- Page 1 User Guide SCP 226 and SCP 104 Series System Control Panels 68-959-01 Rev. F 07 12...
- Page 2 Precautions Safety Instructions • English Warning Power sources • This equipment should be operated only from the power source indicated on the product. This equipment is intended This symbol is intended to alert the user of important to be used with a main power system with a grounded (neutral) operating and maintenance (servicing) instructions in the conductor.
- Page 3 安全须知 • 中文 警告 电源 • 该 设 备 只 能 使 用 产 品 上 标 明 的 电 源 。 设 备 这个符号提示用户该设备用户手册中 必 须 使 用 有 地 线 的 供 电 系 统 供 电 。 第 三 条 线 有重要的操作和维护说明。...
- Page 4 Conventions Used in this Guide Notifications the following are used: WARNING: Risk of physical injury. A warning indicates a situation that has the potential to result in death or severe injury. ATTENTION: Attention indicates a situation that may damage or destroy the product or associated equipment.
-
Page 5: Table Of Contents
........1 Remote Communication ....31 Setting Up RS-232 About this Guide ........1 Communication ......31 About the SCP 104 and SCP 226 System Control Panels ......1 Communications Between the Features ..........2 Host and the SCP ......31 SCP-initiated Messages ....32 Application Diagrams ......3 Error Responses ......32... - Page 6 SCP 104 and SCP 226 • Contents...
-
Page 7: Introduction
Introduction This section gives an overview of the SCP 104 and SCP 226 System Control Panels and describes their features. Topics include: • About this Guide • About the SCP 104/226 Series System Control Panels • Application Diagrams About this Guide This guide discusses how to install, connect, and operate the Extron SCP 104 and SCP 226 System Control Panels. -
Page 8: Features
The MediaLink controllers and the System 5 IP each support up to two of the SCP 104/226, the SCP 226 L, or the SCP 104/226 AAP models. The MLC 104/226 and the System 5 IP can each support up to four control modules and one IR Link infrared signal repeater, which can be daisy-chained with the panels. -
Page 9: Application Diagrams
Projector Control Control Projector SHIF /ADS INTE ITOR INPU Extron RGBHV RGB 109xi Video Interface S-video Document Camera Figure 1. Connection Diagram for an SCP 226 AAP with a System 5 IP Switcher SCP 104 and SCP 226 • Introduction... - Page 10 MLS 103V Extron MediaLink ® MPA 152 Switcher Mini Power Ampli er IF IE M IN ST ER Video Extron Audio SI 26 Surface-Mount Speakers Figure 2. Connection Diagram for an SCP 104 SCP 104 and SCP 226 • Introduction...
-
Page 11: Installation And Operation
Installation and Operation This section describes the front and rear panel features of the six SCP 104/226 models and provides procedures for installing and operating the control panels. Topics that are covered include: • UL Requirements Installation Overview • •... -
Page 12: Installation Overview
Locate the small corner notch on the clear cap, and slide the screwdriver between the clear cap and the diffuser (see figure 3). Using a rotating motion of the screwdriver, carefully pry the two pieces apart (see figure 3). SCP 104 and SCP 226 • Installation and Operation... - Page 13 Gently, but firmly, press the reassembled button into place on the SCP front panel. Repeat steps 1 through 7 as needed to relabel other buttons. SCP 104 and SCP 226 • Installation and Operation...
-
Page 14: Rear Panel Features And Connections
Off (down) if the SCP will be connected to an MLC or • a System 5 IP On (up) if the SCP will be operating in • standalone mode (not connected to a controller) 2 3 4 SCP 104 and SCP 226 • Installation and Operation... - Page 15 Off (down) if the SCP 104 will be • connected to an MLC 104. On (up) if the SCP 104 will be connected to a System 5 • IP or an MLC 104 IP Plus. SCP power and control connectors — These two female 5-pole 3.5 mm captive screw connectors function identically...
-
Page 16: Wiring The Rs-232 Port
Ground (G) 5 Ground Rx Receive Transmit (Tx) Receive (Rx) 2 Transmit 9-pin HD Connector To Computer or Control System RS-232 Port Figure 6. Connecting a Host to the SCP 104 SCP 104 and SCP 226 • Installation and Operation... - Page 17 SCP to be able to communicate with the computer or terminal emulator. • Do not connect anything to this port if an MLC or a System 5 IP is connected to the SCP. SCP 104 and SCP 226 • Installation and Operation...
