6.5" WVGA Touch Screen Monitor
ALPINE ELECTRONICS MARKETING, INC.
1-1-8 Nishi Gotanda
Shinagawa-ku
Tokyo 141-0031, Japan
Phone 03-5496-8231
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place
Torrance, California 90501 U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
ALPINE ELECTRONICS OF CANADA, INC.
777 Supertest Road
Toronto, Ontario M3J 2M9 Canada
Phone 1-800-ALPINE-1 (1-800-257-4631)
TME-S370
•
OWNER'S MANUAL
Please read before using this equipment.
•
MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
•
MANUAL DE OPERACIÓN
Leealo antes de utilizar equipe.
ALPINE ELECTRONICS OF AUSTRALIA PTY, LTD.
161-165 Princess Highway, Hallam
Victoria 3803, Australia
Phone 03-8787-1200
ALPINE ELECTRONICS (EUROPE) GmbH
Wilhelm-Wagenfeld-Str. 1-3
80807 Munich, Germany
Phone 089-32 42 640
ALPINE ELECTRONICS OF U.K., LTD.
ALPINE House
Fletchamstead Highway, Coventry CCV4 9TW,
Phone 0870-33 33 763
ALPINE ELECTRONICS (BENELUX) GmbH
Leuvensesteenweg 510-B6,
1930 Zaventem, Belgium
Tel.: 02-725 1315
ALPINE ELECTRONICS FRANCE S.A.R.L.
98, Rue de la Belle Etoile, Z.I. paris Nord II,
B.P. 50016, 95945 Roissy Charles de Gaulle
ALPINE ELECTRONICS DE ESPAÑA, S.A.
U.K.
Designed by Alpine Electronics of America, Inc.
R
(RCS PONTOISE B 338 101 280)
Cedex, France
Phone 01-48638989
ALPINE ITALIA S.p.A.
Viale C. Colombo 8, 20090 Trezzano
Sul Naviglio (MI), Italy
Phone 02-484781
Portal de Gamarra 36, Pabellón, 32
01013 Vitoria (Alava)-APDO 133, Spain
Phone 945-283588
Printed In China
EN
FR
ES
Advertisement
Table of Contents
Related Manuals for Alpine TME-S370
Summary of Contents for Alpine TME-S370
- Page 1 Toronto, Ontario M3J 2M9 Canada Phone 0870-33 33 763 01013 Vitoria (Alava)-APDO 133, Spain Phone 1-800-ALPINE-1 (1-800-257-4631) Phone 945-283588 ALPINE ELECTRONICS (BENELUX) GmbH Leuvensesteenweg 510-B6, 1930 Zaventem, Belgium Tel.: 02-725 1315 Designed by Alpine Electronics of America, Inc. Printed In China...
- Page 2 IMPORTANT SERIAL NUMBER: Please record the serial number of your unit INSTALLATION DATE: in the space provided below and keep it as a INSTALLATION TECHNICIAN: permanent record. The serial number plate is PLACE OF PURCHASE: located on the bottom of the unit.
-
Page 3: Table Of Contents
ENGLISH Contents Operating Instructions WARNING Information Warning ........2 In Case of Diffi culty ......15 Caution ........2 Specifi cations ........17 Precautions ......... 3 Accessories ........17 Getting Started Installation and Location of Controls......4 Turning Power On and Off ....4 Connections Adjusting the Volume and Mute ..4 Warning ........ -
Page 4: Operating Instructions Warning
Failure to do so may cause personal injury or damage (train crossings, etc.) can be dangerous and may result to the product. Return it to your authorized Alpine in an accident. LISTENING AT LOUD VOLUME dealer or the nearest Alpine Service Center for LEVELS IN A CAR MAY ALSO CAUSE HEARING repairing. -
Page 5: Precautions
Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. Installation Location Make sure the TME-S370 will not be installed in a location subjected to: • Direct sun and heat • High humidity and water •... -
Page 6: Getting Started
Built-in Speaker Getting Started Outputs sound for AUX and Navigation guidance. AMPS Mounting Hole Universal AMPS accessory is available in any Location of Controls third party dealer. Locking Connector to the hideaway box Connects to the hideaway box. Make sure to lock properly. Turning Power On and Off Press POWER to turn on the unit. -
Page 7: Switching The Source
SETUP Switching the Source The System Setup screen is displayed. Touch the desired source on Source Select screen. • For details, refer to “Setup” (page 11). The AUX Input screen is displayed. • The name given as the source name in “Source Name”... -
Page 8: Auxiliary Device Operation
Finds the beginning of track/chapter. Touching and holding plays fast-reverse. Operation Pauses and plays back. If an ALPINE device is connected to AUX, the device Finds the beginning of a track/chapter. Touching is controllable from the unit. This section explains and holding plays fast-forward. -
Page 9: Ipod Operation (Optional)
If the disc does not include that language, the disc's default Operable when optional Alpine DVD-HU is connected. language is selected instead. When DVD-HU is selected in "Source Name" under AUX •... -
Page 10: Dvb-T Operation (Optional Europe Only)
