Installation

Installation, cont'd

Rear Panel Features

100-240V 50/60 Hz 0.5A
1 2
Figure 2-1 — ECP 1000 rear panel
AC power connector — One standard AC power connector
1
attaches the event control panel to any power source from
100VAC to 240VAC, operating at 50 or 60 Hz.
Cooling fan — One fan cools the ECP 1000 unit. The filter can
2
be removed and washed as needed. See page A-2 for
instructions.
RS-232/program connector — One 9-pin D female connector
3
allows you to communicate with Extron's SGS 408 Control
Program.
RS-232/SGS 408 connectors — Three 9-pin D female connectors
4
allow you to attach an ECP 1000 event control panel to up to
three SGS 408 seamless switchers. The connectors correspond to
the screen selection buttons on the ECP 1000's top panel.
Installation
To install and set up the ECP 1000, follow these steps:
Mount the SGS 408 switcher(s) as described in the SGS 408
1
User's Manual (Extron part number 68-520-01).
Set the ECP 1000 on a flat surface.
2
For each SGS 408 to which the ECP 1000 will be connected,
3
attach an ECP comm cable (provided with the SGS 408)
between an SGS connector on the ECP 1000 and the RS-232
connector on the SGS 408. Figure 2-2 shows a typical
application.
If desired, attach a host computer or other control device
4
to the RS-232/program connector.
2-2 ECP 1000 • Installation
TO SGS
3 2 1
PROGRAM
3 4
Continue the procedure for installing the SGS 408.
5
Attach power cords and plug the SGS 408 seamless
6
switcher, ECP 1000 event control panel, input devices, and
output devices into a grounded AC source.
Select an input from the front panel buttons on the
7
SGS 408 switcher or RCP 1000 remote control unit.
The image should now appear. If not, ensure that all
8
devices are plugged in and receiving power. Check the
cabling and make adjustments as needed. Select a
different input to check for a display.
Projectors
SGS 408
CT N CT N
EFFE TRAN SITIO TRAN EFFE SITIO
INPUT 408 INPUT 408
SGS CHER SGS CHER
SITIO TAKE NS RAM IEW HIC SWIT TAKE SITIO NS IEW RAM HIC SWIT
TRAN PROG PREV LESS GRAP TRAN PROG PREV GRAP LESS
CUT UT RATE SEAM CUT RATE UT SEAM
8 OUTP 8 OUTP
7 EFFE CTS 2 7 EFFE CTS 2
6 1 6 1
5 5
M 4 M 4
PRO GRA 4 PRO GRA 4
3 3 3 3
2 8 2 8
1 7 1 7
BLAC K ION BLAC K ION
FREE ZE 6 MUN ICAT FREE ZE 6 MUN ICAT
5 RCP COM Tx 5 RCP COM Tx
PREV IEW 4 Rx PREV IEW 4 Rx
3 3
2 2
1 1
K K
ZE BLAC ZE BLAC
FREE FREE
Program
Program
Monitor
Monitor
Preview
Preview
Monitor
Monitor
ECP 1000
Up to 50'
RCP 1000
Figure 2-2 — SGS 408 and ECP 1000 application
ECP 1000 • Installation
SGS 408
CT N
EFFE TRAN SITIO
INPUT 408
SGS CHER
TAKE NS SITIO IEW RAM HIC SWIT
TRAN PREV PROG LESS GRAP
CUT UT RATE SEAM
8 OUTP
7 EFFE CTS 2
6 1
5
M 4
PRO GRA 4
3 3
2 8
1 7
BLAC K ION
FREE ZE 6 MUN ICAT
5 RCP Tx COM
PREV IEW 4 Rx
3
2 SGS 408
1
K
ZE BLAC
FREE
Program
Monitor
Preview
Monitor
Control Room
2-3
