564 SS IPI Fireplace • Operation • Maintenance WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life. Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
Introduction We welcome you as a new owner of a 564 SS gas fireplace. This manual details operation and maintenance of this fireplace. Please familiarize yourself with the Owner's Manual before operating your heater and save the manual for future reference. Important Information No other 564 SS gas fireplace has the same serial number as yours.
Table of Contents Introduction and Important Information Introduction ... 2 Important Information ... 2 Installation Warnings ... 2 Features ... 3 Heating Specifications ... 3 Safety Precautions Safety Precautions ... 4 Operation Before You Begin ... 6 Location of Controls ... 6 Starting the Fireplace for the First Time ...
IF YOU SMELL GAS: * Do not light any appliance * Extinguish any open flame * Do not touch any electrical switch or plug or unplug anything * Open windows and vacate building * Call gas supplier from neighbor's house, if not reached, call fire department This unit must be installed by a qualified installer to prevent the possibility of an explosion.
Page 5
Do not place clothing or other flammable items on or near the heater. Because this heater can be controlled by a thermostat there is a possibility of the heater turning on and igniting any items placed on or near it. The viewing glass should be opened only for conducting service.
Before You Begin • Read this entire manual before you use your new fireplace (especially the section "Safety Precautions" on pages 4 & 5). Failure to follow the instructions may result in property damage, bodily injury, or even death. Location of Controls Lift up and swing the lower grill down to acces the area below the firebox.
Starting the Fireplace for the First Time • Burn the heater at a high setting with the blower off for an extended period (up to 48 hours). This will cure the painted surfaces. Fumes from the paint curing and oil burning off the steel will occur. This is normal.
Adjusting the Flame Height This fireplace has an adjustable flame to tailor the look and heat output to your specific needs. It is adjusted by turning the flame adjust knob. Accent Light This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output.
Adjusting the Optional Blower Speed The blower helps transfer heat from the heater into the room. It will not turn on until the heater is up to temperature (approximately 15 minutes after starting). See the illustration below for instructions on adjusting the blower speed.
Normal Operating Sounds Blower Snap Disk This part can produce a clicking sound as it turns the blower on and off. Gas Control Valve As the gas control valve is turned on and off you will hear a dull clicking sound. This is the valve opening up and shutting down.
Maintaining Your Fireplace's Appearance Fingerprints or other marks left on the optional plated surface may become etched in place if they are not wiped clean prior to turning the fireplace on. Clean the plated surface with denatured alcohol and a soft cloth (with the fireplace cool).
Accent Light Replacement Two accent lights are included in your fireplace to provide additional lighting. These bulbs will burn out over time. To replace, follow the directions below: • Shut off gas to the fireplace and let it cool for 15 minutes. •...
Grill Installation and Removal Follow the directions below to install. Upper Grill Installation (FPX and Avalon) Hold the grill at an angle and insert the lower slot over the lower bushing on the fireplace (both sides) Lower Grill Installation Hold the grill at an angle and insert the lower slot over the bushing on the fireplace (both sides).
Glass Frame Removal and Installation Warning: The appliance must be completely cool before removing the glass. Warning: Do not strike or slam the glass. Based upon the face being used, either: (a) swing the access door down and remove the top grill, (b) remove the face (unscrew or lift off - see the instructions included with the face for details).
Page 16
Glass Frame Removal and Installation (continued) The latch can come loose from the latch assembly. This occurs only when it is rotated. Follow the directions below to re-install the latch if it comes loose. Hold the latch at an angle and insert it into the slot on the glass frame anchor. Latch Glass Frame Anchor...
Page 18
Maintenance Rear Log Installation The rear log has a flat notch on both sides that center it on the grate. Place the rear log on the grate and slide it all the way back until the log contacts the end- brackets on the grate.
Glass Cleaning The glass may be cleaned with a non- abrasive cleaner. To clean the inside of the glass, simply remove the glass on a non-scratching surface, and clean the inside surface. If the outside surface of the glass frame requires cleaning, follow the directions below to remove the outer glass frame and screen.
Troubleshooting Table Problem: The ON/OFF switch is turned to "OFF" Main Burners Will The remote control is not working correctly Not Start The thermostat is disconnected or set too low No Propane in Tank The power backup batteries are dead Receiver Beeps The ON/OFF switch is turned to "OFF"...
Wiring Diagram Orange Yellow / Green CONTINUOUS GREENSMART Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken.
Register your TRAVIS INDUSTRIES, INC. Limited 7 Year Warranty online at traviswarranty.com, or complete the enclosed Warranty card and mail it within ten (10) days of the appliance purchase date to: TRAVIS INDUSTRIES, INC., 4800 Harbour Pointe Blvd. SW, Mukilteo, WA 98275. TRAVIS INDUSTRIES, INC. warrants this gas appliance (appliance is defined as the equipment manufactured by Travis Industries, Inc.) to be defect-free in material and workmanship to the original purchaser from the date of purchase as follows: Check with your dealer in advance for any costs to you when arranging a warranty call.
Accessories The accessories listed below are available at your Travis dealer. To locate a dealer, visit: GreenSmart™ Remote / Thermostat This accessory allows for remote control of your fireplace (burner, flame height, accent light).. It has a built-in thermostat if you wish for automatic temperature control. Blower The optional blowers help transfer heat to your home.
Index Accent Light Replacement ... 12 Accent Light ... 8 Adjusting the Flame Height ... 8 Adjusting the Optional Blower Speed ... 9 Battery Replacement ... 11 Before You Begin ... 6 Comfort Control ... 7 Continuous Pilot / GreenSmart™ Pilot Switch ... 9 Face Installation and Removal ...
