- Page 1 DishDrawer dishwasher User guide DD24, DD60 DD36, DD90 models US CA NZ AU GB IE...
- Page 3 This user guide is an accompaniment to your ‘Quick start guide’ which is included with your dishwasher. For operating instructions, see your ‘Quick start guide’ . If you no longer have your ‘Quick start guide’ , you can download it from our local website, listed on the back cover. Refer to your ‘Quick start guide’...
-
Page 5: Table Of Contents
Contents Electrical connection (GB IE only) Safety and warnings Caring for your dinnerware Racking features Loading suggestions Water hardness and dishwashing Wash programs and detergent quantities Adding detergent Using rinse aid Water softener User maintenance instructions Troubleshooting If there is a fault How to attend to a fault Classic models Designer models... -
Page 6: Electrical Connection (Gb Ie Only)
Electrical connection (GB IE only) For Great Britain only Fuse cover Important! Fuse This appliance must be earthed. Fuse replacement The mains lead of this appliance is fitted with a BS 1363A 13 A fused plug. To change a fuse in this type of plug, use an ASTA approved fuse to BS 1362 type and proceed as follows: Remove the fuse cover and fuse. -
Page 7: Safety And Warnings
Safety and warnings Your dishwasher has been carefully designed to operate safely during normal dishwashing procedures. Please keep the following instructions in mind when you are using your dishwasher. IMPORTANT SAFETY INSTRUCTIONS WARNING! - When using your dishwasher, follow basic precautions, including the following: Read all instructions before using the dishwasher. -
Page 8: Important Safety Instructions
Safety and warnings IMPORTANT SAFETY INSTRUCTIONS Installation This dishwasher must be installed and located in accordance with the Installation instructions before it is used. If you did not receive Installation instructions with your dishwasher, you can order them by calling your Authorised Repairer or download them from our local Fisher & Paykel website, listed on the back cover. - Page 9 Safety and warnings IMPORTANT SAFETY INSTRUCTIONS Maintenance Disconnect the appliance from the power supply before any cleaning or maintenance. When disconnecting the appliance pull the plug rather than the power supply cord or junction of cord to avoid damage. Do not repair or replace any part of the appliance or attempt any servicing unless specifically recommended in this user guide.
- Page 10 Safety and warnings IMPORTANT SAFETY INSTRUCTIONS Operational - models with remote control To prevent unauthorized use, keep the remote control out of reach of children. Make sure that you keep the remote away from water and steam. Do not immerse and take care not to drop the remote control into water.
-
Page 11: Caring For Your Dinnerware
Caring for your dinnerware The combination of high temperatures and dishwasher detergent may cause damage to some items if they are washed in the dishwasher. Remember, if in any doubt about any aspect concerning items washed in the dishwasher, follow the instructions from the manufacturer of the items, or wash the item by hand. -
Page 12: Racking Features
Racking features Cutlery basket To reduce the risk of injury, we recommend loading knives and sharp utensils with handles facing up. Mix spoons, knives and forks within each section to stop cutlery nesting together and to ensure the water circulates freely. Keep stainless steel from touching silver cutlery to avoid staining. - Page 13 Racking features Removable small items container To optimise the cutlery space within the basket, the small items container can be placed elsewhere on the base rack. If laid flat, make sure the solid plastic side is facing up. If you place a fully laden small items container under the adjustable racks, it is best to leave the rack space directly above the container empty: there may not be enough water reaching items that are placed there.
- Page 14 Racking features Racking features will vary depending on model. Stemware notches These notches help support long-stemmed glassware. Glass supports These clip on the rack wires to give your tall glasses extra stability. Spacing-adjustable tines (DD24/DD60 models only) Designed to fit deep bowls (wide spacing) or small plates (narrow spacing), depending on adjustment.
- Page 15 Racking features Adjustable racks You can adjust these independently of each other to any height: Fold up to unlock the rack. Adjust the height to suit by sliding up or down. Fold down to lock in position. Fold the racks away if you need the space. Knife clip This clips onto the adjustable racks and supports knives and other utensils during the wash.
