INSTALLATION AND
OPERATION MANUAL
GARLAND INDUCTION
BUILT-IN GRIDDLES
with RTCSmp TECHNOLOGY
Real-time Temperature Control System
multi-point sensing
CE models comply with the latest European
Norms:
EN 60335-1, EN 60335-2-36, EN 62233 (EMC/EMV)
North American models: ETL listed in
compliance with UL 197, CSA C22.2 No.109, NSF-4
Complies with FCC part 18, ICES-001
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY
OF THIS OR ANY OTHER APPLIANCE
CAUTION
A SUITABLE GREASE-COLLECTING MEANS MUST BE
IN PLACE BEFORE OPERATING APPLIANCE
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using only genuine
Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed,
adjusted, operated or not maintained in accordance with national and local codes and/or installation instructions provided with
the product or any product that has its serial number defaced, obliterated or removed, and/or which has been modified or
repaired using unauthorized parts or by unauthorized service agents. For a list of authorized service agents and/or genuine
replacement parts, please visit our website at
visit
www.manitowocfoodservice.com.
superseded and is subject to change without notice.
Part # 4532291 Rev 2 (01/15/14)
www.garland-group.com for USA and Canada.
The information contained herein, including design and part specifications, may be
Visit our Video Gallery at
www.Garland-Group.com
SHGRIN3500
SHGRIN5000
PLEASE READ ALL SECTIONS OF THIS MANUAL AND
RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS COMMERCIAL
COOKING EQUIPMENT AND MUST BE INSTALLED BY
PROFESSIONAL PERSONNEL AS SPECIFIED
INSTALLATION
AND ELECTRICAL CONNECTION MUST
COMPLY WITH CURRENT CODES:
IN CANADA – THE CANADIAN ELECTRICAL CODE PART 1
AND / OR LOCAL CODES.
IN USA – THE NATIONAL ELECTRICAL CODE ANSI / NFPA
– CURRENT EDITION.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN CAUSE PROPERTY
DAMAGE, INJURY, OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE INSTRUCTIONS
THOROUGHLY BEFORE INSTALLING OR SERVICING THIS
EQUIPMENT
© 2013 Garland Commercial Ranges Limited
Models:
For international customers, please
Advertisement
Table of Contents
Related Manuals for Garland SHGRIN3500
Summary of Contents for Garland SHGRIN3500
- Page 1 IN PLACE BEFORE OPERATING APPLIANCE Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using only genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed,...
-
Page 2: Warranty
Garland RTCSmp Induction Built-in Griddles WARRANTY Our warranty statements for induction products are available on-line. Please visit our website at www.garland-group.com/minisite/service to download the latest revision. If you might have any questions, please contact Garland. USING THIS MANUAL This manual contains important information regarding safety, installation, operation, maintenance, and troubleshooting. -
Page 3: Table Of Contents
Installation and Operation Manual Garland RTCSmp Induction Built-in Griddles CONTENTS WARRANTY ............................. 2 USING THIS MANUAL ........................2 DESCRIPTION OF WARNING SYMBOLS ..................2 CONTACTS ............................2 Safety Requirements ......................4 1.1 Risk Involved By Disregarding Safety Information ....................4 1.2 Safety Instructions for Operator ............................. -
Page 4: Safety Requirements
Risk Involved By Disregarding Safety Information Disregarding the safety instructions may cause harm to people, the surroundings, and the induction unit. Garland is not responsible for any damages or personal injury caused by failure to observe the safety requirements. Risks involved when disregarding safety precautions may include: •... -
Page 5: Improper Use Of The Equipment
Unauthorized Modification and Use of Spare Parts Please contact Garland if you intend to make any changes on the induction unit. For safety reasons, always use genuine parts and accessories approved by Garland. Any unauthorized modification as well as any installation of unapproved components will void all warranty. -
Page 6: Components And Features
Components and Features Garland RTCSmp Induction Built-in Griddles Components and Features Application The unique and patented RTCSmp Install Griddle-Line units are specially engineered for cooking a large variety of food throughout the day. These compact griddles offer numerous great features including fast heat up time, uniform heat distribution, and precise temperature monitoring across the entire cooking surface. -
Page 7: Dimensions And Technical Specifications
Dimensions and Technical Specifications Garland RTCSmp Induction Built-in Griddles Dimensions and Technical Specifications Rating Plate The rating plate lists important information such as model number, serial number, and electrical specifications. The rating plate is affixed to the bottom of the unit. -
Page 8: Operating Conditions
Dimensions and Technical Specifications Garland RTCSmp Induction Built-in Griddles Operating Conditions Max. Tolerance of Nominal Supply Voltage +6 /-10 % Supply frequency 50/60 Hz Ingress Protection class IP X0 Maximum Ambient Temperature In Storage > -4°F to +158°F (-20°C to +70°C) In Operation >+ 41°F to +104°F (+5°C to +40°C) -
Page 9: Installation
Installation Garland RTCSmp Induction Built-in Griddles Installation IMPORTANT • Kitchen designers and installation contractors are responsible for designing and installing correctly the appropriate support structures and ventilation system for the cooking equipment. • When designing kitchen cabinets for the induction equipment, please take into account all installation requirements, including factors such as: ease of electrical installation, size of the power conductor, and length of the wires. -
Page 10: Grease Chute And Grease Collector
