Motorola MTP750 Specifications

MTP750_AN3_04_006Rev1.fh8 3/21/06 12:38 PM Page 1
LONG BATTERY LIFE
Work with peace of mind, knowing you can rely on the highly accurate battery gauge.
The MTP750 operates continuously up to 23 hours on one battery (on a 5-5-90 duty
cycle), thus providing longer talk time that last more than 2 work shift (8 hours).
LANGUAGE SUPPORT
The MTP750 supports English, Simplified and Traditional Chinese. Users can work in
the language most comfortable to them.
MTP750 Motorola TETRA Portable Radio 380-430MHz and 806-870 MHz
GENERAL SEPCIFICATIONS*
Dimensions HxWxD
Weight
Battery Capacity
Operating life
5/5/90
5/35/60
Talk Groups - TMO
Talk Groups - DMO
Individual call list
Phone call list
PABX call list
Text Message List
Status List
Country code/Network code list
Scan list
ENVIRONMENTAL
Operating Temperature
Storage Temperature
Humidity
Dust and Water
Shock and vibration
RF SPECIFICATIONS
Frequency Bands
Transmit Band
Receive Band
DMO Band
RF Channel Bandwidth
Switching Bandwidth (TMO)
Switching Bandwidth (DMO)
Transmitter/Receiver
Separation
Transmitted RF Power
RF Power Control
RF Power of Accuracy
Receiver Class
Receiver Static Sensitivity
Receiver Dynamic Sensitivity
Accessories include:
• Choice of IMPRES™ batteries
• IMPRES™ single unit charger with optional conditioning
• IMPRES™ multiple unit charger with optional display capability
• Choice of headsets
• One, two and three wire earpieces (black or beige)
• Acoustic tube with clear voicetube (low or extreme noise levels)
• Selection of enhanced and standard Remote Speaker Microphones
• Choice of carry accessories
• Data cable
Please refer to the MTP750 accessories brochure for further details.
Composite
mm 143 x 55 x 39 (with standard Li Ion battery)
g 367 (with standard Li Ion battery)
244 (without battery)
mAh 1500 Standard Li Ion (Minimum)
1200 NiMH (Minimum)
1150 NiMH FM approved (Minimum)
Hours With standard Li Ion battery
Up to 23
Up to 17
512
208
100
100
25
20
100
100
20 lists of 20 groups
°C
-30 to +60
°C
-40 to +85
EIA/TIA 603 (95%)
IP54
MIL810 C/D/E
MHz 380-430 806-870
MHz 380-430 806-825
MHz 380-430 851-870
MHz 380-430 851-870
kHz 25
MHz 50 (380-430)
19 (851-870)
MHz 50 (380-430)
19 (851-870)
MHz 10 (380-430)
45 (806-870)
Watt 1 (380-430)
1 (806-870)
3 steps of 5dB
+/- db 2 dB
A and B
dBm -112
dBm -103
* Please note all product features are subject to infrastructure support.
All specifications shown are typical and subject to change without notice.
Talk time, standby times and dispatch times are approximate and depend on
network configuration, signal strength and features selected.
Motorola Electronics Pte Ltd
MIC Level 7, 12 Ang Mo Kio Street 64
Ang Mo Kio Industrial Park 3, Singapore 569088
www.motorola.com/governmentandenterprise
MOTOROLA and the Stylized M Logo are registered in the U.S. Patent and Trademark Office.
All other products or service names are the property of their registered owners. ©Motorola, Inc. 2006
AN3-04-006 Rev.1
C M Y CM MY CY CMY K
Voice Services Supported – Group:
Group call – TMO
Group call – DMO
Late Entry (TMO/DMO)
Emergency call
Emergency call "Hot Microphone"
Announcement Talk Group call
Dynamic Group Number Assignment (DGNA)
Local site trunking
Scanning
Priority monitor
Talking Party Identification
Loud/discreet audio mode
Voice Services supported –
Private call:
Simplex/duplex operation
Flexible dialling (list scroll, short number dialling,
direct dial, alpha search, last number called)
Loud/discreet audio mode
Calling line Identification Presentation
Voice Services supported –
Telephone call (PABX/PSTN):
Full duplex operation
Speaker phone
Flexible dialling (list scroll, direct dial,
alpha search, speed dial, one-touch dial)
DTMF overdial
Calling line Identification Presentation
Security services supported:
Air Encryption TEA1, TEA3
Radio Stun
PIN/PUK code access
Keypad lock
Data/messaging services supported:
Short Data Service (SDS)
Alphanumeric Text Service
Predictive Text Entry (iTAP)
Built-in database enquiry templates
One touch status messaging
Packet data service
Peripheral Equipment Interface (PEI) for external RS232
short and packet data devices
New text message notification during calls
Languages supported:
English, Simplified Chinese and Traditional Chinese
Other:
- Compatible to Vehicular Adaptor
- Wideband RF operation
(one model supports multiple RF bands)
- Keypad tones on/off
- Alert tones on/off
- Backlight options
(disabled, manual, automatic and semi-automatic)
- Manual/automatic network selection
- Scan list edit via keypad
- Full screen ultra-precise battery gauge
- Factory Mutual intrinsically safe version
- Side connector for audio accessories
- Bottom connector for programming, upgrading,
vehicle adapter and packet and short data
- End-stop talk group selection knob
- Dedicated emergency button
- 13 programmable buttons
- Vibracall supported by enhanced remote speaker
microphone
- DMO Gateway Compatibility
- DMO Repeater Compatibility
Stringent Motorola Compliance with ISO 9001
Accelerated Life Testing Standard-on international quality
simulating five years of hard system assurance on design,
use in real life. EIA R5-3168 development, production,
in Shock, Vibration, Dust, installation and servicing of a
Humidity, IP54 for Sealing. product.
Stamp of Approval from
the U.S. Military for use
in rough environment.
