WARNING:
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read the installation,
operation and maintenance
instructions thoroughly
before installing or servicing
this equipment.
DANGER:
Failure to follow these
instructions could result in
fire or explosion that could
cause property damage,
personal injury or death.
DANGER:
DO NOT use gas grill for
indoor cooking or heating.
TOXIC fumes can accumulate
and cause asphyxiation. DO
NOT use in or on boats or
recreational vehicles.
PROP 65 WARNING:
Chemicals known to the state
of California to cause cancer,
birth defects or other
reproductive harm are created
by the combustion of
propane.
WARNING:
FOR YOUR SAFETY :
For Outdoor Use Only
(outside any enclosure)
GSS3219B
Owner's Manual
5 Burner LP Gas Barbecue Grill
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
IF YOU ARE ASSEMBLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SERVICE@BBQTEK.COM OR
CALL 1-877-885-8225 (TOLL-FREE), 10:00 A.M. – 19:00 P.M.
(EST), MONDAY-FRIDAY.
0
MODEL# GSS3219B
Advertisement
Table of Contents
Related Manuals for BBQ GSS3219B
Summary of Contents for BBQ GSS3219B
- Page 1 MODEL# GSS3219B 5 Burner LP Gas Barbecue Grill WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER: Failure to follow these...
-
Page 2: Grill Operation
NOTE: This grill must be used with propane gas only (propane gas cylinder not included). Installer: Leave this manual with the consumer. Consumer: Retain this manual for future reference. GSS3219B Owner’s Manual... -
Page 3: Table Of Contents
Operating Your Grill....................... 16 Connecting Gas Cylinder ....................16 Checking for Leaks......................17 Lighting Your Grill......................17 Excess flow safety valve reset procedure ..............19 Care and Maintenance ....................20 Troubleshooting ......................21 Warranty Program ......................23 GSS3219B Owner’s Manual... -
Page 4: For Your Safety
Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. Safe Locations For Use Of This Outdoor Grill GSS3219B Owner’s Manual... -
Page 5: General Information
*** A clogged tube can lead to a fire beneath the grill. *** Step 3. Ensure that the valve nozzle is pointing straight and completely inserted into the venturi tube. General Information A propane gas cylinder is required for operation. This gas grill is NOT intended for commercial use. GSS3219B Owner’s Manual... -
Page 6: Package Contents
Brackt Side burner frame Bracket 1 PC 1 PC Door Heat plate Led light 2 PCS 3 PCS Left side shelf Cooking grid 1 PC 3 PCS Side bar tool hanger Warming rack 2 PCS 1 PC GSS3219B Owner’s Manual... -
Page 7: Hardware Contents
HH: M4 Spring Washer ... 8 PCS II: M4 Nut ... 4 PCS JJ: Battery ... 3 PCS KK: Screwdriver... 1 PC Hardware listed above is not scaled to exact size. (A screwdriver is required on assembly and is included for your convenience). GSS3219B Owner’s Manual... -
Page 8: Assembly Instructions
Slide the cart right side panel (C) until it locks into place. Tighten bolts by hand until secured. Repeat the procedure for the cart left side panel (B) assembly. Go back and tighten all bolts using the screwdriver provided. GSS3219B Owner’s Manual... - Page 9 Repeat the procedure for the frame of cart left side panel. e) Go back and tighten all bolts using the screwdriver provided. M6X15 Bolt 4 PCS M6 Spring Washer 4 PCS M6 Flat Washer 4 PCS GSS3219B Owner’s Manual...
- Page 10 Push down the top pin of left door (G-1) and insert it into the pre-drilled hole on the left end of front beam. Repeat the procedure for the right door (G-2). d) Close the two doors. GSS3219B Owner’s Manual...
- Page 11 M6 washer (EE) into each pre-drilled hole. Tighten bolts by hand until secured. d) Go back and tighten all bolts using the screwdriver provided. M6X15 Bolt 2 PCS M6 Spring Washer 2 PCS M6 Flat Washer 2 PCS GSS3219B Owner’s Manual...
