MODELS:
BDV300, BDV400, BDV500, BDV600
WARNINGS
IF thE INFORMAtION IN thESE INStRuctIONS ARE
NOt FOLLOWED ExActLy, A FIRE OR ExpLOSION
MAy RESuLt cAuSING pROpERty DAMAGE,
pERSONAL INjuRy OR LOSS OF LIFE.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WhAt tO DO IF yOu SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
WARNING: Improper installation, adjustment,
alteration, services or maintenance can cause injury or
property damage. Refer to this manual. For assistance
or additional information consult a qualified installer,
service agency or the gas supplier.
This appliance may be installed in an aftermarket*,
permanently located, manufactured home (USA
only) or mobile home, where not prohibited by
local codes.
this appliance is only for use with the type of gas
indicated on the rating plate. this appliance is
not convertible for use with other gases, unless a
certified kit is used.
* Aftermarket: Completion of sale, not for purpose of resale,
from the manufacturer.
READ BEFORE INStALLING. SAVE thESE INStRuctIONS
BDV Series
Direct Vent Gas Fireplace

Installation and Operating Instructions

DuE tO hIGh tEMpERAtuRES, thE
AppLIANcE ShOuLD BE LOcAtED
Out OF tRAFFIc AND AWAy FROM
FuRNItuRE AND DRApERIES.
chILDREN AND AD uLtS ShOuLD
BE ALERtED tO thE hAZARDS OF
hIGh SuRFAcE tEMpERAtuRE AND
ShOuLD StAy AWAy tO AVOID BuRNS
OR cLOthING IGNItION.
y O u N G c h I L D R E N S h O u L D B E
SupERVISED WhEN thEy ARE IN thE
SAME ROOM AS thE AppLIANcE.
cLOthING OR OthER FLAMMABLE
MAtERIAL ShOuLD NOt BE pLAcED ON
OR NEAR thE AppLIANcE.
KEEp thE ROOM AREA cLEAR AND
FREE FROM cOMBuStIBLE MAtERIALS,
GASOLINE, AND OthER FLAMMABLE
VApORS AND LIquIDS.
540700
BDV cover
54D0700 1/09 Rev. 14