Installation Garland RTCSmp Induction Built-in Griddles • When installing the built-in unit, ensure the intake air and exhaust air are conducted separately. The in- take air and exhaust air must not mix. To avoid build-up of hot exhaust air inside the counter, draw the exhaust air out of the counter. -
Page 11: Dimensions And Installation
Installation Garland RTCSmp Induction Built-in Griddles The call-outs in the illustrations show: (C) Air Intake Kit: the air duct can be connected from the unit to the bottom or to the side of the cabinet. (D) If there is no direct path to install the air intake duct/grease chute, make openings on an inner shelf for the duct/chute to pass through. -
Page 12: Built-In Griddle Plate Installation
Installation Garland RTCSmp Induction Built-in Griddles Template for Holes and Studs: C. Four (4) welding bolts D. Opening for service interface E. Holes for mounting control switch To install a control unit: Use the dimensions from the template above to install studs and create cut-outs on the cabinet. -
Page 13: Drop-In Mounting Instructions
Installation Garland RTCSmp Induction Built-in Griddles 4.5.2.2 Drop-In Mounting Instructions IMPORTANT To protect the induction unit from water penetration, you must apply and bond the silicone adhesive properly to create a water-tight seal. Before you begin the installation, it is very important to use... -
Page 14: Air Intake Kit Installation
Installation Garland RTCSmp Induction Built-in Griddles To flush mount the griddle unit: IMPORTANT To protect the induction unit from water penetration, you must apply and bond the silicone adhesive properly to create a water-tight seal. Before you begin the installation, it is... -
Page 15: Installation Steps
Installation Garland RTCSmp Induction Built-in Griddles An example of an Air Intake Kit connected to a built-in induction unit: A. Cut-out opening B. Silicone (PACTAN) C. Air exhaust opening D. Sleeve with clamp mounted on bottom of unit E. Flex aluminum air duct (max. length 244cm [96”] ) F. -
Page 16: Electrical Installation
Installation Garland RTCSmp Induction Built-in Griddles Electrical Installation IMPORTANT • Refer to the electrical specifications in chapter 3 Dimensions and Technical Specifications AND markings/instruction labels on the unit. If the information differs between the data listed in the manual and the markings on the unit, always follow the markings on the unit. -
Page 17: Function Test
Function Test Garland RTCSmp Induction Built-in Griddles Function Test IMPORTANT When the unit is in use, the griddle plate is hot. To avoid CAUTION burn injuries, do not touch the unit during operation. • Before carrying out the function test, the user must understand how to operate the unit. -
Page 18: Operating Instructions
When the system is in the stand-by mode, the point on the display blinks once every second. Heat-up Time — from 68° - 392°F (20° - 200°C): • SHGRIN3500, approx. 4 ½ minutes | SHGRIN5000, approx. 3 ½ minutes Part # 4532291 Rev 2 (01/15/14) -
Page 19: Considerations
• Using Proper Cooking Utensils Use only Garland Induction Griddle Spatula (provided) to turn over food products on the griddle plate. Using any sharp-edged objects such as knife or fork can damage the griddle surface. • Recovering from Temperature Loss Temperature loss occurs when cold food is put on the griddle plate. -
Page 20: Cleaning
A dirty, blocked air intake filter can cause electronic damage to the induction unit. Ensure to clean the filter at least once a week or as often as required. Garland’s Air Intake Filter is dishwasher-safe. Wipe the filter dry before inserting it back into the Filter Holder. -
Page 21: Maintenance
Maintenance Garland RTCSmp Induction Built-in Griddles Maintenance Maintenance and servicing work other than cleaning as described in this manual must be done by an CAUTION authorized service personnel. Do not open the induction unit – dangerous electric voltage inside! The induction unit may only be opened by an authorized service personnel. -
Page 22: 10 Troubleshooting
Only an authorized service technician would have the training and correct tools to diagnose the internal components accurately and thoroughly. Contact a Factory Authorized Service agency for assistance. For a list of Garland authorized service agencies, please visit our website www.garland-group.com. Part # 4532291 Rev 2 (01/15/14) -
Page 23: 10.2 Problems And Possible Causes
Troubleshooting Garland RTCSmp Induction Built-in Griddles 10.2 Problems and Possible Causes Problem Possible Causes Action To Take By Operator No heat, 7-segment No power supply. Check the electrical supply, e.g. power cable plugged into the wall socket. display is OFF (dark) Check primary fuses. -
Page 24: Troubleshooting With Error Codes (For Service Technicians)
When a malfunction occurs, an Error Code (e.g. E03) alternating with the set value is shown on the display. To obtain the internal data and error code for troubleshooting, you need an IR Adapter, proper connectors, and software. The table below is a reference guide. For further information and assistance, please contact Garland Technical Service. - Page 25 Troubleshooting Garland RTCSmp Induction Built-in Griddles NOTES: Part # 4532291 Rev 2 (01/15/14)
- Page 26 Troubleshooting Garland RTCSmp Induction Built-in Griddles NOTES: Part # 4532291 Rev 2 (01/15/14)
- Page 27 Installation and Operation Manual Garland RTCSmp Induction Built-in Griddles CORRECT DISPOSAL OF THIS PRODUCT This marking shown on the product indicates that the product should not be disposed as household waste or regular commercial waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment.
- Page 28 Installation & Operation Manual GARLAND INDUCTION BUILT-IN GRIDDLES with RTCSmp TECHNOLOGIES Garland Commercial Ranges Ltd. T. 1-905-624-0260 USA Sales, Parts and Service 1-800-424-2411 1177 Kamato Road, Mississauga, F. 1-905-624-5669 Canadian Sales 1-888-442-7526 Ontario, CANADA L4W 1X4 www.garland-group.com Canada or USA Parts/Service 1-800-427-6668...