- Page 12 Repeat the above procedure for the assembly of right side shelf (K) and body assembly (L). h) Go back and tighten all bolts using the screwdriver provided. M6 X 33 Bolt 2 PCS M6X15 Bolt 2 PCS M6 Flat Washer 2 PCS GSS3219B Owner’s Manual...
- Page 13 (O). d) Go back and tighten all bolts using the screwdriver provided. M4X15 Bolt 4 PCS M4 Flat Washer 4 PCS M4 Spring Washer 4 PCS M4 Nut 4 PCS GSS3219B Owner’s Manual...
- Page 14 Place the heat plates (P) onto the heat plate support. b) Place the cooking grids (Q) upon the heat plates. Place the warming rack (R) on the warming grid support as shown. d) Close the top lid. GSS3219B Owner’s Manual...
- Page 15 Step 16 (Grease cup & support assembly) a) Hook the grease cup support (S) into the two holes on the grease pan. b) Place the grease cup (T) onto the grease cup support. GSS3219B Owner’s Manual...
- Page 16 Re-cover the battery cover onto the LED light. M6X15 Bolt 2 PCS M6 Spring Washer 2 PCS M6 Flat Washer 2 PCS battery 3 PCS Fully Assembled View Left Side Right Side GSS3219B Owner’s Manual...
-
Page 17: Operating Your Grill
8. Place dust cap on cylinder valve outlet whenever the cylinder is not in use. Install only the type of dust cap on cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in leakage of propane. DANGER: To prevent fire or explosion hazard when testing for a leak: GSS3219B Owner’s Manual... -
Page 18: Checking For Leaks
3. Press the valve knob and rotate it counterclockwise to the ‘’HIGH’’ position. The burner should light immediately. If more than one burner is desired, repeat the procedure 2-3 until all desired burners are lit. 4. Adjust burners to the desired cooking temperature. GSS3219B Owner’s Manual... - Page 19 FIG. B FIG. C Normal: Soft blue flames with yellow Out of adjustment: Noisy hard blue Poor combustion: Wavy, yellow tips between I inch - 2 inches high. flames – too much air. flames- too little air. GSS3219B Owner’s Manual...
-
Page 20: Excess Flow Safety Valve Reset Procedure
To ensure the procedure is safely and successfully performed, please carefully follow these instructions. ● Close the LP tank valve. Turn all burner control knobs to the OFF position. Disconnect the regulator from the LP tank. Open the lid of the grill. Turn burner control knobs to HIGH. GSS3219B Owner’s Manual... -
Page 21: Care And Maintenance
Cooking Grates – The porcelain grates have a glass-like composition that should be handled with care. Use a mild dishwashing detergent or baking soda and hot water solution. Non-abrasive scouring powder can be used on stubborn stains. GSS3219B Owner’s Manual... -
Page 22: Troubleshooting
Obstruction of gas flow. Clear burner tubes. Check for bent or kinked hose. Disengagement of burner to valve. Reengage burner and valve. Spider webs or insect nest in venturi. Clean venturi. Burner ports clogged or blocked. Clean burner ports. GSS3219B Owner’s Manual... - Page 23 If flames are blue and noisy – close flap at the end of the venturi tubes in 1/8 in. increments until flames are correct. *Propane Models must be open a minimum of 1/8 in.. GSS3219B Owner’s Manual...
-
Page 24: Warranty Program
If you have any questions related to the product or warranty, please visit our website at www.bbqtek.com or email us to service@bbqtek.com or call our customer service center at 1-877-885-8225, 10:00 A.M. to 19:00 P.M. (EST), Monday through Friday. Manufactured by: Lucas BBQ Co., Ltd. Niuyang Industrial Zone, Liaobu Town, Dong Guan City, Guang Dong, China. Printed in China GSS3219B Owner’s Manual...