-
Page 16: Loading Suggestions
Loading suggestions When loading your drawer, make sure that you place items so that water coming from the rotating spray arms below can reach all areas (wash performance will be reduced if it can’t) nothing blocks the water from getting to items on the adjustable racks glass and other fragile items are stable, so that they do not accidentally topple and break during the wash. -
Page 17: Water Hardness And Dishwashing
Water hardness and dishwashing What is water hardness? Hard water is water with a high concentration of minerals such as calcium and magnesium. In soft water, this concentration is low. Water hardness varies by geographical location. How does water hardness affect dishwashing? Hard water can be detrimental to the performance of your dishwasher. -
Page 18: Wash Programs And Detergent Quantities
Wash programs and detergent quantities DD24/DD60 models Find out about water hardness in your home, then use the table below to determine how much detergent to use for each wash program. See also section ‘Water hardness and dishwashing’ . For information on which program to use for your load, see your ‘Quick start guide’ . The detergent dispenser has markings to help you measure the correct quantities. - Page 19 Wash programs and detergent quantities DD36/DD90 models Find out about water hardness in your home, then use the table below to determine how much detergent to use for each wash program. See also section ‘Water hardness and dishwashing’ . For information on which program to use for your load, see your ‘Quick start guide’ . The detergent dispenser has markings to help you measure the correct quantities.
-
Page 20: Adding Detergent
Adding detergent Suitable detergents and where to place them Note: You may see other, equally suitable types of dishwasher detergent on the shelves of your supermarket. Read and follow the detergent manufacturer’s recommendations. Pouch packs of gel or powder Solid dishwasher tablets place in detergent dispenser, but place on tablet tray in cutlery only if pack fits easily around prongs... - Page 21 Adding detergent Unsuitable detergents These types of detergent are not suitable and may damage your dishwasher or lead to a service call that is not covered by warranty. Important! Do not use these in your dishwasher! Liquid detergents Laundry detergents Hand washing liquids Soaps Disinfectants...
-
Page 22: Using Rinse Aid
Using rinse aid We recommend using liquid rinse aid regularly to give the best drying results. Rinse aid gives a streak-free, sparkling clean look to glass and chinaware. It also prevents metal from tarnishing. The rinse aid dispenser is on the inside of the drawer, underneath the detergent dispenser. It holds approximately 1.7 fl oz / 50 ml of rinse aid. -
Page 23: Water Softener
Water softener Setting up the water softener Important! Only some models (those with a letter ‘H’ in the model name) have a built-in water softener. Models with water softener are not currently available in New Zealand and Australia. Determine the water hardness in your local area Your local water company will be able to provide you with information. - Page 24 Water softener Notes: If your water hardness is above 625ppm/36 gpg, we highly recommend you completely fill the detergent dispenser for all programs except Rinse and the rinse aid setting should be at 5. If your water hardness is above 625ppm/36 gpg, the wash performance of your dishwasher will decline. You may hear some unusual noises when the water softener is in operation, this is normal.
- Page 25 Water softener Important! The water softener must always be filled with granular salt made especially for dishwasher water softening systems. We do not recommend the use of cooking salt like table salt, rock salt or pellets as they may contain impurities that will impair or diminish the life of the water softener. The salt reservoir Water softening can only take place when there is salt in the reservoir.
-
Page 26: User Maintenance Instructions
User maintenance instructions - DD24/DD60 models Important! Disconnect the dishwasher from the power supply (unplug or switch off at the circuit breaker) and allow all its parts to cool before any cleaning or maintenance. Holiday time If the dishwasher is not going to be used for some time, we recommend you leave it clean and empty. - Page 27 User maintenance instructions - DD24/DD60 models Important ! If a dishwasher cleaner/descaler is used, you must run a wash program with detergent immediately afterward to prevent any damage to your dishwasher. The dishwasher must be used with the filter plate, drain filter and spray arm correctly in place. Cleaning the drain filter Unplug the dishwasher or turn it off at the power supply.
- Page 28 User maintenance instructions - DD24/DD60 models Cleaning the spray arm and filter plate To remove and clean the spray arm and filter plate Unplug the dishwasher or turn it off at the power supply. Unclip the glass supports (if fitted) from the rack wires and fold all the adjustable racks away, so that they are upright and close to the top.
- Page 29 User maintenance instructions - DD24/DD60 models To replace the filter plate and spray arm Before replacing the filter plate, ensure the O-ring is correctly O-ring positioned on the base, as shown. Orientate the filter plate and lower it into place: make sure its kidney-shaped hole aligns with the matching recess in the dishwasher base.
- Page 30 User maintenance instructions - DD36/DD90 models Important! Disconnect the dishwasher from the power supply (unplug or switch off at the circuit breaker) and allow all its parts to cool before any cleaning or maintenance. Holiday time If the dishwasher is not going to be used for some time, we recommend you leave it clean and empty.
