WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY:
For Outdoor Use Only
(outside any enclosure)
GSF2818KMN
Owner's Manual
Outdoor Natural Gas Barbecue Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8225 (TOLL-FREE), 07:00 A.M. – 16:00 P.M.
(EST), MONDAY-FRIDAY.
Service Center: 1-877-885-8225
0
MODEL# GSF2818KMN
Advertisement
Table of Contents
Related Manuals for BBQ GSF2818KMN
Summary of Contents for BBQ GSF2818KMN
- Page 1 MODEL# GSF2818KMN Outdoor Natural Gas Barbecue Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
-
Page 2: Grill Operation
Always read and understand the WARNINGS and INSTRUCTIONS that are contained in this manual before attempting to use this gas barbecue grill to prevent possible bodily injury or property damage. NOTE: This grill must be used with natural gas only. Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSF2818KMN Owner’s Manual... -
Page 3: Table Of Contents
Fuel Gas Code, ANSI Z223.1/ NFPA54. Reference to Natural Gas and Propane Installation code CSA B149.1 or Propane Storage and Handling code B149.2 IMPORTANT NOTICE: READ ALL INSTRUCTIONS PRIOR TO ASSEMBLY AND USE. Safety First! Read and understand all warnings and precautions prior to operating your grill. GSF2818KMN Owner’s Manual... - Page 4 Always confirm that the installation of this grill conforms with the requirements of all local codes or, in the absence of applicable local codes, with either the National Fuel Gas Code, ANSI Z223. NFPA 54 or CAN/CGA-B149.2. GSF2818KMN Owner’s Manual...
-
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. GSF2818KMN Owner’s Manual... - Page 6 2pcs GSF2818KMN Owner’s Manual...
- Page 7 Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSF2818KMN Owner’s Manual...
-
Page 8: Assembly Instructions
Tighten bolts by hand until secure. Repeat the procedure for the cart right side panel and cart back panel assembly. Repeat the procedure for the left side cart panel (K) assembly. Go back and tighten all bolts using the screwdriver provided. GSF2818KMN Owner’s Manual... - Page 9 Push down the top pin of left door insert it into the pre-drilled hole on the left end of cart front beam. Repeat the procedure for the right door (O) assembly. d) Close the two doors. GSF2818KMN Owner’s Manual...
- Page 10 (BB) into each pre-drilled hole. Tighten bolts by hand until secured. d) Go back and tighten all bolts using the screwdriver provided. e) Repeat the procedure for the assembly of right side shelf (V) and another one side bar tool hanger. GSF2818KMN Owner’s Manual...
- Page 11 (B), then close the side burner lids. d) Connect the side burner ignition wire by sliding it onto the electrode on the right side burner assembly (U). (See the right diagram). e) Go back and tighten all bolts using the screwdriver provided. GSF2818KMN Owner’s Manual...
- Page 12 Close the top lid. Step 16 (Natural gas hose) a) Join the natural gas hose, quick release connector and gas supply connection securely, as shown in diagram. Then connect the gas hose with the tube of burners. GSF2818KMN Owner’s Manual...
- Page 13 Move the roller and put it into the slot on right side wall of the firebox. Tighten the screw on roller by hand. Note: Make certain the shaft will be not pulling out from the motor during operation. Fully Assembled View Right Side Left Side GSF2818KMN Owner’s Manual...
-
Page 14: Operating Your Grill
1. Make 2-3 oz. of leak solution by mixing one part liquid dishwashing soap with three parts water. 2. Make sure control knobs are in the “OFF” position. 3. Spray some solution on the connection points of the natural gas hose. GSF2818KMN Owner’s Manual... -
Page 15: Lighting Your Grill
If the burner does not light, repeat 2 or 3 more times. If ignition does NOT occur in 5 seconds turn the burner controls to OFF, wait 5 minutes, and repeat the lighting procedure. Adjust valve knob to the desired cooking temperature. GSF2818KMN Owner’s Manual... - Page 16 “Flare-ups” sometimes occur when food drippings fall onto the hot heat distribution plate or burners and ignite. Some flaring is normal and desirable as it helps impart the unique flavors associated with grilled foods. Controlling the intensity of the flare-ups is GSF2818KMN Owner’s Manual...
-
Page 17: Excess Flow Safety Valve Reset Procedure
If the inside surface of the grill lid has the appearance of peeling paint, baked on grease has turned to carbon and is flaking off. Clean thoroughly with a strong solution of detergent and hot water. Rinse with water and allow it to completely dry. GSF2818KMN Owner’s Manual... -
Page 18: Troubleshooting
Excess flow safety device may have Refer to the Excessive flow safety been activated valve reset procedure on page 16. Irregular flame pattern, flame does not Clean burner ports. Burner ports are clogged or blocked. run the full length of burner. GSF2818KMN Owner’s Manual... - Page 19 1/8 in. increments until flames are correct. *Natural Gas Models must be open a minimum of 1/16 in. *Propane Models must be open a minimum of 1/8 in.. GSF2818KMN Owner’s Manual...
-
Page 20: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8225, 07:00 A.M. to 16:00 P.M. (EST), Monday through Friday.
