1250 Wood Insert
•
Masonry Fireplace Insert
SAFETY NOTICE:
If this appliance is not properly installed, a house fire may
result. For your safety, follow the installation directions.
Contact local building or fire officials about restrictions and
installation inspection requirements in your area.
Travis Industries, Inc.
4800 Harbour Pointe Blvd. SW
Mukilteo, WA 98275
www.travisproducts.com
Owner's Manual
•
Save these instructions
for future reference
© Copyright 2011, T.I.
$10.00
100-01233_000
4110304
Zero-Clearance (Metal)
Fireplace Insert
Tested to: U.L. 1482 & ULC S628
Listed
Advertisement
Table of Contents
Related Manuals for Travis Industries 1250
Summary of Contents for Travis Industries 1250
-
Page 1: Safety Notice
1250 Wood Insert Owner's Manual • • Masonry Fireplace Insert Zero-Clearance (Metal) Fireplace Insert Save these instructions for future reference SAFETY NOTICE: If this appliance is not properly installed, a house fire may result. For your safety, follow the installation directions. -
Page 2: General Information Introduction & Important Information
Introduction Introduction We welcome you as a new owner of a 1250 wood-burning fireplace insert. In purchasing a 1250 fireplace insert you have joined the growing ranks of concerned individuals whose selection of an energy system reflects both a concern for the environment and aesthetics. This insert is one of the finest appliances the world over. -
Page 3: Table Of Contents
Replacing the Door Gasket ........25 Replacing the Door Handle ........25 Firebox Parts .............. 26 Baffle Removal and Replacement ......26 Air Tube Removal and Replacement ......27 Warranty ............... 28 Listing Information ............ 30 Index ................32 © Travis Industries 100-01233 4110304... -
Page 4: Safety Precautions
(UL 103 HT) cause a house fire. Liner residential type chimney or an Do not connect this appliance to approved masonry chimney with any chimney serving another a standard clay tile, or stainless appliance. steel liner. © Travis Industries 100-01233 4110304... - Page 5 Always follow the instructions in this manual. Travis Industries, Inc. grants no warranty, implied or stated, for the installation or maintenance of your appliance, and assumes no responsibility of any consequential damage(s).
-
Page 6: Features & Specifications
13-1/2" 343mm 3" 77mm Figure 1 (a) Measure side and top clearances from the top plate. Measure front clearances from the stove face (b) Fireplace Opening Emissions 4.4 Grams Per Hour (EPA Phase II Approved) © Travis Industries 100-01233 4110304... -
Page 7: Fireplace Insert Installation
Planning The Installation We suggest that you have an authorized Travis Industries dealer install your fireplace insert. If you install the fireplace insert yourself, your authorized dealer should review your installation plans. Check with local building officials for any permits required for installation of this fireplace insert and notify your insurance company before proceeding with installation. -
Page 8: Fireplace Requirements
Attach the "This fireplace has been altered..." plate to the fireplace (use two screws or other suitable method). You may wish to place it in a location where it will be covered by the surround panels. © Travis Industries 100-01233... -
Page 9: Insert Placement Requirements
Extension Onto Hearth Figure 3 Hearth Requirements • Must extend 16" (USA) or 18” (Canada) in front of the insert and 8" on both sides. • Must be non-combustible and at least .018" thick (26 gauge) © Travis Industries 100-01233 4110304... -
Page 10: Masonry Fireplace Requirements
") may be removed (if applicable). The masonry lining (" "), insulation (" "), and any structured rigid frame members (metal sides, floor, door frame, face of the fireplace, etc. – " ") may not be removed or altered Figure 4 © Travis Industries 100-01233 4110304... -
Page 11: Drafting Performance
This appliance relies upon natural draft to operate. External forces, such as wind, barometric pressure, topography, or factors of the home (negative pressure from exhaust fans, chimneys, air infiltration, etc.), may adversely affect draft. Travis Industries can not be responsible for external forces leading to less than optimal performance. -
Page 12: Surround Panel Installation
2. Adjust the position of the side panels so they are: 1) flush with the bottom of the insert; 2) both the same distance back from the front of the insert; 3) perpendicular to the floor (use the top panel, if necessary, to judge alignment). Tighten the screws that hold the side panels in place. © Travis Industries 100-01233 4110304... - Page 13 2. Push the insert into the fireplace, allowing the insulation to form a seal between the panels and the fireplace. Use a screwdriver to tuck any exposed insulation behind the panels. © Travis Industries 100-01233 4110304...