-
Page 18: Wiring The Power Connector (Optional)
• Do not tin the stripped power supply leads before installing the captive screw connector. Tinned wires are not as secure in the captive screw connectors and could be pulled out. SCP 104 and SCP 226 • Installation and Operation... -
Page 19: Connecting To The Mlc 104/226, The System 5 Ip, And Control Modules
MLC 104 IP Plus, the SCP must have firmware version 1.01 or higher. • When an SCP 104/226 is connected to a System 5 IP switcher, the SCP must have firmware version 1.01 or higher loaded, and the switcher must have firmware version 2.01 or higher. - Page 20 Ground ( ) & Drain Wire +12 VDC = Red Figure 11. Connecting the SCP 226 to the MLC 226 IP SCP 104 to MLC 104 IP Plus with IRCM-DV+ modules COMM LINK MLC 104 IP Plus A B C D E Rear Panel...
- Page 21 = Black & Drain Wire Ground ( ) & Drain Wire +12 VDC = Red Figure 13. Connecting Control Modules to Two SCP 226 Control Panels and to an MLC 226 IP SCP 104 and SCP 226 • Installation and Operation...
- Page 22 = Violet = Black & Drain Wire Ground ( ) & Drain Wire +12 VDC = Red Figure 14. Connecting an SCP 104 to a System Switcher and a Control Module SCP 104 and SCP 226 • Installation and Operation...
- Page 23 = Black & Drain Wire Ground ( ) & Drain Wire +12 VDC = Red Figure 15. Connecting Two SCP 26 Control Panels to a System Switcher and Two Control Modules SCP 104 and SCP 226 • Installation and Operation...
-
Page 24: Scp And System 5 Ip Button Unctions
5/ PC ADJUST System 5 IP DISPLAY VOLUME CONFIG SCP 104 SCP 104 Figure 16. Button Equivalents on an SCP 104 Connected to a System 5 IP Switcher SYSTEM 5 IP VOLUME PROJECTOR INPUT SELECTION INPUT 5 CLIP AUTO PC VIDEO... -
Page 25: Mounting The Scp
Mounting Options You can mount the SCP 104/226 in an electrical box or surface mounting box (not provided), or you can use a mounting bracket (not provided) to secure it to a wall, podium, table, or other furniture. -
Page 26: Mounting To A Lectern (Scp 226 L)
SCP using the provided wood screws. NOTE: The templates are not to scale and are provided for reference only. Lectern Extron SCP 226 L Figure 19. Mounting an SCP 226 L to a Lectern SCP 104 and SCP 226 • Installation and Operation... -
Page 27: Front Panel Features
Front Panel Features The controls on the SCP 104/226 replicate the programmed MLC 104/226 buttons and controls, and most of the System 5 IP front panel controls. All button functions for the MLCs and the System 5 IP are configured via RS-232 or Ethernet. - Page 28 PROJECTOR VOLUME SCP 104 Figure 20. SCP 104 Front Panel SCP 104 AAP Figure 21. SCP 104 AAP Front Panel SCP 104 and SCP 226 • Installation and Operation...
- Page 29 PROJECTOR VOLUME Extron SCP 226 Figure 22. SCP 226 Front Panel PROJECTOR VOLUME Extron SCP 226 AAP Figure 23. SCP 226 AAP Front Panel SCP 104 and SCP 226 • Installation and Operation...
- Page 30 The SCP 104 models have four of these buttons, while the SCP 226 models have nine. (The buttons indicated by the front panel illustrations have a different set of switch...
- Page 31 IR 402 with an SCP 226 L. PROJECTOR VOLUME Extron SCP 226 SCP 226 L 30 feet maximum IR 402 Remote Figure 25. Using the IR 402 with an SCP 226 SCP 104 and SCP 226 • Installation and Operation...
