WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation
and maintenance instructions
thoroughly before installing or
servicing this equipment.
DANGER
Failure to follow these
instructions could result in fire or
explosion that could cause
property damage, personal injury
or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or
on boats or recreational vehicles.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propane.
WARNING
For Outdoor Use Only
(Outside any enclosure)
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS
UNIT FOR SOMEONE ELSE, GIVE THIS MANUAL
TO HIM OR HER TO SAVE FOR FUTURE
REFERENCE.
FOR CUSTOMER SERVICE, CALL 1-877-885-8227,
6 A.M. – 5 P.M. PST, MONDAY-FRIDAY.
GPF2414
Owner's Manual
Deluxe LP Gas Grill
ITEM # 19272
Printed in China
Advertisement
Table of Contents
Related Manuals for BBQ GrillWare 19272
Summary of Contents for BBQ GrillWare 19272
- Page 1 ITEM # 19272 Deluxe LP Gas Grill WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operation and maintenance instructions thoroughly before installing or servicing this equipment. DANGER Failure to follow these...
-
Page 2: Table Of Contents
Table of Contents For Your Safety....................2 Illustrated Parts List ..................4 Hardware List....................5 Assembly Instructions..................6 Operating Your Grill: Connecting Gas Cylinder........14 Checking for Leaks..........14 Lighting Your Grill..........14 Maintenance and Care........15 Award- Winning Barbecue Recipes...............16 Troubleshooting....................17 Warranty Program.....................19 WARNING WARNING FOR YOUR SAFETY FOR YOUR SAFETY If you smell gas: DO NOT store or use gasoline or... -
Page 3: For Your Safety
For Your Safety Dear Valued Customer, Congratulations on your new barbecue grill purchase! You’ve made the right choice. In this manual, you will find assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operation, proper care and use of your grill. - Page 4 CAUTION 1. To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or unless you are wearing protective gear such as pot holders, gloves, BBQ mittens, etc. 2. Do not alter the grill in any manner. 3.
-
Page 5: Illustrated Parts List
Illustrated Parts List 1. Bottom front panel --------------1pc 2. Bottom back panel---------------1pc 3. Bottom left beam ---------------1pc 4. Bottom right beam---------------1pc 5. Decal------------------------------2 pcs 6. Wheel-----------------------------2 pcs 7. Wheel axle--------------------------1pc 8. Top front panel-------------------1pc 9. Top back panel ------------------1pc 10. Top left beam--------------------1pc 11. - Page 6 Step 7 Open lid and attach the grill body (15) as shown. Step 8 Open lid, attach the handle insulator (26), and lid handle (16) onto the lid as shown. GPF2414 Owner’s Manual...
-
Page 7: Hardware List
Hardware List M6 Bolt M4 Bolt 35 pcs 2 pcs M6 Nut M6 Washer 6 pcs 2 pcs M6 Spring M10 Nut Washer 2 pcs 2 pcs M10 Washer Side Burner Knob 2 pcs M6 Washer Screwdriver Wrench 2 pcs (A screwdriver and wrench also are included for your convenience) GPF2414 Owner’s Manual... -
Page 8: Assembly Instructions
Assembly Instructions Remove all contents from packaging. Make sure all parts are present before attempting to assemble. Tighten all bolt connections by hand first. Once the grill is fully assembled, go back and tighten with a screwdriver. Estimated Assembly Time: Approximately 30 to 40 minutes Step 1 Install bottom front panel (1) with bottom back panel (2) by connecting the bottom... - Page 9 Step 3 Install top front panel (8) and top back panel (9) as shown. Step 4 Install top left beam (10) and top right beam (11) as shown. GPF2414 Owner’s Manual...
- Page 10 Step 5 Install top and bottom tank hooks (12 and13) as shown. Step 6 Attach control panel (14) as shown. GPF2414 Owner’s Manual...
- Page 11 Step 9 Connect left and right side shelf supports (17 and 18) and tank partition (27) as shown. Step 10 Attach left and right side shelves (19 and 20) as shown. GPF2414 Owner’s Manual...
- Page 12 Step 11 Install gas valve, connect gas valve orifice with burner venturi tube, and insert side burner knob (H) onto the side burner as shown. Step 12 Place heating plate (21) and cooking grid (22) inside the grill body as shown. GPF2414 Owner’s Manual...
- Page 13 Step 13 Place the warming grid (21) into the lid and grill body as shown. Step 14 Connect grease cup support (24) under grill body and place grease cup (25) on it as shown. GPF2414 Owner’s Manual...
- Page 14 Step 15 Place gas cylinder on top and bottom tank hooks and connect gas regulator with gas cylinder as shown. (Gas tank is sold separately.) Fully Assembled View GPF2414 Owner’s Manual...
-
Page 15: Checking For Leaks
Operating the Grill USE ONLY THE REGULATOR PROVIDED If a replacement is necessary, call our customer service center. The use of unauthorized parts can create an unsafe condition and environment. Connecting Gas Cylinder The propane gas supply cylinder to be used must be constructed and marked in accordance with the Specifications for Propane Gas Cylinders of the U.S. Department of Transportation (DOT). -
Page 16: Side Burner
Precautions After lighting, please observe the burner flame, make sure all burner ports are lit. If burner flame goes out during operation, immediately turn the gas “OFF” and open lid to let the gas clear for at least 5 minutes before re-lighting. Before cooking on grill for the first time, operate the grill for approximately 15 minutes with the lid closed and the gas turned on “HIGH”. -
Page 17: Award-Winning Barbecue Recipes
Cleaning the Burner Assembly Turn gas off at the control knobs and propane tank. Remove cooking grids and heat plate. Remove grease cup. Remove burner by unscrewing nut from beneath burner “foot” using a screwdriver and pliers. Lift burner up and away from gas valve orifice. Clean inlet (venturi) of burner with small bottle brush or compressed air. -
Page 18: Troubleshooting
Troubleshooting Problem Possible Cause Prevention/Cure Burner will not light using Wires or electrode covered Clean wire and/or electrode Knobs. with cooking residue. with rubbing alcohol. Electrode and burners are wet. Wipe dry with cloth. Electrode cracked or Replace electrode. it sparks at the crack. Wire loose or disconnected. - Page 19 Persistent grease fire. Grease trapped by food buildup Turn knobs to OFF. Turn gas off at propane tank. around burner system. Leave lid in closed position and let fire burn out. After grill cools, remove and clean all parts. Flashback [fire in burner Burner and/or burner tubes are Clean burner and/or burner tubes.
-
Page 20: Warranty Program
WARRANTY PROGRAM Proof of purchase is required to access this warranty program, which is in effect from date of purchase. Inability to provide proof of purchase or after the warranty has expired, customers will be subject to parts, shipping and handling fees.
