Installation, cont'd
Figure 2-5 — Mounting the MKP to the wall box
4. Reconnect the power supply and restore power.

Rear Panel and Side Panel Connections

All connectors are on the rear or side of the MKP (figure 2-6).
These connectors will be inaccessible once the MKP is installed.
1
Tx
HOST
Rx 2
RS-232
GND LAN
Tx
SWITCH
Rx 3
RS-232
GND
12 VDC
4
GND
Figure 2-6 — MKP rear and side panels
2-8 MKP 2000 Remote Control Panel • Installation
3
U T
2 O U TP
1 6
T
IN PU
5
R K E
4
9 TA
8
N C EL
7 C A
0
0
0 0
C K
B A P 2
M K
H O
S T
R S
-2 3 T x
2
R x
L A
G N N
S W D
IT C
R S H T x
-2 3
2
R x
G N
D
1 2
V D
C
G N
D
LAN (Ethernet) port — If desired, connect a Category (CAT) 5e
1
or higher (network) cable between this
Activity
connector and either the matrix switcher to be
LED
controlled or to an Ethernet local area network
Link
(LAN).
LED
RJ-45
See "TP cable termination," on page 2-12, to
Port
properly wire the RJ-45 connector for your
application.
Ethernet connection indicators — The Link and Activity LEDs
indicate the status of the Ethernet connection. The green Link
LED indicates that the MKP is properly connected to an
Ethernet LAN. This LED should light steadily. The yellow
Activity LED indicates transmission of data packets on the RJ-45
connector. This LED should flicker as the MKP communicates.
Host RS-232 port — If desired, connect a host computer or
2
control system to this 3-pole, 3.5 mm, RS-232 connector
(figure 2-7).
Pin Function
Tx
HOST
Rx
TX Transmit data
RS-232
GND
RX Receive data
Tx
SWITCH
Rx Gnd Signal ground
RS-232
GND
Figure 2-7 — RS-232 connector
Switch RS-232 port — If desired, connect a cable between this
3
3-pole, 3.5 mm, RS-232 connector and a matrix switcher
(figure 2-7).
Power connector — Plug the included external 12 VDC power
4
supply into this 2-pole captive screw connector. See "Power
supply wiring," on page 2-14, to wire the connector.
MKP 2000 Remote Control Panel • Installation 2-9
