- Page 1 User guide DishDrawer® DD60SDFHTX6,DD60SHTI6, DD60DDFHX6,DD60DHI6 models...
-
Page 3: Table Of Contents
Contents Safety and warnings Controls Operation Wash programme chart Caring for your dinnerware Dishwasher standards test Racking features and accessories Loading suggestions Detergent dispenser Dishwasher detergent and tablets Water softener Rinse aid dispenser Option adjustments Care and cleaning Troubleshooting Fault codes Warranty and service Important! SAVE THESE INSTRUCTIONS... -
Page 5: Safety And Warnings
Safety and warnings Your DishDrawer® has been carefully designed to operate safely during normal dishwashing procedures. Please keep the following instructions in mind when you are using your DishDrawer®. Important safety instructions WARNING! - When using your dishwasher, follow basic precautions, including the following: Read all instructions before using the DishDrawer®. -
Page 6: Important Safety Instructions
Safety and warnings Important safety instructions Installation This DishDrawer® must be installed and located in accordance with the Installation instructions before it is used. If you did not receive Installation instruction sheets with your DishDrawer®, you can order them by calling your Authorised Service Agent. Installation and service must be performed by a qualified technician. - Page 7 Safety and warnings Important safety instructions Important! Under no circumstances should you open the drawer whilst the DishDrawer® is in operation. Operational Always press the button to pause and wait until you hear the three additional beeps before opening the drawer. The DishDrawer®...
-
Page 8: Controls
Controls If you have a double DishDrawer®, each drawer has its own controls and can run independently of the other. Power button button turns the DishDrawer® on or off. Opening the drawer will automatically turn the DishDrawer® on for 30 seconds. To end a wash programme in mid cycle, press button. -
Page 9: Eco Button
Controls Keylock The Keylock feature disables all the buttons on the DishDrawer®. To activate, press and hold the button until you hear one beep (3 seconds). The light above the button is lit when Keylock is activated. To cancel the Keylock feature, press and hold the button until the light above the button disappears. -
Page 10: Operation
Operation Load dishes Start Remove all food scraps and load the dishes. Close the drawer and press the button. Add detergent Finish Check rinse aid The DishDrawer® will beep six times to Press the button indicate the end of the wash programme. At Select a wash programme the end of the wash programme the drying Select... -
Page 11: Wash Programme Chart
Wash programme chart Standard wash programme - when to use Heavy Normal Fast Delicate Rinse Heavily soiled Dishes with Lightly soiled Lightly soiled and Prevents odours and pots, pans and normal soils dishes. heat sensitive soils drying on dishes. dishes. for optimum crockery. -
Page 12: Caring For Your Dinnerware
Caring for your dinnerware The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in the DishDrawer®. Remember, if in any doubt about any aspect concerning items washed in the DishDrawer®, follow the instructions from the manufacturer of the items, or wash the item by hand. -
Page 13: Dishwasher Standards Test
Dishwasher standards test The DishDrawer®s are tested to IEC 60436 standards for both wash and dry performance. The following are loading pattern diagrams, detergent quantities and rinse aid quantities used for the DishDrawer®. dishdrawer loading diagrams Wash programme Normal Eco Detergent quantities 2.5g (pre-wash) per drawer 15.5g (main wash) per drawer... -
Page 14: Racking Features And Accessories
Racking features and accessories Cutlery basket Mix spoons, knives and forks within each section to stop cutlery nesting together. Most cutlery is placed with the handle pointing down. For your safety, knives and sharp utensils should have their handles up. Small light items like baby bottle teats are best placed under the anti-nesting grids to prevent them from being displaced. - Page 15 Racking features and accessories Adjustable racks You can adjust these independently of each other to any height: Fold up to unlock the rack. Adjust the height to suit by sliding up or down. Fold down to lock in position. Fold the racks away if you need the space. Glass supports These clip on the rack wires to give your tall...
-
Page 16: Loading Suggestions
Loading suggestions dishdrawer loading diagrams When loading your DishDrawer®, make sure that you place items so that water coming from the rotating spray arm below can reach all areas (wash performance will be reduced if it can’t) nothing blocks the water from getting to items on the adjustable racks. Typical breakfast load dishdrawer loading diagrams Typical dinner party load... - Page 17 Loading suggestions dishdrawer loading diagrams dishdrawer loading diagrams How NOT to load your DishDrawer® crowding nesting etc. crowding nesting etc. Overcrowded and wash water will not The plates are nesting together and wash reach some of the dinnerware. water may not get through. Cups, glasses and bowls must have their Ensure cutlery are not nesting or stuck openings facing down.
