ASSEMBLY

• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• Left and right parts are marked "L" or "Left" and
"R" or "Right."
• To identify small parts, see page 5.
1. While a second person lifts the Base (1),
attach the Front Stabilizer (6) to the Base
with two M10 x 80mm Carriage Bolts (82)
and two M10 Locknuts (81).
• In addition to the included tool(s), assembly
requires the following tools:
one Phillips screwdriver
one adjustable wrench
one rubber mallet
• Assembly may be easier if you have a set of
wrenches. To avoid damaging parts, do not use
power tools.
1
82
6
6
81
81
1
