- Page 1 ® TMX-R700A Mobile Overhead Monitor OWNER’S MANUAL...
- Page 2 It is dangerous and illegal for the driver to watch the TV/Video while WARNING driving the vehicle. The driver may be distracted from looking ahead and an accident could occur. Caution • Read this manual thoroughly before starting installation and operation. You will find a number of Safety Warnings in this manual to tell you about things that could hurt you or other people if you were to ignore the Warnings.
- Page 3 • Direct Fit To Alpine Overhead Console Note: If you have any questions regarding the application of this device, see your authorized Alpine dealer. It is recommended that this product be used with Alpine’s various Overhead Consoles. Your authorized Alpine dealer will have more information on these products.
- Page 4 To replace the bulb, gently open the dome light lens from the front . Use a 12V, 5W bulb or equivalent. (e.g. SYLVANIA DE3022) 6) Alpine Back-lit Logo Blue, back-lit ALPINE logo will turn on when the overhead monitor main power is on.
-
Page 5: Operation - Remote Control
OPERATION - Remote Control REMOTE CONTROL Power Press this button to turn Main Power to the TMX-R700 ON or OFF (Ignition/ACC must be ON and the LCD Panel must be open). Closing the LCD Panel turns Main Power OFF automatically. NOTE: Whenever the LCD Panel is opened from the closed position or Ignition/ACC is ON at opened position, the Main... - Page 6 OPERATION - Remote Control REMOTE CONTROL (continued) Setup Press the Setup button to make adjustments to the picture. The various options will rotate in the following order. Once the parameter you want to change is on the screen, use the Volume UP or DN buttons to increase or decrease the level respectively.
- Page 7 WIRING/CONNECTIONS 1. Mini-DIN Connector (Pigtail) This is connected to the TMX-R700 Overhead Monitor, through the 5m, Mini-DIN Extension Cable. 2. Dome Light Wire This wire connects the built-in Dome Light to the cable from the vehicle’s Dome Light Switch. Positive Switched System Negative Switched System...
- Page 8 Make sure the connection is made to bare metal and is securely fastened using the sheet metal screw provided. Remote Out The Remote Out wire connects to any ALPINE Mobile Video product which has an external remote input function. For example, products such as a DVD, VCR and TV Tuner.
-
Page 9: Specifications
SPECIFICATIONS Specifications Video Display System ......NTSC/PAL Compatibility Display Screen ......Size 7 inches, 6.07”(W) x 3.43”(H) 16:9 Aspect Ratio Element TFT-LCD, Active Matrix Format 7.0”, 480(W) x 234(H) x 3 Total 336,960 pixels Back Light ......Cold Cathode Fluorescent Lamp Power Requirement ...... - Page 10 Typical Rear Seat Entertainment System It is dangerous and illegal for the driver to watch the TV/Video while WARNING driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.
- Page 11 Dual Rear Seat Entertainment System It is dangerous and illegal for the driver to watch the TV/Video while WARNING driving the vehicle. The driver may be distracted from looking ahead and an accident could occur.
- Page 12 1-888-NAV-HELP (1-888-628-4357) ALPINE ELECTRONICS OF CANADA, INC. Suite 203, 7300 Warden Ave. Markham, Ontario L3R 9Z6, Canada Tel.: 1-800-ALPINE1 (1-800-257-4631) ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough Victoria 3173, Australia Tel.: (03) 9769-0000 ALPINE ELECTRONICS GmbH Kreuzerkamp 7-11 40878 Ratingen, Germany Tel.: 02102-45 50...
