3-12
C
3: C
HAPTER
ONFIGURATION
Conventions
U
T
A
SING
RANSCEND
CCESS
Download/Upload File . (IP only) Allows (1) AccessBuilder
configuration parameters to be uploaded to a specified TFTP server, (2)
configuration parameters to be downloaded from a specified TFTP
server to a specified AccessBuilder, (3) AccessBuilder server image to
be downloaded form a TFTP server to a specified AccessBuilder.
System Configuration Parameters. Opens a dialog box to
configure system-related parameters, such as server name, date, time,
greeting, etc.
Protocols. Allows specified protocol-related parameters to be enabled
or disabled.
Modem Scripts. Allows modem scripts to be added, created, edited
or deleted.
Async Ports. Allows the specified asynchronous port-related
parameters to be changed.
Remote Users. Allows remote user-related parameters such as phone
number, password, etc., to be added, deleted or changed.
SNMP. Allows defining or redefining of the set of SNMP
managers-related parameters or copying them to another
AccessBuilder server.
Port Color Conventions
The asynchronous ports are color-coded to show status, as shown in
the table below:
Table 3-2 Port Color Conventions
Color
Meaning
White
Not in use
Green
In session (dial in)
Cyan
(Greenish blue) In session (dial out)
Blue
Disabled
Yellow
Router (LAN-to-LAN)
B
M
(TABM)
UILDER
ANAGER
