WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSC3219TA
Owner's Manual
DELUXE LP GAS GRILL
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE, GIVE
THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO SERVICE@BBQTEK.COM
OR CALL 1-877-885-8227 (TOLL-FREE),
07:00 A.M. – 16:00 P.M. (EST), MONDAY-FRIDAY.
MODEL #GSC3219TA
Advertisement
Table of Contents
Related Manuals for BBQ GSC3219TA
Summary of Contents for BBQ GSC3219TA
- Page 1 THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE reproductive harm are created REFERENCE. by the combustion of propane. FOR CUSTOMER SERVICE, EMAIL TO SERVICE@BBQTEK.COM OR CALL 1-877-885-8227 (TOLL-FREE), 07:00 A.M. – 16:00 P.M. (EST), MONDAY-FRIDAY. WARNING: FOR YOUR SAFETY:...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSC3219TA Owner’s Manual... -
Page 3: Table Of Contents
Operating Your Grill....................... 15 Connecting Gas Cylinder ....................15 Checking for Leaks......................16 Lighting Your Grill......................16 Excess flow safety valve reset procedure ..............18 Care and Maintenance ....................19 Troubleshooting ......................21 Warranty Program ......................23 GSC3219TA Owner’s Manual... -
Page 4: For Your Safety
Move gas hoses as far away as possible from hot surfaces and dripping hot grease. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. GSC3219TA Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. GSC3219TA Owner’s Manual... -
Page 6: Package Contents
Grease cup 1 PC Grease cup support 1 PC Tank clip 1 PC Tank holder 1 PC Right side panel 1 PC Cart bottom 1 PC Right bottom side panel 1 PC left bottom side panel 1 PC GSC3219TA Owner’s Manual... -
Page 7: Hardware Contents
M4 spring washer 26 PCS M6 flat washer 1 PC 24 PCS M6 spring washer Screwdriver Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSC3219TA Owner’s Manual... -
Page 8: Assembly Instructions
Repeat the procedure with the right side panel (D) and the left side of cart bottom. Go back and tighten all the bolts using the screwdriver provided. M6×15 bolt 2 PCS M6 flat washer 2 PCS GSC3219TA Owner’s Manual M6 spring washer 2 PCS... - Page 9 (K) and the right end of front beam and back beam. e) Go back and tighten all bolts using the screwdriver provided. M4×15 bolt 8 PCS M4 spring washer 8 PCS M4 flat washer 8 PCS GSC3219TA Owner’s Manual...
- Page 10 Go back and tighten all bolts using the screwdriver provided. e) Insert the tank clip (V) into the holes on the tank holder. M6×15 bolt 4 PCS M6 flat washer 4 PCS M6 spring washer 4 PCS GSC3219TA Owner’s Manual...
- Page 11 (M). d) Close the two doors. Step 8 a) Insert the two side rollers of the drawer (I) into the two roller guides on the cart assembly. b) Push the drawer forward into cart assembly. GSC3219TA Owner’s Manual...
- Page 12 (S) and the right side of body assembly . Go back and tighten all bolts using the screwdriver provided. M6×30 bolt 2 PCS M6×15 bolt 2 PCS M6 flat washer 4 PCS M6 spring washer 4 PCS GSC3219TA Owner’s Manual...
- Page 13 (CC) into each pre-drilled hole. Tighten bolts by hand until secure. Go back to tighten all the bolts using screwdriver provided. d) Insert the ignition cable onto the electrode. M6×15 bolt 2 PCS M6 flat washer 2 PCS GSC3219TA Owner’s Manual...
- Page 14 (U) into the two holes on the grease pan. b) Place the grease cup (T) onto the grease cup support. Insert the grease pan stopper (C) into the holes on the top side of back beam. GSC3219TA Owner’s Manual...
- Page 15 Connect the tank with regulator by screwing the collar onto the tank valve. (See diagram to right.) d) Conduct the leak test on page 16 to make certain all connections are connected securely. Fully Assembled View Left Side Right Side GSC3219TA Owner’s Manual...
-
Page 16: Operating Your Grill
8. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Install only the type of dust cap on cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane. GSC3219TA Owner’s Manual... -
Page 17: Checking For Leaks
3. Press the valve knob and rotate it counterclockwise to the ‘’HIGH’’ position. The burner should light immediately. If more than one burner is desired, repeat the procedure 2-3 until all desired burners are lit. 4. Adjust burners to the desired cooking temperature. GSC3219TA Owner’s Manual... - Page 18 FIG. B FIG. C Normal: Soft blue flames with yellow Out of adjustment: Noisy hard blue Poor combustion: Wavy, yellow tips between I inch - 2 inches high. flames – too much air. flames- too little air. GSC3219TA Owner’s Manual...
-
Page 19: Excess Flow Safety Valve Reset Procedure
To ensure the procedure is safely and successfully performed, please carefully follow these instructions: ● Close the LP tank valve. Turn all burner control knobs to the OFF position. Disconnect the regulator from the LP tank. Open the lid of the grill. GSC3219TA Owner’s Manual... -
Page 20: Care And Maintenance
Nylon cleaning pad Wire brush Paper clip Putty knife/scraper Compressed air DO NOT use cleaners that contain acid, mineral spirits or xylene. Outside surfaces Use a mild dishwashing detergent and hot water solution to clean. Rinse thoroughly with water. GSC3219TA Owner’s Manual... - Page 21 Inspect burner for damage (cracks or holes). If damage is found, replace with a new burner. Reinstall burner. Make certain the gas valve orifices are correctly positioned, pointing straight into burner inlet (venturi tube). Also, check position of spark electrode. GSC3219TA Owner’s Manual...
-
Page 22: Troubleshooting
Turn front of grill to face wind or Increase flame height. Low on propane gas. Replace or refill propane tank. Flame blow out. Excess flow valve tripped. Refer to the Excessive flow safety valve reset procedure on page 18. GSC3219TA Owner’s Manual... - Page 23 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in.. GSC3219TA Owner’s Manual...
-
Page 24: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8227, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday.
