- Page 1 SINGLE DISHDRAWER™ DISHWASHER CONTEMPORARY DD60SAW9, DD60SAX9, DD60SCW9, DD60SCX9, DD60SCTW9 DD60SCTX9, DD60SDFX9, DD60SDFTX9, DD60SDFTB9 INSTALLATION GUIDE NZ AU UK IE...
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! To reduce the risk of fire, injury to persons or damage when using the appliance, follow the important safety instructions listed below. Read all the guidance before using the appliance. Electric Shock Hazard Servicing Failure to follow this advice may result in Do not repair or replace any part of the appliance unless specifically recommended in electrical shock or death. -
Page 4: Tools And Components
TOOLS AND COMPONENTS PARTS SUPPLIED TOOLS REQUIRED Keep all packing materials until the unit has been inspected. Not supplied Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. Fisher &... -
Page 5: Product Dimensions
PRODUCT DIMENSIONS — DD60SC MODELS DD60SC DD60SCT PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth D Depth of chassis PLAN ISOMETRIC E Height of door panel F Depth of door panel G Ventilation gap below door panel H Height from top of drawer panel to top of chassis I Max. - Page 6 PRODUCT DIMENSIONS — DD60SD MODELS DD60SD DD60SDT PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth* D Depth of chassis PLAN ISOMETRIC E Height of door panel F Depth of door panel G Ventilation gap below door panel H Height from top of drawer panel to top of chassis I Max.
- Page 7 PRODUCT DIMENSIONS — DD60SA MODELS DD60SA PRODUCT DIMENSIONS A Overall height B Overall width C Overall depth D Depth of chassis PLAN ISOMETRIC E Height of door panel F Depth of door panel G Ventilation gap below door panel H Height from top of drawer panel to top of chassis I Max.
-
Page 8: Cabinetry Dimensions
CABINETRY DIMENSIONS CLEARANCES Connections can be located in an adjacent cabinet on either side of the DishDrawer*** PLAN ISOMETRIC STD MODELS TALL MODELS CABINETRY CLEARANCES CABINETRY DIMENSIONS A Minimum clearance to adjacent cupboard door A Minimum inside height* min. 412 min. -
Page 9: Left Side
PLUMBING & ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to ‘Cabinetry preparation’ for service access requirements. If the drain hoses supplied are not long enough to reach your services, you may purchase a Fisher &... - Page 10 CABINETRY PREPARATION SERVICE ACCESS MOISTURE PROTECTION We recommend locating the service holes on either side of the DishDrawer as shown below. If the hole is created through wood, ensure the edges are smooth and rounded If the holes is created through metal, ensure the edge protector is fitted. Align the supplied moisture protection tape to the cabinetry as illustrated Ensure this area is free of debris...
- Page 11 SECURE TO CABINETRY VIA BRACKETS (METHOD A) Secure all four side brackets to the DishDrawer™ Dishwasher, aligning bracket A with slot A and bracket B Secure to cabinetry via the brackets. with slot B. Pre-drilling a pilot hole may be required depending on the cabinetry material.
- Page 12 SECURE TO CABINETRY VIA DRAWER REMOVAL (METHOD B) Push the product into the cavity, pulling the hoses through as you push to avoid Secure to cabinetry via all three fixing crushing or twisting them. locations in the chassis. Push the product in the positions Ensure sound insulation is illustrated to avoid denting the door.
- Page 13 PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION SINK TRAP/WASTE TEE INSTALLATION Install the drain hose support to the Install the drain hose support to the back wall, as close to the underside of back wall, as close to the underside of the countertop as possible.
-
Page 14: Installer Checklist
INSTALLER CHECKLIST TO BE COMPLETED BY THE INSTALLER Electrical … Ensure all electrical tests have been conducted in accordance with local regulations. Installation … Check all parts are installed correctly and are secure. Test operation … Ensure DishDrawer™ Dishwasher is securely fastened to the cabinetry and drawer opens …... -
Page 15: Troubleshooting
