INSTALLATION AND
OPERATION MANUAL
GARLAND ECG SERIES
ELECTRIC PRODUCTION
GRIDDLES
FOR YOUR SAFETY:
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
IMPROPER INSTALLATION, ADJUSTMENT,
ALTERATION, SERVICE OR MAINTENANCE
CAN CAUSE PROPERTY DAMAGE, INJURY,
OR DEATH. READ THE INSTALLATION,
OPERATING AND MAINTENANCE
INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR
SERVICING THIS EQUIPMENT
Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent
using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been
improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation
instructions provided with the product, or any product that has its serial number defaced, obliterated or removed,
or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
For a list of authorized service agents, please refer to the Garland web site at http://www.garland-group.com.
The information contained herein, (including design and parts specifications), may be superseded and is subject
to change without notice.
GARLAND COMMERCIAL INDUSTRIES
185 East South Street
Freeland, Pennsylvania 18224
Phone: (570) 636-1000
Fax: (570) 636-3903
Part # 3073400 (01/28/08)
Part #3073400 (01/28/08)
APPLIANCE
WARNING:
GARLAND COMMERCIAL RANGES, LTD.
1177 Kamato Road, Mississauga, Ontario L4W 1X4
CANADA
Phone: 905-624-0260
Fax: 905-624-5669
PLEASE READ ALL SECTIONS OF THIS MANUAL
AND RETAIN FOR FUTURE REFERENCE.
THIS PRODUCT HAS BEEN CERTIFIED AS
COMMERCIAL COOKING EQUIPMENT AND
MUST BE INSTALLED BY PROFESSIONAL
PERSONNEL AS SPECIFIED.
INSTALLATION AND ELECTRICAL CONNECTION
MUST COMPLY WITH CURRENT CODES:
IN CANADA - THE CANADIAN ELECTRICAL
CODE PART 1 AND / OR LOCAL CODES.
IN USA – THE NATIONAL ELECTRICAL CODE
ANSI / NFPA – CURRENT EDITION.
ENSURE ELECTRICAL SUPPLY CONFORMS WITH
ELECTRICAL CHARACTERISTICS SHOWN ON
THE RATING PLATE.
Enodis UK LTD.
Swallowfi eld Way, Hayes, Middlesex UB3 1DQ ENGLAND
Telephone: 081-561-0433
Fax: 081-848-0041
© 2004 Garland Commercial Industries, Inc.
Page 1
Advertisement
Table of Contents
Related Manuals for Garland ECG-24R
Summary of Contents for Garland ECG-24R
- Page 1 Users are cautioned that maintenance and repairs must be performed by a Garland authorized service agent using genuine Garland replacement parts. Garland will have no obligation with respect to any product that has been improperly installed, adjusted, operated or not maintained in accordance with national and local codes or installation instructions provided with the product, or any product that has its serial number defaced, obliterated or removed, or which has been modified or repaired using unauthorized parts or by unauthorized service agents.
-
Page 2: Important Information
IMPORTANT INFORMATION WARNING: This product contains chemicals known to the state of california to cause cancer and/or birth defects or other reproductive harm. Installation and servicing of this product could expose you to airborne particles of glass wool/ceramic fibers. Inhalation of airborne particles of glass wool/ceramic fibers is known to the state of California to cause cancer. -
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT INFORMATION......... . 2 DIMENSIONS AND SPECIFICATIONS . -
Page 4: Dimensions And Specifications
6" (152mm) NEMA 15-30P NEMA 15-50P NEMA 15-20P NEMA 8-50P Entry Crated Uncrated ECG-24R ECG-24R 208V, 3ph ECG-48R ECG-24R 240V, 1ph 240v, 3ph ECG-36R 208V, 3ph 208/240V, 3ph (208V requires 40" (1016mm) 38" (965mm) ECG-36R 240V, 3ph 60A locking plug) -
Page 5: Introduction
If there is any question of interpretation of any of the literature pertaining to Garland Electric Chain Griddles, please contact your Authorized Service Agency or our Customer Service Department at 1 800 427 6668. -
Page 6: Siting
Electrical Connections The base on which the unit is to be sited, must be capable of The Garland ECG series complies with the standards adequately supporting the weight of the appliance and any CSA C22.2 no. 109 – latest edition, the UL197 – latest ancillary equipment. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Griddles 2. Switch “OFF” all sections. 3. Switch “OFF” main power switch on the control panel. Griddle tops are designed to have food cooked directly on the surface. Do not put pots or pans on the griddle surface as Thermostat Temperature Verification this will scratch or nick the surface and will result in improper cooking or sticking of product. -
Page 8: Maintenance & Cleaning
MAINTENANCE & CLEANING Preparing A New Griddle Griddle Cleaning 1. Remove the protective coating on the surface using a After Each Use mild detergent. 1. Using a traditional 64mm-76mm (2 1/2”-3”) scraper 2. Thoroughly rinse the griddle with vinegar and a water or spatula scrape the griddle surface (to remove food solution (3/4-cup vinegar per quart of water) and dry. -
Page 9: Griddles Do's & Don'ts
MAINTENANCE & CLEANING Continued Griddles Do’s & Don’ts 3. Do not use the griddle as a hot top. A large pan or pot will trap heat and can cause the griddle plate to warp. DO’S 4. Do not overheat the griddle to preheat faster. Preheating 1. - Page 10 Page 10 Part #3073400 (01/28/08)