Display Mode Setting DVB-T Operation (Optional Europe Only) See Display Mode on page 10 for details. Operable when optional Alpine DVB-T is connected. When Menu Control Screen DVB-T is selected in "Source Name" under AUX Setup Operation (page 12), the DVB-T is displayed in Source Select screen. -
Page 11: Tv Operation (Optional)
Setup Operation (page 12), Sirius TV is displayed in Source Source Select screen. Select screen. Refer to owner's manual of Alpine Analog TV Tuner. Refer to owner's manual of Sirius TV. • The operation control bar changes to the visual •... -
Page 12: Display Mode
Display Mode WIDE (Default Setting) / CINEMA / NORMAL WIDE: The monitor displays a normal picture wider to fi t in a wide-screen monitor by evenly stretching out the picture horizontally. CINEMA: The monitor displays a normal picture by stretching out the picture vertically. This mode is good for displaying a cinema type picture at the 16 : 9 ratio. -
Page 13: Setup
Touch [ ] to exit setup menu. Setup System Setup Operations The operation cannot be performed while the vehicle is in motion. In order to operate the setup, enable lock-out function. See page 21 for details. General Setups You can À exibly customize the unit to suit your own preferences and usage. -
Page 14: Aux Setup Operations
Off: Outputs sound through the built-in speakers. The volume indicator is displayed. On: The built-in speaker is mute and head unit volume is adjustable from TME-S370 touch volume control. The volume indicator is not displayed. In order to control DVD-HU volume, make sure remote wire is... -
Page 15: Navigation Setup Operations
Navigation Setup Operations Camera Setup Operations Adjusts the Navigation display setting. Adjusts the Camera display setting. Refer to Refer to page 14 for details. page 14 for details. Returns to the factory default settings of Returns to the factory default settings of Camera setup. -
Page 16: Display Setups
Camera Display Setup Display Setups Brightness / Color / Tint / Contrast / Sharpness It’s easy to customize the unit to suit your preferences. Use steps 1 to 4 below to select one of the SETUP modes to modify. See the applicable section below for details about the selected Setup item. -
Page 17: Reset Display Setting
“Soft” or “Hard,” is at fault. Otherwise, make sure the rest of your respectively. system is properly connected, or then consult your authorized Alpine dealer. Visual EQ Mode Off (Default Setting) / Night Movie / Soft / Sharp / Basic High Contrast No function or display. - Page 18 No picture is produced. Caution Display • Monitor’s mode is not switched to the mode you want to see. Switch to the mode you want to see. Make sure your input device is connected. Picture is unclear or noisy. • Vehicle’s battery power is weak. Check the battery power and wiring.
-
Page 19: Specifi Cations
Accessories SpeciÀ cations Check accessory parts MONITOR SECTION 6.5 inch Screen Size Touch-Display Monitor Hideaway Box with Cable Resolution WVGA TFT active matrix Operation System Number of Picture Elements 1,152,000 pcs. Effective Number of 99.99% or more Picture Elements Illumination System Power Connector Parking Wire GENERAL... -
Page 20: Installation And Connections
Installation and Connections Before installing or connecting the unit, KEEP SMALL OBJECTS SUCH AS BOLTS OR please read the following and pages 2 to 3 of SCREWS OUT OF THE REACH OF CHILDREN. this manual thoroughly for proper use. Swallowing them may result in serious injury. If swallowed, consult a physician immediately. -
Page 21: Precautions
(e.g. on-board computer). Do not monitor. tap into these leads to provide power for this unit. When connecting the TME-S370 to the fuse box, make sure the fuse for the intended circuit of the TME-S370 has the appropriate amperage. Failure to do so may result in damage to the unit and/or the vehicle. -
Page 22: Connections
Connections ACCESSORY ACCESSORY Battery Black REMOTE OUT REMOTE OUT White/Brown Connects to White/Brown Alpine video device. See page M.CONT M.CONT White/Pink 6 for AUX device White/Pink options. REVERSE To the reverse gear. Orange/White Use only when rearview camera is connected. -
Page 23: Lock-Out Function
ACC (+12V) Connect to vehicle accessory / ignition Black Connect to vehicle ground line REMOTE White/Brown Remote out for controlling peripherals M-CONT White/Pink “Monitor Control” activate while S3 remote function is used REVERSE Orange/White Switch to rearview camera screen FOOT BRAKE Yellow/Black Enables displaying video or operating setup (For front use) HAND BRAKE...