- Page 31 User maintenance instructions - DD36/DD90 models Important ! If a dishwasher cleaner/descaler is used, you must run a wash program with detergent immediately afterward to prevent any damage to your dishwasher. The dishwasher must be used with the filter plate, drain filter and spray arms correctly in place. Cleaning the drain filter Unplug the dishwasher or turn it off at the power supply.
- Page 32 User maintenance instructions - DD36/DD90 models Cleaning the spray arms and filter plate Ensure the dishwasher is cool before you start cleaning. To remove the base rack and spray arms Unplug the dishwasher or turn it off at the power supply. Take out the cutlery basket.
- Page 33 User maintenance instructions - DD36/DD90 models To replace the spray arms and base rack Clip the spray arms back onto their mounting valves. Be careful that you don’t force them too hard and apply too much pressure on the wash pump housing. You should hear them click into place.
-
Page 34: Troubleshooting
Troubleshooting Problem Possible cause What to do Wash program unsuitable See your ‘Quick start guide’ for a suitable Unclean dishes for the load. wash program, or the soils were too heavily baked on and dishes may need soaking. Spray arm unable to rotate. Ensure no items are obstructing the spray arm path. - Page 35 Troubleshooting Problem Possible cause What to do Drawer will not Childlock feature is on or Turn the Childlock off. Hold down the open (no beeping, the ‘Closed drawer autolock’ button until the symbol disappears from no wash underway) option is on, or both. the display or the light above the button goes out and/or press the button to open the drawer.
-
Page 36: Troubleshooting
Troubleshooting Problem Possible Cause What to do The wash program The wash program is still No action required. The program will seems to have underway. It is in a ‘quiet’ transition into a more audible phase after the finished (the phase that is needed for ‘quiet’... -
Page 37: If There Is A Fault
If there is a fault How do I know if there is a fault? Your dishwasher will self‐diagnose and let you know by beeping continuously and showing a fault code on the wash program panel inside the drawer (all models) and in the display (Classic models only) . -
Page 38: Classic Models
How to attend to a fault ‐ Classic models START HERE Press to stop the beeping. Look up the fault code in the table opposite and note it down. If it’s a ‘U’ code If it’s an ‘E’ code U1: Turn on the water supply, Press . - Page 39 How to attend to a fault ‐ Classic models Display Fault Code Possible cause of fault No water – the water supply hasn’t been turned on. Fault in the other drawer preventing the use of this drawer. The spray arm has loosened or come off its mounting, or water pressure is too low.
-
Page 40: Designer Models
How to attend to a fault ‐ Designer models START HERE Press to stop the beeping. Try to open the drawer (without using excessive force). Press . Wait a few Can the drawer be opened? seconds, then press again. Check which program indicators Is the light above the are lit on the wash program panel. - Page 41 How to attend to a fault ‐ Designer models Wash program panel Fault Code Possible cause of fault No water – the water supply hasn’t been turned on. Fault in the other drawer preventing the use of this drawer. The spray arm has loosened or come off its mounting, or water pressure is too low.
-
Page 42: Integrated Models With Badge
How to attend to a fault ‐ Integrated models with badge START HERE Press to stop the beeping. Try to open the drawer (without using excessive force). Press . Wait a few Can the drawer be opened? seconds, then press again. - Page 43 How to attend to a fault ‐ Integrated models with badge Wash program panel Fault Code Possible cause of fault No water – the water supply hasn’t been turned on. Fault in the other drawer preventing the use of this drawer. The spray arm has loosened or come off its mounting, or water pressure is too low.
-
Page 44: How To Attend To A Fault
How to attend to a fault ‐ Integrated models with remote control START HERE Try to open the drawer (without using excessive force). Disconnect the dishwasher from the power supply to stop Can the drawer be opened? the beeping, then contact Customer Care. - Page 45 How to attend to a fault ‐ Integrated models with remote control Wash program panel Fault Code Possible cause of fault No water – the water supply hasn’t been turned on. Fault in the other drawer preventing the use of this drawer. The spray arm has loosened or come off its mounting, or water pressure is too low.