-
Page 32: Resetting
PROJECTOR To reset, press and hold these buttons VOLUME simultaneously while applying power. SCP 104 Figure 27. Resetting the SCP 104 to Factory Defaults SCP 104 and SCP 226 • Installation and Operation... -
Page 33: Updating The Firmware
SCP. You can obtain the Firmware Loader from the Extron website as follows: Visit the Extron website at www.extron.com. On the Extron home page, select the tab. Download SCP 104 and SCP 226 • Installation and Operation... -
Page 34: Loading Firmware To The Scp
Firmware left sidebar menu. The Download Center Firmware screen appears. Locate SCP 104/226 on the firmware list and click on the link at right. Download Follow the instructions on the subsequent screens to download and install the latest firmware on your computer. - Page 35 . When the computer connects to the SCP, the Connect following message appears in the Connected Device field: Figure 32. Successful Connection Message In the New Firmware File (Optional) section of the Add Device screen, click Browse SCP 104 and SCP 226 • Installation and Operation...
- Page 36 When the firmware update is finished, appears Completed above the Total Progress bar. In the Devices section, the Progress column displays , and the Status column 100% displays . Close the Firmware Loader window. Completed SCP 104 and SCP 226 • Installation and Operation...
-
Page 37: Remote Communication
Most responses from the panel to the host end with a carriage return and a line feed (CR/LF), which signals the end of the response character string. A string is one or more characters. SCP 104 and SCP 226 • Remote Communication... -
Page 38: Scp-Initiated Messages
– Bad filename/File not found Using SIS Commands SIS commands can be used with the SCP 104/226 only when it is in standalone mode; that is, DIP switch #1 on the rear panel is in the On (up) position. The available commands enable you to test the front panel LEDs and buttons, and to query for certain information about the SCP. -
Page 39: Using The Command And Response Tables
71. The hex codes for both versions of the same letter can be used interchangeably unless otherwise stated. In the SIS command and response tables, only the lowercase version of the command and its hex equivalent are shown. SCP 104 and SCP 226 • Remote Communication... -
Page 40: Command And Response Table For Sis Commands
Query firmware version — q or 1q 31 71 x.xx factory Query firmware version — 32 71 y.yy updated Query part number 60-671-nn = SCP 226 60-671-nn 60-672-nn = SCP 104 60-672-nn Query model name and nnn = 104 or 226 SCPnnn description... - Page 41 ASCII Command Response Command Additional Description (Host to SCP) (Host to SCP) (SCP to Host) Information Requests (continued) Request control module and 33 32 69 P1nn • K1nn • K2nn • K3nn • K4nn • connected modules (for 3-pole connection only) nn = SCP address nn = control module 1;...
- Page 42 ASCII Command Response Command Additional Description (Host to SCP) (Host to SCP) (SCP to Host) Upload Firmware Upload firmware When you receive the Go Upload response, upload the firmware according to the procedure for your terminal emulator. When the upload is complete, you receive the response.
-
Page 43: Special Function Sis Commands
Special Function SIS Commands The syntax for setting a special function for an SCP 104/226 , where is the value of the action to be * __ # performed, is the value for the button or switch, and the function number. -
Page 44: Command And Response Table For Special Function Sis Commands
Command and Response Table for Special Function SIS Commands X? and Y? Values and ASCII Command Response Command Additional Descriptions (Host to SCP) (SCP to Host) Switch Responses X? ] Button press on front panel or (none) = Switch number for the function. SwPrs * remote control There are 128 options available... - Page 45 ASCII Command Response X? and Y? Values and Command (Host to SCP) (SCP to Host) Additional Descriptions Front Panel Button LED Control X? ] FPC lamp control = LED state: = Button: * 51# 0 = all LEDs off 0 = no button 1 = green LED on 1 = projector on 2 = red LED on...
-
Page 46: Using The Switch And Button Table
SCP front panels and on the IR 402 remote control (see the Switch and Button table). The switch locations are the same on the SCP 104/226 AAP and on the SCP 226 L. SCP 104 and SCP 226 • Remote Communication... - Page 47 Front panel switch locations PROJECTOR VOLUME Extron SCP 226 Figure 35. Switch Locations on the SCP 226 Fig_Switch locations SCP 104 PROJECTOR VOLUME SCP 104 Figure 36. Switch Locations on the SCP 104 SCP 104 and SCP 226 • Remote Communication...
- Page 48 Module 2: switches 46-65 Module 3: switches 66-85 Module 4: switches 86-105 Switch numbers are sequential from left to right, top row to bottom row, as shown in figure 38 on the next page. SCP 104 and SCP 226 • Remote Communication...
