Tripp Lite SR42UB1032 Specifications

Model #: SR42UB1032
42U SmartRack Premium Enclosure - Thread (10-32) Mounting Holes (includes doors and side panels)
Description
The SR42UB1032 houses 3000 lb of standard 19-inch rack equipment in 42U. Its front and rear pairs of vertical rails have threaded 10-32 mounting
holes that are adjustable in quarter-inch increments from 4 to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail
placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.
The SR42UB1032 features a massive front-to rear-ventilation capacity that meets or exceeds server manufacturer requirements. Its integrated
baying tabs make it easy to combine multiple enclosures in rows for data center applications. This enclosure is also compatible with
hot-aisle/cold-aisle configurations.
With its locking, reversible, removable front and rear doors, and locking, removable side panels, the SR42UB1032 provides ultimate equipment
safety. The side panels are half size for ease of removal and reinstallation. The split rear door design allows the enclosure to be placed closer to a
wall. The SR42UB1032 meets all requirements toward PCI DSS compliance.
The top panel of the SR42UB1032 is vented to help remove warm air from the enclosure and draw in cool air by convection. The top panel includes
ports for cable routing, and can be quickly removed without tools. To facilitate cable access, the SR42UB1032 is open-bottom.
All components of the SR42UB1032 are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection to
the facility earth ground. The removable front and rear doors feature quick-release ground wires.
To simplify deployment, the SR42UB1032 comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where it
can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for moving
the enclosure over long distances.
The SR42UB1032 comes with a 5-year product warranty. As part of the SmartRack family, the SR42UB1032 is compatible with Tripp Lite's extensive
range of rackmount accessories, enabling you to customize your solution to meet any requirement.
Package Includes
SR42UB1032 Rack Enclosure
(4) side panels
(4) side panel locks
(2) door & side panel keys
Mounting Hardware
Owner's Manual
Features
Highlights
42U SmartRack enclosure with doors and side panels
4 interior vertical posts with threaded 10-32 mounting holes
Standard 24" (600mm) width and 42" (1050mm) depth for optimizing floor
space
Ships fully assembled
Massive front to rear ventilation capacity
3000 lb stationary / 2250 lb rolling load capacity
Locking, removable, reversible front and rear doors
Locking, removable side panels keyed alike with doors
Pre-installed casters and leveling feet
Rolls through standard 7 foot doorway
Meets all enclosure requirements towards PCI DSS (Payment Card Industry
Data Security Standard) Compliance