-
Page 46: Warranty And Service
Warranty and service Before you call for service or assistance ... Check the things you can do yourself. Refer to the ‘Installation instructions’ , ‘User guide’ and ‘Quick start guide’ and check that: your product is correctly installed you are familiar with its normal operation. If after checking these points you still need assistance, please see you ‘Service and warranty’... -
Page 48: Wash Program Data
Wash program data - DD24/DD60 models For information on which program to use for your load, see your ‘Quick start guide’ . Wash cycle times indicated are approximate. USA & CANADA - Classic, Designer, and Integrated double models HEAVY NORMAL FAST DELICATE RINSE... - Page 49 Wash program data- DD24/DD60 models NEW ZEALAND & AUSTRALIA - Classic, Designer, and Integrated double models HEAVY NORMAL FAST DELICATE RINSE (~124 mins) (~128 mins) (~49 mins) (~92 mins) (~11 mins) pre-wash main wash 70 main wash 60 main wash 55 main wash 50 post-rinse x2 post-rinse...
- Page 50 Wash program data - DD24/DD60 models GREAT BRITAIN AND IRELAND HEAVY NORMAL FAST DELICATE RINSE (~126 mins) (~95 mins) (~53 mins) (~92 mins) (~11 mins) pre-wash main wash 70 main wash 65 main wash 55 main wash 50 post-rinse x2 post-rinse x2 post-rinse post-rinse x2...
- Page 52 Wash program data - DD36/DD90 models For information on which program to use for your load, see your ‘Quick start guide’ . Wash cycle times indicated are approximate. USA & CANADA - Designer models HEAVY NORMAL FAST DELICATE RINSE (~141 mins) (~148 mins) (~58 mins) (~85 mins)
- Page 53 Wash program data- DD36/DD90 models NEW ZEALAND & AUSTRALIA - Designer models HEAVY NORMAL FAST DELICATE RINSE (~130 mins) (~120 mins) (~55 mins) (~98 mins) (~11 mins) pre-wash main wash 70 main wash 50 main wash 55 main wash 50 post-rinse x2 post-rinse post-rinse...
- Page 54 Wash program data - DD36/DD90 models GREAT BRITAIN AND IRELAND HEAVY NORMAL FAST DELICATE RINSE (~126 mins) (~95 mins) (~60 mins) (~99 mins) (~11 mins) pre-wash main wash 70 main wash 65 main wash 55 main wash 50 post-rinse x2 post-rinse x2 post-rinse post-rinse x2...
-
Page 56: Standards Test
Standards test - USA & CANADA) DD24 models The dishwashers are tested to various standards for wash performance using the parameters detailed below. Rinse agent setting Maximum place setting 10 for double models Water softener setting Adjust the water softener to match the water (for DD24-H models only) hardness. - Page 57 Standards test - (USA & CANADA) DD36 models The dishwashers are tested to various standards for wash performance using the parameters detailed below. Rinse agent setting Maximum place setting Base rack, folding tines, cutlery basket with cutlery Accessories to be used in the grid, adjustable racks, glass supports, multi- dishwasher standards test purpose clip.
-
Page 58: New Zealand And Australia
Standards test - NZ & AUSTRALIA) DD60 models The dishwashers are tested to AS/NZS 2007 standards for both wash and dry performance, using the parameters detailed below. Wash program Normal Eco (At the end of the program, open the drawer 50 mm to improve the dry performance.) Detergent quantities 23.75g (main wash) per drawer... - Page 59 Standards test - (NZ & AUSTRALIA) DD90 models The dishwashers are tested to AS/NZS 2007 standards for both wash and dry performance using the parameters detailed below. Normal Eco Wash programme (At the end of the programme, open the drawer 50 mm to improve the dry performance.) Detergent quantities 26.25g (main wash)
-
Page 60: Great Britain And Ireland
Standards test - GREAT BRITAIN & IRELAND) DD60 models The dishwashers are tested to EN50242 standards for both wash and dry performances using the parameters detailed below. Wash program Normal Eco Detergent quantities 2.5g (pre-wash) per drawer 15.5g (main wash) per drawer Rinse aid setting Water softener setting Adjust the water softener to match the water... - Page 61 Standards test - (GREAT BRITAIN & IRELAND) DD90 models The dishwashers are tested to EN50242 standards for both wash and dry performances using the parameters detailed below. Wash programme Normal Eco Detergent quantities 5g (pre-wash) 22g (main wash) Rinse aid setting Water softener setting Adjust the water softener to match the water hardness.
- Page 64 www.fi sherpaykel.com www.fi sherpaykel.ca www.fi sherpaykel.co.nz www.fi sherpaykel.com.au www.fi sherpaykel.co.uk www.fi sherpaykel.ie Copyright © Fisher & Paykel 2012. All rights reserved. The product specifications in this booklet apply to the specific products and models described at the date of issue. Under our policy of continuous product improvement, these specifications may change at any time.
