Using Your Remote Transmitter; Arming The Security System; Pre-Arm Mode; Disarming The Security System - Code Alarm F10 Owner's Manual

4

Using Your Remote Transmitter

Press to ARM the
Security System and
Lock Doors

Arming the Security System

To arm the system, exit the vehicle, close all doors, then press* the
ARM button. The horn/siren will "chirp" twice
will flash twice, indicating the system is armed. The doors will also
lock at this time (if equipped and connected). The status indicator (red
warning light on the dash) will blink steadily, once per second.

Pre-arm Mode

If the horn/siren "chirps" and the parking lights flash only once, this
indicates that the vehicle courtesy light is on, or that an entrance is
not closed securely. Check to see that doors, hood, and trunk are
properly closed. Once all entrances are secured (and the courtesy
light is off), the system will "chirp" / flash again. The system is now fully
armed. (If the entrance is not secured within 4 minutes, the system will
arm and ignore the unsecured entrance until it is closed.)

Disarming the Security System

To disarm the system, press the DISARM button. The horn/siren will
"chirp" once and the parking lights will flash once, and the doors will
unlock.
The courtesy light will turn on for 1 minute, or until the vehicle is started.

Attempted Intrusion Identification

If the horn/siren "chirps" four times
when disarming, this indicates that the
system was triggered in your absence.
The status indicator will also flash
rapidly. Perform the following operation
to determine the protected zone that
triggered the system:
After disarming, press the emergency override button.
The horn/siren will "chirp" to indicate the cause of the alarm trigger:
* Throughout this manual, 'press' refers to pressing for less than 1 second; 'press and hold' refers to
pressing for more than 1 second.
† If you have chosen the Silent Arming Option, the siren will not sound when arming or disarming until the
appropriate button is pressed a second time.
Press to DISARM
Security System and
Unlock Doors
Press and HOLD for
TRUNK
Press both ARM and
DISARM for Panic
† and the parking lights
1 chirp IT-s Interior Theft Sensor
2 chirps Door
3 chirps Hood
4 chirps Trunk/Optional Sensors
5 chirps Ignition was turned on
Programming Selectable Options, cont'd
OPTION DESCRIPTION
Option Bank 0 - 3 Chirps (Learn Transmitters)
Option Bank One - 4 Chirps (Keyless & Alarm Options)
1. Lock with Ignition Doors lock when all doors are closed and
ignition is turned on
2.Unlock with Ignition Doors unlock when ignition is turned off
3.Delayed Door Lock 3 sec. delay locking for theater dimming
4.Extended Locks Lock duration is (1) 5 sec. or (2) 0.6 sec.
5. Double Unlock Pulse Unit provides two pulses on each unlock
6. Passive Arming Alarm automatically arms 60 sec.
after ignition is turned off
Option Bank Two - 5 Chirps (Chirps)
1. Silent Choice (1) Horn Chirps 1st Press (2) Second Press
2.Chirp Delete Deletes ARM/DISARM chirps
3. Horn Pulse (1) RPS (2) Pulsed
4. Door Trigger Polarity (1) Positive (2) Negative
5. Iluminated Entry (1) Dome (2) Armed out
6. Si r en/Horn (1)RPS (2)Si r en
7. Light Touch adj ARM raises sensitivity; DISARM lowers sensitivity
4. Full Shock adj ARM raises sensitivity; DISARM lowers sensitivity
13
Default settings in BOLD
STATUS INDICATOR
ON OFF
ON OFF
ON OFF
ON(1) OFF(2)
O N OFF
O N OFF
ON(1) OFF(2)
ON OFF
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
ON(1) OFF(2)
ON OFF
ON OFF