-
Page 18: Detergent Dispenser
Detergent dispenser Important! Only use powdered detergent recommended for domestic automatic dishwashers in the detergent dispenser. Dishwasher detergents are strongly alkaline and can be dangerous if swallowed. Avoid contact with skin and eyes. Keep children and infirm persons away from the DishDrawer® when the drawer is open. Check that the detergent receptacle is empty after completion of the wash cycle. -
Page 19: Dishwasher Detergent And Tablets
Dishwasher detergent and tablets Detergent quantities The detergent quantities recommended below are for individual drawers. Wash programmes main wash (g)* Heavy Normal Delicate Fast * 5g equates to approximately 1 teaspoon, 15g equates to approximately 1 tablespoon. Dishwasher tablets Tablets can either be placed in the cutlery basket or alternatively, placed directly in the wash compartment as below. -
Page 20: Water Softener
Water softener Setting up the water softener Using hard water (above 100ppm) for dishwashing can be detrimental to the performance of your DishDrawer®. Glasses will become opaque and dishes will become spotted or covered in a white film. Determine the water hardness in your local area Your local water company will be able to provide you with information. -
Page 21: Salt Indicator Light
Water softener Important! The water softener must always be filled with granular salt made especially for dishwasher water softening systems. We do not recommend the use of cooking salt like table salt, rock salt or pellets as they may contain impurities that will impair or diminish the life of the water softener. The salt reservoir Water softening can only take place when there is salt in the reservoir. -
Page 22: Rinse Aid Dispenser
Rinse aid dispenser We highly recommend the regular use of liquid rinse aid to give the best drying results. Rinse aid gives a streak-free, sparkling clean look to glass and chinaware. In addition, it prevents metal from tarnishing. The rinse aid dispenser is on the inside of the drawer, located underneath the detergent dispenser. -
Page 23: Option Adjustments
Option adjustments The following options can be adjusted to suit your preferences: Rinse aid setting Reduce the Rinse aid setting if there is excess foam after a wash programme or if you are using dishwasher tablets with built-in rinse aid. Increase the Rinse aid setting if dishes are wet or streaky after a wash programme. - Page 24 Option adjustments...
-
Page 25: Care And Cleaning
Care and cleaning Important! Disconnect the DishDrawer® from the power supply before any cleaning or maintenance. Cleaning the surfaces Important! We do not recommend the use of the following cleaning aids on your DishDrawer® as they may damage the surfaces: Plastic or stainless steel scouring pads Abrasive, solvent, household cleaners Acid or alkaline cleaners... -
Page 26: Filter Plate
Care and cleaning Cleaning the drain filter, spray arm and filter plate We recommend that the drain filter is cleaned whenever there is evidence of food particles. The spray arm and filter plate may need cleaning about once a month in normal use or more often should the need arise. - Page 27 Care and cleaning Cleaning the spray arm and filter plate Ensure the DishDrawer® is cool before you start cleaning and follow the instructions for removing the drain filter and spray arm. Unplug the DishDrawer® from the power supply. Unclip the glass supports from the rack wires and fold all the adjustable racks away, so that they are upright and close to the top.
-
Page 28: Troubleshooting
Troubleshooting Problem Possible cause What to do Wash programme Refer to the ‘Wash programme chart’ for a Unclean dishes unsuitable for the load. suitable wash programme, or the soils were too heavily baked on and dishes may need soaking. Spray arm unable to rotate. Ensure no items are obstructing the spray arm path. - Page 29 Troubleshooting Problem Possible Cause What to do Continuous A fault has occurred. Refer to the ‘Fault codes’ section. beeping Intermittent DishDrawer® is in pause Close the DishDrawer® and press the beeping mode. button. DishDrawer® will Power supply is not Connect the power supply. not start connected.
-
Page 30: Fault Codes
Fault codes How to recognise a fault code When a fault has occurred, the DishDrawer® will continuously beep every second. The fault code will be displayed on the wash programme selector. Each fault code is shown in the following chart. How to attend to a fault code Press the button to remove the fault code. - Page 31 Fault codes Fault codes Possible causes What to do Flood switch has been Turn the water and power supply to the activated. DishDrawer® off and call your Authorised Service Centre or Customer Care. Motor problem. Call your Authorised Service Centre or Customer Care.
- Page 32 Fault codes Fault codes Possible causes What to do Fill fault. Turn the DishDrawer® water supply on. Ensure the spray arm is placed on the impeller and can rotate about the centre. If the DishDrawer® is full of water, it will need to be emptied manually.
-
Page 33: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the installation instructions and your user guide and check that: your product is correctly installed you are familiar with its normal operation. If after checking these points you still need assistance or parts, please refer to the Service &... - Page 36 Copyright © Fisher & Paykel 2009. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
