Advertisement
Table of Contents
Related Manuals for Jøtul C 350 Winterport
Summary of Contents for Jøtul C 350 Winterport
-
Page 1: Installation And Operating Instructions
Fireplace Insert Installation and Operating Instructions for the United States & Canada „ The Jøtul C 350 Winterport fireplace insert is listed to burn solid wood only. Do not burn any other fuels. „ Read this entire manual before you install and use this appliance. -
