Tripp Lite SR45UBEXPNDNR3 Brochure & Specs

45U 4-Post SmartRack Premium Open Frame Rack
(no sides, doors or roof)
MODEL NUMBER: SR45UBEXPNDNR3
Description
The SR45UBEXPNDNR3 is an expansion model with no sides, doors or roof. An expansion model is useful
when baying together multiple enclosures. Its integrated baying tabs make it easy to combine multiple
enclosures in rows for data center applications.
The SR45UBEXPNDNR3 houses 3000 lb of standard 19-inch rack equipment in 45U. It is an expansion model
that comes without sides, doors or roof. The front and rear pairs of vertical rails have square mounting holes that are adjustable in quarter-inch increments
from 4 to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail placement without requiring time-consuming measurements.
Each rack space within the enclosure is numbered for ready reference and supports tool-less button-mount 0U installation of up to four compatible PDUs and
cable managers.
All components of the SR45UBEXPNDNR3 are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to the
facility earth ground.
To simplify deployment, the SR45UBEXPNDNR3 comes with heavy duty 3" preinstalled casters that enable it to be easily maneuvered into the desired
location, where it can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for
moving the enclosure over long distances.
The SR45UBEXPNDNR3 comes with a 5-year product warranty. As part of the SmartRack family, the SR45UBEXPNDNR3 is compatible with Tripp Lite's
extensive range of rackmount accessories, enabling you to customize your solution to meet any requirement.
Features
Open frame rack with no sides, doors or roof
Ships fully assembled for rapid deployment and roll into place on 3" pre-installed casters (casters are removable)
Front and rear sets of equipment mounting rails adjust in 1/4" increments. Adjustment is quick and convenient. The easy-view depth index ensures
consistent rail placement without requiring time-consuming measurements.
Tool-less accessory mounting rails (2 rails per enclosure) include slots for quick installation of compatible PDUs and vertical cable managers. Mounting
1 / 4
Highlights
45U SmartRack Premium open
frame rack (no sides, doors or
roof)
4 interior vertical posts with
unthreaded square hole openings
Standard 24" (600mm) width and
42" (1050mm) depth for
optimizing floor space
Ships fully assembled
3000 lb stationary / 3000 lb rolling
load capacity
Preinstalled heavy duty 3"
casters and leveling feet
Includes 50 pieces of M6 cage
nuts and 50 pieces of M6 screws
(equipment mounting hardware)
Package Includes
SR45UBEXPNDNR3
Mounting Hardware
Owner's Manual