- Page 49 26 to 45. 46 to 65. PREV/REW PLAY NEXT/FWD PAUSE STOP PREV/REW PLAY NEXT/FWD PAUSE STOP DVD Half VCR Half (Module 1) (Module 2) Figure 38. Switch Numbering for Control Modules (IRCMs and RCMs) SCP 104 and SCP 226 • Remote Communication...
-
Page 50: Switch And Button Table
CM0_11 Pause − VCR CM2_14 Rewind − VCR CM0_12 CM2_15 CM0_13 Forward − VCR CM2_16 CM0_14 Menu − DVD CM2_17 CM0_15 CM2_18 Undefined CM0_16 CM2_19 Undefined CM0_17 CM2_20 Not valid CM0_18 CM3_1 SCP 104 and SCP 226 • Remote Communication... -
Page 51: Reference Information
SCP 226 AAP (black or white) 60-671-12, -13 SCP 226 L (black or white) 60-671-32 Included Parts These items are included in each order for an SCP 104 or SCP 226. Models Part Numbers 3.5 mm, 5-pole male captive screw... -
Page 52: Recommended Cables
SMB 102 2-gang (black) 60-640-02 SMB 103 3-gang (black) 60-641-02 SMB 104 4-gang (black) 60-642-02 SMB 105 5-gang (black) 60-643-02 Other Mounting Options MLM-WB+ (black) 60-458-03 UCM RAAP (black, white) 70-344-02, -03 SCP 104 and SCP 226 • Reference Information... -
Page 53: Cutout Templates
SCP 104 4.50" 2.83" FOR FURNITURE MOUNT (11.43 cm) (7.40 cm) To install SCP 104 directly into furniture, cut along this line. 0.61" (1.55 cm) 1.40" (3.56 cm) TEMPLATE IS NOT FULL SIZE. SCP 104 and SCP 226 • Reference Information... -
Page 54: Scp 104 Aap Cutout Template
(21.16 cm) To install SCP 104 directly into furniture, cut along this line. SURFACE CUT-OUT AREA Top Panel FOR FURNITURE MOUNT 1.45" (3.68 cm) 0.61" TEMPLATE IS NOT FULL SIZE. (1.55 cm) SCP 104 and SCP 226 • Reference Information... -
Page 55: Scp 226 Cutout Template
SCP 226 SURFACE CUT-OUT AREA FOR FURNITURE MOUNT 6.40" (16.3 cm) To install SCP 226 directly into furniture, cut along this line. 1.39" (3.53 cm) 0.61" (1.55 cm) TEMPLATE IS NOT FULL SIZE. SCP 104 and SCP 226 • Reference Information... -
Page 56: Scp 226 Aap Cutout Template
10.13" (25.65 cm) 8.72" (22.15 cm) SURFACE CUT-OUTAREA 3.62" FOR FURNITURE MOUNT (9.20 cm) 1.45" (3.68 cm) TEMPLATE IS NOT FULL SIZE. 0.61" (1.55 cm) SCP 104 and SCP 226 • Reference Information... -
Page 57: Scp 226 L Cutout Template
SURFACE CUT-OUT AREA SCP 226 FOR FURNITURE MOUNT 6.50" (16.51 cm) To install SCP 226 directly into furniture, cut along this line. 0.25" (0.64 cm) 0.30" (0.76 cm) TEMPLATE IS NOT FULL SIZE. SCP 104 and SCP 226 • Reference Information... - Page 58 SCP 104 and SCP 226 • Reference Information...
- Page 59 Extron Warranty Extron Electronics warrants this product against defects in materials and workmanship for a period of three years from the date of purchase. In the event of malfunction during the warranty period attributable directly to faulty workmanship and/or materials, Extron Electronics will, at its option, repair or replace said products or components, to whatever extent it shall deem necessary to restore said product to proper operating condition, provided that it is returned within the warranty period, with proof of...
- Page 60 Extron USA Headquarters Extron Europe Extron India +800.633.9876 (Inside USA/Canada Only) +800.3987.6673 (Inside Europe Only) 1800.3070.3777 (Inside India Only) +31.33.453.4040 +91-80 3055.3777 Extron USA - West Extron USA - East +31.33.453.4050 FAX +91 80 3055 3737 FAX +1.714.491.1500 +1.919.850.1000 +1.714.491.1517 FAX +1.919.850.1001 FAX Extron Japan Extron China...
