To turn RESTART off, enter diagnostic mode. Phase 3 only, press the
ADVANCE button once. Use the WATER LEVEL DOWN button to turn the
RESTART on or off.
Low Water Level LED off = RESTART off.
Low Water Level LED on = RESTART on. (Default setting.)
If a situation is encountered with a Phase 1.4, 4, 5 or 6 module where the
restart feature is permanently programmed off, follow the following steps to
return the machine to normal operation:
• Enter diagnostic mode as normal.
• Press and hold the ADVANCE button. (When this button is first pressed,
the beep tone will sound. This is O.K.)
• While pressing the ADVANCE button, press the WATER LEVEL DOWN
button to toggle the RESTART feature on. A long beep will acknowledge
the setting has been retained in EEPROM. Press POWER to retain
selection.
The RESTART status can be identified when SmartDrive is first turned on at
the wall:
If the 5 leftmost wash progress LEDs are off, RESTART is on.
If the 5 leftmost wash progress LEDs are flashing, RESTART is off.
RESTART is a service aid only and should be left ON in the customer's
home. To return to normal operation, and to reset the RESTART feature to
the default setting, disconnect SmartDrive from the power supply.

Recycle Feature

After servicing, SmartDrive may require an extended test where it can be left
to complete a number of wash cycles. By turning on RECYCLE SmartDrive
will continuously repeat the selected wash cycle until RECYCLE is turned off.
To turn RECYCLE on, enter diagnostic mode. Phase 3 only, press the
ADVANCE button once. Use the WATER LEVEL UP button to turn the
RECYCLE on or off.
Medium Water Level LED on = RECYCLE on.
Medium Water Level LED off = RECYCLE off. (Default setting.)
7
