Tripp Lite SR42UBWDVRT Specifications

Model #: SR42UBWDVRT
42U WIDE SmartRack Premium Enclosure with Pre-Installed SRCABLEVRT3 (includes sides and doors)
Description
SR42UBWDVRT is a WIDE version of our standard 42U SmartRack Enclosure (750mm wide compared to the standard 600mm wide) and includes
preinstalled SRCABLEVRT3. The SRCABLEVRT3 helps eliminate cable stress by organizing the cables within the enclosure. The vertical cable
manager is 6-ft high and 3" wide.
The SR42UBWDVRT houses 3000lbs of standard 19-inch rack equipment in 42U. Its front and rear pairs of vertical rails have square mounting
holes that are adjustable in quarter-inch increments from 4 to 37 inches. Adjustment is quick and an easy-view depth index ensures consistent rail
placement without requiring time-consuming measurements. Each rack space within the enclosure is numbered for ready reference.
With its locking, reversible, removable front and rear doors and locking, removable side panels, the SR42UBWDVRT provides ultimate equipment
safety. The side panels are half size for ease of removal and re-installation. The split rear door design allows the enclosure to be placed closer to a
wall. The SR42UBWDVRT meets all requirements toward PCI DSS compliance.
The top panel of the SR42UBWDVRT is vented to help remove warm air from the enclosure and draw in cool air by convection. the top panel
includes ports for cable routing, and can be quickly removed without tools.
All components of the SR42UBWDVRT are grounded to the enclosure frame. Front and rear threaded grounding points are provided for connection
to the facility earth ground. The removable front and rear doors feature quick-release ground wires.
To simplify deployment, the SR42UBWDVRT comes with preinstalled casters that enable it to be easily maneuvered into the desired location, where
it can be secured by adjusting the preinstalled levelers. Note: the casters are intended for minor position adjustments and are not designed for
moving enclosures over long distances.
The SR42UBWDVRT comes with a 5-year product warranty. As part of the SmartRack family it is compatible with Tripp Lite's extensive range of
rackmount accessories, enabling you to customize your solution to meet any requirements.
Package Includes
SR42UBWDVRT Rack Enclosure
(4) side panels
(4) side panel locks
(2) door & side panel keys
(50) M6 screws
(50) M6 washers
(50) M6 cage nuts
Owner's Manual
Features
Comes with the SRCABLEVRT3 pre-installed (6-ft vertical cable manager with 3" width) to help eliminate cable stress inside the enclosure
Front and rear sets of equipment mounting rails adjust in 1/4" increments. Adjustment is quick and convenient. The easy-view depth index
Highlights
30" (750mm) wide and 42" (1050mm) deep enclosure with doors and side
panels
Pre-Installed 6-ft vertical cable manager - high capacity for large cable bundles
4 interior vertical posts with unthreaded square hole openings
Massive front to rear ventilation capacity
3000 lb stationary / 2250 lb rolling load capacity
Locking, removable, reversible front and rear doors
Locking, removable side panels keyed alike with doors
Meets all enclosure requirements towards PCI DSS (Payment Card Industry
Data Security Standard) Compliance
