IP Phone 2002 User Guide
BCM
Business Communications Manager
Document Status: Standard
Document Version: 03.01
Part Code: NN40050-107
Date: November 2006

Advertisement

Table of Contents
loading

Related Manuals for Nortel IP Phone 2002

Summary of Contents for Nortel IP Phone 2002

  • Page 1 IP Phone 2002 User Guide Business Communications Manager Document Status: Standard Document Version: 03.01 Part Code: NN40050-107 Date: November 2006...
  • Page 2 Nortel Networks. Trademarks Nortel, the Nortel logo, and the Globemark are trademarks of Nortel Networks. Microsoft, MS, MS-DOS, Windows, and Windows NT are registered trademarks of Microsoft Corporation. All other trademarks and registered trademarks are the property of their respective owners.

  • Page 3: Table Of Contents

    IP Phone 2002 button and light descriptions ....... . .
  • Page 4 Contents NN40050-107 NN40050-107...

  • Page 5: Getting Started

    Chapter 1 Getting started The Nortel IP Phone 2002 brings voice and data to your desktop. Introduction This guide contains information about: • telephone buttons and lights • telephone display • telephone setup • how to make and answer calls •...

  • Page 6: Ip Phone 2002 Button And Light Descriptions

    Chapter 1 Getting started IP Phone 2002 button and light descriptions Figure 2 shows the IP Phone 2002 lights and buttons. Figure 2 IP Phone 2002 buttons Table 1 shows a description of the lights and buttons. IP Phone 2002...

  • Page 7: Ip Phone 2002 Telephone Display

    Programmable memory button #09 (Default: Blank) The following button is reserved for future development. PC Expansion button IP Phone 2002 telephone display There are three areas to the IP Phone 2002 telephone display: • Button label area • Information area •...

  • Page 8: Button Label Area

    Chapter 1 Getting started Figure 3 shows an example of the display and describes each area. Figure 3 Display area Call fwd Page gen Button label area Conference Intercom 07/24 3:12 pm Information area Forward Timer More Feature options area Button label area The button label area shows the label and status of the four programmable memory buttons.

  • Page 9: Telephone Setup

    Chapter 1 Getting started Telephone setup This section describes the IP Phone 2002 display features: • Display contrast • Language choice • Ring type Note: For more information about the features available on your telephone and how to use them, refer to the Telephone Features User Guide.
  • Page 10 Chapter 1 Getting started NN40050-107 NN40050-107...

  • Page 11: Features And Buttons

    Chapter 2 Features and buttons This chapter describes some of the IP Phone 2002 buttons and call features: • Basic call features • Navigation buttons • Memory buttons Note: For more information about the features available on your telephone and how to use them, refer to the Telephone Features User Guide.

  • Page 12: Answer Calls

    Chapter 2 Features and buttons When you hear an external dial tone, dial the external telephone number. Note: Contact your System Administrator for a list of line pool codes. When entering a line pool access code on PRI lines, you do not hear dial tone. Internal calls using intercom buttons Lift the handset.

  • Page 13: Mute

    Handsfree, or headset calls. Time offset When your IP Phone 2002 is located in a different time zone from your system, the display shows the system time, not the local time. The Time Offset feature enables you to adjust the time that appears on the display.

  • Page 14: Navigation Buttons

    Chapter 2 Features and buttons Navigation buttons Use the Navigation buttons to scroll through or make changes to your call log. Press Feature 812. Call log Call log displays use the following special characters: (underline) identifies a new item ¯ identifies answered calls identifies long distance calls §...

  • Page 15: Memory Buttons

    Chapter 2 Features and buttons Memory buttons This section contains information about the IP Phone 2002 memory buttons and how to use them. These are buttons not assigned as line or intercom buttons. Memory buttons store internal and external numbers or features to give you one-touch dialing or feature activation.
  • Page 16 Chapter 2 Features and buttons NN40050-107 NN40050-107...
