Smooth Fitness CE-2.5 Elliptical User Manual page 8

8 SMOOTH CE 2.5 ELLIPTICAL
COMPLETE PARTS LIST
Item No.
49 Belt 650J
50 End cap
51 Drive pulley 6001
52 Pedal, LH
53 Pedal, RH
54 Adjustable foot
55
56 End cap (T-Bar)
57 Middle cover, LH
58 Middle cover, RH
59 Side cover, LH
60 Side cover, RH
61 FAN
62 motor
63 Screw M5*20
Magnet ∮14.5*7L
64
65 Washer 5/16*16*1.0
66 Pulley
67 Base frame
68 Upright tube
69 Swivel tube, LH
70 Swivel tube, RH
71 Fix handle bar
72 Handle bar, LH
73 Handle bar, RH
74 Pedal tube, left
75 Pedal tube, right
76 Front foot
77 Rear foot
78 Flywheel holder bracket
79 Belt ightener
80 Metal cross, LH
81 Metal cross, RH
82 Cable for Fan
83 Fan control board
84 Metal plate
85 Connecting tube Left
86 Connecting tube Right
87(A) Front cover, LH
87(B) Front cover, RH
88 Front cover
Description Qty. Part No.
1 CE25-49
2 CE25-50
2 CE25-51
1 CE25-52
1 CE25-53
2 CE25-54
2 CE25-55
2 CE25-56
1 CE25-57
1 CE25-58
1 CE25-59
1 CE25-60
1 CE25-61
1 CE25-62
16 CE25-63
1 CE25-64
10 CE25-65
2 CE25-66
1 CE25-67
1 CE25-68
1 CE25-69
1 CE25-70
1 CE25-71
1 CE25-72
1 CE25-73
1 CE25-74
1 CE25-75
1 CE25-76
1 CE25-77
1 CE25-78
1 CE25-79
1 CE25-80
1 CE25-81
1 CE25-82
1 CE25-83
2 CE25-84
1 CE25-85
1 CE25-86
1 CE25-87(A)
1 CE25-87(B)
1 CE25-88
