Display LED's (green)
LAN Port
Power
(RJ-45 connector
Reset
Supply
10/100 Mbps )
(12V;1A)
Table 1: Definitions of the HT70X Connectors
DC 12V
Internet Port (RJ-45)
LAN Port (RJ-45)
RESET
Phone Port(s) (RJ-11)
There are four (4) LED buttons that help you manage the status of your HandyTone 701, and
there are five (5) LED buttons that help you manage the status of your HandyTone 702 and 704.
Table 2: Basic Definitions of the HT70X LEDs Pattern
LEDs
POWER LED
Internet LED
Link/Activity LED
PHONE LED
NOTE: All LEDs display green when ON
Grandstream Networks, Inc.
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: +44 (0)1245 808195 Fax: +44 (0)1245 808299
HT702
LAN Port
Phone (RJ-11
(RJ-45 connector
FXS Ports)
10/100 Mbps
with LEDS)
Power adapter connection
Connect to the internal LAN network. (HT701 Only)
Connect to the internal LAN network. (HT702 and HT704 Only)
Factory Reset button: Press for 7 seconds to reset factory default settings.
FXS port: to be connected to analog phones / fax machines.
Indicates Power. Remains ON when power is connected
Indicates Access to Internet. Remains ON while there is Access (HT701 and HT702 Only)
Indicates if There is Activity on the Internet Port (HT701 and HT702 Only)
Indicate status of the respective FXS Ports-PHONE on the back panel
Unregistered – OFF
Registered and Available – ON (Solid Green)
Off-Hook / Busy – Blinking every second
Slow blinking FXS LEDs indicates voicemail
HT-70X User Manual
Firmware Version 1.0.0.18
HT704
Display LED's (green)
Power Phone (RJ-11
Reset
Supply FXS Ports)
(12V;1A)
Page 6 of 35