-
Page 14: Insert With Positive Connection
A block-off plate or other non-combustible sealing device (e.g. damper adapter) is required. It must seal the chimney to insure smoke does not enter the home while providing the chimney system with sufficient draft. Figure 7 © Travis Industries 100-01233 4110304... -
Page 15: Operating Your Appliance
Over-firing may lead to damage of plated surfaces. If you are uncertain of over-firing conditions, we suggest placing a stove thermometer (e.g. Rutland® Model 710) directly over the door on the stove top - temperatures exceeding 800° are generally considered over-firing and will void the warranty. © Travis Industries 100-01233 4110304... - Page 16 The door becomes hot during use. Use a glove to open the door if the handle is hot. To prevent smoke from entering the room, open the door a small amount and let air enter the firebox. Rotate Swing the door the door handle. open. © Travis Industries 100-01233 4110304...
-
Page 17: Starting A Fire
When you light the newspaper this “top-down” fire will burn its way to the center, igniting the larger pieces. With some practice, this method should work for you. © Travis Industries 100-01233 4110304... -
Page 18: Adjusting The Burn Rate
If the ashes are disposed of by burial in soil or otherwise locally ASHES dispersed, they should be retained in the closed container until all cinders have thoroughly cooled. © Travis Industries 100-01233 4110304... -
Page 19: Blower Operation
The 3/16" and 5/16" steel may creak or click when the stove heats up and cools down - this is normal. Blower Sounds: The blower will make a slight "humm" as it pushes air through the stove. © Travis Industries 100-01233 4110304... -
Page 20: Hints For Burning
Wood Cutting and Storage Cut wood to length and Store the wood off the ground in a chop into quarters. covered area. Allow for airflow Air Flow around the wood to dry the wood. Air Flow Air Flow © Travis Industries 100-01233 4110304... -
Page 21: Troubleshooting
See the section "Door and Glass Inspection" on page 23 for details. • Check the ash bed for coals. Often, coals are still glowing under a slight bed of flyash. By raking these into a pile you can re-start your stove quickly. © Travis Industries 100-01233 4110304... -
Page 22: Maintaining Your Appliance
The ash acts as a light abrasive. The glass will develop a very slight haze over time. This is normal and will not affect viewing of the fire. © Travis Industries 100-01233 4110304... -
Page 23: Monthly Maintenance
Excess creosote buildup may cause a chimney fire, that may result in property damage, injury, or death. Operating this appliance continually at a low burn rate (air starvation) or using green (un-seasoned wood) will increase the formation of creosote. © Travis Industries 100-01233 4110304... -
Page 24: Yearly Maintenance
Slight scaling or rusting of the metal is normal. Make sure the push pins hold the air tubes in place. Floor and Wall Firebricks - replace any severely damaged firebrick along the side or floor of the firebox. © Travis Industries 100-01233 4110304... -
Page 25: Door Parts
You may need to open and close the door repeatedly to get the gasket to seat fully. Replacing the Door Handle See the illustration above for a component list (see pg. 23 for details on adjusting the door). © Travis Industries 100-01233 4110304... -
Page 26: Firebox Parts
Do not pry firebrick - they chip and crack easily. Remove the floor firebricks first. The side firebrick are removed later because they are pinned in place by the floor firebrick. Clean the firebox prior to replacing the firebrick. © Travis Industries 100-01233 4110304... -
Page 27: Air Tube Removal And Replacement
All three air tubes are identical. Air Tube Collar Air Tube Remove the left pin on the air tube collar Roll Pin Slide the air tube to the left, swing it down and remove from the firebox. © Travis Industries 100-01233 4110304... -
Page 28: Warranty
TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call. - Page 29 21. This 5 year warranty is the only warranty supplied by Travis Industries, Inc., the manufacturer of the appliance. All other warranties, whether express or implied, are hereby expressly disclaimed and purchaser’s recourse is expressly limited to the warranties set forth herein.
-
Page 30: Listing Label
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT INSTALLATION AND RESTRICTIONS IN YOUR AREA. SUITABLE FOR USE IN FACTORY-BUILT (Z.C.) FIREPLACES AND MASONRY FIREPLACES. SERIAL NO: MODEL: 1250 INSERT Report No. B0515PRT-001 Certified for USA and Canada Control No. 4000515 Tested to: UL 1482 and ULC S628-93 FACTORY-BUILT (Z.C.) FIREPLACE OR MASONRY FIREPLACE INSTALLATION... -
Page 31: Listing Information
Listing Information © Travis Industries 100-01233 4110304... -
Page 32: Index
Over-Firing the Stove ..........15 Overnight Burn ............19 Paint (Touch-Up Paint) .......... 24 Paint Curing ............15 Re-Loading the Stove ........... 19 Safety Label ............30 Safety Precautions ..........4 Smell (from paint curing) ........15 © Travis Industries 100-01233 4110304...
